Owner’s Manual

SMART1500LCDXL

Not suitable for mobile applications

Important Safety Instructions 2

Quick Installation 3

Basic Operation 4

UPS On/Off 4

LCD Display 4

LCD Features 4

Display Power Conditions 5

Enable/Disable Alarm 5

LCD Brightness 5

Self-test 5

Power Sensitivity 6

Scroll Control 6

External Battery Settings 7

Error Messages 7

Features 8

Storage and Service 9

Warranty Registration 10

Español 12

Français 22

1111 W. 35th Street, Chicago, IL 60609 USA

www.tripplite.com/support

EXTERNAL BATTERY CAPACITY

SENSITIVITY SCROLL

LOAD

RUNTIME

OUTPUT

INPUT

TEST BATT

. .

K H

MIN

MODE MUTE

201103012 933072.indb 1 3/8/2011 1:43:09 PM

Important Safety Instructions

SAVE THESE INSTRUCTIONS

This manual contains instructions and warnings that should be followed during the installation,

operation and storage of this product. Failure to heed these warnings may affect the warranty.

UPS Location Warnings

• Install your UPS indoors, away from excess moisture or heat, conductive contaminants, dust

or direct sunlight.

• For best performance, keep the indoor temperature between 32º F and 104º F

(0º C and 40º C).

• Leave adequate space around all sides of the UPS for proper ventilation.

• Do not mount unit with its front or rear panel facing down (at any angle). Mounting in this

manner will seriously inhibit the unit’s internal cooling, eventually causing product damage not

covered under warranty.

UPS Connection Warnings

• Connect your UPS directly to a properly grounded AC power outlet. Do not plug the UPS into

itself; this will damage the UPS.

• Do not modify the UPS’s plug, and do not use an adapter that would eliminate the UPS’s

ground connection.

• Do not use extension cords to connect the UPS to an AC outlet.

• If the UPS receives power from a motor-powered AC generator, the generator must provide

clean, filtered, computer-grade output.

• The mains socket outlet that supplies the UPS should be easily accessible and located near

the UPS.

Equipment Connection Warnings

• Use of this equipment in life support applications where failure of this equipment can

reasonably be expected to cause the failure of the life support equipment or to significantly

affect its safety or effectiveness is not recommended. Do not use this equipment in the

presence of a flammable anesthetic mixture with air, oxygen or nitrous oxide.

• Do not connect surge suppressors or extension cords to the output of your UPS. This might

damage the UPS and may affect the surge suppressor and UPS warranties.

• Connect the UPS to an outlet that is adequately protected against excess currents, short

circuits and earth faults as part of the building installation.

Battery Warnings

• Your UPS does not require routine maintenance. Do not open your UPS for any reason. There

are no user-serviceable parts inside.

• Batteries can present a risk of electrical shock and burn from high short-circuit current.

Observe proper precautions. Do not open the UPS or batteries. There are no user-serviceable

parts inside the UPS. Battery replacement should be performed only by authorized service

personnel using the same number and type of batteries (Sealed Lead-Acid). The batteries are

recyclable. Refer to your local codes for disposal requirements or visit www.tripplite.com/

UPSbatteryrecycling for recycling information.

• When adding an external battery pack, connect only a Tripp Lite recommended battery pack of

the correct voltage and type. Do not connect or disconnect the external battery pack when the

UPS is operating on battery power. Visit Tripp Lite on the Web at www.tripplite.com/support/

battery/index.cfm to locate the specific battery for your UPS.

201103012 933072.indb 2 3/8/2011 1:43:09 PM

STEP 1: To install the UPS in a 4-post rack, attach the included

mounting hardware to the UPS as shown in diagram A. To mount the

UPS in a 2-post rack, attach the included hardware to the UPS as

shown in diagram B. Then, using an assistant if necessary, lift the

UPS and attach it to a standard rack or rack enclosure with user-

supplied hardware. Caution: If the UPS is placed flat on a

surface, do NOT stack any other object directly on top of the

unit. The UPS will stand in a tower position without the aid of the

included hardware. However, for added stability Tripp Lite

recommends that the included hardware be attached as shown in

diagram C. The UPS and included hardware are designed for

common rack and rack enclosure types and may not be appropriate

for all applications.

STEP 2: Plug the UPS into a properly grounded outlet.

After plugging the UPS into a wall outlet, push the

MODE

button for two

seconds to turn the UPS on (see Basic Operation section). Please

Note! The UPS will not turn on automatically in the presence of

live utility power.

STEP 3: Plug your equipment into the UPS.

* Your UPS is designed to support electronic equipment only. You will overload the

UPS if the total VA ratings for all the equipment you connect to the outlets exceeds

the UPS’s Output Capacity. To find your equipment’s VA ratings, look on their

nameplates. If the equipment is listed in amps, multiply the number of amps by

120 to determine VA. (Example: 1 amp × 120 = 120 VA).If you are unsure if you

have overloaded the outlets, run a self-test (see Self-Test description in Basic

Operation section).

Quick Installation

STEP 4: Optional Installation.

All models include USB and RS-232 communication ports as well as Tel/DSL/network surge

protection jacks. These connections are optional; the UPS will work properly without these

connections. See the connector's description in the Basic Operation section for connection

instructions.

If the LINE POWER icon does not illuminate when the UPS is turned ON, try the

following:

1. Make sure that the UPS is plugged into a live AC outlet.

2. Press the

MODE

button for 2 seconds to start the UPS. (A beep should sound when the

UPS starts.)

3. If the UPS still does not start, contact Tripp Lite Tech Support for assistance.

201103012 933072.indb 3 3/8/2011 1:43:10 PM

UPS ON/OFF

• PlugtheUPSintoagroundedoutlet.

• TurntheUPSon:Press and hold the

MODE

button for 2 seconds. The UPS alarm will beep

once briefly after 2 seconds have passed.

• PlugequipmentintotheUPS: Your UPS is designed to support electronic equipment

only. You will overload the UPS if the total VA ratings for all the equipment you connect to

the “Battery, Surge and Noise Protected” outlets exceeds the UPS’s Output Capacity. To

estimate your equipment’s power requirements, look on the nameplate. If the equipment

is listed in amps, multiply the number of amps by 120 to determine VA, (Example: 1 amp

x 120 = 120 VA). Your UPS is fully loaded when the display indicates 100% load.

• TurntheUPSoff:Press and hold the

MODE

button for 2.5 seconds. The UPS alarm will beep

once after 2.5 seconds have passed.

LCD Display

The LCD Display indicates a variety of UPS operational conditions. All descriptions apply when

the UPS is plugged into an AC outlet and turned on. The LCD Display can be rotated for easy

viewing, regardless of whether the UPS is in a horizontal or vertical (“tower”) position. To

rotate the display, insert a small tool in the slots on the sides of the display to pop it out of

the UPS housing; rotate the display, and snap it back into the UPS housing.

LCD Features

Tap the

MODE

button to advance from one display to the next. Use the

MUTE

button to toggle

settings for Power Sensitivity Control, External Battery Setting Control, Scroll Control, Alarm,

LCD Brightness and Self-test functions. The last option displayed before navigating away from

this menu option will be the selected setting. When the preferred setting has been selected,

continue by pressing the

MODE

button. If the screen is idle for 20 seconds, the LCD will return

to the home screen, retaining the last selected settings.

Basic Operation

201103012 933072.indb 4 3/8/2011 1:43:10 PM

Basic Operation continued

Display Power Conditions

Use the

MODE

button to advance through

power conditions.

1. Voltage In

2. Voltage Out

3. Estimated Runtime (in minutes)

4. Load %

5. Load Wattage*

6. Battery Capacity %

* Load Wattage is displayed in watts up to “999”, and then will be displayed in Kilowatts.

Enable/Disable Alarm

Tap the

MODE

button repeatedly to advance to the LCD display featuring the icon. Press the

MUTE

button to select ON or OFF alarm mode settings. The last option displayed before

navigating away from this menu option will be the selected setting.

LCD Brightness

Tap the

MODE

button repeatedly to advance to the LCD Brightness display marked “LCD”. Press

the

MUTE

button to select Medium Backlight (default), High Backlight or Dim Backlight. The last

option displayed before navigating away from this menu option will be the selected setting.

Note: After 2 minutes of inactivity, the backlight will revert to the Dim setting until a button is pressed.

Self-test

Tap the

MODE

button repeatedly to advance to the TEST BATT display. Press the

MUTE

button to

initiate the test. The test will last approximately 10 seconds as the UPS switches to battery to

test the capacity with a load. Upon completion of the test, the display will indicate PAS or

BAD (pass or bad) for 20 seconds, then return to the home screen. Connected equipment

can remain on during the test. Do not unplug your UPS, this will remove safe electrical

grounding.

INPUT

1 2

RUNTIME

MIN

456

201103012 933072.indb 5 3/8/2011 1:43:11 PM

Basic Operation continued

Power Sensitivity

Tap the

MODE

button repeatedly to advance to Sensitivity display, as shown here:

Press the

MUTE

button to advance through the options. The last option displayed, before

navigating away from this menu option, will be the selected setting.

This setting is normally set to 100%, which enables the UPS to protect against waveform

distortions in its AC input. When such distortion occurs, the UPS will normally switch to

providing PWM sine wave power from its battery reserves for as long as the distortion is

present. In some areas with poor utility power or where the UPS’s input power comes from a

backup generator, frequent brownouts and/or chronic waveform distortion could cause the

UPS to switch to battery too often, draining its battery reserves. You may be able to reduce

how often your UPS switches to battery due to waveform distortion or brownouts by

experimenting with different settings. As the setting is reduced, the UPS becomes more

tolerant of variations in its input power’s AC waveform. NOTE: When experimenting with different

settings, operate connected equipment in a safe test mode so that the effect on the equipment of any waveform

distortions in the UPS’s output can be evaluated without disrupting critical operations. The experiment should last

long enough to assure that all expected line conditions are encountered.

Scroll Control

Tap the

MODE

button repeatedly to advance to the Scroll display as shown here:

Press the

MUTE

button to advance to the next available option. The last option displayed, before

navigating away from this menu option, will be the selected setting.

This display option allows the user to select the option to automatically scroll each operating

condition of the UPS (such as Input Voltage, Output Voltage and Runtime) automatically.

NOTE:

1. Each condition is displayed in 2 second intervals.

2. If a button is pressed while Scroll Mode is enabled, the scroll function will pause for 10 seconds to allow the

user to manually make menu selections.

201103012 933072.indb 6 3/8/2011 1:43:11 PM

Basic Operation continued

External Battery Setting Control

Tap the

MODE

button repeatedly to advance to the External Battery display, as shown here:

Press the

MUTE

button to advance to the next available option. The last option displayed, before

navigating away from this menu option, will be the selected setting.

Note: The Battery Runtime calculation is based on this setting.

This feature setting allows the user to configure the UPS for use with an External Battery Pack

or without an External Battery Pack. The Runtime will be automatically reconfigured.

NOTE: Battery Packs cannot be daisychained. Only one Battery Pack can be attached to the UPS.

Error Messages

In the event that the UPS battery requires replacement, the icon will flash, as well as

the icon. If there is an overload, the ,, and icons will flash simultaneously

along with a numeric read out of the load percentage.

BAT T ERYEX T ERNAL

201103012 933072.indb 7 3/8/2011 1:43:11 PM

Features

MODE

UPS Features

ON/OFF/MODE Button: Press and hold for 2 seconds to turn on the

UPS and 2.5 seconds to turn the UPS off. When the UPS is on, tap

this button repeatedly to advance through LCD display screens. If

utility power is absent, pressing and holding this button for 2.5

seconds will “cold-start” the UPS; i.e. turn it on and supply power to

the outlets from its batteries.

MUTE/ENTER Button: Use this button to toggle selection options for:

self-test, enable/disable alarm, LCD brightness, Sensitivity Control,

Scroll Control and the External Battery Setting Control. This button

can also be used to temporarily mute an active alarm by briefly

pressing it.

Tel/DSL Line Protection Jacks: These jacks protect equipment

against surges over a single phone line. Connecting your equipment

to these jacks is optional. Your UPS will work properly without this

connection. An RJ-11 cable will be included with your UPS.

USB and RS-232 Communication Ports: These ports can connect

your UPS to any computer for automatic file saves and unattended

shutdown in the event of a power failure. Use with Tripp Lite’s

PowerAlert Software (available as a FREE download at

www.tripplite.com) and appropriate USB or DB9 cable. Both a USB

and a DB9 cable will be included with your UPS.

NOTE:

1. This connection is optional. The UPS will work properly without this connection.

2. This UPS System provides basic communication compatibility with most integrated

Windows®, Macintosh®, and Linux®power management applications.

Battery Backup Protected/Surge Protected Outlets: Provide both

battery backup and surge protection. Plug your computer, monitor and

other critical equipment into these outlets. Note: Do not plug laser

printers into the UPS.

Removable Mounting Hardware: Adapts the UPS to either tower or

rackmount (2U) applications.

External Battery Connector: Use to connect a Tripp Lite external

battery pack for additional runtime. Refer to instructions available with

the battery pack for complete connection information and safety

warnings.

NOTE: Visit Tripp Lite on the Web at www.tripplite.com/support/battery/index.cfm to

locate the specific battery for your UPS.

Resettable Input Circuit Breaker: Protects your electrical circuit

from overcurrent draw from the UPS load. If this breaker trips, remove

some of the load, then reset it by pressing it in.

MUTE

201103012 933072.indb 8 3/8/2011 1:43:13 PM

Storage and Service

Storage

To avoid battery drain, all connected equipment should be turned off and disconnected from

the UPS. Press and hold the

MODE

button for 2.5 seconds. Your UPS will be completely turned

off (deactivated), and will be ready for storage. If you plan on storing your UPS for an

extended period, fully recharge the UPS batteries every three months. Plug the UPS into a

live AC outlet, turn it on by pressing and holding the

MODE

button for 2 seconds, and allow the

batteries to recharge for 4 to 6 hours. If you leave your UPS batteries discharged for a long

period of time, they will suffer a permanent loss of capacity.

Service

A variety of Extended Warranty and On-Site Service Programs are available from Tripp Lite.

For more information on service, visit www.tripplite.com/support. Before returning your

product for service, follow these steps:

1. Review the installation and operation procedures in this manual to insure that the service

problem does not originate from a misreading of the instructions.

2. If the problem continues, do not contact or return the product to the dealer. Instead, visit

www.tripplite.com/support.

3. If the problem requires service, visit www.tripplite.com/support and click the Product

Returns link. From here you can request a Returned Material Authorization (RMA) number,

which is required for service. This simple on-line form will ask for your unit’s model and

serial numbers, along with other general purchaser information. The RMA number, along

with shipping instructions will be emailed to you. Any damages (direct, indirect, special or

consequential) to the product incurred during shipment to Tripp Lite or an authorized Tripp

Lite service center is not covered under warranty. Products shipped to Tripp Lite or an

authorized Tripp Lite service center must have transportation charges prepaid. Mark the

RMA number on the outside of the package. If the product is within its warranty period,

enclose a copy of your sales receipt. Return the product for service using an insured

carrier to the address given to you when you request the RMA.

201103012 933072.indb 9 3/8/2011 1:43:13 PM

Visit www.tripplite.com/warranty today to register the warranty for your new Tripp Lite product. You’ll be

automatically entered into a drawing for a chance to win a FREE Tripp Lite product! *

* No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.

FCC Part 68 Notice (United States Only)

If your Modem/Fax Protection causes harm to the telephone network, the telephone company may

temporarily discontinue your service. If possible, they will notify you in advance. If advance notice isn’t

practical, you will be notified as soon as possible. You will be advised of your right to file a complaint with

the FCC. Your telephone company may make changes in its facilities, equipment, operations or

procedures that could affect the proper operation of your equipment. If it does, you will be given advance

notice to give you an opportunity to maintain uninterrupted service. If you experience trouble with this

equipment’s Modem/Fax Protection, please visit www.tripplite.com/support for repair/warranty information.

The telephone company may ask you to disconnect this equipment from the network until the problem

has been corrected or you are sure the equipment is not malfunctioning. There are no repairs that can

be made by the customer to the Modem/Fax Protection. This equipment may not be used on coin service

provided by the telephone company. Connection to party lines is subject to state tariffs. (Contact your

state public utility commission or corporation commission for information.)

FCC Notice, Class B

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and (2) this device must accept any interference

received, including interference that may cause undesired operation.

Note: This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against

harmful interference in a residential installation. This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment off and on, the user is encouraged to try to correct

the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Any changes or modifications to this equipment not expressly approved by Tripp Lite could void the user’s

authority to operate this equipment.

Warranty Registration

201103012 933072.indb 10 3/8/2011 1:43:13 PM

Otros manuales para SMART1500LCDXL

Tabla de contenidos

Idiomas:

Otros manuales de Unión Postal Universal de Tripp Lite

Tripp Lite

Tripp Lite SmartOnline 220/230/240V Input/Output Manual de usuario

Tripp Lite

Tripp Lite SmartOnline SU50K3/3INTPM Manual de usuario

Tripp Lite

Tripp Lite SUPDM15 Manual de usuario

Tripp Lite

Tripp Lite TE1200 Manual de usuario

Tripp Lite

Tripp Lite OmniSmart Instrucciones de instalación y funcionamiento

Tripp Lite

Tripp Lite TM500 Manual de usuario

Tripp Lite

Tripp Lite SmartPro SMART3000RMXL2U Guía de instalación

Tripp Lite

Tripp Lite 500 VA Manual de usuario

Tripp Lite

Tripp Lite HT850UPS Manual de usuario

Tripp Lite

Tripp Lite SmartOnline SU5000RT3UHV Manual de usuario

Tripp Lite

Tripp Lite SmartOnline SU2200RMNAFTA Manual de usuario

Tripp Lite

Tripp Lite UPS System AVRX550U Manual de usuario

Tripp Lite

Tripp Lite SmartOnline SU1500XL Manual de usuario

Tripp Lite

Tripp Lite SmartPro SMART5000RT3U Manual de usuario

Tripp Lite

Tripp Lite SmartOnline SU3000RTXL2U Manual de usuario

Tripp Lite

Tripp Lite SmartOnline SU12000RT4U Manual de usuario

Tripp Lite

Tripp Lite SmartPro VS Manual de usuario

Tripp Lite

Tripp Lite BCPRO850 Guía de configuración

Tripp Lite

Tripp Lite SmartPro Rackmount SMX500RT1U Manual de usuario

Tripp Lite

Tripp Lite SmartOnline SU10000RT3U2TF Manual de usuario

Tripp Lite

Tripp Lite SmartOnline SU1500LCD1U Manual de usuario

Tripp Lite

Tripp Lite SmartPro SMART700USB Guía de configuración

Tripp Lite

Tripp Lite SmartPro Series Manual de usuario

Tripp Lite

Tripp Lite Internet Office INTERNET750U Manual de usuario

Manuales populares de Unión Postal Universal de otras marcas

Pylontech

Pylontech Victron & Pylontech US5000 Manual de usuario

Tecnoware

Tecnoware EVO DSP PLUS MM 6.8 Manual de usuario

Mecer

Mecer ME-1000-WTU Manual de usuario

Mustek

Mustek PowerMust 530(B) Plus Manual de instalación y operación

Emerson

Emerson Liebert NXL series Manual de usuario

MAKELSAN

MAKELSAN BOXER SERIES Manual de usuario

Block

Block PC-0524-400-0 Manual de usuario

CyberPower

CyberPower CP585LCD Manual de usuario

Eaton

Eaton 3S Instrucciones de montaje

CyberPower

CyberPower Office Tower Series UPS 1000 Manual de usuario

CyberPower

CyberPower BM100 Manual de usuario

Best Power

Best Power 610 Manual de usuario

Best Power

Best Power Unity/I UT3K Manual de usuario

Mustek

Mustek PowerMust 400 Offline Manual de usuario

Xantrex

Xantrex Trace 512 UR-UPS Manual de usuario

Forza

Forza SL-1501UL Manual de usuario

LEGRAND

LEGRAND keor 310081 Manual de usuario

ABB

ABB Conceptpower DPA 500 Manual de usuario
