Tripp Lite BC Personal Datashield BCPERS300 Manual de usuario

BC Personal 300VA Tower Standby 120V UPS

MODEL NUMBER: BCPERS300

Description

Tripp Lite's BCPERS300 standby UPS offers AC surge suppression and long lasting battery support for desktop PCs, network workstations and a wide variety

of consumer and electronic devices. Uninterruptible Power Supply / UPS circuits switch to battery backup mode within milliseconds to keep connected

equipment running without interruption or data loss during power failures, brownouts and overvoltages. AC surge suppression prevents connected equipment

damage.

Features

BCPERS300 small tower 120V standby UPS offers AC power protection from blackouts, brownouts, overvoltages and transient surges

300VA / 180 watt UPS output capacity

Uninterruptible Power Supply / UPS operation maintains battery-derived AC output during blackouts, brownouts and overvoltages to prevent data loss

and system downtime for connected equipment

6.3 minutes runtime at 100% load (180 watts), 16.8 minutes runtime at 50% load (90 watts)

17 minutes runtime for a desktop computer system consuming 80 watts continuous

3 built-in NEMA 5-15R UPS supported outlets

NEMA 5-15P input connection with 6ft / 1.8m line cord

Network grade AC surge and lightning protection is available from all outlets

Front panel LEDs indicate line mode and battery mode status

Hot swappable user battery replacement

Optional PDUB15 bypass PDU enable hot-swappable UPS replacement with no disruption to connected equipment

Small tower housing supports desk or floor placement

Specifications

OUTPUT

Output Volt Amp Capacity (VA) 300

Output Watt Capacity (watts) 180

Highlights

300VA tower 120V standby UPS

Maintains AC output during power

failures

NEMA 5-15P input plug and 3

NEMA 5-15R outlets

Package Includes

BCPERS300 UPS System

Instruction manual

1 / 4

Nominal Output Voltage(s)

Supported 115V; 120V

Frequency compatibility 60 Hz

Output voltage regulation (Battery

mode) 115V (+/- 5%)

Built-in UPS output receptacles 3 5-15R outlet(s)

Hot-Swap PDU options PDUB15 (2U / 8 5-15R outlets)

Output AC waveform (AC mode) Sine wave

Output AC waveform (battery mode) PWM sine wave

INPUT

Rated input current (at maximum

load) 2.8A

Nominal Input Voltage(s) Supported 120V AC

UPS input connection type 5-15P

UPS Input cord length (ft.) 6

UPS Input cord length (m) 1.8

Recommended Electrical Service 15A 120V

Phase Single-Phase

BATTERY

Full load runtime (minutes) 6.3 min. (180w)

Half load runtime (minutes) 16.8 min. (90w)

DC system voltage (VDC) 12

Battery Access Battery access door

UPC ASSIGNMENT

Unit Carton UPC# 037332032676

LEDS ALARMS & SWITCHES

LED Indicators 2 LEDs indicate line power, battery power status

Switches 1 built-in slider switch for main power off/on control

SURGE / NOISE SUPPRESSION

UPS AC suppression joule rating 720

UPS AC suppression response time Instantaneous

EMI / RFI AC noise suppression Yes

2 / 4

PHYSICAL

Installation form factors supported

with included accessories Tower

Installation form factors supported

with optional accessories Wallmount (UPSWM - tower mounting kit)

Primary form factor Tower

UPS / Power Module dimensions in

primary form factor (height x width x

depth / inches)

8.5 x 4.2 x 5.5

UPS / Power Module dimensions in

primary form factor (height x width x

depth / cm)

21.6 x 10.8 x 14

UPS / Power Module weight (lbs) 10.9

UPS / Power Module weight (kg) 4.9

UPS Shipping dimensions (height x

width x depth / inches) 11.5 x 4.8 x 8.5

UPS Shipping dimensions (height x

width x depth / cm) 29.2 x 12.1 x 21.6

Shipping weight (lbs) 12

Shipping weight (kg) 5.4

UPS housing material PVC

ENVIRONMENTAL

Operating Temperature Range +32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius

Storage Temperature Range +5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius

Relative Humidity 0 to 95%, non-condensing

AC mode BTU / hr. (full load) 18.9

Battery mode BTU / hr. (full load) 143.6

AC mode efficiency rating (100%

load) 97%

LINE / BATTERY TRANSFER

Transfer time 2-4 milliseconds

Low voltage transfer to battery

power (setpoint) 99V (adjustable to 83V via potentiometer)

High voltage transfer to battery

power (setpoint) 176 (adjustable to 147 via potentiometer)

SPECIAL FEATURES

Green & high efficiency features Greater than 95% efficiency - GREEN UPS

3 / 4

CERTIFICATIONS

UPS Certifications Tested to UL1778 (USA); Tested to CSA (Canada); Tested to NOM (Mexico); Meets FCC Part 15 Category B (EMI)

WARRANTY

Product Warranty Period (Worldwide) 2-year limited warranty

Connected Equipment Insurance

(U.S., Canada & Puerto Rico) $100,000 Ultimate Lifetime Insurance

Related Items

Optional Products

Model Number Description Qty.

WEXT5-BCPERS 5-Year Extended Warranty - For BC Personal Models 1

PDUB15 Single-Phase Hot-Swap PDU, 1.4kW 15A 120V, 2U Horizontal Rackmount, 8 NEMA 5-15R outlets,

set of 2 NEMA 5-15P input plugs 1

UPSWM Wallmount Bracket and installation accessories (4 washers, 4 screws, 1 Velcro safety strap) 1

More information, including related products, owner's manuals, and additional technical specifications, can be found online at:

http://www.tripplite.com/sku/BCPERS300.

Specifications are subject to change without notice. Photos may differ slightly from final products.

4 / 4
