Tripp Lite U222-007-R Manual de usuario

Tripp Lite

1111 West 35th Street

Chicago, IL 60609 USA

Telephone: +(773) 869 1234

E-mail: [email protected]

Model #: U222-007-R

USB Hubs - 7-Port USB 2.0 Hub

Highlights

Connect up to 7 USB Peripherals

Hi-Speed 480Mbps data transfer

Backward compatible to USB 1.1

Over-current protection safeguards connected equipment from overvoltages

Included base stand for upright positioning

Description

Tripp Lites ultra small 7-port USB 2.0 hub is the most versatile and powerful hub on the market. This USB 2.0 certified hub allows you to connect up

to seven USB devices to a single USB port on a Notebook/PC/MAC. This hub has been certified by the USB-IF to support Hi-Speed data

transmission rates up to 480Mbps. Perfect for both the mobile and desktop user. While the hub will function perfectly in virtually all cases without

needing external power, a compact, multi-voltage AC adapter (110/220V ) has been provided for the rare circumstance when connecting a power

hungry device. This USB 2.0 device is backwards compatible so that it will function with both USB 2.0 devices as well as USB 1.1 peripherals.

Over-current protection safeguards connected equipment from overvoltages. Includes stand for upright positioning. Tripp Lite offers a lifetime

replacement warranty on all cable products.

Applications

Notebook and desktop computers

System Requirements

Windows® 98/SE/2000/ME/XP/Vista/MAC

USB port

Package Includes

U222-007-R USB 2.0 Certified 7-Port Mini Hub

Compact 110/220V AC power adapter, with NEMA 1-15P plug

4 ft. extension cable

Instructions

Features

USB2.0 Certified Hub

Supports all data transfer rates up to 480Mbps

Features 7-ports to increase the number of available USB ports on a computer

Compact design is ideal for use with a laptop/notebook computer

Does not require external power, software, or complicated set-up procedures

Plug-and-play/hot-swappable allows you to add or remove a device at any time

Per-port overcurrent protection

Bus-powered or self-powered

Compact, multi-voltage power supply (110/220V) provided

Compatible with Windows 98, Windows 98 SE, Windows 2000, Windows ME, Windows XP, Vista and Mac OS 8.6 or higher

Tripp Lite warrants this product to be free from defects in materials and workmanship for life

Specifications

PHYSICAL

Color Black/White

CONNECTIONS

Connector A

USB A (FEMALE)

Connector B

USB B (FEMALE)

Number of Connectors 7

Ports 8

CERTIFICATIONS

Approvals USB 2.0 Certified, FCC and CE

Related Items

USB Cables & Adapters

U022-006 USB Cable - 6-ft. USB 2.0 AB Gold Device Cable Qty: [optional]

U022-010 USB Cable - 10-ft. USB 2.0 AB Gold Device Cable Qty: [optional]

U209-000-R USB Adapters - USB to Serial Adapter USB-A to DB9M Qty: [optional]

U024-006 USB Cable - 6-ft. USB AA Gold Extension Cable for USB 2.0 Cable Qty: [optional]

U024-010 USB Cable - 10-ft. USB AA Gold Extension Cable for USB 2.0 Cable Qty: [optional]

U022-015 USB Cable - 15-ft. USB 2.0 AB Gold Device Cable Qty: [optional]

More information, including related products, owner's manuals, and additional technical specifications, can be found online at

www.tripplite.com/en/products/model.cfm?txtModelID=3167.
