Tripp Lite TLP606 Manual de usuario

Tripp Lite

1111 West 35th Street

Chicago, IL 60609 USA

Telephone: +(773) 869 1234

E-mail: [email protected]

Model #: TLP606

Protect It! Surge Suppressor

Highlights

6 outlet / 6-ft. cord

750 joule rating

$20,000 Ultimate Lifetime Insurance (USA, Puerto Rico & Canada only)

Description

Tripp Lite's TLP606 offers economical AC surge suppression for protection of workstations, desktop PCs, telecom systems and other sensitive

electronics. Built-in AC surge suppression shields connected equipment from damage and performance problems due to transient surges. TLP606

offers 6 total outlets, 6 foot cord and diagnostic LED to warn of suppressor damage. AC suppression rated at 750 joules shields equipment from

surges and line noise. Attractive white suppressor housing with keyhole mounting tabs offer convenient protection of desktop computer equipment

and accessories. $20,000 Ultimate Lifetime Insurance (USA & Canada Only).

PLUG/OUTLETS: Input: NEMA5-15P/Output: 6 NEMA5-15R/6-ft. AC line cord

ELECTRICAL: 120V AC, 50/60Hz, 15A (Requires NEMA5-15R wall receptacle)

FORMAT: Corded multi-outlet strip with 1 transformer spaced outlet

SUPPRESSION: AC: 150V RMS Clamping/750 joules/330V UL1449

Applications

Ideal for any desktop, network or home computing application requiring AC line protection

Package Includes

TLP606 surge suppressor

Instruction manual with warranty information

Features

6 outlets

6-ft. cord

Surge suppression rating: 750 joules

EMI/RFI noise filtering

15 amp resettable circuit breaker

Green protection LED

Includes full normal mode (H-N) and common mode (N-G/H-G) line surge suppression

Can accommodate 1 large transformer plug without covering remaining outlets, 3 total transformers

Keyhole support for wall mounting

Lighted power switch

$20,000 Ultimate Lifetime Insurance (USA & Canada only)

Lifetime product warranty

Specifications

OVERVIEW

Intended Application Home/Office

SYSTEM OVERVIEW

Voltage compatibility 120 V AC

Frequency compatibility 50/60 Hz

OUTPUT

Output volt amp capacity

(amps)

Output watts 1800

Outlet quantity / type 6 NEMA 5-15R

Outlet orientation Single row of 6 outlets

Overload protection 15A resettable illuminated combo switch / circuit breaker

Transformer accommodation Supports 1 large transformer plug accessory without covering remaining outlets, accepts up to 3 transformers

total

INPUT

Input connection type NEMA 5-15P

Input cord gauge, type 14 gauge, SJT

Input cord length (ft.) 6 ft.

Input cord length (m) 1.8

Recommended Electrical

Service

120V (110-125V)

LEDS ALARMS & SWITCHES

Diagnostic LEDs Built-in LED confirms suppressor "protection present" (green) status

Switches Combination AC circuit breaker and 2 position red illuminated on/off power switch

SURGE / NOISE SUPPRESSION

Protection modes Includes full normal mode (H-N) and common mode (N-G / H-G) line surge suppression

AC suppression joule rating 750 joules

Clamping voltage (RMS) 150V

AC suppression response

time

< 1 ns

UL1499 let through rating 330V - UL Verified

DATALINE SURGE SUPPRESSION

Telephone/DSL Protection No

Cable (Coax) Protection No

Network (Ethernet) Protection No

PHYSICAL

Shipping weight (lbs) 1

Shipping weight (kg) 0.5

Shipping Dimensions

(HWD/in)

13 x 4.75 x 1.9

Shipping Dimensions

(HWD/cm)

33 x 12.1 x 4.8

Unit weight (lbs) 0.8

Unit weight (kg) 0.4

Unit Dimensions (HWD/in) 10.5 x 1.5 x 1.5

Unit Dimensions (HWD/cm) 26.7 x 3.8 x 3.8

Material of construction Plastic

Integrated keyhole mounting

tabs

Keyhole mounting tabs enable wall mounting

AC line cord color Gray

Style Strip

CERTIFICATIONS

UL1449 1998 Rev. (AC

Suppression)

UL1449

UL1363 (Power Tap) UL1363

cUL / CSA (Canada) cUL

Approvals Exceeds IEEE 587 category A&B specifications

WARRANTY

Product Warranty Period Lifetime

Connected Equipment

Coverage

$20,000

More information, including related products, owner's manuals, and additional technical specifications, can be found online at

www.tripplite.com/en/products/model.cfm?txtModelID=2632.
