Tripp Lite TLM626SA Manual de usuario

Tripp Lite

1111 West 35th Street

Chicago, IL 60609 USA

Telephone: +(773) 869 1234

E-mail: [email protected]

Model #: TLM626SA

Safety Surge Suppressor - Rugged, Safe Surge Suppression for Industrial/Automotive/Factory Environments

Highlights

6 outlets (including transformer outlets and 4 safety covers)

6 ft. cord

420 joule rating

Rugged metal case

$10,000 Ultimate Lifetime Insurance (USA and Canada only)

Description

This Tripp Lite surge suppressor is designed to provide safe, reliable surge protection in harsh environments. A 420 joule rating can protect

connected equipment against even the strongest surges. 6 outlets protect connected equipment against damaging surges, spikes and line noise.

Convenient transformer outlets accommodate multiple transformers without blocking other outlets. A 6 ft. grounded cord reaches distant outlets. A

lighted on/off switch with integrated circuit breaker provides power control over connected equipment. Breaker protects against dangerous system

overload. Protected LED confirms that connected equipment is being protected. 4 safety covers shield unused outlets from debris and accidental

contact. A rugged metal case stands up to the harshest environments. Integrated keyhole slots on bottom panel provide convenient wall/desk

mounting. Tripp Lite will repair or replace any connected equipment damaged by surges, including direct lightning strikes, up to $10,000 and for life!

As an added safety feature, the surge suppressor's bright yellow color alerts you and others that power cords and tools are in use.

Applications

Industrial

Automotive

Factory

Hardware

Package Includes

TLM626SA SAfety Surge Suppressor

4 safety covers

Owner's manual

Features

6 OUTLETS protect connected equipment against damaging surges, spikes and line noise

6 FT. GROUNDED CORD reaches distant outlets

LIGHTED ON/OFF SWITCH with INTEGRATED CIRCUIT BREAKER provides power control over connected equipment. Breaker protects

against dangerous system overload.

PROTECTED LED - If this green LED ever goes out, Tripp Lite will replace your surge suppressor under warranty at no charge!

CONVENIENT TRANSFORMER OUTLETS accommodate multiple transformers without blocking other outlets.

4 SAFETY COVERS shield unused outlets from debris and accidental contact.

RUGGED METAL CASE stands up to the harshest environments.

INTEGRATED KEYHOLE SLOTS on bottom panel provide convenient wall/desk mounting.

420 joules of surge protection

OSHA color guidelines, outlined in Document 1910.145, alert users to hazardous situations, which may cause minor or moderate injury.

This Tripp Lite product complies with those guidelines.

$10,000 ULTIMATE LIFETIME INSURANCE (USA and Canada only)

Specifications

OVERVIEW

Intended Application Industrial/Factory Floor

SYSTEM OVERVIEW

Voltage compatibility 120V AC

Frequency compatibility 60Hz

OUTPUT

Output volt amp capacity

(amps)

Outlet quantity / type 6 NEMA 5-15R

Outlet orientation 1 single row of 6

Overload protection Combo power switch and circuit breaker

Outlet safety covers Yes (4)

Transformer accommodation Yes (2)

INPUT

Input connection type NEMA 5-15P

Input cord gauge, type 14 gauge, SJT

Input cord length (ft.) 6 ft.

Recommended Electrical

Service

120V (110-125V)

LEDS ALARMS & SWITCHES

Diagnostic LEDs 1 green "protected" LED confirms surge suppression is present

Switches Lighted on/off power switch

SURGE / NOISE SUPPRESSION

Protection modes Includes full normal mode (H-N) and common mode (N-G/H-G) line surge suppression

AC suppression joule rating 420 joules

Clamping voltage (RMS) 150V

AC suppression response

time

< 1 ns

EMI / RFI filtering Up to 20 dB

DATALINE SURGE SUPPRESSION

Telephone/DSL Protection No

Cable (Coax) Protection No

Network (Ethernet) Protection No

PHYSICAL

Shipping weight (lbs) 1.70

Shipping Dimensions

(HWD/in)

13.61 x 4.97 x 2.01

Unit weight (lbs) 1.46

Unit Dimensions (HWD/in) 12.23 x 2.30 x 1.28

Material of construction Metal

Integrated keyhole mounting

tabs

Yes

Receptacle Color black

AC line cord color yellow

Style Strip

CERTIFICATIONS

Approvals cULus, RoHS

WARRANTY

Product Warranty Period Lifetime

Connected Equipment

Coverage

$10,000

More information, including related products, owner's manuals, and additional technical specifications, can be found online at

www.tripplite.com/en/products/model.cfm?txtModelID=3667.
