Tripp Lite IBAR4 Manual de usuario

4-Outlet Isobar Surge Protector with 6-ft cord and

All-Metal Housing

MODEL NUMBER: IBAR4

Description

For more than 20 years, America's leading companies have trusted Tripp Lite's Isobar Premium surge and noise

suppressors to protect sensitive computer, networking and telecom equipment. With more than 18 million

satisfied customers, the Isobar remains the world's #1 selling premium surge suppressor. Loaded with a

generous combination of high quality components, near indestructible all-metal case and unique noise filtration

system, the isobar offers the highest level of protection attainable in a multi-outlet strip. Robust surge

suppression circuits with sine-wave tracking offer extreme levels of protection against the heaviest surge

conditions exceeding IEEE 587 category A & B specifications and reducing 6,000V test surges to harmless

levels under 35 volts. Isobar's unique protection system combines large toroidal chokes, ferrite rod-core

inductors, HF/VHF capacitors and multiple layers of metal oxide varistors into exclusive isolated filter banks that

remove EMI/RFI interference, even noise generated by other pieces of connected equipment. IBAR4 offers 4

outlets arranged in two filter banks to prevent system crashes, reboots and performance problems common as

noisy system peripherals are powered off and on. Surge suppression rated at 3330 joules / 85,000 amps offers network-grade protection. Widely spaced

NEMA5-15 outlets accommodate up to 2 large transformer plugs without blocking outlets. Includes 6 foot AC line cord with space-saving angled input plug and

keyhole mounting tabs.

PLUG / OUTLETS: Input: NEMA 5-15P / Output: 4 NEMA5-15R / 6 ft. AC line cord

ELECTRICAL: 120V AC, 50/60Hz (Requires NEMA 5-15R wall receptacle)

SUPPRESSION: AC: 140V RMS Clamping / 3330 joules / 85,000 amps

FORMAT: Corded all-metal strip with transformer spaced outlets

Features

Tripp Lite's ISOBAR is the world's #1 selling premium suppressor series with more than 18 million satisfied customers and a safety-tested history of 20+

years

Highlights

4 outlets/6-ft cord

3330 joule rating—more joules

mean more protection!

All-metal housing won’t crack,

burn or melt

Isolated filter banks remove

damaging line noise

$50,000 Insurance for connected

equipment (USA & Canada only)

Lifetime warranty

Applications

Ideal for premium protection of

personal computers with

peripherals, network and CAD /

CAM / CAE workstations,

internetworking accessories,

telecommunications systems,

point of sale equipment, audio /

video and home theater systems

in any home, office or industrial

application

Package Includes

IBAR4 Surge Suppressor

Set of 4 outlet safety covers

Instruction manual with warranty

information

1 / 4

years

Robust surge suppression with sine-wave tracking protects against the heaviest of surge conditions, exceeding IEEE category A&B specifications and

reducing 6,000V test surges to harmless levels less than 35 volts.

Multi-component suppression circuits combine toroidal chokes, ferrite rod-core inductors, HF/VHF capacitors and multiple layers of metal oxide varistors

into exclusive isolated filter banks that remove EMI/RFI interference, even noise from other pieces of connected equipment.

4 outlets arranged in two filter banks prevent system crashes, reboots and performance problems common as noisy peripherals are powered off and on.

Network grade surge suppression rated at 3330 joules / 85,000 amps

Widely spaced outlets accommodate up to 2 large transformer plugs without blocking outlets

Lighted power switch with integrated 12 amp circuit breaker, offers power control & overload protection

6 foot AC line cord with space-saving angled input plug

Keyhole mounting tabs for installation in a variety of application

120V AC, 50/60Hz electrical compatibility

$50,000 Ultimate Lifetime Insurance (USA and Canada Only)

Specifications

OVERVIEW

Intended Application Home/Office, Computer Networks

OUTPUT

Frequency compatibility 50 / 60 Hz

Output watts 1440

Circuit Breaker (amps) 12

Outlet quantity / type 4 NEMA 5-15R

Transformer accommodation Supports up to 2 large transformer plug accessories without covering remaining outlets

INPUT

Nominal Input Voltage(s) Supported 120V AC

Recommended Electrical Service 120V (110-125V)

Input connection type NEMA 5-15P input plug

Input plug features Space-saving right angle input plug

Input cord length (ft.) 6

Input cord length (m) 1.83

Voltage compatibility (VAC) 120

Maximum Surge Amps 135000

UPC ASSIGNMENT

Unit Carton UPC# 037332010094

2 / 4

LEDS ALARMS & SWITCHES

Switches Combination AC circuit breaker & 2 position red illuminated on/off switch

SURGE / NOISE SUPPRESSION

AC suppression joule rating 3330

AC suppression response time NM = 0 ns. CM =

Protection modes Includes full normal mode (H-N) and common mode (N-G / H-G) line surge suppression

Clamping voltage (RMS) 140

AC suppression surge current rating 85,000 amps (36,000 NM / 49,000 CM)

AC suppression components used Metal oxide varistors, toroidal balanced chokes, ferrite rod-core inductors and VHF capacitors.

Safe thermal fusing Prevents unsafe conditions during extreme extended overvoltages and catastrophic occurences

UL1449 let through rating 330V

IEEE587 Cat. A ringwave let through Less than 35 volts

EMI / RFI filtering 40-80 dB

Isolated filter banks Unique isolated filter bank design offers additional filtering between each duplex pair of outlets on the strip to

prevent electrical noise interference between connected loads. Includes 2 filter banks.

Immunity Conforms to IEE 587 / ANSI C62.41

DATALINE SURGE SUPPRESSION

Cable (Coax) Protection No

Network (Ethernet) Protection No

PHYSICAL

Shipping Dimensions (HWD/in) 11.5 x 7 x 3

Shipping Dimensions (HWD/cm) 29.21 x 17.78 x 7.62

Shipping weight (lbs) 2.75

Shipping weight (kg) 1.25

Unit Dimensions (HWD/in) 2.5 x 6 x 3.5

Unit Dimensions (HWD/cm) 6.35 x 15.24 x 8.89

Unit weight (lbs) 1.88

Unit weight (kg) 0.85

Material of construction Metal

Integrated keyhole mounting tabs Metal end caps are fitted with keyhole mounting tabs for wallmount installation

Housing Color Light Gray

Receptacle Color Black

AC line cord color Light Gray

3 / 4

Style Strip

Outlets center to center

measurement Distance between horizontal outlets = 39.45mm; Distance between vertical outlets = 39.30mm

Keyhole slot center to center

measurement Distance between horizontal outlets = 131.90mm; Distance between vertical outlets = 58.17mm

SPECIAL FEATURES

Appearance Rugged all-metal corded strip format with high quality duplex receptacles

Right-Angle Plug Yes

CERTIFICATIONS

UL1449 3rd Edition (AC

Suppression) Tested to UL1449 3rd Edition requirements by ETL

cUL / CSA (Canada) Approved for Canada by ETL

Approvals Exceeds IEEE 587 category A&B specifications

WARRANTY

Product Warranty Period (Worldwide) Lifetime limited warranty

Connected Equipment Insurance

(U.S., Canada & Puerto Rico) $50,000 Ultimate Lifetime Insurance

Specifications are subject to change without notice. Photos may differ slightly from final products.

4 / 4
