Tripp Lite B136-101 Manual de usuario

Owner’s Manual

Warranty

Registration:

chance to win a FREE Tripp Lite

product—www.tripplite.com/warranty

Component Video +

Stereo Audio over Cat5

Extenders and Extender/Splitters

Extender Kit Models: B136-101 and B136-101-WP-1

Extender/Splitter Local Unit Models: B136-004

Extender Unit Models: B136-100 and B136-100-WP-1

Package Contents 2

Product Features 3

Optional Accessories 4

Extender/Splitter Installation 5

Extender/Splitter Daisy-Chain Installation 7

Extender Kit Installation 10

Warranty & Warranty Registration 12

Español 13

Français 25

1111 W. 35th Street, Chicago, IL 60609 USA

www.tripplite.com/support

201102138 932999.indb 1 3/8/2011 12:00:15 PM

Package Contents

All Units:

• B136-004,B136-100,B136-100-WP-1,

B136-101orB136-101-WP-1

• Owner’sManual

B136-004 Only:

• ExternalPowerSupply(Input:100-240V,

50/60Hz,0.5AOutput:5V,2A)

• 1ft.Component+AudioDaisy-ChainCable

B136-100-WP-1 and B136-101-WP-1 Only:

• WallplateHardware

201102138 932999.indb 2 3/8/2011 12:00:15 PM

Product Features

• B136-004workswithaB136-100orB136-100-

WP-1toextendacomponentvideo(1080p,60Hz)

andstereoaudiosignalupto328ft.(100m.)from

thesource.Extendthesignalupto400ft.(121m.)

usingzero-skewcable(TrippLiteP524-01K).

• B136-101andB136-101-WP-1arekitsthatcome

withunitsforboththesourcesideandthedisplay

side,allowingacomponentvideo(1080p,60Hz)

andstereoaudiosignaltobeextendedupto328ft.

(100m.).Extendthesignalupto400ft.(121m.)

usingzero-skewcable(TrippLiteP524-01K).

• Transmitacomponentvideoandstereoaudio

signaltouptofourA/VdevicesusingtheB136-004

Extender/Splitter.

• ExpandthenumberofconnectedA/Vdevicestoup

to13(12remote,1local)bydaisy-chainingupto3

localunitstogether.

• B136-004featurescomponentvideoandstereo

audioportsforconnectinganoptionallocalA/V

device.

• UptothreeB136-004scanbeconnectedtoa

TrippLiteB132-004-RBRackmountBracketand

mountedinjust1Uofrackspace.

• TheB136-100,B136-100-WP-1,B136-101and

B136-101-WP-1requirenoexternalpower.

• TheB136-101-WP-1andB136-100-WP-1

wallplatesfeatureRJ45-typeconnectors,allowing

youtousestandardpatchcableandavoid110

punchdownconnections.

201102138 932999.indb 3 3/8/2011 12:00:15 PM

Optional Accessories

• A008-SeriesComponentVideoGoldCables

• A050-SeriesStereoAudioGoldCables

• B132-004-RB1URackmountBracket

• N001-SeriesCat5eSnaglessPatchCables

• N002-SeriesCat5ePatchCables

• N020-01K-GYGrayCat5eBulkStrandedCable–

1000ft.

• N022-01K-GYGrayCat5eBulkSolidCable–

1000ft.

• N030-010RJ45PlugsforSolidWireCat5e

Cable–10pack

• N031-050RJ45PlugsforStrandedWireCat5e

Cable–50pack

• N201-SeriesCat6SnaglessPatchCables

• N202-SeriesCat6Snagless24AWGSolidPatch

Cable

• N222-01K-GYGrayCat6BulkSolidCable–1000ft.

• P524-01KZero-SkewUTPBulkCable–1,000ft.

Note: The B136-004, B136-100 and B136-100-WP-1 are

sold separately. A B136-100 or B136-100-WP-1 is required

for each output port on the B136-004 extender/splitter that

you wish to connect an A/V device to. The B136-101 and

B136-101-WP-1 are kits that come with units for both the

source and device side.

201102138 932999.indb 4 3/8/2011 12:00:15 PM

B136-004

OPTIONAL LOCAL

A/V DEVICE

DVD

B136-100-WP-1

B136-100

Extender/Splitter Installation

Notes:

1) Test to make sure that the entire installation works

properly before pulling cables through ceilings/walls.

2) To achieve the maximum distance of 400 ft. (121 m.) at

1080p, Zero-Skew cabling must be used, such as

Tripp Lite P524-01K.

3) To achieve extension distance of 328 ft. (100 m.) at

1080p, 24Awg solid wire cabling must be used.

Tripp Lite N202-Series (Cat6), N022-01K-GY (Cat5e Bulk)

and N222-01K-GY (Cat6 Bulk) contains 24Awg solid wire.

201102138 932999.indb 5 3/8/2011 12:00:17 PM

Extender/Splitter Installation

1MakesuretheA/VsourceispoweredOFF.

2ConnectthesourcetotheportsontheB136-004

labeledSOURCEusingTrippLiteA008-Series

ComponentVideoandA050-SeriesStereoAudio

Cables.

3Optional:ConnectalocalA/Vdevicetotheports

ontheB136-004marked LOCALusingTrippLite

A008-SeriesComponentVideoandA050-Series

StereoAudioCables.

4ConnecttheexternalpowersupplytotheB136-

004localunitandplugitintoaTrippLiteSurge

Suppressor,PDUorUninterruptiblePowerSupply

(UPS).TheredLEDwillilluminatetoindicatepower

isbeingreceivedfromtheexternalpowersupply.

5UsingCat5e/6cable,connectoneoftheRJ45

outputportsontheB136-004totheRJ45input

portontheB136-100orB136-100-WP-1remote

unit.

6Repeatstep5foreachadditionalremoteunityou

areconnecting.

7ConnecttheB136-100componentvideoand

stereoaudioconnectorstotheA/Vdevice,or

connecttheB136-100-WP-1totheA/Vdevice

usingTrippLiteA008-SeriesComponentVideoand

A050-SeriesStereoAudioCables.

8Repeatstep7foreachadditionalA/Vdeviceyou

areconnecting.

9TurnonthepowertotheA/Vsource.

201102138 932999.indb 6 3/8/2011 12:00:17 PM

Level 1

Level 2

Level 3

OPTIONAL LOCAL

A/V DEVICE

DVD

Extender/Splitter Daisy-Chain Installation

Notes:

1) Test to make sure that the entire installation works

properly before pulling cables through ceilings/walls.

2) To achieve the maximum distance of 400 ft. (121 m.) at

1080p, Zero-Skew cabling must be used, such as

Tripp Lite P524-01K.

3) To achieve extension distance of 328 ft. (100 m.) at

1080p, 24Awg solid wire cabling must be used.

Tripp Lite N202-Series (Cat6), N022-01K-GY (Cat5e Bulk)

and N222-01K-GY (Cat6 Bulk) contains 24Awg solid wire.

201102138 932999.indb 7 3/8/2011 12:00:17 PM

1MakesuretheA/VsourceispoweredOFF.

2Connectthesourcetotheportsontherst

B136-004localunitlabeledSOURCEusing

TrippLiteA008-SeriesComponentVideoand

A050-SeriesStereoAudioCables.

3Usingtheincluded1ft.component+audiocable,

orTrippLiteA008-SeriesComponentVideoand

A050-SeriesStereoAudioCables,connectthe

portslabeledLOCALontherstB136-004tothe

SOURCEportsonasecondB136-004.

4Repeatstep3ifyouwanttodaisy-chainathird

B136-004localunit.Note: No more than three

local units can be connected.

5Connecttheexternalpowersupplytotherst

B136-004localunitandplugitintoaTrippLite

SurgeSuppressor,PDUorUninterruptiblePower

Supply(UPS).TheredLEDwillilluminateto

indicatepowerisbeingreceivedfromtheexternal

power supply.

6Repeatstep5foreachlocalunitinthe

installation.

7Optional:ConnectalocalA/VdevicetotheLOCAL

portsonthelastB136-004usingTrippLiteA008-

SeriesComponentVideoandA050-SeriesStereo

AudioCables.

8UsingCat5e/6cable,connectanavailableRJ45

outputportonaB136-004totheRJ45inputport

onaB136-100orB136-100-WP-1remoteunit.

Extender/Splitter Daisy-Chain Installation

201102138 932999.indb 8 3/8/2011 12:00:17 PM

9Repeatstep8foreachadditionalremoteunityou

areconnecting.

10 ConnecttheB136-100componentvideoand

stereoaudioconnectorstotheA/Vdevice,or

connecttheB136-100-WP-1totheA/Vdevice

usingTrippLiteA008-SeriesComponentVideo

andA050-SeriesStereoAudioCables.

11 Repeatstep10foreachadditionalA/Vdeviceyou

areconnecting.

12 TurnonthepowertotheA/Vsource.

Extender/Splitter Daisy-Chain Installation

201102138 932999.indb 9 3/8/2011 12:00:17 PM

DVD B136-101

B136-101-WP-1

DVD

Extender Kit Installation

Notes:

1) Test to make sure that the entire installation works

properly before pulling cables through ceilings/walls.

2) To achieve the maximum distance of 400 ft. (121 m.) at

1080p, Zero-Skew cabling must be used, such as

Tripp Lite P524-01K.

3) To achieve extension distance of 328 ft. (100 m.) at

1080p, 24Awg solid wire cabling must be used.

Tripp Lite N202-Series (Cat6), N022-01K-GY (Cat5e Bulk)

and N222-01K-GY (Cat6 Bulk) contains 24Awg solid wire.

201102138 932999.indb 10 3/8/2011 12:00:18 PM
