TREX Viper Manual de usuario

VIPER

USER MANUAL

CONGRATULATIONS

on your purchase of Viper, a classic vibe pedal from T-Rex Engineering.

Viper will give you a range of cool, modulated 70s sounds – all enhanced

with a T-Rex bite. You’ll recognize the vibe effect at once, and it’s easy to

dial in everything from “Little Wing” to “Bridge of Sighs”.

Turn the page to see how it works.

WATCH IT – THIS VIBE BITES!

The main controls on your Viper pedal are the DEPTH, SPEED and LEVEL

knobs, while the MODE button lets you select the basic character of your

vibe.

DEPTH controls the overall strength of the vibe effect. Start with a lower

setting for a nice, subtle effect, and turn it up to send your sound whirl-

ing around the room.

The SPEED knob lets you adjust how fast or slow your sound modulates

– no matter what the depth, or what mode you’re in.

LEVEL - lets you adjust the overall output of your Viper pedal.

Use the MODE button to switch between the two classic vibe modes

– a rotating speaker effect and a subtler vibrato sound.

Trim to customize your sound. The trim dial on the back of the unit

(accessible using a flat-head screwdriver) lets you shape the intensity

and character of your vibe sound. Experiment to get just the vibe you’re

looking for.

TECHNICAL SPECS

Input Impedance@1KHz 880 KOhm

Output Impedance@1KHZ 24 Ohm

Power supply 12V DC

Minimum Power supply Voltage 10,8V DC

Maximum Power supply Voltage 12,5V DC

Current Draw @ 12V DC 162 mA

Maximum Input signal Vp/p 1,5Vp/p

External connectors Input Jack. Output Jack, 12V DC Jack

Controls On/Off, Level, Depth, Speed, Mode

Depth 120 mm

Width 100 mm

Height 55 mm

Weight (excl. battery) 0,594 kg

ABOUT T-REX

Based in Vejle, Denmark, T-Rex Engineering makes classic and

signature effects pedals for the world’s best musicians. Our ap-

proach blends hi-tech innovation with old-world craftsmanship

– always in the service of killer tone.

EU REGULATIONS • ENVIRONMENT PROTECTION

T-Rex accepts and follows the regulations and directives issued

by the EU. We find these environment protecting regulations

very good, and we are happy to follow them.

RoHS

REACh

T-REX WARRANTY CONDITIONS

T-Rex offers a 2-year warranty on all our products. In the unlikely event

of a malfunction, please contact our technical support at info@t-rex-

engineering.com before sending us the product for repair. When the

product has been sent to us at sender’s cost, we will repair or replace

your product and send it back to you - free of charge and usually within

3 weeks (shipping not included). The product needs to be accompanied

by a copy of your receipt, serial number, return address, phone number,

e-mail address and a brief explanation of the problem. Please note that

we cannot replace a product until we have received it here in Denmark.

The warranty is lost if the product has been damaged by alteration, mis-

use, accident, or neglect; or if the product has been repaired or serviced

by persons not authorized by T-Rex. Read more about warranty condi-

tions at www. t-rex-engineering.com.

T-Rex Engineering ApS, Tel.: +45 75 72 71 81, Fax: +45 75 72 71 98

www.t-rex-engineering.com •mail: info@t-rex-engineering.com

Steen Meldgaard Laursen

Managing Director

ISSUED IN VEJLE, 2007

Lars Dahl-Jørgensen

Development Director

Sebastian Jensen

Production Director
