TRENDnet TEW-430APB - Wireless Access Point Manual de usuario

TEW-430APB Wireless Access Point is today's link to Wireless Technology.

Compliant with the IEEE Wireless Networking Standard 802.11g, it provides

Direct Sequence Spread Spectrum (DSSS) operation for transparent bridging

and roaming capabilities for wireless nodes. The TEW-430APB also provides

WDS bridging functions, allowing users to connect two or more Access Points

together, wirelessly. With this Wireless Access Point and Wireless Network

Adapters, users can connect to Ethernet/Fast Ethernet LAN at home or office to

access network resources with coverage up to 300 meters.

TEW-430APB (c1)

54Mbps 802.11g Wireless Access Point

TEW-503PI (07-28-2005) TEW-430APB

rev:07.07.2006

•

Operates as Access Point, AP Client or WDS Wireless Bridging/Repeater mode

Provides Security with 64/128-Bit WEP, WPA/WPA2 and WPA-PSK/WPA2-PSK

Supports 802.1x Authentication and MAC Address Control for Authorization Access (20 entries)

Supports Most Operating Systems, such as Windows 95/98/ME/NT/2000/XP, Unix and Mac

Allow Users to Disable ESSID Broadcast to Increase Wireless Security

Built-in 10/100Mbps Auto-Sensing Fast Ethernet Port

Dynamic Data Rate Scaling at 54, 48, 36, 24, 18, 12, 9 and 6 Mbps for 802.11g

Dynamic Data Rate Scaling at 11, 5.5, 2 and 1 Mbps for 802.11b

Allow Auto Fallback Data Rate for Optimized Reliability, Throughput and Transmission Range

2dBi Detachable Diversity Antenna. Replace with Optional High-Gain Antenna to Extend the Range/Coverage Area.

Easy Configuration and Maintenance with Web Browser (HTTP)

Flash Memory for Firmware Upgrade and Save/Restore Settings

Distance coverage 50 to100 meters indoor, 100 to 300 meters outdoor depending on the environment

3-Year Warranty

FEATURES

NEW

IMPLEMENTS

RoHS compliant

New Housing

New Standard GUI

Add McAfee Bonus

Chipset > Realtek 8186+8225

Media Connector

Modulation

LED Indicators

Power

Dimensions

Weight

Temperature

Humidity

Protocol

Data Rate (Auto Fallback)

Channel

Antenna

Receiving Sensitivity

Output Power

Operating Mode

Security

Transmit Power

• IEEE 802.11g (Wireless LAN) • IEEE 802.3u (Fast Ethernet)

• 2.412 ~ 2.484 GHz

• 10/100Mbps, Half/Full Duplex

• 11Mbps 8% PER @ -78dBm (typical) • 54Mbps 10% PER @ -68dBm (typical)

• 802.11b: DSSS • 802.11g: DBPSK/DQPSK/CCK/OFDM

• AP, AP Client, WDS Bridge & Repeater Modes

• 64/128-Bit WEP (Hex/ASCII), WPA/WPA2 • WPA-PSK/WPA2-PSK • MAC Address Filter, SSID Broadcasting Control

• Power, LAN & WLAN

• 7.5V DC, 1A External Power Adapter

• 150 x 110 x 30 mm (5.9 x 4.3 x 1.2 inches) (without antenna)

• 226g (8 oz.)

• CSMA/CA with ACK

• Operating: -0° ~ 40°C (32° ~104°F); Storage: -25° ~ 70°C (-13° ~ 158°F)

• Max. 90% (non-condensing)

• CE, FCC

• 802.11b: 18dBm (typically) • 802.11g: 15dBm (typically)

• 802.11b: 11, 5.5, 2 and 1Mbps • 802.11g: 54, 48, 36, 24, 18, 12, 9 and 6Mbps

• 1~ 11 Channels (US) 1~13 Channels (EU)

• 1 x 2dBi Detachable Diversity Antennas with Female Reverse SMA Connector

• 13 dBm (min)

Certifications

Frequency Range

Wireless

Standards

Hardware

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet

products and is subject to change at any time, without notice. For the most recent product information please visit

http://www.trendnet.com.

54Mbps 802.11g Wireless Access Point

TEW-430APB

RELATED PRODUCTS

PACKAGE CONTENTS

TEW-421PC

TEW-423PI

• CD-ROM (User’s Guide)

• Power Adapter (5V, 1.2A)

• TEW-430APB

802.11g 54Mbps Wireless CardBus PC Card

802.11g 54Mbps Wireless PCI Adapter

• Quick Installation Guide

ORDERING INFORMATION

To Order Please Call:

1-888-326-6061

3135 Kashiwa Street,Torrance, CA 90505 USA

Tel: 1-888-777-1550

Fax: 310-891-1111

Web:

Email: [email protected]

www.trendnet.com

SPECIFICATIONS

NETWORKING SOLUTIONS

Workstation with

Wireless PCI Adapter

(TEW-423PI)

Notebook with

Wireless PC Card

(TEW-421PC)

Cable/DSL 4-Port

Firewall Router

(TW100-BRF114)

Workstation with

PCI Adapter

(TE100-PCIWN)

54Mbps 802.11g Wireless LAN Access Point

(TEW-430APB)

Cable/DSL

Modem

Internet
