TRENDnet NWay Manual de usuario

Aug/02 1 MNADM6509001

8-Port 10/100Mbps NWay Switch

User Manual

Ver. 1.00

All brand names and trademarks are properties of their respective owners.

Aug/02 2 MNADM6509001

Introduction

The 8-Port NWay Switch is designed to for the needs of small enterprise and home networks. Its easy

installation can boost network performance just in a couple of minutes. With its Auto-Negotiation capability, all

ports can be configured to its optimum speed of 10/20Mbps or 100/200Mbps automatically. It eliminates

bottlenecks and bandwidth constraints, optimizes network performance. Inevitably the 8-Port NWay Switch is

your best choose to improve network performance with the highest performance/price ratio.

Key Features

y10/100Mbps twisted-pair ports with Auto-negotiation.

yBridging capability for 100Mbps and 10Mbps segments.

yProvides Store-and-Forward Switching Architecture.

ySupports Auto MDI/MDI-X.

ySupports IEEE802.3x Flow-Control Full-Duplex operation.

ySupports Back-Pressure Flow-Control Half-Duplex operation.

y1M bits Packet Buffer.

y1K entries Address Table.

yEight RJ-45 Ports

yOne Uplink Port

Packing List

Thank you for purchasing of this Switch. The package should contain the following items:

yOne 8-Port Switch

yOne AC/DC Power Adapter

yOne User Manual

yFour rubber feet

If anything is missing, please contact your place of purchase.

Cabling

10Mbps

Category 3, 4, or 5 Twisted-Pair cable can be used for transmitting data at 10Mbps or 20Mbps bandwidth on

10BASE-T networks.

100Mbps

Only Category 5 Twisted-Pair cable can be used for transmitting data at 100Mbps or 200Mbps bandwidth on

100BASE-TX networks.

Aug/02 3 MNADM6509001

Networking

Connecting computers to Switch

1. Make sure all computers to be connected to the Switch have installed properly a network interface card.

2. Connect computer to the Switch with a twisted-pair cable. The cable should have RJ-45 plugs. Use

Category 5 cable for all connections. Please pay attention to the length of each cable should be less than

100 meters.

3. Plug one end of the cable to the RJ-45 port of the computer’s NIC. Plug the other end to any available port

on the Switch.

Up linking to other Switch

1. Prepare a straight-through Category 5 twisted-pair cable with RJ-45 plugs. Make sure the cable does not

longer than 100 meters.

2. Connect one end of the cable to the Switch’s Uplink port.

3. Connect the other end of the cable to the other Switch’s MDI-X port (in our Switch, Port 1 to Port 8 are

MDI-X ports).

Alternatively, you can connect two Switches at both ends MDI-X ports with a crossover cable.

Please note that the UPLINK Port shares with Port 8. Only either of them can be used at a time, not both.

Status LEDs

LED Color State Indication

POWER Amber On Power is ON

SPEED Green On

Off

Connection at 100Mbps

Connection at 10Mbps

LINK/ACT Green On

Off

Flash

Valid Network Connection

No Network Connection

Sending/Receiving Data

FDX Green On

Off

Full-Duplex Mode

Half-Duplex Mode

Aug/02 4 MNADM6509001

Specifications

Model 8-Port 10/100Mbps NWay Switch

Access Method CSMA/CD

Standards IEEE802.3u 100BASE-TX

IEEE802.3 10BASE-T

Media Support 10BASE-T 100-Ohm Cat. 3, 4, 5 twisted-pair

100BASE-T 100-Ohm Cat. 5 twisted-pair

Ports 8 RJ-45 + 1 Uplink Port

Bandwidth 100BASE-TX: 200/100Mbps via Auto-Negotiation

10BASE-T: 20/10Mbps via Auto-Negotiation

Switching Method Store-And-Forward

Filtering/Forwarding Rate 100Mbps: 148800 packets/second

10Mbps: 14880 packets/second

Flow Control Full Duplex – IEEE802.3x

Half Duplex – Back Pressure

MAC Entry 1K entries

Packet Buffer 1M bits per system

Power Requirement DC 6V/1A

Operating Temperature 0 to 45 degree C

Storage Temperature -20 to 70 degree C

Humidity 10% to 90% non-condensing

Status LEDs Port: 3 (SPEED, LINK/ACT, FDX)

System: 1 (POWER)

Dimensions 161 x 84 x 26 mm

Certification FCC Class A, CE Mark
