TRENDnet TE100-P1U Manual de usuario
TE100-P1U
3.01
Quick Installation Guide
Table of Contents
English 1
1. Before You Start 1
2. How to Install 2
3. Configure the Print Server 3
4. Add the Printer to your computer 5
Troubleshooting 7
Version 08.01.2012
1. Before You Start
CD-ROM Drive
Router
An available DHCP Server – routers usually have a built-in DHCP server
PS Utility/PS Wizard Requirements
Windows 7 (32/64-bit), Vista (32/64-bit), XP (32/64-bit), 2003 Server, 2000, ME,
98SE
Package Contents
TE100-P1U
CD-ROM (Utility and User's Guide)
Multi-Language Quick Installation Guide
Power Adapter (5V DC, 2.5A)
System Requirements
1
Supported Operating Systems CPU Memory
Windows 7 (32/64-bit)
Windows Vista (32/64-bit)
Mac OS X (10.6)
Windows XP (32/64-bit) /
2003 Server / 2000 / ME / 98SE
1GHz or above
800MHz or above
Intel Processor
300MHz or above
1GB RAM or above
512MB RAM or above
1GB RAM or above
256MB RAM or above
Mac OS X (10.5)
Mac OS X (10.4)
Mac OS X (10.1-10.3)
867MHz or above
333MHz or above
300MHz or above
512MB RAM or above
256MB RAM or above
256MB RAM or above
2. How to Install
4. Power ON the printer.
2
Note: Please power OFF your printer before connecting it to the print server. Then turn
on your printer after you make your hardware connections.
1. Connect a RJ-45 network cable from a Switch/
Router to the LAN port of the Print Server.
2. Connect the USB Printer to the USB port of the
Print Server.
3. Connect the Power Adapter to the Print Server
and then to a power outlet.
3
1. Insert the Utility CD-ROM into your computer's
CD-ROM Drive.
3. Configure the Print Server
Note: The Print Server can be managed using the PS-Utility or a web browser. For MAC
users, change your computers IP address to 192.168.0.X (where X is an available
number from 2-254). Since the Print Server's default IP address is 192.168.0.1, make
sure no other network devices are assigned an IP address of 192.168.0.1. Then enter
http://192.168.0.1 in your web browser to access the Print Server's Web Utility.
For Windows Users
2. Click Run Autorun.exe (Windows 7/Vista only).
3. Click Install Utility PS Utility.
4
6. Click OK.
Print Server configuration is now complete.
4. Follow the InstallShield Wizard instructions.
Click Finish.
5. Select the Print Server and click Change IP
Address. Manually assign the IP Address of
the Print Server and then click OK.
Note: The IP Address must match the network
segment of your network.
7. Click Show Web Setup.
5
4. Add the Printer to your computer
Note: For printing instructions for Windows ME, 98SE and Mac OS X, please consult
the User's Guide included on the Utility CD-ROM.
Windows 7/Vista/2003 Sever/XP/2000
2. Select the print server, select the desired port
and then click Add Printer.
3. Click Select from manufacturer list. Select
the appropriate driver for your printer and then
click Next.
1. Click PS Wizard and then click
Win 7/Vista/2003/XP/2000.
6
8. Repeat steps 1 to 7 to add the printer to other
computers on the network.
Add Printer is now complete.
For detailed information regarding the TE100-P1U configuration and advanced settings,
please refer to User's Guide on the Utility CD-ROM, or TRENDnet's website at
http://www.trendnet.com.
Register Your Product
To ensure the highest level of customer service and support, please take a moment to
register your product Online at: www.trendnet.com/register
Thank you for choosing TRENDnet.
4. Click Next.
5. Click Print Test Page.
7. Click Finish.
6. Click OK.
1. I inserted the Utility CD-ROM into my computer's CD-ROM Drive but the installation menu does
not appear automatically. What should I do?
1. For Windows 7, if the installation menu does not appear automatically, click on the Windows
Icon on the bottom left hand corner of the screen, click the “Search programs and files” box,
type D:\autorun.exe, where “D” in “D:\autorun.exe” is the letter assigned to your CD-ROM
Driver, and then press the ENTER key on your keyboard
2. For Windows Vista, if the installation menu does not appear automatically, click Start, click the
Start Search box, type D:\autorun.exe where "D" in "D:\autorun.exe" is the letter
assigned to your CD-ROM Drive, and then press the ENTER key on your keyboard.
3. For 98SE/XP/2000, if the window does not appear automatically, click Start, click Run and
type D:\autorun.exe where “D” in “D:\autorun.exe” is the letter assigned to your CD-ROM Drive,
and then press the ENTER key on your keyboard.
2. The PS Wizard / PS Utility is unable to see my print server. What should I do?
1. Double check your hardware connections; make sure that the print server and printer are
powered ON and are properly connected.
2. Click Discover.
3. Disable any software firewall programs (e.g. ZoneAlarm). If your computer is running
Windows 7, XP, or Vista, disable the built in firewall program.
3. My printer does not print the entire document. What should I do?
Windows 7
1. Click on the Windows icon on the bottom left-hand corner of the screen.
2. Click Devices and Printers.
3. Right click on the printer and select Printer Properties.
4. Click the Advanced tab.
5. Uncheck Enable advanced printing features.
6. Click Apply.
7. Click OK.
Windows Vista
1. Click on the Windows icon on the bottom left-hand corner of the screen.
2. Click Control Panel.
3. Click Classic View.
4. Click Printers.
5. Right click on the printer and select Properties.
6. Click the Advanced tab.
7. Uncheck Enable advanced printing features.
8. Click Apply.
9. Click OK.
Troubleshooting
7
4. I successfully added a printer to my computer and I can print a test page, but I cannot print
anything from Microsoft Word or other applications.
Make sure the printer is set as your default printer.
1. On Windows 7, click the Windows icon Devices and Printers and verify that your printer icon
has a check on it.
2. On Windows Vista, click the Start Icon Control Panel Classic View Printers and verify
that your printer icon has a check on it.
3. On Windows XP/2000/2003/98SE Server, click Start and then click Printers & Faxes, verify that
your printer icon has a check on it.
5. I configured my print server to automatically receive an IP Address from a DHCP server, and
now I cannot go into the Print Server's web utility.
1. Open PS Wizard (See 4. Add the Printer to your PC) to locate your print server's IP Address.
2. For MAC users, press the Reset button at the back of the TE100-P1U, hold the button for 15
seconds, release the button, and enter in a web browser to access the web http://192.168.0.1
utility feature.
6. How do I setup the TE100-P1U on a Mac?
Type in http://192.168.0.1 in you browser to logon to the built-in web configuration
If you still encounter problems or have any questions regarding the TE100-P1U, please contact
TRENDnet's Technical Support Department.
