THA-101 WiFi Smart Plug Quick Install Guide

Setup for Repeater Mode

Power on the Extender

Step1. Plug your Wireless Extender into an

electrical socket.

Step2. Check the LEDs: the power LED

should be always on when system is

ready.

Connect to the Wireless

Extender

Step1. Default SSID is “THA-101” and

security key is “12345678”.

Step2. Set your wireless adapter in DHCP

client and waiting for getting IP

Address from the Wireless Extender.

Step3. Open a web browser and ente

“192.168.1.254” in URL field to open

the configuration page.

Step4. Default user name is “admin” and

password is “password” to access

WEB GUI.

Manually Configuration:

Step1. Open Wireless Settings / AP Client

page.

Step2. Setup the SSID and Security of AP

that you want to connect to: Click

APPLY to finish.

Notes:

The Wireless Extender is designed as a pure wireless

device, so there are no any RJ-45 ports for Etherne

cable to connect to. Please prepare any IEEE802.11

ac/b/g/n compliant wireless adapter for next setup

step. OR you can use “SCAN” to refresh the

wireless network and select an AP to

connect to.

“Theproductshallbeusedintheresidential

environmentnotwithstandinguseincommercial,

businessenvironments.Ifyouwanttouseother

thantheaboveenvironments,pleasecontact

AboComfirst.”

WPS Configuration:

Step1. Press the WPS button of the Wireless

Extender over 3 seconds.

Step2. Then press the WPS button of the

wireless router/AP over 3 seconds

too. Step 1 and Step 2 need to be

done in 200 seconds.

FCC Statement:

Federal Communication Commission Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15

of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to

radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to

try to correct the interference by one of the following measures:

●Reorient or relocate the receiving antenna.

●Increase the separation between the equipment and receiver.

●Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

●Consult the dealer or an experienced radio/TV technician for help.

Check if Connected

The green–checked icon ahead is the

Wireless Router/AP which the Wireless

Extender is working to.

WPS button behavior:

Less than 2 sec →N/A, WPS LED no blinking.

More than 2 sec →Do WPS, WPS LED start blinking

Reset button behavior:

Less than 2 sec →N/A, D5-D1 LEDs no blinking.

2-5 seconds →Do REBOOT, D5-D1 LEDs fast blinking.

More than 5 sec→Do Factory Default, D5-D1 LEDs

blinking slowly.

Hardware Button Behavior

FCC Caution: Any changes or modifications not expressly approved by the party

responsible for compliance could void the user’s authority to operate this equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device

may not cause harmful interference, and (2) this device must accept any interference received, including interference

that may cause undesired operation.

For product available in the USA/Canada market, only channel 1~11 can be operated. Selection of other channels is not

possible.

This device and it's antennas(s) must not be co-located or operating in conjunction with any other antenna or transmitter

except in accordance with FCC multi-transmitter product procedures.

IMPORTANT NOTE:

FCC Radiation Exposure Statement:

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment

should be installed and operated with minimum distance 20cm between the radiator & your body.
