Features：
Description：
Archer C7 AC1750 Wireless
Dual Band Gigabit Router
The TP-LINK’s Archer C7 upgrades your network to the next generation of Wi-Fi. With combined wireless speeds of up to 1.75Gbps and 6 antennas,
the device provides ultimate speeds and wireless range. You can run multiple bandwidth intensive applications in a large home or oce. Simple
tasks like sending e-mails or web browsing can be handled by the 2.4GHz band while bandwidth intensive tasks like online gaming or HD video
streaming can be processed by the 5GHz band– all at the same time.
If you prefer a wired connection, the Archer C7 boasts ve gigabit ports to provide a lightning-fast and lag-free experience. The two USB 2.0 ports
will allow you to power a robust home Internet network by sharing printers, ash storage, ftp servers, or media players.
The next generation of Wi-Fi, leading 802.11ac standard
Simultaneous 5GHz 1300Mbps and 2.4GHz 450Mbps
connections for1.75Gbps of total available bandwidth
Full gigabit ports ensure ultra fast data transfer speeds
3*5dBi external antennas and 3 internal antennas provide
maximum whole directional wireless coverage and reliability
Dual USB Ports - easily share printers, les or media with your
friends or family locally or over the internet
The device’s built-in print server supports wireless printing from
dierent computers by connecting a USB printer to the router
Guest Network Access provides secure Wi-Fi access for guests
sharing your home or oce network
Supports IPV6 (Internet Protocol Version 6)
Wireless On/O Switch lets you simply turn the wireless radio on
or o
Easy one-touch wireless security encryption with the WPS button
Parental Control allows administrators to establish restricted
access for children or sta
Dual
USB Ports
Gigabit
Ports
Up to
1300Mbps
+450Mbps
Security
Connection
Dual Band
5+2.4GHz IPv6-
Enabled
Maximum
Range
www.tp-link.com
Specifications are subject to change without notice. TP-LINK is a registered trademark of TP-LINK Technologies Co., Ltd. Other brands and product names are
trademarks or registered trademarks of their respective holders. No part of the specifications may be reproduced in any form or by any means or used to make
any derivative such as translation, transformation, or adaptation without permission from TP-LINK Technologies Co., Ltd.
Specifications：
Archer C7 AC1750 Wireless Dual Band Gigabit Router
Interface
Button
External Power Supply
Antenna type
Wireless Standards
Frequency
Signal Rate
EIRP
Reception Sensitivity
Wireless Functions
Wireless Security
WAN Type
DHCP
Quality of Service
Port Forwarding
Dynamic DNS
VPN Pass-Through
Access Control
Firewall Security
USB Sharing
Management
Internet Protocol
HARDWARE FEATURES
WIRELESS FEATURES
SOFTWARE FEATURES
4 10/100/1000Mbps LAN Ports
1 10/100/1000Mbps WAN Port
2 USB 2.0 Port
WPS/Reset Button
Wireless On/O Switch
Power On/O Button
12VDC / 2.5A
Three 5GHz 5dBi detachable antennas (RP-SMA)
Three 2.4GHz internal antennas
IEEE 802.11a/n/ac, 5GHz
IEEE 802.11b/g/n, 2,4GHz
2.4GHz and 5GHz
5GHz: Up to 1300Mbps
2.4GHz: Up to 450Mbps
<20dBm
5GHz
11a 6Mbps： -96dBm, 11a 54Mbps： -79dBm
11ac HT20: -71dBm, 11ac HT40: -66dBm, 11ac HT80: -63dBm
2.4GHz
11g 54M: -77dBm
11n HT20: -74dBm, 11n HT40: -72dBm
Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics
WEP, WPA / WPA2, WPA-PSK/ WPA2-PSK encryption
Dynamic IP/Static IP/PPPoE/PPTP(Dual Access)/L2TP(Dual Access)/BigPond
Server, Client, DHCP Client List,
Address Reservation
WMM, Bandwidth Control
Virtual Server, Port Triggering, UPnP, DMZ
DynDns, Comexe, NO-IP
PPTP, L2TP, IPSec
Parental Control, Local Management Control, Host List, Access
Schedule, Rule Management
DoS, SPI Firewall
IP Address Filter/MAC Address Filter/Domain Filter
IP and MAC Address Binding
Support Samba(Storage)/FTP Server/Media Server/Printer Server
Access Control
Local Management
Remote Management
IPv4, IPv6
www.tp-link.com
Copyright © 2011 TP-LINK Technologies Co., Ltd. All rights reserved.
Specifications：
Specifications are subject to change without notice. TP-LINK is a registered trademark of TP-LINK Technologies Co., Ltd. Other brands and product names are
trademarks or registered trademarks of their respective holders. No part of the specifications may be reproduced in any form or by any means or used to make
any derivative such as translation, transformation, or adaptation without permission from TP-LINK Technologies Co., Ltd.
Diagram:
Dual USB Ports Sharing
Archer C7 AC1750 Wireless Dual Band Gigabit Router
Package:
Archer C7 AC1750 Wireless
Dual Band Gigabit Router
3 detachable antennas
Power supply unit
Resource CD
Ethernet Cable
Quick Installation Guide
Certications
System Requirements
Dimensions (W X D X H)
Environment
OTHERS
CE, FCC, RoHS
Microsoft Windows 8/7/Vista/XP/2000/NT/98SE, MAC OS, NetWare,
UNIX or Linux.
9.6 x 6.4 x 1.3 in. (243 x 160.6 x 32.5mm)
Operating Temperature: 0℃~40℃(32℉~104℉)
Storage Temperature: -40℃~70℃(-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
Internet
Archer C7 AC1750 Wireless
Dual Band Gigabit Router
Printing or scanning files
Power On/Off
Power Wireless On/Off
Dual USB Ports
Internet
Connect to DSL, Fiber or Cable modem
Gigabit Ethernet
Connect to computers, TVs and
game consoles
WPS/Reset
Sharing files/photos/musics/videosHard drive1/Flash disk/
Printer2connection
Related Products:
Archer T4U AC1200 Wireless
Dual Band USB Adapter
Archer T2U AC600 Wireless
Dual Band USB Adapter
DSL/Fiber/Cable modem
1Some USB hard drive that works at a high power without using any external power adapter might not be supported.
2The USB Printer Controller supports Windows 8/7/Vista/XP 32/64bits and Mac OS. For the printer compatibility information,
please visit www.tp-link.com
