TP-Link Omada EAP230-Wall Manual de usuario

Quick Installation Guide

Wall-Plate Access Point

CONTENT

English............................................................................................................... 1

Български ....................................................................................................... 6

Čeština............................................................................................................11

Қазақша .........................................................................................................16

Magyar ............................................................................................................21

Polski................................................................................................................26

Русский язык...............................................................................................31

Română...........................................................................................................36

Slovenčina .....................................................................................................41

Srpski jezik.....................................................................................................46

Українська мова.........................................................................................51

Lietuvių............................................................................................................56

Slovenščina...................................................................................................61

Hrvatski...........................................................................................................66

Latviešu ..........................................................................................................71

Eesti..................................................................................................................76

English

Note: Images may dier from your actual product.

Network Topology

A typical network topology for the AP is shown below.

Router

PoE Switch

Management Host AP AP AP

Clients

English

The AP can only be powered via a PSE device (such as a PoE

switch) which complies with Power Source Class 2 (PS2) or

Limited Power Source (LPS) of IEC 62368-1.

A DHCP server (typically a router) is required to assign IP

addresses to the APs and clients in your local network.

The management host can be in the same or dierent network

segment with the APs.

Pre-Installation Checklist

Before installation, be sure that you have the following items:

• A pre-installed wall junction box

• An RJ45 plug

• A triangular screwdriver (Only for some models)

• A Phillips screwdriver

• A PoE switch

Installation Steps

The AP can be mounted into a wall junction box. The junction

box should be pre-installed with a running-in-wall Ethernet cable

connected to a PoE switch.

86mm wall

junction box

Standard EU wall

junction box

Standard US wall

junction box

(Only for some models)

English

1. Detach the faceplate of the junction box with a Phillips

screwdriver (demonstrated with a standard US wall junction

box).

2. Detach the faceplate of the AP with a screwdriver.

3. Connect the Ethernet cable inside the junction box to an

RJ45 plug. Then connect the cable to the UPLINK+PoE port.

English

Position the Ethernet cable to ensure it is not strained.

Note: If the junction box does not have enough room to accommodate

the AP without straining the Ethernet cable, replace the junction box with

an open-end or deeper one.

4. Insert the enclosed screws and tighten them with a

screwdriver to secure the mounting bracket.

Note:

• Do not over tighten the screws. If the enclosed screws do not t the

English

junction box, use the screws attached to the junction box instead.

• For some models, switch the order of Step 3 and Step 4.

5. Press the faceplate of the AP back into position.

Software Configuration

To quickly set up a wireless network connection with mass APs,

please follow the steps below.

1. Get the Controller from https://www.tp-link.com or contact

the sales sta.

2. Launch the Controller and follow the conguration wizard to

create a primary wireless network.

3. Adopt the AP devices in the Controller management interface

to change their status from Pending to Connected.

Български

Забележка: Изображенията може да се различават от вашия

действителен продукт.

Мрежова топология

Една типична мрежова топология за AP е показана по-долу.

Рутер

PoE комутатор

Хост за управление AP AP AP

Клиенти

Български

Точката за достъп (АР) може да се захранва само чрез PSE

устройство (като PoE комутатор), което отговаря на Клас 2

на източник на захранване (PS2) или ограничен източник на

захранване (LPS) на IEC 62368-1.

Нужен е DHCP сървър (в типичния случай - рутер), които да

присвоява IP адреси на AP устройствата и клиентите във

вашата локална мрежа. Управляващият хост може да бъде в

същия или различен мрежов сегмент с AP устройствата.

Списък с необходимите неща преди

инсталация

Преди инсталация, моля, уверете се, че имате следните неща:

• Предварително инсталирана розетка за свързване на

стената

• RJ45 накрайник

• Триъгълна отвертка (Само за някои модели)

• Отвертка с накрайник тип “звезда”

• PoE комутатор

Стъпки за инсталация

Точката за достъп (АР) може да бъде монтирана в стенна

съединителна кутия. Разклонителната кутия трябва да бъде

инсталирана предварително с прокаран в стената Ethernet

кабел свързан към PoE комутатор.

86mm

разклонителна

кутия за стена

Стандартна ЕС

разклонителна

кутия за стена

Стандартна стенна кутия

за свързване (САЩ)

(Само за някои модели)

Български

1. Отделете лицевата страна на разклонителната кутия с

отвертка “звезда” (демонстрирано със стандартна стенна

съединителна кутия, използвана в САЩ).

2. Отделете лицевата страна на AP с отвертка.

3. Свържете Ethernet кабела в разединителната кутия

към RJ45 накрайник. След това свържете кабела към
