TP-Link JetStream T2600G-18TS Manual de usuario

Business Networking Solution

Installation Guide

JetStream Gigabit L2 Managed Switch

T2600G-18TS (TL-SG3216)

T2600G-28TS (TL-SG3424)

T2600G-52TS (TL-SG3452)

T2600G-28MPS (TL-SG3424P)

IAbout this Installation Guide

About this Installation Guide

This Installation Guide describes the hardware characteristics, installation methods and the points that should

be attended to during the installation. This Installation Guide is structured as follows:

Chapter 1 Introduction.

This chapter describes the external components of the switch.

Chapter 2 Installation.

This chapter illustrates how to install the switch.

Chapter 3 Lightning Protection.

This chapter illustrates how to prevent lightning damage.

Chapter 4 Connection.

This chapter illustrates how to do the physical connection of the switch.

Chapter 5 Configuration

This chapter instructs you to configure the switch via Web Interface and CLI commands.

Appendix A Troubleshooting.

Appendix B Hardware Specifications.

Audience

This Installation Guide is for:

Network Engineer Network Administrator

Conventions

• Some models featured in this guide may be unavailable in your country or region. For local sales information,

visit http://www.tp-link.com.

• The figures in Chapter 2 to Chapter 5 are for demonstration purposes only. Your switch may differ in

appearance from that depicted.

• This Guide uses the specific formats to highlight special messages. The following table lists the notice icons

that are used throughout this guide.

Remind to be careful. A caution indicates a potential which may result in device damage.

Remind to take notice. The note contains the helpful information for a better use of the product.

Related Document

The User Guide and CLI Reference Guide of the product are provided on the resource CD. To obtain the latest

product information, please visit the official website:

http://www.tp-link.com

JetStream Gigabit L2 Managed Switch

II Contents

Contents

Chapter 1 Introduction ——————————— 01

1.1 Product Overview.................................................01

1.2 Appearance............................................................01

Chapter 2 Installation ——————————— 07

2.1 Package Contents ...............................................07

2.2 Safety Precautions ..............................................07

2.3 Installation Tools...................................................09

2.4 Product Installation .............................................09

Chapter 3 Lightning Protection ——————— 11

3.1 Cabling Reasonably.............................................11

3.2 Connect to Ground .............................................13

Chapter 4 Connection ——————————— 16

4.1 Ethernet Port..........................................................16

4.2 SFP Port...................................................................16

4.3 Console Port ..........................................................16

4.4 Verify Installation..................................................17

4.5 Power On .................................................................18

4.6 Initialization.............................................................18

Chapter 5 Conguration —————————— 19

5.1 Congure the Switch via GUI ...........................19

5.2 Congure the Switch Using CLI......................20

Appendix A Troubleshooting ———————— 23

Appendix B Hardware Specications ————— 25

JetStream Gigabit L2 Managed Switch

01Introduction

Chapter 1 Introduction

1.1 Product Overview

T2600G-18TS, T2600G-28TS, T2600G-52TS and T2600G-28MPS are Gigabit Ethernet

switching products recently developed by TP-Link. T2600G-18TS possesses 16 RJ45

ports and 2 SFP slots. T2600G-28TS/T2600G-28MPS possesses 24 RJ45 ports and 4

SFP slots. T2600G-52TS characterizes with 48 RJ45 ports and 4 SFP slots. The SFP slot

enables remote connection with SFP slots on other devices through SFP module and

fiber. T2600G-18TS/T2600G-28TS/T2600G-52TS/T2600G-28MPS is compatible with all

kinds of gigabit SFP modules. Here you are recommended to choose gigabit SFP module

produced by TP-Link, which can perfectly extend your network and enlarge the bandwidth.

T2600G-18TS/T2600G-28TS/T2600G-52TS/T2600G-28MPS is your first choice to extend the

originally large and medium-sized network.

Designed for workgroups and departments, T2600G-18TS/T2600G-28TS/T2600G-52TS/T2600G-

28MPS from TP-Link provides wire-speed performance and full set of L2 management features. It

provides a variety of service features and multiple powerful functions with high security.

The EIA-standardized framework and smart configuration capacity can provide flexible solutions

for a variable scale of networks. Static routing allows devices in different VLANs/subnets to

communicate with each other in an IPv4/IPv6 network. OAM, L2PT and sFlow can meet the

requirement of large ISP customers. ACL, 802.1x and Dynamic ARP Inspection provide robust

security strategies. QoS and IGMP snooping/filtering optimize voice and video application. Link

aggregation (LACP) increases aggregated bandwidth, optimizing the transport of business critical

data. SNMP, RMON, WEB and CLI Log-in bring abundant management policies. TP-Link JetStream

L2 Managed Switch integrates multiple functions with excellent performance, and is friendly to

manage, which can fully meet the need of the users demanding higher networking performance.

1.2 Appearance

■Front Panel

The front panel of T2600G-18TS is shown as the following figure.

Figure 1-1 Front Panel of T2600G-18TS

10/100/1000Mbps

RJ45 Port

LEDs Console

(USB)

Console

(RJ45)

SFP Port

JetStream Gigabit L2 Managed Switch

02 Introduction

The front panel of T2600G-28TS is shown as the following figure.

Figure 1-2 Front Panel of T2600G-28TS

T2600G-28TS

10/100/1000Mbps

RJ45 Port

LEDs Console

(USB)

Console

(RJ45)

SFP Port

LEDs

LED Status Indication

PWR

On The switch is powered on.

Off The switch is powered off or power supply is abnormal.

Flashing Power supply is abnormal.

SYS Flashing The switch works properly.

On/Off The switch works improperly.

1000Mbps On A device is linked to the corresponding port and running at 1000Mbps.

Off A 10/100Mbps device or no device is linked to the corresponding port.

Link/Act

On A device is linked to the corresponding port and running properly.

Flashing Data is being transmitted or received.

Off No device is linked to the corresponding port.

Console (RJ-45) Port

Designed to connect with the serial port of a computer or terminal for monitoring and configuring

the switch.

Console (USB) Port

Designed to connect with the USB port of a computer for monitoring and configuring the switch.

The switch has an RJ-45 console port and a micro-USB console port available. Console input is

active on only one console port at a time. By default, the micro-USB connector takes precedence

over the RJ-45 connector.

10/100/1000Mbps RJ45 Port

Designed to connect to the device with a bandwidth of 10Mbps, 100Mbps or 1000Mbps. Each

10/100/1000Mbps RJ45 port has a corresponding 1000Mbps LED and Link/Act LED.

SFP Port

Designed to install the SFP module. T2600G-28TS features 4 individual SFP ports and supports

1000M SFP module connection only.

JetStream Gigabit L2 Managed Switch

03Introduction

The front panel of The T2600G-52TS is shown as the following figure.

Figure 1-3 Front Panel of T2600G-52TS

ConsoleConsole(USB)

10/100/1000Mbps

RJ45 Port

LEDs

Console

(USB)

Console

(RJ45)

SFP Port

Console (USB) Port

Designed to connect with the USB port of a computer for monitoring and configuring the switch.

The switch has an RJ-45 console port and a micro-USB console port available. Console input is

active on only one console port at a time. By default, the micro-USB connector takes precedence

over the RJ-45 connector.

Console (RJ-45) Port

Designed to connect with the serial port of a computer or terminal for monitoring and configuring

the switch.

LEDs

LED Status Indication

PWR

On The switch is powered on.

Off The switch is powered off or power supply is abnormal.

Flashing Power supply is abnormal.

SYS Flashing The switch works properly.

On/Off The switch works improperly.

10/100/

1000Mbps

(Port 1-48)

Green

On A 1000Mbps device is linked to the corresponding port, but no

activity.

Flashing A 1000Mbps device is linked to the corresponding port and

data is being transmitted or received.

Yellow

On A 10/100Mbps device is linked to the corresponding port, but

no activity.

Flashing A 10/100Mbps device is linked to the corresponding port and

data is being transmitted or received.

Off No device is linked to the corresponding SFP port but no

activity.

Link/Act

(Port 49-52)

There is a device linked to the corresponding port.

Flashing

The corresponding SFP port is transmitting or receiving data.

Off There is no device linked to the corresponding SFP port.

10/100/1000Mbps RJ45 Port

Designed to connect to the device with a bandwidth of 10Mbps, 100Mbps or 1000Mbps. Each

10/100/1000Mbps RJ45 port has a corresponding 1000Mbps LED.

JetStream Gigabit L2 Managed Switch

04 Introduction

SFP Port

Designed to install the SFP module. T2600G-52TS features 4 individual SFP ports and supports

1000M SFP module connection only.

The front panel of The T2600G-28MPS is shown as the following figure.

Figure 1-4 Front Panel of T2600G-28MPS

10/100/1000Mbps

RJ45 Port

LEDs Console

(USB)

Console

(RJ45)

SFP Port

T2600G-28MPS has an LED mode switch button which is for switching the LED status indication.

When the Speed LED is on, the port LED is indicating the data transmission rate. When the PoE LED

is on, the port LED is indicating the power supply status. By default the Speed LED is on. Pressing

the mode switch button, the Speed LED will turn off and the PoE LED will light up. Then the PoE LED

will turn off after being on for 60 seconds and the Speed LED will light up again.

When the Speed LED is on, the port LED is indicating the data transmission status.

LEDs

LED Status Indication

PWR

On The switch is powered on.

Off The switch is powered off or power supply is abnormal.

Flashing Power supply is abnormal.

SYS Flashing The switch works properly.

On/Off The switch works improperly.

FAN

Green All the fans work properly.

Yellow Not all the fans work properly.

Off The switch works improperly.

Speed or

PoE (Port

1-24）

Green

On A 1000Mbps device is linked to the corresponding port, but no activity.

Flashing A 1000Mbps device is linked to the corresponding port and data is

being transmitted or received.

Yellow

On A 10/100Mbps device is linked to the corresponding port, but no

activity.

Flashing A 10/100Mbps device is linked to the corresponding port and data is

being transmitted or received.

Off No device is linked to the corresponding SFP port but no activity.

1000Base-X

(Port 25-28)

There is a device linked to the corresponding port.

Flashing

The corresponding SFP port is transmitting or receiving data.

Off There is no device linked to the corresponding SFP port.

When the PoE LED is on, the port LED is indicating the power supply status.

JetStream Gigabit L2 Managed Switch

05Introduction

LEDs

LED Status Indication

PWR

On The switch is powered on.

Off The switch is powered off or power supply is abnormal.

Flashing Power supply is abnormal.

SYS Flashing The switch works properly.

On/Off The switch works improperly.

PoE Max

On The remaining PoE power≤7W.

Flashing The remaining PoE power keeps≤7W after this LED is on for 2

minutes.

Off The remaining PoE power＞7W.

FAN

Green All the fans work properly.

Yellow Not all the fans work properly.

Off The switch works improperly.

Speed or

PoE (Port

1-24）

Green On The port is supplying power normally.

Flashing The supply power exceeds the correponding port's maximum power.

Yellow On Overload or short circuit is detected.

Flashing Power-on self-test has failed.

Off Not providing PoE power on the port.

1000Base-X

(Port 25-28)

There is a device linked to the corresponding port.

Flashing

The corresponding SFP port is transmitting or receiving data.

Off There is no device linked to the corresponding SFP port.

Console (RJ-45) Port

Designed to connect with the serial port of a computer or terminal for monitoring and configuring

the switch.

Console (USB) Port

Designed to connect with the USB port of a computer for monitoring and configuring the switch.

The switch has an RJ-45 console port and a micro-USB console port available. Console input is

active on only one console port at a time. By default, the micro-USB connector takes precedence

over the RJ-45 connector.

10/100/1000Mbps RJ45 Port

Designed to connect to the device with a bandwidth of 10Mbps, 100Mbps or 1000Mbps. Each

10/100/1000Mbps RJ45 port has a corresponding 1000Mbps LED.

SFP Port

Designed to install the SFP module. T2600G-28MPS features 4 individual SFP ports and

supports 1000M SFP module connection only.

JetStream Gigabit L2 Managed Switch

06 Introduction

Port Feature

Model 10/100/1000Mbps RJ45 Port SFP Port Console Port

T26 0 0G-18TS 16 2 2

T2600G-28TS 24 4 2

T2600G-52TS 48 4 2

T2600G-28MPS 24 4 2

■Rear Panel

The rear panel of the switch is shown as the following figure.

Figure 1-5 Rear Panel

100-240V~50/60Hz 0.5A

Power

Socket

Grounding

Terminal

Kensington

Security slot

Kensington Security Slot

Secure the lock (not provided) into the security slot to prevent the device from being stolen.

Grounding Terminal

The switch already comes with lightning protection mechanism. You can also ground the switch

through the PE (Protecting Earth) cable of AC cord or with Ground Cable. For detailed information,

please refer to Chapter 3 Lightning Protection.

Power Socket

Connect the female connector of the power cord here, and the male connector to the AC power

outlet. Please make sure the voltage of the power supply meets the requirement of the input

voltage (100-240V~ 50/60Hz).

Caution:

Please use the provided power cord.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cambiar de TP-Link

TP-Link

TP-Link UH720 Manual de usuario

TP-Link

TP-Link JetStream TL-SG2210P Manual de usuario

TP-Link

TP-Link JetStream TL-SG3424P Manual de usuario

TP-Link

TP-Link JetStream T1500G-10MPS Manual de usuario

TP-Link

TP-Link JetStream T2600G-28TS Manual de usuario

TP-Link

TP-Link TL-SF1008P Manual de usuario

TP-Link

TP-Link TL-SL2210WEB Manual de usuario

TP-Link

TP-Link 24+2/24+2G Manual de usuario

TP-Link

TP-Link JetStream TL-SG2008 Manual de usuario

TP-Link

TP-Link KS205 Manual de usuario

TP-Link

TP-Link T3700G-28TQ Manual de usuario

TP-Link

TP-Link JetStream L2 Lite TL-SG3210 Manual de instrucciones

TP-Link

TP-Link TL-SF1016D Manual de usuario

TP-Link

TP-Link TL-SF1008D Manual de usuario

TP-Link

TP-Link TL-SL2428 Manual de usuario

TP-Link

TP-Link T1600-28TS Manual de instrucciones

TP-Link

TP-Link T1600G Series Manual de usuario

TP-Link

TP-Link TL-SG5426 - Manual de usuario

TP-Link

TP-Link JetStream L2 Lite TL-SG3210 Manual de usuario

TP-Link

TP-Link KS205 Manual de usuario

TP-Link

TP-Link TL-SG2424P Manual de usuario

TP-Link

TP-Link JetStream T1500G-10PS Manual de usuario

TP-Link

TP-Link Omada DS1018GMP Manual de usuario

TP-Link

TP-Link TL-SG108E Manual de usuario

Manuales populares de Cambiar de otras marcas

URC

URC Total Control MFS-8 Manual de usuario

Azbil

Azbil HPQ-D11 Manual de usuario

Sony

Sony DFS-900M Manual de usuario

SICK

SICK i17S Manual de usuario

F&F

F&F SZR-277 Manual de usuario

Shure

Shure UAMS/BK Manual de usuario

Dräger

Dräger X-zone Switch Off Manual de usuario

Asco

Asco Joucomatic 349 Series Manual de usuario

BT Mini Hub Manual de usuario

D-Link

D-Link DES-1226G Manual de usuario

Johnson Controls

Johnson Controls FS80-C Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manual de usuario

MicroNet

MicroNet SP1200A Manual de usuario

Ruijie

Ruijie RG-PF2920 Series Manual de instalación y funcionamiento

Altinex

Altinex DA1914SX Manual de usuario

MiLAN

MiLAN MIL-SM2401M Manual de usuario

RJM

RJM MASTERMIND PBC/6X Manual de usuario

Atlas

Atlas MMK-KVM8 Manual de usuario
