TP-Link JetStream L2 Manual de usuario

Installation Guide

L2 Managed Switch

T2500-28TC (TL-SL5428E)

Business Networking Solution

Downloaded from ManualsNet.com search engine

Specifications are subject to change without notice. is a registered trademark of TP-LINK

TECHNOLOGIES CO., LTD. Other brands and product names are trademarks of their respective holders.

No part of the specifications may be reproduced in any form or by any means or used to make any derivative such

as translation, transformation, or adaptation without permission from TP-LINK TECHNOLOGIES CO., LTD. Copyright

http://www.tp-link.com

FCC STATEMENT

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part

15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when

the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio

frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful

interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct the interference at his own expense.

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:

1) This device may not cause harmful interference.

2) This device must accept any interference received, including interference that may cause undesired operation.

Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s

authority to operate the equipment.

CE Mark Warning

This is a class A product. In a domestic environment, this product may cause radio interference, in which case the

user may be required to take adequate measures.

Industry Canada Statement

CAN ICES-3 (A)/NMB-3(A)

Downloaded from ManualsNet.com search engine

Related Document

The User Guide and CLI Reference Guide of the product are provided on the resource

CD.

To obtain the latest product information, please visit the Official Website:

http://www.tp-link.com

About this Installation Guide

This Installation Guide describes the hardware characteristics, installation methods and

the points that should be attended to during installation.

This Installation Guide is structured as follows:

Chapter 1 Introduction. This chapter describes the External Components of the

switch.

Chapter 2 Installation. This chapter illustrates how to install the switch.

Chapter 3 Lightning Protection. This chapter illustrates how to prevent lightning

damage.

Chapter 4 Connection. This chapter illustrates how to do the physical connection of

the switch.

Chapter 5 Configuration. This chapter instructs you to configure the switch via Web

Interface and CLI commands.

Appendix A Troubleshooting.

Appendix B Hardware Specifications.

Downloaded from ManualsNet.com search engine

III

Audience

This Installation Guide is for:

Network Engineer

Network Administrator

Conventions

This guide uses the specific formats to highlight special messages. The following table

lists the notice icons that are used throughout this guide.

Remind to be careful. A caution indicates a potential which may

result in device damage.

Remind to take notice. The note contains the helpful

information for a better use of the product.

Audience

Downloaded from ManualsNet.com search engine

Contents

Chapter 1 Introduction ———————————— 01

1.1 Product Overview.........................................01

1.2 Appearance .................................................01

Chapter 2 Installation ————————————— 04

2.1 Package Contents.........................................04

2.2 Safety Precautions........................................04

2.3 Installation Tools ..........................................06

2.4 Product Installation ......................................06

Chapter 3 Lightning Protection ———————— 08

3.1 Cabling Reasonably ......................................08

3.2 Connect to Ground .......................................10

3.3 Equipotential Bonding...................................11

3.4 Use Lightning Arrester ..................................12

Chapter 4 Connection ————————————— 13

4.1 Ethernet Port ...............................................13

4.2 SFP Port ......................................................13

4.3 Console Port ................................................13

4.4 Verify Installation .........................................14

4.5 Power On ..................................................14

4.6 Initialization.................................................15

Chapter 5 Conguration———————————— 16

5.1 Congure the Switch via GUI ........................16

5.2 Congure the Switch Using CLI .....................17

Appendix A Troubleshooting—————————— 21

Appendix B Hardware Specications —————— 22

Downloaded from ManualsNet.com search engine

L2 Managed Switch

Chapter 1 Introduction

1.1 Product Overview

TP-LINK JetStream L2 Managed Switch, designed for workgroups and departments,

provides wire-speed performance and abundant layer 2 management features. It

provides a variety of service features and multiple powerful functions with high security.

The EIA-standardized framework and smart configuration capacity can provide flexible

solutions for a variable scale of networks. ACL, 802.1x and Dynamic ARP Inspection

provide robust security strategies. QoS and IGMP snooping/filtering optimize voice and

video application. Link aggregation (LACP) increases aggregated bandwidth, optimizing

the transport of business critical data. SNMP, RMON, WEB/CLI/Telnet Log-in bring

abundant management policies. TP-LINK JetStream L2 Managed Switch integrates

multiple functions with excellent performance, and is friendly to manage, which can

fully meet the need of the users demanding higher networking performance.

1.2 Appearance

■Front Panel

The front panel of T2500-28TC is shown as the following figure.

T2500-28TC

LEDs

10/100Mbps RJ45 Port

SFP Port

10/100/1000Mbps RJ45 Port

Console Port

Figure 1-1 Front Panel of T2500-28TC

LEDs

LED Status Indication

Power

On The switch is powered on

Off The switch is powered off or power supply is abnormal

Flashing Power supply is abnormal

System Flashing The switch works properly

On/Off The switch works improperly

10/100M

On Green A 100Mbps device is connected to the corresponding port

Yellow A 10Mbps device is connected to the corresponding port

Flashing Data is being transmitted or received

Off No device is connected to the corresponding port

1000M

On Green A 1000Mbps device is connected to the corresponding port

Yellow A 10/100Mbps device is connected to the corresponding port

Flashing Data is being transmitted or received

Off No device is connected to the corresponding port

Introduction

Downloaded from ManualsNet.com search engine

L2 Managed Switch

Note: The port 25–28 of the switch are “Combo”ports. A “Combo”port consists of a

RJ45 port and an SFP port, and the two ports share the same LED.

Port Feature

Model Console Port 10/100Mbps

RJ45 Port

10/100/1000Mbps

RJ45 Port SFP Port

T2500-28TC 124 4 4

Console Port

Designed to connect with the serial port of a computer or terminal for monitoring

and configuring the switch.

10/100Mbps Port

Designed to connect to the device with a bandwidth of 10Mbps or 100Mbps. Each

has a corresponding 10/100M LED.

10/100/1000Mbps Port

Designed to connect to the device with a bandwidth of 10Mbps, 100Mbps or

1000Mbps. Each has a corresponding 1000M LED.

SFP Port

Designed to install the SFP module. The switch features some SFP transceiver

slots that are shared with the associated RJ45 ports. The associated two ports are

referred as a “Combo”port, which means they cannot be used simultaneously,

otherwise only SFP port works.

■Rear Panel

The rear panel of T2500-28TC is shown as the following figure.

Figure 1-2 Rear Panel of T2500-28TC

Grounding Terminal

The switch already comes with lightning protection mechanism. You can also ground

the switch through the PE (Protecting Earth) cable of AC cord or with Ground Cable.

For detailed information, please refer to Chapter 3 Lightning Protection.

Introduction

Grounding Terminal

Power Socket

Downloaded from ManualsNet.com search engine

L2 Managed Switch

Power Socket

Connect the female connector of the power cord here, and the male connector to

the AC power outlet. Please make sure the voltage of the power supply meets the

requirement of the input voltage (100-240V~ 50/60Hz).

Caution: Please use the provided power cord.

Introduction

Downloaded from ManualsNet.com search engine

L2 Managed Switch

Chapter 2 Installation

2.1 Package Contents

Make sure that the package contains the following items. If any of the listed items is

damaged or missing, please contact your distributor.

One Resource CD

One Switch One Power Cord and one

Console Cable

This Installation Guide

Two mounting brackets and

the ttings

T2500-28TC (TL-SL5428E)

2.2 Safety Precautions

To avoid any device damage and bodily injury caused by improper use, please observe

the following rules.

■Safety Precautions

■Keep the power off during the installation.

■Wear an ESD-preventive wrist strap, and make sure that the wrist strap has a good

skin contact and is well grounded.

■Use only the power cord provided with the switch.

■Make sure that the supply voltage matches the specifications indicated on the rear

panel of the switch.

■Ensure the vent hole is well ventilated and unblocked.

■Do not open or remove the cover of the switch.

■Before cleaning the device, cut off the power supply. Do not clean it by the waterish

cloth, and never use any other liquid cleaning method.

■Site Requirements

To ensure normal operation and long service life of the device, please install it in an

environment that meets the requirements described in the following subsection.

Temperature/Humidity



ȭ

T2500-28TC

Installation

Downloaded from ManualsNet.com search engine

L2 Managed Switch

Please keep a proper temperature and humidity in the equipment room. Too high/low

humidity may lead to bad insulation, electricity leakage, mechanical property changes

and corrosions. Too high temperature may accelerate aging of the insulation materials

and can thus significantly shorten the service life of the device. For normal temperature

and humidity of the device, please check the following table.

Environment Temperature Humidity

Operating 0℃~ 40℃10% ~ 90%RH Non-condensing

Storage -40℃~ 70℃5% ~ 90%RH Non-condensing

Clearness

T2500-28TC

The dust accumulated on the switch can be absorbed by static electricity and result

in poor contact of metal contact points. Some measures have been taken for the

device to prevent static electricity, but too strong static electricity can cause deadly

damage to the electronic elements on the internal circuit board. To avoid the effect of

static electricity on the operation of the switch, please attach much importance to the

following items:

■Dust the device regularly, and keep the indoor air clean.

■Keep the device well grounded and ensure static electricity has been transferred.

Electromagnetic Interference

T2500-28TC

Electronic elements including capacitance and inductance on the device can be affected

by external interferences, such as conducted emission by capacitance coupling,

inductance coupling, and impedance coupling. To decrease the interferences, please

make sure to take the following measures:

■Use the power supply that can effectively filter interference from the power grid.

■Keep the device far from high-frequency, strong-current devices, such as radio

transmitting station.

■Use electromagnetic shielding when necessary.

Lightening Protection

T2500-28TC

Extremely high voltage currents can be produced instantly when lightning occurs and

the air in the electric discharge path can be instantly heated up to 20,000℃. As this

Installation

Downloaded from ManualsNet.com search engine

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cambiar de TP-Link

TP-Link

TP-Link Tapo H100 Manual de usuario

TP-Link

TP-Link TL-SG1024 Manual de usuario

TP-Link

TP-Link TL-SG108PE Manual de usuario

TP-Link

TP-Link JetStream TL-SL3452 Manual de usuario

TP-Link

TP-Link tapo S505 Manual de usuario

TP-Link

TP-Link TL-SG3210 Manual de instrucciones

TP-Link

TP-Link Jetstream Series Manual de usuario

TP-Link

TP-Link POE150S Manual de usuario

TP-Link

TP-Link TL-SG2216 Manual de usuario

TP-Link

TP-Link JetStream TL-SG5412F Manual de usuario

TP-Link

TP-Link TL-SG1016PE Manual de usuario

TP-Link

TP-Link TL-SG1008 Manual de usuario

TP-Link

TP-Link TL-SF1005D Manual de usuario

TP-Link

TP-Link TL-SG108PE Manual de usuario

TP-Link

TP-Link JetStream TL-SG2008 Manual de usuario

TP-Link

TP-Link TL-SG2424 Manual de usuario

TP-Link

TP-Link TL-SL5428E Manual de usuario

TP-Link

TP-Link JetStream T2600G-28TS Manual de usuario

TP-Link

TP-Link HS200 Manual de usuario

TP-Link

TP-Link T1700X-16TS Manual de usuario

TP-Link

TP-Link TL-SG2424P Manual de usuario

TP-Link

TP-Link TL-SG1008P Manual de usuario

TP-Link

TP-Link T1700G-28TQ Manual de usuario

TP-Link

TP-Link JetStream TL-SL3428 Manual de usuario

Manuales populares de Cambiar de otras marcas

URC

URC Total Control MFS-8 Manual de usuario

Azbil

Azbil HPQ-D11 Manual de usuario

Sony

Sony DFS-900M Manual de usuario

SICK

SICK i17S Manual de usuario

F&F

F&F SZR-277 Manual de usuario

Shure

Shure UAMS/BK Manual de usuario

Dräger

Dräger X-zone Switch Off Manual de usuario

Asco

Asco Joucomatic 349 Series Manual de usuario

BT Mini Hub Manual de usuario

D-Link

D-Link DES-1226G Manual de usuario

Johnson Controls

Johnson Controls FS80-C Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manual de usuario

MicroNet

MicroNet SP1200A Manual de usuario

Ruijie

Ruijie RG-PF2920 Series Manual de instalación y funcionamiento

Altinex

Altinex DA1914SX Manual de usuario

MiLAN

MiLAN MIL-SM2401M Manual de usuario

RJM

RJM MASTERMIND PBC/6X Manual de usuario

Atlas

Atlas MMK-KVM8 Manual de usuario
