TP-Link TD-8840 Manual de usuario

Specifications are subject to change without notice. is a registered

trademark of TP-LINK Technologies Co., Ltd. Other brands and product names are

trademarks or registered trademarks of their respective holders.

No part of the specifications may be reproduced in any form or by any means or used to

make any derivative such as translation, transformation, or adaptation without permission

FCC STATEMENT

This equipment has been tested and found to comply with the limits for a class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation.

This equipment generates, uses and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions, may cause harmful interference to

radio communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help.

CE Mark Warning

This is a Class B product. In a domestic environment, this product may cause radio

interference, in which case the user may be required to take adequate measures.

EC DECLARATION OF CONFORMITY (EUROPE)

In compliance with the EMC Directive 89/336/EEC, Low Voltage Directive 73/23/EEC, this

product meets the requirements of the following standards:

• EN55022

• EN55024

• EN60950

SAFETY NOTICES

Caution: Do not use this product near water, for example, in a wet basement or near a

swimming pool.

Avoid using this product during an electrical storm. There may be a remote risk

of electric shock from lightning.

Package contents.............................................................................................................. 2

Chapter 1: Product Overview............................................................................................ 3

1.1 Product main specification................................................................................... 3

1.2 Supporting protocol.............................................................................................. 3

1.3 Transmit data-rate................................................................................................ 4

1.4 ATM property........................................................................................................ 4

1.5 System support.................................................................................................... 4

1.6 Working environment........................................................................................... 4

1.7 Electric parameter................................................................................................ 4

Chapter 2: Hardware Installation Guide............................................................................ 5

2.1 System requirement............................................................................................. 5

2.2 LED explanation................................................................................................... 5

2.3 Rear-panel........................................................................................................... 5

2.4 Hardware installation procedures（figure2-1）................................................... 6

Chapter 3: System Configuration...................................................................................... 7

3.1 Computer Configuration....................................................................................... 7

3.2 Login.................................................................................................................... 8

3.3 Web Setup......................................................................................................... 10

3.4 Software Dial...................................................................................................... 19

Chapter 4: Advantage management setup...................................................................... 20

Chapter 5: FQA............................................................................................................... 21

Appendix A: Default Configuration .................................................................................. 22

Appendix B: Contact Information..................................................................................... 23

TD-8840 External ADSL2+ Router User Guide

Package contents

The following contents should be found in your box:

¾One TD-8840 External ADSL2+ ROUTER

¾One AC power Adapter for TD-8840 External ADSL2+ ROUTER

¾One Resource CD for TD-8840 External ADSL2+ ROUTER, including:

•This Guide

•Other Helpful Information

•Quick installation Guide Program

¾Quick installation Guide

¾One RJ45 cable

¾Two RJ11 cable

¾One ADSL splitter

Note: If any of the above items are damaged or missing, please contact the retailer from

whom you purchased the TD-8840 External ADSL2+ ROUTER for assistance.

- 2 -

TD-8840 External ADSL2+ Router User Guide

Chapter 1: Product Overview

TP-LINK® TD-8840 External ADSL2+ ROUTER is the latest product designed and

manufactured by TP-LINK Technologies Co., Ltd. With TP-LINK’s excellent circuit design

and high quality production, we guarantee the ADSL2+ ROUTER’s high performance,

great stability and easy to use.

The TD-8840 uses integrated ADSL2+ transceiver and a 256-MHz MIPS32 CPU. The

AFE supports full-rate ADSL connectivity conforming to the ITU and ANSI specifications;

MIPS32 CPU with MMU and 16-KB I-cache/8-KB D-cache is integrated into the device.

In addition to the basic DMT physical layer functions, the ADSL PHY supports dual latency

ADSL framing (fast and interleaved) and the I.432 ATM Physical Layer.

The TD-8840 is a complete plug-and-play solution. With standard Ethernet interface, it

can be directly connected to any 10M/100M Ethernet devices, support Auto-MDIX.

The TD-8840 not only uses html (web mode through Ethernet port) to configure the

ROUTER but also uses external utility software. You can download it from our website

(http://www.tp-link.com).

1.1 Product main specification

¾Adopt the high performance IC which integrate the AFE transceiver and the 256

MHZ MIPS32 CPU, guarantee that this product is efficient and steady.

¾High speed and asymmetry data transmit mode, built-in 4-port switch realize

multi-user to share wide-band internet access

¾Support All ADSL2+ industrial standards

¾Compatible with all mainstream DSLAM (CO)

¾Firmware upgradeable

¾Provide integrated access of internet and route function which face to SOHO user

¾Advanced DMT modulation and demodulation

¾Real-time Configuration and device monitoring

¾Quick response semi-conductive surge protect circuit, provides reliable ESD and

surge-protect function

1.2 Supporting protocol

- G.992.1 (G.dmt) - Annex A/B/C

- G.992.2 (G.lite) - Annex A/B/C

- ANSI T1.413

- G.992.3 (ADSL2) - Annex A/B/C/M and Annex L (RE-DSL) compliant

- G.992.5 (ADSL2+) Annex A/B/C and Annex L (RE-DSL) compliant

- ADSL dual latency (fast path and interleaved path)

- I.432 ATM physical layer compliant

- 3 -

TD-8840 External ADSL2+ Router User Guide

- Supports RFC2364 (PPPoA)

- Supports RFC2516 (PPPoE)

- Supports RFC1483 (EoA)(Bridged *and Router)

- Supports RFC1577 (IPoA)

NOTE. “*” Needs the third-party software.

1.3 Transmit data-rate

¾Max download data-rate: 24Mbps

¾Max upload data-rate: 1Mbps

¾Max line length: 6Km

1.4 ATM property

¾AAL0, AAL5, OAM, RM, and raw cell types supported

¾Direct hardware support for 4 Receive VCs, with additional RX VCs and TX VCs

supported in software

¾Full 24-bit Virtual Path Identifier (VPI) and Virtual Circuit Identifier (VCI)

1.5 System support

¾Support PVC

¾Support NAT、DHCP and so on

¾Support IEEE 802.3、IEEE 802.3u

¾Support 10Base-T/100BASE-TX full-duplex or half duplex Ethernet

¾Support Auto-MDIX

1.6 Working environment

¾Operating temperature: 0 ~40℃℃

¾Storage temperature: -40 ~70℃℃

¾Humidity: 10%~90% (non-condensing)

1.7 Electric parameter

¾Adaptor power Output: 9VAC/0.8A，50Hz or 60 Hz

¾Power consumption: 6W Maximum

- 4 -

TD-8840 External ADSL2+ Router User Guide

Chapter 2: Hardware Installation Guide

The TD-8840 maintains five separate interfaces, four Ethernet and one ADSL interface.

The Router should not be located where it will be exposed to moisture or excessive heat.

Place the Router in a location where it can be safely connected to the various devices as

well as to a power source.

2.1 System requirement

Confirm your computer has been installed with networking interface card (NIC) before

connecting ADSL2+ ROUTER to your computer, with operating system supporting the

TCP/IP protocol.

2.2 LED explanation

The front panel of ADSL2+ ROUTER includes one power indicator (RED) and seven

function indicators (GREEN), as explained in chart 1-1:

Indicator Description Status Function Details

PWR Power On

Off Power OK

Power fail

ADSL ADSL status

Slow flash

Quick flash

Self-detecting when power up

Connecting to the telecom network

Connection to telecom network OK

ALARM Mistake On

Off

There is mistake when ADSL transmitting data or

receiving data

ADSL normal

ACT Data On

Off

There is data transmitting or receiving on WAN

port

No data transmitting or receiving on WAN port

LAN

1~4 Ethernet On

Off

Flash

1~4(LAN) port normal

Connection on 1~4(LAN) port abnormal

Data transmitting or receiving on 1~4(LAN) port

Chart 1-1

2.3 Rear-panel

¾ON/OFF: Turn on/off the ADSL2+ ROUTER’s power.

¾Power (9VAC/0.8A input): please do not use any unknown power adaptor,

otherwise your ADSL2+ ROUTER may be damaged.

¾RESET(reset default): First press the reset button of ROUTER, then turn on the

ROUTER’s power for at least three seconds. It will resume the default

- 5 -

TD-8840 External ADSL2+ Router User Guide

manufacturer’s setup.

¾1~4(LAN): Connect with your computer’s NIC.

¾LINE(WAN): Connect to the MODEM Port of Splitter or Connecting the telephone

line.

2.4 Hardware installation procedures（figure2-1）

The procedure to install the Router can be described in general terms in the

following steps:

First Step: Connecting the MODEM port of Splitter with the TD-8840 ADSL2+ ROUTER

LINE port by telephone line. While you need to use a telephone, please attach telephone

line into the phone of Splitter.

Second Step: Connect category 5 cable with RJ45 jacks to theADSL2+ ROUTER’s

LAN port and your computer’s NIC.

Third Step: Plug one end of theAC Power Adapter into the Power jack on the Ethernet

ADSL2+ ROUTER and the other end to a standard electrical outlet.

Last Step: Check the line connection to see if everything is ready. Power up finally.

（Figure2-1）

- 6 -

TD-8840 External ADSL2+ Router User Guide

Chapter 3: System Configuration

3.1 Computer Configuration

1. Connect the cable according to Chapter 2, turn on the power.

2. Change the IP address of your PC（Figure 3-1）: Open TCP/IP Properties of the LAN

card in your PC, enter the IP address as 192.168.1.* (* is any value between 2 to

254, Net mask is 255.255.255.0, Gateway is 192.168.1.1, DNS address is the value

provided by ISP).

Figure 3-1

Please note:

Users of Windows 98 can open TCP/IP Properties according to the following: Right-click

(Mouse) Network Neighbor -> Choose Properties -> Double-click TCP/IP PCI Fast

Ethernet Adapter.

- 7 -

TD-8840 External ADSL2+ Router User Guide

The users of Windows 2000/NT/XP can do the following: Right-click Network Neighbor

-> Choose Properties -> Right-click Local Connection -> Choose Properties ->

Double-click Internet Protocol (TCP/IP).

NOTE: The words in fact may be different with this guide.

Remarks: you can check whether your configuration is successful through PING

command. Enter Ping 192.168.1.1

If the screen looks like the following, you have been successful.

Pinging 192.168.1.1 with 32 bytes of data:

Reply from 192.168.1.1: bytes=32 time<10ms TTL-128

…

If the screen looks like the following, the connection has failed. Please try again.

Pinging 192.168.1.1 with 32 bytes of data:

Request timed out.

3.2 Login

Startup Internet Explorer, and enter 192.168.1.1;then enter default user name(admin)、

password(admin), When ADSL2+ connection is OK, you will see the Figure 3-2.

Figure 3-2

- 8 -

Otros manuales para TD-8840

Tabla de contenidos

Otros manuales de Enrutador de red de TP-Link

TP-Link

TP-Link EC120-F5 Manual de usuario

TP-Link

TP-Link TD-W8961NB Manual de usuario

TP-Link

TP-Link TL-PA8030P Manual de usuario

TP-Link

TP-Link Archer C20 Manual de usuario

TP-Link

TP-Link AC750 Archer C2 Manual de usuario

TP-Link

TP-Link TL-WR850N Manual de usuario

TP-Link

TP-Link Archer C90 Manual de usuario

TP-Link

TP-Link TD-W8910G Manual de usuario

TP-Link

TP-Link TL-R470T+ Manual de usuario

TP-Link

TP-Link TD-W8951NB Manual de usuario

TP-Link

TP-Link TD-VG5612 Manual de usuario

TP-Link

TP-Link Archer D9 Manual de usuario

TP-Link

TP-Link TL-MR6400 Manual de usuario

TP-Link

TP-Link TL-WA820RE Manual de usuario

TP-Link

TP-Link TD-8810 Manual de usuario

TP-Link

TP-Link WR740N Guía de configuración

TP-Link

TP-Link EC231-G1u Manual de usuario

TP-Link

TP-Link Deco Wi-Fi 6 Manual de usuario

TP-Link

TP-Link Archer AXE75 Manual de usuario

TP-Link

TP-Link TL-WA850RE Manual de usuario

TP-Link

TP-Link TL-WR841HP Manual de usuario

TP-Link

TP-Link TL-WR841N Manual de usuario

TP-Link

TP-Link TL- WR740N Manual de usuario

TP-Link

TP-Link Archer A20 Manual de usuario

Manuales populares de Enrutador de red de otras marcas

Allnet

Allnet ALL0333AU Manual de usuario

HomeSeer

HomeSeer HT-SEL Manual de usuario

Sercomm

Sercomm Genesis OC3505D Manual de usuario

Billion

Billion BIPAC 5102 Series Manual de usuario

Motorola

Motorola MR1900 Manual de usuario

Digi

Digi IX14 Manual de usuario

Cisco

Cisco NCS 540 Manual

XAVi

XAVi X8821e Manual de usuario

BEC

BEC 6200WZL Manual de usuario

MikroTik

MikroTik hAP ac3 Series Manual de usuario

Korenix

Korenix JetNet 5428G Series Manual de usuario

NETGEAR

NETGEAR FS526T - Switch Manual de usuario

Korenix

Korenix JetNet 5710G Series Manual de usuario

Automated Logic

Automated Logic ZN551 Manual del propietario

Cisco

Cisco ASR 1000 Series Manual del operador

EnGenius

EnGenius ESR-9710 Manual de usuario

Cisco

Cisco 805 Series Instrucciones de funcionamiento y seguridad

LevelOne

LevelOne FBR-1416 Manual de usuario
