Installation Guide

L2 Managed Switch

TL-SG3210/TL-SG3216/TL-SG3424/TL-SG3424P

Business Networking Solution

Specifications are subject to change without notice. is a registered trademark of TP-LINK

TECHNOLOGIES CO., LTD. Other brands and product names are trademarks of their respective holders.

No part of the specifications may be reproduced in any form or by any means or used to make any derivative such

as translation, transformation, or adaptation without permission from TP-LINK TECHNOLOGIES CO., LTD. Copyright

http://www.tp-link.com

FCC STATEMENT

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part

15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when

the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio

frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful

interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct the interference at his own expense.

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:

1) This device may not cause harmful interference.

2) This device must accept any interference received, including interference that may cause undesired operation.

Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s

authority to operate the equipment.

CE Mark Warning

This is a Class A product. In a domestic environment, this product may cause radio interference, in which case the

user may be required to take adequate measures.

Related Document

The User Guide and CLI Reference Guide of the product are provided on the resource CD.

To obtain the latest product information, please visit the official website:

http://www.tp-link.com

About this Installation Guide

This Installation Guide describes the hardware characteristics, installation methods and

the points that should be attended to during installation.

This Installation Guide is structured as follows:

Chapter 1 Introduction.

This chapter describes the external components of the switch.

Chapter 2 Installation. This chapter illustrates how to install the switch.

Chapter 3

Lightning Protection. This chapter illustrates how to prevent lightning damage.

Chapter 4 Connection. This chapter illustrates how to do the physical connection of

the switch.

Chapter 5 Configuration. This chapter instructs you to configure the switch via Web

Interface and CLI commands.

Appendix A Troubleshooting.

Appendix B Hardware Specifications.

Appendix C Technical Support.

Audience

This Installation Guide is for:

Network Engineer

Network Administrator

Conventions

Due to the similarity in structure of TP-LINK JetStream L2 Managed Switch series,

in this Installation Guide we take TL-SG3216 as an example to illustrate Chapter 2

Installation, Chapter 3 Lighting Protection and Chapter 4 Connection.

This guide uses the specific formats to highlight special messages. The following table

lists the notice icons that are used throughout this guide.

Remind to be careful. A caution indicates a potential which may

result in device damage.

Remind to take notice. The note contains the helpful

information for a better use of the product.

III

Contents

Chapter 1 Introduction ———————————— 01

1.1 Product Overview.........................................01

1.2 Appearance .................................................01

Chapter 2 Installation ————————————— 06

2.1 Package Contents.........................................06

2.2 Safety Precautions........................................06

2.3 Installation Tools ..........................................08

2.4 Product Installation ......................................08

Chapter 3 Lightning Protection ———————— 10

3.1 Cabling Reasonably ......................................10

3.2 Connect to Ground .......................................12

3.3 Equipotential Bonding...................................13

3.4 Use Lightning Arrester ..................................14

Chapter 4 Connection ————————————— 15

4.1 Ethernet Port ...............................................15

4.2 SFP Port ......................................................15

4.3 Console Port ................................................16

4.4 Verify Installation .........................................16

4.5 Power On ..................................................16

4.6 Initialization.................................................17

Chapter 5 Conguration———————————— 18

5.1 Congure the Switch via GUI ........................18

5.2 Congure the Switch Using CLI .....................19

Appendix A Troubleshooting—————————— 24

Appendix B Hardware Specications —————— 25

Appendix C Technical Support ————————— 26

L2 Managed Switch

Chapter 1 Introduction

1.1 Product Overview

TP-LINK JetStream L2 Managed Switch, designed for workgroups and departments,

provides wire-speed performance and abundant layer 2 management features. It

provides a variety of service features and multiple powerful functions with high security.

The EIA-standardized framework and smart configuration capacity can provide flexible

solutions for a variable scale of networks. ACL, 802.1x and Dynamic ARP Inspection

provide robust security strategies. QoS and IGMP snooping/filtering optimize voice and

video application. Link aggregation (LACP) increases aggregated bandwidth, optimizing

the transport of business critical data. SNMP, RMON, WEB/CLI/Telnet Log-in bring

abundant management policies. TP-LINK JetStream L2 Managed Switch integrates

multiple functions with excellent performance, and is friendly to manage, which can

fully meet the need of the users demanding higher networking performance.

TL-SG3424P Managed PoE Switch is also a Power Sourcing Equipment (PSE*). All

the Auto-Negotiation RJ45 ports on the switch support Power over Ethernet (PoE*)

function, which can automatically detect and supply power with those powered devices

(PDs*) complying with IEEE 802.3af and IEEE 802.3at.

*PSE: a device (switch or hub for instance) that will provide power in a PoE setup.

*PoE: This technology describes a system to transmit electrical power, along with data,

to remote devices over standard twisted-pair cable in an Ethernet.

*PD: a device powered by a PSE and thus consumes energy. Examples include

powering IP telephones, wireless LAN access points, network cameras, network hubs,

embedded computers etc.

1.2 Appearance

■Front Panel

The front panel of TL-SG3210 is shown as the following figure.

LEDs

Console Port

10/100/1000Mbps RJ45 Port

SFP Port

Figure 1-1 Front Panel of TL-SG3210

Introduction

L2 Managed Switch

LEDs

LED Status Indication

PWR

On The switch is powered on.

Off The switch is powered off or power supply is abnormal.

Flashing Power supply is abnormal.

SYS Flashing The switch works properly.

On/Off The switch works improperly.

10/100/1000M

On A device is linked to the corresponding port.

Flashing Data is being transmitted or received.

Green The linked device is running at 1000Mbps.

Yellow The linked device is running at 10/100Mbps.

Off No device is connected to the corresponding port.

1000M

On A device is linked to the corresponding port.

Flashing Data is being transmitted or received.

Off No device is connected to the corresponding port.

The front panel of TL-SG3216 is shown as the following figure.

Console Port

LEDs

10/100/1000Mbps RJ45 Port

SFP Port

Figure 1-2 Front Panel of TL-SG3216

The front panel of TL-SG3424 is shown as the following figure.

21F 23F

Console Port

LEDs

10/100/1000Mbps RJ45 Port

SFP Port

Figure 1-3 Front Panel of TL-SG3424

LEDs

LED Status Indication

Power

On The switch is powered on.

Off The switch is powered off or power supply is abnormal.

Flashing Power supply is abnormal.

System Flashing The switch works properly.

On/Off The switch works improperly.

Introduction

L2 Managed Switch

LED Status Indication

1000Mbps

On A 1000Mbps device is connected to the corresponding port.

Off A 10/100Mbps device or no device is connected to the

corresponding port.

Link/Act

On A device is connected to the corresponding port, but no

activity.

Flashing Data is being transmitted or received.

Off No device is connected to the corresponding port.

The front panel of TL-SG3424P is shown as the following figure.

Console Port

LEDs

10/100/1000Mbps RJ45 Port

SFP Port

Figure 1-4 Front Panel of TL-SG3424P

TL-SG3424P has an LED mode switch button which is for switching the LED

status indication. When the Speed LED is on, the port LED is indicating the data

transmission rate. When the PoE LED is on, the port LED is indicating the power

supply status. By default the Speed LED is on. Pressing the mode switch button, the

Speed LED will turn off and the PoE LED will light up. Then the PoE LED will turn off

after being on for 60 seconds and the Speed LED will light up again.

When the Speed LED is on, the port LED is indicating the data transmission rate.

LED Status Indication

Power

On The switch is powered on.

Off The switch is powered off or power supply is abnormal.

Flashing Power supply is abnormal.

System Flashing The switch works properly.

On/Off The switch works improperly.

10/100/

1000 Mbps

Green On A 1000 Mbps device is connected to the corresponding

port, but no activity.

Flashing Data is being transmitted or received.

Yellow On A 10/100 Mbps device is connected to the corresponding

port, but no activity.

Flashing Data is being transmitted or received.

Off No device is connected to the corresponding port.

When the PoE LED is on, the port LED is indicating the power supply status.

LED Status Indication

Power

On The switch is powered on.

Off The switch is powered off or power supply is abnormal.

Flashing Power supply is abnormal.

System Flashing The switch works properly.

On/Off The switch works improperly.

Introduction

L2 Managed Switch

LED Status Indication

PoE Max

On The remaining PoE power≤7W.

Flashing The remaining PoE power keeps ≤7W after this LED is

on for 2 minutes.

Off The remaining PoE power≥

7W.

10/100/

1000 Mbps

Green

On The port is supplying power normally.

Flashing The supply power exceeds the correponding port's

maximum power.

Yellow On Overload or short circuit is detected.

Flashing Power-on self-test has failed.

Off No PoE power supply is provided on the port.

Note: TL-SG3216/TL-SG3424/TL-SG3424P switch features some “Combo”ports. A

“Combo”port consists of a RJ45 port and a SFP port, and the two ports share the

same LED.

Port Feature

Model 10/100/1000Mbps

RJ45 Port Console Port SFP Port

TL-SG3210 8 1 2

TL-SG3216 16 1 2

T L-S G3 42 4/ T L-S G 3424 P 24 1 4

10/100/1000Mbps Port

Designed to connect to the device with a bandwidth of 10Mbps, 100Mbps or

1000Mbps. Each has a corresponding 1000Mbps LED.

Console Port

Designed to connect with the serial port of a computer or terminal for monitoring

and configuring the switch.

SFP Port

Designed to install the SFP module. TL-SG3216/TL-SG3424/TL-SG3424P switch

features some SFP transceiver slots that are shared with the associated RJ45 ports.

The associated two ports are referred as a “Combo”port, which means they cannot

be used simultaneously, otherwise only SFP port works. TL-SG3210 features two

individual SFP ports.

Note: For TL-SG3216/TL-SG3424/TL-SG3424P, when using the SFP port with a

100M module or a gigabit module, you need log on to the GUI (Graphical User

Interface) of the switch and congure its corresponding Speed and Duplex mode on

Switching→Port→Port Cong page. For 100M module, please select 100MFD while

select 1000MFD for gigabit module. By default, the Speed and Duplex mode of SFP port

is 1000MFD. TL-SG3210 supports 1000M SFP module connection only.

■Rear Panel

The rear panel of TL-SG3210 is shown as the following figure.

Introduction

L2 Managed Switch

Grounding Terminal

Power Socket

Figure 1-5 Rear Panel of TL-SG3210

The rear panel of TL-SG3216/TL-SG3424/TL-SG3424P is shown as the following figure.

Grounding Terminal

Power Socket

Figure 1-6 Rear Panel of TL-SG3216/TL-SG3424/TL-SG3424P

Grounding Terminal

The switch already comes with lightning protection mechanism. You can also ground

the switch through the PE (Protecting Earth) cable of AC cord or with Ground Cable.

For detailed information, please refer to Chapter 3 Lightning Protection.

Power Socket

Connect the female connector of the power cord here, and the male connector to

the AC power outlet. Please make sure the voltage of the power supply meets the

requirement of the input voltage (100-240V~ 50/60Hz).

Caution: Please use the provided power cord.

Introduction

L2 Managed Switch

Chapter 2 Installation

2.1 Package Contents

Make sure that the package contains the following items. If any of the listed items is

damaged or missing, please contact your distributor.

One Resource CD

One Switch One Power Cord, One Console

Cable and one Ground Cable

This Installation Guide

Two mounting brackets and

the ttings

2.2 Safety Precautions

To avoid any device damage and bodily injury caused by improper use, please observe

the following rules.

■Safety Precautions

■Keep the power off during the installation.

■Wear an ESD-preventive wrist strap, and make sure that the wrist strap has a good

skin contact and is well grounded.

■Use only the power cord provided with the switch.

■Make sure that the supply voltage matches the specifications indicated on the rear

panel of the switch.

■Ensure the vent hole is well ventilated and unblocked.

■Do not open or remove the cover of the switch.

■Before cleaning the device, cut off the power supply. Do not clean it by the waterish

cloth, and never use any other liquid cleaning method.

■Site Requirements

To ensure normal operation and long service life of the device, please install it in an

environment that meets the requirements described in the following subsection.

Temperature/Humidity

ȭ

ȭ

Installation

Otros manuales para JetStream L2 Lite TL-SG3210

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Enrutador de red de TP-Link

TP-Link

TP-Link AC2100 Manual de usuario

TP-Link

TP-Link Archer CR700 Manual de usuario

TP-Link

TP-Link Archer AX80 Manual de usuario

TP-Link

TP-Link Deco Manual de usuario

TP-Link

TP-Link RE705X Manual de usuario

TP-Link

TP-Link Archer A9 Manual de usuario

TP-Link

TP-Link TL-WR850N Manual de usuario

TP-Link

TP-Link SafeStream TL-R605 Manual de usuario

TP-Link

TP-Link Deco X50-4G Manual de usuario

TP-Link

TP-Link SafeStream TL-R480T+ Manual de usuario

TP-Link

TP-Link Archer C5200 Manual de usuario

TP-Link

TP-Link TD-W8968 Manual de usuario

TP-Link

TP-Link TL-R4000+ Manual de usuario

TP-Link

TP-Link BetterEnergy Manual de usuario

TP-Link

TP-Link Archer VR26007 Manual de usuario

TP-Link

TP-Link TL-WR902AC Manual de usuario

TP-Link

TP-Link Omada Pro 4G+ Manual de usuario

TP-Link

TP-Link Archer AX95 Manual de usuario

TP-Link

TP-Link SafeStream TL-ER6120 Manual de usuario

TP-Link

TP-Link Archer D2 Manual de usuario

TP-Link

TP-Link Touch P5 Manual de usuario

TP-Link

TP-Link TD-W8961N Manual de usuario

TP-Link

TP-Link TD-8817 Manual de usuario

TP-Link

TP-Link ARCHER MR200 Manual de usuario

Manuales populares de Enrutador de red de otras marcas

Allnet

Allnet ALL0333AU Manual de usuario

HomeSeer

HomeSeer HT-SEL Manual de usuario

Sercomm

Sercomm Genesis OC3505D Manual de usuario

Billion

Billion BIPAC 5102 Series Manual de usuario

Motorola

Motorola MR1900 Manual de usuario

Digi

Digi IX14 Manual de usuario

Cisco

Cisco NCS 540 Manual

XAVi

XAVi X8821e Manual de usuario

BEC

BEC 6200WZL Manual de usuario

MikroTik

MikroTik hAP ac3 Series Manual de usuario

Korenix

Korenix JetNet 5428G Series Manual de usuario

NETGEAR

NETGEAR FS526T - Switch Manual de usuario

Korenix

Korenix JetNet 5710G Series Manual de usuario

Automated Logic

Automated Logic ZN551 Manual del propietario

Cisco

Cisco ASR 1000 Series Manual del operador

EnGenius

EnGenius ESR-9710 Manual de usuario

Cisco

Cisco 805 Series Instrucciones de funcionamiento y seguridad

LevelOne

LevelOne FBR-1416 Manual de usuario
