TP-Link Archer AX53 Manual de usuario
Power On/Off
ResetPower
LAN1WAN
Reset
WPS/Wi-Fi
LAN2 LAN3 LAN4 Power
TP-Link Archer AX53 and AX55
Router
This router can be mounted on a wall or placed on a shelf/desk.
Backpanel
Get to know your router!
Connect power-
adapter here
(12V/1,5A).
USB 2.0 port
(not available on
AX53)
connect USB-devices.
Internet-port
Connect to berconverter/
cablemodem using at least a
1m long ethernetcable.
WPS/Wi-button
Press to activate WPS.
Press and hold for more
than 2 sec to turn wi on/o.
On/o-
button
Turns the
router on/o.
Ethernet-ports
Connect a computer or
other devices to your
router.
Reset-button
Resets router to
default factory
settings.
After a reset, the
router needs to be
re-installed.
TP-Link Archer AX53 and AX55
Troubleshooting
When the router has power and access to internet the lights might look
like the image above. If anthing is connected to the ethernet-ports,
the ETHERNET-light will be on. Same with the USB-light.
Troubleshoot using lights
POWER 2.4GHz 5GHz ETHERNET
INTERNET USB
2.4 GHz is on when the 2.4 GHz
wireless band is enabled.
5 GHz is on when the 5 GHz
wireless band is enabled.
INTERNET is blue when
internet-service is available.
ETHERNET is on when at least
one device that is turned on is
connected to the LAN-ports.
POWER blinks slowly when the
router is starting up or being up-
dated. Do not turn o your router.
POWER blinking quickly means a
WPS-connection is in progress.
When POWER is o the router is
powered o. USB is blinking when USB-device
is being identied.
USB is on when the
connected USB-device is ready to
use.
On our router there are six lights. If you’re experiencing problems the
lights are a good place to start your troubleshooting.
Power On/Off
ResetPower
LAN1WAN
Reset
WPS/Wi-Fi
LAN2 LAN3 LAN4 Power
Easy troubleshooting
1. Restart your router by turning it o using the power-button, waiting
5 sec and turning it on again.
2. Troubleshoot using the routers lights using the guide seen above
(check your berconverter or cablemodem too).
3. Problems with wi: try connecting an ethernet cable from the router
to your computer. If this xes the problem something is wrong with the
wireless network. A common reason for this is that wi has
been turned o using the wi-button. Or that something in the routers
surroundings or a close neighbour’s wi is interfering with the signal.
4. If the problems remain, try bypassing the router (if you have a
cablemodem your need to release your IP-address, contact us and
we’ll help you). Use the ethernet cable between your router and
berconverter/cablemodem. Instead of having your router connected,
connect a computer instead. Restart the computer. If internet works
now the problem is in your router.
INTERNET is orange when the
router’s internet-port is connected
but no internet service is available.
TP-Link Archer AX53 and AX55
Connect our router
Connect using cable
Wireless internet (Wi)
It’s recommended to use a cable connection if you for example play games online.
Router
Fiberconverter/
Cablemodem
Computer/Game-
consol/TV etc.
Ethernet-port
Router
Fiberconverter/
Cablemodem
Don’t place the router somewhere that might have a
negative impact on the wireless range, read more here.
!
• If you have a cablemodem you need to release your IP-address
before changing router. Read more here.
• Keep the routers software updated. You should update your router
yearly to ensure it’s secure.
• The routers wireless range can be aected by many dierent
things. The most common one is the placement; if there are thick
walls or it’s placed near devices with electromagnetic radiation it
might have a negative eect on the routers range.
Important to think about
At Lyssna-Njut Fibernät AB you can choose to buy your router with
basic conguration, ready to use right away. Without the basic
installation the router must be installed and updated before you can
use it (read more at tp-link.com).
Computer
Click the network icon on your computer
desktop, choose your network and enter
your password (network-id and password
is located on the backside of the router). To
not have to connect manually everytime,
enable ”Connect automatically”.
Smart devices (mobile, tablet etc.)
Go to settings and turn on wi. Choose
your network and enter your password.
TP-Link Archer AX53 and AX55
WPS-connection
Windows computer:
Connect like you would when using wi, but instead of entering the
password press the WPS-button to connect.
Printer, mediaplayer etc:
On the device you want to connect – press the WPS button. Press the
WPS-button on the router to connect.
Don’t hold down the WPS-button for more than 2 sec,
that turns o the wireless network.
!
WPS easily connects devices to your router (WPS does not work with
iOS-devices). To connect devices with WPS to your router, press the
WPS button. The POWER-light is blinking when connection is in
progress. A connection must be made within 2 minutes.
Connect using WPS
Android device:
Go to Network connections Wi. On some devices the option for
WPS Push is in the menu, if not click the three dots in the top right
corner and click advanced to go to WPS Push. Press the WPS-button
on the router to connect your device.
Blå: Pantone 7687C
Röd: Pantone 1925C
