Totevision LCD-1700TS Manual de usuario

LCD-1700VRTS

LCD-1700TS

LCD-1211TS

LCD-1042TS

LCD-840TS

LCD-641TS

Biggest Thing in

Touch Screen LCD Monitors

LCD-1700VRTS LCD-1700TS LCD-1211TS

LCD-1042TS LCD-840TS

LCD-641TS

LCD-1700VRTS Same as LCD-1700VR*, 17" LCD in rack mount, 8 RU, with ELO touch screen

LCD-1700TS Same as LCD-1700V*, 17" LCD monitor, with ELO touch screen

LCD-1211TS Same as LCD-1211VB*, 12.1" sunlight readable LCD, 1250 Nit, with MicroTouch touch screen

LCD-1042TS Same as LCD-1042VB*, 10.4" sunlight readable LCD, 1200 Nit, with MicroTouch touch screen

LCD-840TS Same as LCD-840V*, 8.4" LCD monitor, with ELO touch screen

LCD-641TS Same as LCD-641V*, 6.4" LCD monitor, with ELO touch screen

* For detailed specification, including dimensions and inputs, see individual pages for LCD-1700VR, LCD-1700V,

LCD-1211VB, LCD-1042VB, LCD-840V, and LCD-641V.

1319 Dexter Ave. N • Ste. 020 • WA 98109

Tel: 206-623-6000 • FAX: 206- 623-6609

E-mail: [email protected]

http://www.totevision.com

All touch screen monitors are special order only.

• 5-wire resistive type touch screens

• Serial type

• RS-232, VGA cable, and power supplies are provided.

• Touch screen drivers for ELO are available online at www.elotouch.com

and will need to be downloaded.

• LCD-1211TS and LCD-1042TS uses PenMount Touch Screen drivers

and can be installed from the disc provided in box.

General Installation

1. Setup LCD touch screen with computer with VGA cable and RS-232 cable. Connect power supply to unit and turn on.

2. Set display settings for monitor. Refer to individual specification page for the LCD monitor resolution.

3. Download or put in CD for touch screen driver. Install.

4. Run setup. Specify what serial port you will use (Com 1, Com 2, Com 5...).

5. Run calibration to activate touch screen.

More detailed instructions can be found for touch screen setup on our website at www.totevision.com under Manuals and Instruction Pages.
