Totevision LCD-1510V Manual de usuario

________________________________________ 15” LCD MONITOR

CHAPTER 1

INTRODUCTION

BEFORE INSTALLING YOUR MONITOR

Read this manual cover to cover.

PAY ATTENTION to all WARNING and CAUTIONS

DO NOT use computer components not recommend by the

manufacture

Do not attempt to service the monitor your self. If a problem

occurs, contact the manufacture's authorized service center

ABOUT YOUR MONITOR

This monitor is a microprocessor-controlled, color monitor that

uses a TFT LCD panel. The monitor conforms to EPA Energy

Star and VESA DPMS (Display Power Management Signaling)

power management standards.

RGB MODE

This monitor is equipped with a microprocessor that identifies

your computer 's video mode and allows user to adjust the setting.

VIDEO MODE

This monitor can accept the NTSC or PAL signal to display the

video screen automatically. It also implement the video screen on PC

function, we called PIP function. We also provide one pair of BNC

in/out connector inside.

15” LCD MONITOR _____________________________________

FACTORY-PRESET MODES

Table 1 shows standard video mode setting that has been

pre-adjusted at the factory for accurate video display. These setting

are stored in the monitor's memory

Table 1. Factory-Preset Modes

PC mode

Mode Resolution H-Freq.(KHz) V-Freq(Hz)

NEC 640x400 24.83 56.4

VGA 640x350

720x400

640x480

31.47

37.86

37.5

SVGA 800x600

800x600

35.16

37.88

48.08

46.87

56.3

60.3

72.2

XGA 1024x768

1024x768

48.36

56.47

SXGA 1280x1024

1280x1024

63.98

Macintosh 640x480

832x624

1024x768

49.7

48.78

60.241

66.7

74.55

74.927

Video Mode

NTSC 525 lines, 60 fields

PAL 625 lines, 50/60 fields

Note: The 15” LCD monitor didn’t support SXGA mode

________________________________________ 15” LCD MONITOR

SPECIFICATIONS

 LCD-1510V 15” LCD Monitor

Overall Dimension (HxWxD): 404 x 393 x 162 mm

Effective Display area (H/V): 304.1 x 228.1 mm

Display colors: 16.7M (dithering) colors

Scan Frequencies:

Horizontal 31.47K to 60KHz

Vertical 60Hz to 75Hz

Viewing Angle: 140°(Horizontal & Vertical)

Number of Pixels: 1024x768 pixels

Pixel pitch: 0.297x0.297 mm

Picture Tube: 15" TFT LCD panel

Power:

Input 110~240VAC (auto-sensing)

Frequency: 48-62Hz

Consumption 35Watts maximum (on)

1 Watts (Power saving off mode)

PC RGB Connector: 15pin Mini D-sub (Standard)

Audio connector 1 x stereo input

Speaker 2W x 2

RGB Signals:

Video Analog RGB 0.7Vp-p/75Ω

Sync Separate

Display Data Channel:

Compatibility VESA DDC 1/2B

Video connector Input

S-connector x 1 (S-video In)

AV connector x 3 ( one for video, Two for audio)

Mini D type x 1 (for YcbCr/Component In)

BNC connector x 1 ( Composite Video In)

Video Connector output

15” LCD MONITOR _____________________________________

BNC connector x 1 (Composite Video Out)

Operations:

User Controls On/Off Power Button

+/- and Up/down keys

On Screen Display Auto adjustment, Brightness, contrast

color temperature, Hue, Tint,

Source select, PIP setup

H-position, V-position, OSD position

Audio volume, bass, treble, mute

Load default

Control Type: Digital

Compatibility: IBM and compatible, Apple

Macintosh, NEC

Environmental Limits:

Operating Temp 32°to 103°F ( 0°to 40°C )

Storage Temp. -4°to 140°F ( -20°to 60°C )

Operating Humidity 10 to 85% without Condensation

Storage Humidity 10 to 95% without Condensation

Agency Approval

EMI FCC-B and CE

Emissions MPR-II

Energy Saving EPA energy star, VESA DPMS

Safety UL, TUV
