Totevision LCD-702 Manual de usuario

7.0" 16:9 Wide Screen

Universal Headrest Monitor

FLUSH MOUNTING / PHYSICAL MOUNTING SELECTABLE

OPERATING

INSTRUCTIONS

Before operating the unit, please read these instructions carefully. 05' 12OT01004639

Important Notice

It is unlawful in most jurisdictions for a person to drive a motor vehicle which is

equipped with a television or screen that is located in the motor vehicle at

any point forward of the back of the driver's seat, or that is visible directly

or indirectly to the driver while operating the vehicle.

CAUTION

Do not operate the monitor at temperatures below 32°F (0°C) or above 140°F (60°C).

Keep the monitor clean and dry.3.

Do not drop the monitor or expose to strong impacts.

Do not expose to direct sunlight for extended periods of time.

e11 022771

Installation Guide:

The kit includes a protective trim ring and an optional spacer ring for use when the mounting

surface is uneven.

1. Select appropriate locations in your vehicle for the monitor and for the power supply module.

2. Be sure there is sufficient depth for the trim ring. Add the spacer ring for shallow locations

with uneven curved surfaces such as upholstery. Be sure there is enough space for both

the trim ring and for any excess interconnect cable.

3. Ensure that the interconnect cable will reach from the monitor location to the power supply

module.

4. Create the required opening for the monitor and trim ring. Be sure it is not too large, and

that there is enough space behind the trim ring to store any excess interconnect cable.

Excess cable does not fit within the trim ring.

5. Route the cable through the opening in the trim ring

6. Mount the trim ring with the screws provided.

7. Connect the cable to the monitor.

8. Securely snap the monitor into place.

Cable

If you need to remove the monitor

from the trim ring, insert a credit

card between the monitor and the

trim ring to release the monitor

from the flexible locking retainer

tabs. Gently pull the monitor from

the trim ring. Very gentle pressure

can be applied using the credit card.

HEADREST SHROUD

MONITOR

TRIM RING(OPTIONAL)

WIRE IN TUBE

Electrical Connections:

Wiring System:

Red Wire : ACC

Black Wire : Ground

Yellow Wire : Battery (+)

Note: Please make sure all cables are connected correctly, wrong connections

will damage the monitor.

Red

Video-1 Input

Video-2 Input

Fuse Yellow

Black

Basic Operation:

Front Control Panel:

POWER : ON / OFF / Mode Selection and

Enter button (press and hold the button will power off)

1. LCD Panel

7. Infrared Remote

Controller Receiver

DOWN : Positive and Negative Adjustment

MENU : Activation of Menu Indicator

. UP : Positive and Negative Adjustment

2. Headrest Shroud

Basic Operation(Optional):

Remote Control:

The remote control includes the following buttons for use with this monitor:

Monitor Menu, Mode, Up, Down,Left, Right and Power.

1. Use a small coin to play open battery

holder from compartment.

2. Remove old battery and put in a

new one with positive sign " + "

facing upward.

3. Push compartment into position.

Precaution :

1. Dispose off used battery properly.

2. Do not misuse battery by short - circuiting the " + " and " - " terminal or put

it into fire.

3. Remove used battery from compartment to prevent leakage from damaged

battery.

4. To avoid accident , prevent children from playing with the battery.

Replacement of Battery:

remote controller

battery holder

battery

RC-1029A

MOBILE AV REMOTE CONTROL

REP

SCAN SAVE

MUTE

DISP

BAND

VOL

MEMORY

CH/DISC/SET

POWER

1 2 3

MODE

SYSTEM SELECTION

CHANNEL SELECTION

POWER ON/OFF

FUNCTION SETTING

ONLY WORK ON IN-DASH WIDE SCREEN COLOR MONITOR

On-Screen-Display Settings:

When monitor is power on, press mode button on remote or power button control panel to select

video inputs AV1/AV2 NTSC PAL. (Press and hold power button on control panel will power off

the monitor.)

Press the Menu button on the remote or front control panel, the OSD menu will show the LCD

screen as below, use the up/down buttons on remote or up/down buttons on front control panel to

select setting .

MODE:

MONITOR SETTINGS:

COLOR:

Press Menu button on remote or on control panel, OSD menu will show on LCD screen as below

(left chart), press up/down button on remote or press and hold up/down button on control panel to

select "COLOR" setting, "COLOR" setting will show as below (right chart).

BRIGHT:

Press Menu button on remote or on control panel, OSD menu will show on LCD screen as below

(left chart) , press enter button on remote or power button on control panel to select "BRIGHT"

setting, "BRIGHT" setting will show as below (right chart).

COLOR

> BRIGHT

TINT

DIMMER

FORMAT

RESET

MODE

BRIGHT 50

(Remote Control

optional)

TINT:

Press Menu button on remote or on control panel, OSD menu will show on LCD

screen as below (left chart), press up/down button on remote or press

and hold up/down button on control panel to select "TINT" setting. "TINT" setting

will show as below (right chart).

DIMMER:

Press Menu button on remote or on control panel, OSD menu will show on LCD

screen as below (left chart), press up/down button on remote or press

and hold up/down button on control panel to select "DIMMER" setting. "DIMMER"

setting will show as below (right chart).

DISPLAY MODE: (FORMAT)

Press Menu button on remote or on control panel, OSD menu will show on LCD

screen as below (left chart), press up/down button on remote or up/down button

on control panel to select "FORMAT" setting. Press enter button on or power

button on control panel to select "FORMAT" setting, NORMAL/ PANORAMA/

ZOOM/ FULL display mode ."FORMAT" setting will show as below (right chart).

COLOR

BRIGHT

> TINT

DIMMER

FORMAT

RESET

MODE

TINT 50

COLOR

BRIGHT

TINT

> DIMMER

FORMAT

RESET

MODE

DIMMER

OFFON

COLOR

BRIGHT

TINT

DIMMER

> FORMAT

RESET

MODE

FORMAT

NORMAL

On-Screen-Display Settings:

The Wide Screen Universal Monitor includes mounting options described in the

following sections. Before you install the monitor, consider the following

important notices:

NEVER install this monitor where it can be viewed from the driving position;1.

this is a violation of many state and local vehicle codes.

Avoid mounting locations where there is a risk of impact with a passenger in

the event of an accident.

Always mount the monitor securely using the mounting hardware that is

provided. Do not use the monitor unless it is properly secured to the vehicle.

Box Contents:

The Widescreen Universal Monitor includes the following parts and equipment:

1. Monitor

2. Remote control (optional)

3. Mounting pedestal

4. Flush mounting trim ring (optional)

5. 2 Video Inputs Harness

Installation Notes:

RESET IMAGE:

Press Menu button on remote or on control panel, OSD menu will show on LCD screen as below

(left chart), press up/down button on remote or up/down button on control panel to select

"RESET" setting. Press enter button on power button on control panel to select "RESET" setting,

"RESET" setting will show as below (right chart).

COLOR

BRIGHT

TINT

DIMMER

FORMAT

> RESET

MODE

RESET
