Toshiba TDP-TW95E Manual de usuario

Table of Contents

Chapter 1 1-1

Specifications 1-1

Using the Menus 1-3

Names of the Terminals on the Rear Panel 1-4

List of Supported Signals 1-5

Chapter 2 2-1

Replaceable Part Hierarchy 2-1

Required Tools 2-2

Parts Replacement 2-3

Chapter 3 3-1

SINGOWS 2000 3-1

Chapter 4 4-1

FirmwareUpgrade 4-1

Version Information 4-7

Chapter 5 5-1

Wiring Diagram 5-1

Block Diagram 5-2

Chapter 6 6-1

LEDDisplay 6-1

Troubleshooting 6-2

Operation of Power Supply 6-18

Chapter 7 7-1

Electrical adjustment 7- 1

Lighting Position Adjustment 7-13

Easy AF Adjustment 7-15

AFAdjustment 7-16

Easy Connect 7-23

Chapter 8 8-1

Functional Test 8-1

Chapter 9 9-1

Spare Parts List 9-1

ontents

1-1

Chapter 1

Specifications

Chapter 1

1-2

■CONTROL terminal

●Pin assignment

Mini DIN 8 Pin Connector

●lnterface format

1 Communication method

RS-232C,9600bps,No Parity,Data Length: 8 bits;

Stop Bit Length: 1 bit

2 Communication format

Only 1 command valid per communication.

3 Data format For input commands,only ASCll-compliant all-uppercase alphanumeric

characters supported.

4Replies Acknowledge :Normallyended

:Aborted

No Acknowledge

If commands are to be sent consecutively, wait for the response from the projector

before sending the next command.

●Main Commands

Item Command

Power on PON

Power off PDF

Icon display on MC0

Icon display off MO1

Auto setting (RGB input) PAT

Status display on DON

Status display off DOF

Note

●Contact your dealer for control cable and other commands.

No.

Signal

Name

Description

1 RXD Receiving data

2 CTS Consent to send

3 DSR Data set ready

4 GND Signal ground

5 RTS Request to send

6 N.C No connection

7 TXD Sending data

8 GND Signal ground

STX(02h) Command(3Byte) ETX(03h)

ACK(06h) CR (0Dh) Data

ACK (06h) ESC (1Bh)

NAK (15h)

Cha

ter 1

1-3

Using the Menus

You can call up on-screen menus, and conduct a number of adjustments and settings using the operation

buttons on the control panel (main unit side) and remote control.

■How to use the menus

The menu shown below is for operation instructions purposes and might differ from the actual display.

1. Press the MENU button Display the Setting display menu

2. Select a Category

3.Adjustments & Settings

4.End Press the MENU button.

(The menu disappears 30 seconds after the last operation.)

Select a Category by using

There are following four Categories:

Image adjustment menu

Display Setting menu

Default Setting menu

Status Display menu

Displays the current

adjustments and Settings

of selected Category.

Item shown with gray

cannot be adjusted with

the current input source

1-4

Cha

ter 1

Names of the Terminals on the Rear Panel

Name :Main Function

(1) CONTROL terminal : When operating the projector via a computer, connect

this to the controlling computer’s RS-232C port.

(2) MONITOR terminal : Connect to a computer display, etc.

(3) AUDIO IN terminal : Input audio signals from a computer, or from video

equipment with a component video signal output terminal.

(4) COMPUTER 1 IN terminal : Input RGB signal from a computer or other source, or a

component video signal (Y/PB/PR) from video

equipment.

(5) AUDIO (L/R) terminal : Input audio signals from video equipment.

(6) S-VIDEO terminal : Input S video signals from video equipment.

(7) USB terminal : Connects the supplied wireless LAN USB adapter or a

commercial USB memory.

(8) AUDIO OUT terminal : Outputs audio signals.

(9) COMPUTER 2 IN terminal : Input analog RGB signal from a computer or other

source,or a componet video signal (Y/PB/PR) from

video equipment.

(10) AUDIO (L/R) terminal : Input audio signals from video equipment.

(11) VIDEO terminal Input video signals from video equipment.

1-5

Cha

ter 1

List of Supported Signals

■List of Supported Signals(RGB signals)

This projector supports the following RGB signals. Note, however, that depending on the computer model,

the screen may show flicker or streaking. Please adjust the projector if this happens.

Resolution Mode Refresh Rate(Hz) H-frequency(kHz) Clock（MHz）

720 x 400 720x400_85 85.039 37.927 35.500

VGA_60 59.940 31.469 25.175

VGA_72 72.809 37.861 31.500

VGA_75 75.000 37.500 31.500

640×480

VGA_85 85.008 43.269 36.000

SVGA_56 56.250 35.156 36.000

SVGA_60 60.317 37.879 40.000

SVGA_72 72.188 48.077 50.000

SVGA_75 75.000 46.875 49.500

800 x 600

SVGA_85 85.061 53.674 56.250

832 x 624 MAC16" 74.550 49.725 57.283

XGA_60 60.004 48.363 65.000

XGA_70 70.069 56.476 75.000

XGA_75 75.029 60.023 78.750

XGA_85 84.997 68.667 94.500

1024 x 768

MAC19" 74.700 60.134 79.857

1152 x 864 SXGA1_75 75.000 67.500 108.000

QuadVGA_60 60.000 60.000 108.000

1280 x 960

QuadVGA_85 85.002 85.938 148.500

SXGA3_60 60.020 63.981 108.000

SXGA3_75 75.025 79.976 135.000

1280 x 1024

SXGA3_85 85.024 91.146 157.500

1400 x 1050 SXGA+ 59.978 65.317 121.750

UXGA_60 60.000 75.000 162.000

UXGA_65 65.000 81.250 175.500

UXGA_70 70.000 87.500 189.000

UXGA_75 75.000 93.750 202.500

1600 x 1200

UXGA_85 85.000 106.250 229.500

Note

●Signals whose resolution exceeds the native resolution (1024×768 pixels) will be

compressed. For this reason, some information may be lost, or image quality may be affected.

Chapter 1

1-6

■List of supported signals (Y/PB/PR signals)

■List of supported signals (Video, S-Video signals)

■Pin assignment of COMPUTER 1 IN, COMPUTER 2 IN &MONITOR terminals

Mini D sub 15 Pin connector

• RGB input

RGB signals :0.7V (p-p) 75 Ω

Horizontal sync signal :TTL level (Pos/neg polarity)

Vertical sync signal :TTL level (Pos/neg polarity)

• Y/PB/PR input

Y signal :1.0V (p-p) 75 Ω

PB/PR signals :0.7V (p-p) 75 Ω

*Do not connect anything

Signal format fh(kHz) fv(Hz)

480i(525i)@60Hz 15.73 59.94

480p(525p)@60Hz 31.47 59.94

576i(625i)@50Hz 15.63 50.00

576p(625p)@50Hz 31.25 50.00

720p(750p)@60Hz 45.00 60.00

720p(750p)@50Hz 37.50 50.00

1080i(1125i)@60Hz 33.75 60.00

1080i(1125i)@50Hz 28.13 50.00

Video mode fh(kHz) fv(Hz) fsc(MHz)

NTSC 15.73 60 3.58

PAL 15.63 50 4.43

SECAM 15.63 50 4.25 or 4.41

PAL-M 15.73 60 3.58

PAL-N 15.63 50 3.58

PAL-60 15.73 60 4.43

NTSC4.43 15.73 60 4.43

Pin description

No. During RGB input During Y/PB/PR input

1 Video signal (R) Color difference signal (PR)

2 Video signal (G) Luminance signal (Y)

3 Video signal (B) Color difference signal (PB)

4 GND *

5 GND *

6 GND (R) GND (PR)

7 GND (G) GND (Y)

8 GND (B) GND (PB)

9 N.C GND

10 GND *

11 GND *

12 N.C *

13 Horizontal sync signal *

14 Vertical sync signal *

15 N.C *

2-1

Chapter 2

Replaceable Part Hierarchy

The flow chart below shows what parts must be removed to access each replaceable part in the projector.

The parts on the first level (Ex. Lamp cover) are accessible without removing any other parts.

The move levels down that a part is, the more parts you need to remove in order to access it.
