Toro 02710 Manual

FormNo.3405-967RevB

32RDMid-SizeRear-DischargeDeck

ModelNo.02710—SerialNo.316000001andUp

ModelNo.02711—SerialNo.316000001andUp

ModelNo.02712—SerialNo.316000001andUp

SetupInstructions

Theseinstructionsarefordealersonly.

Theseinstructionsareforadealertoinstallacutting

deck(Models02710,02711,or02712)toaMid-Size

PowerUnit(Models30069and31914).

WARNING

Performingmaintenancewhiletheengineis

runningcanexposeyourhands,otherparts

ofyourbody,andclothingtogetcaughtin

movingparts,causingseriousinjury.

Ifyoumustperformanymaintenancewhile

theengineisrunning,keepyourhands,feet,

clothing,andpartsofyourbodyawayfrom

thecuttingunitandmovingparts.

WARNING

Engineexhaustcontainscarbonmonoxide,

whichisanodorless,deadlypoisonthatcan

killyou.

Donotrunengineindoorsorinanenclosed

area.

Important:Readandunderstandtheseassembly

instructionsbeforeproceeding.RefertotheParts

CatalogandOperator'sManualforthemachineto

determinewhichofthesepartsaretobetted.

Important:Ensurethatallliftingequipmentis

ingoodconditionandhasasafeandadequate

capacity.Alwaysseekassistancewhenlifting

awkwardorheavyloads.

Important:Torqueallfastenerstothespecied

torquesettings.Thepartsbeingttedmustnotbe

drilled,cutoralteredinanyway.

PreparingtheMachine

NoPartsRequired

Procedure

1.Parkthemachineonalevelsurfaceandengage

theparkingbrake.

2.Shutofftheengine,removethekey,andwait

fortheenginetocool.

3.Raiseandsupportthetractionunit.

4.Removethe4lugnutssecuringbothwheelsto

thetractionunit(Figure1).

g237244

Figure1

Leftsideshown

8111LyndaleAvenueSouth

Bloomington,MN55420

Registeratwww.Toro.com.OriginalInstructions(EN)

AllRightsReserved*3405-967*B

5.Removethewheels(Figure1).

6.RemovethedeckcoverandthePTO

engagementlinkagerodbeforeliftingand

movingtherotarycuttingdeckintoposition

againstthepowerunit(Figure2).

g237246

Figure2

1.Liftpoints

Note:Retainallremovedpartsforlater

installation.

InstallingtheCuttingDeck

Partsneededforthisprocedure:

8Bolt(3/8x1inch)

8Curvedwasher

8Flangenut(3/8inch)

Procedure

1.Install8bolts(3/8x1inch),curvedwashers,

andangenutstosecuretherotarycuttingdeck

tothepowerunitasshowninFigure3.

Important:Ensurethattheenginedeckis

paralleltothemowerdeck+/-0.5degrees

beforetighteningthexingbolts.

g237289

Figure3

1.Bolt(3/8x1inch)3.Curvedwasher

2.Flangenut(3/8inch)4.Reversedhardware

Note:Installtheboltsandwasherstogether

onthesamesideoftheframe.Thereversed

hardwareinstallswiththeboltendandnutfacing

outwards.

2.Torquetheboltsto40to47N·m.

3.ScrewthePTOengagementlinkagerodintothe

powerunitbell-crankyokeandthenconnectthe

otherendtotheassistarmandsecureitwiththe

hairpincotter(Figure4).

g237288

Figure4

1.Bell-crankyoke2.PTOengagementlinkage

4.AdjustthePTOengagementasdirectedinthe

AdjustingtheMowerBeltTensionsectioninthe

tractionunitOperator’sManual.

5.ChecktheadjustmentofthePTOsafetyswitch

asdirectedintheAdjustingtheMowerBelt

TensionsectioninthetractionunitOperator’s

Manual.

6.Checkthedeckdrivebeltrouting(Figure5);

refertotheAdjustingtheMowerBeltTension

sectioninthetractionunitOperator’sManualto

adjustthedeckdrivebelt.

Important:Ensurethatthebeltisonthe

correctsideofthebeltguideunderthe

engineframeandadjustthebeltguide.

g015218

Figure5

PTOengaged

1.Toenginedrivepulley

7.Checkandadjustthebladebrake;referto

theAdjustingtheBladeBrakesectionofthe

Operator’sManual.

InstallingtheGuards

Partsneededforthisprocedure:

1Centerdischargeguard

2Bolt(M8x25mm)

4Washer(M8–17)

2Locknut(M8)

1Drivepulleyguard

2Carriagebolt(M10x25mm)

2Heavywasher(M10)

2Springwasher(M10)

2Nut(M10)

1Undersideguard

1Dragshield

Procedure

1.Installthecenterdischargeguardbeneaththe

machinebetweentheengineframeandthe

cutterdeck.

g237371

Figure6

1.Bolt(M8x25mm)4.Centerboltandwasher

2.Washer(M8–17)5.Centerdischargeguard

3.Washer(M8–17)and

locknut(M8)

A.Removethecenternut,boltandwashers

fromthecenterxingonthedeck(Figure6).

B.Installtheguardtothetractionunitusing2

bolts(M8x25mm),4washers(M8–17),

and2locknuts(M8)inthelowerholeonthe

engineframe(Figure6).

C.Securethefrontoftheguardtothedeck

usingthecenterbolt,washer,andnutyou

removedpreviously(Figure6).

2.RefertotheAdjustingtheHeightofCutsection

intheOperator'sManualandchecktheheight

settingoftherearaxledependingonwhatheight

ofcutisrequired.

3.Installthetractionwheelstothehubsandsecure

withthedrivewheellugnuts;torquethelugnuts

to122to129N·m.

4.Lowertheunittotheground.

5.Centerthedrivepulleyguardontherearofthe

engineframeandinstallitwith2carriagebolts

(M10x25mm),heavywashers(M10),spring

washers,andnuts(M10)asshowninFigure7.

g237375

Figure7

1.Carriagebolt(M10x25

mm)

4.Nut(M10)

2.Heavywasher(M10)5.Drivepulleyguard

3.Springwasher

6.Testttheundersideguardandadjustthe

positionofthedrivepulleyguardifnecessary

(Figure8).

7.Installtheundersideguardanddragshieldto

thedrivepulleyguardandsecurethemwiththe

boltscapturedinthelanyardsonthedrivepulley

guard(Figure8).

g237378

Figure8

1.Bolt,capturedinthe

lanyard

3.Dragshield

2.Undersideguard

8.Adjustthecasterpositionandthebladeheight

tothecorrectheightofcut;refertotheAdjusting

theHeightofCutsectionintheOperator’s

Manual.

CompletingtheInstallation

NoPartsRequired

Procedure

1.Installthedeckcoverandsecureitwiththe

fastenersremovedinstep6of1Preparingthe

Machine(page1).

2.Ifthehydraulicpumpbypassvalveisopen,

closethebypassvalves,butdonotovertighten.

3.Ensurethatallfastenersarecorrectlytightened

andthatalluidlevelsareatthecorrectlevel.

4.Starttheengineandchecktheoperationofall

controls;refertothetractionunitOperator’s

Manual.

5.Collectallpartsanddocumentationforthe

customer.Filloutthewarrantyandpre-delivery

inspectiondocumentation.

Note:Awarrantyregistrationcardneedstobe

completed,bothforthepowerunitandthedeck.

SettingtheIdleSpeed

Partsneededforthisprocedure:

1Screw(M5x50)

Procedure

TocomplywiththeEUNoiseDirective,thedealeris

requiredtoverifythecorrectenginespeedof2,900

rpmwhenthepowerunitisconnectedtoModels

02710and02711and3500rpmwhenthepowerunit

isconnectedtomodel02712.

2900/3500rpmistheunloadedenginerpm,adjusted

withthePTOoff(disengaged).T oleranceisplus0

rpm,minus50rpm.Theengineshouldbewarm;run

theenginefor15minutesbeforeadjusting.Double

checkthenalenginespeed.

1.Loosenthelocknutandunscrewthehighidle

screwafewturns.Whensettingtheengine

speedonpowerunitsconnectedtomodels

02710and02711,replacethehighidlescrew

withthehighidleM5x50screwsuppliedwith

02710and02711(Figure9).

g018377

Figure9

1.Speedcontrollever3.Locknut

2.Cablescrew4.Highidlescrew

2.Movethethrottlelever,ontheoperatorcontrol

panel,toobtainthedesiredenginerpm.

3.Turnthehighidlescrewsothattheendofitjust

touchesthespeedcontrollever,andtightenthe

locknut(Figure9).

4.Checkthehighidlespeedandrepeatthis

procedureifnecessary.

5.Loosenthecablescrewandadjustthecable

lengthsothatthethrottleleverontheoperator

controlpanelissettofullthrottlewhenthe

speedcontrollevertouchesthepreviouslyset

highidlescrew.

6.Tightenthecablescrew.

Notes:
