INSTRUCTIONS FOR USE

Aluminium quad cane with long/short legs

Product code: JMC-C 2670SL / 2660SL

1. Characteristics

The quad cane consists of aluminium-steel frame, height adjustable

ergonomic and chromed handle with powder coated base with four

legs. The quad cane is available either with high base and foamed

handgrip (JMC-C 2670SL) or with low base and plastic handgrip

(JMC-C 2660SL).

a. handgrip

b. height adjustment – locking pin

c. rubber tip

2. Application

The quad cane is ancillary equipment which is designed for patients

with reduced mobility who need stable support and help while walking.

It is also recommended to the elderly as an aid in keeping balance. The

design with four legs provides better stability than regular canes.

Contraindications: coordination and balance disorders, advanced

rheumatic changes, injuries and dysfunctions of upper limbs which may

hinder the support on the quad cane.

3. Adjustment

To adjust the quad cane, press the metal pin and select appropriate

position of the inner tube. Lock the position of the tubes relative to

each other with the use of metal pin. The quad cane is adjustable in 2.5

cm increments.

•To set the proper length of the quad cane, stand upright and bent

upper limb in elbow joint at the angle of 20°.

•The quad cane should be adjusted individually to the user so that

the handgrip is at hip joint level.

•Before use, ensure that the quad cane is stable and the locking pin

fully protrudes through adjustment hole of the quad cane.

NOTE! In case of doubts concerning the technique of moving with the

use of quad cane, consult a person who has appropriate knowledge or

qualifications.

4. Technical data

Type: adjustable

Leg colour: silver

JMC-C 2670SL

Handgrip: black, foamed

Base colour: black

Base dimensions: 26 cm (25.5cm) x 23 cm

Height adjustment:77-101 cm

Weight: 1 kg

Maximum capacity:100 kg

JMC-C 2660SL

Handgrip: grey, plastic

Base colour: grey

Base dimensions: 15 cm x 21 cm

Height adjustment:78-101 cm

Weight: 1 kg

Maximum capacity:100 kg

5. Notes

Timago International Group does not bear responsibility of improper

use of the product, failure to comply safety regulations and misuse.

6. Cleaning and maintenance

•Clean the quad cane using only water and mild detergents.

•Do not use:strong detergents, abrasive agents, bleach, petrol nor

solvents (it may cause frame damage, visible defects, and in

consequence – loss of warranty rights).

•It is recommended to check rubber tips regularly. Replace worn

tips immediately.

7. Storage and transport conditions

Device should not be exposed to direct sunlight, water or moisture.

8. Warranty information

All products distributed by our company are covered by a warranty, the

terms of which are described in the warranty card available on our

website. Please contact the retailer from whom you purchased the

product. Please, keep in mind that for warranty purposes, the proof of

purchase (receipt or invoice) should be retained

9. Labels

Reference

number

Manufacturer

LOT number

Manufacture date

Serial number

Medical device

Note

Please read the

instruction

The manufacturer checked for compliance with

essential medical devices requirements.

Our complete line of products is available from our distributors.

Learn more at: www.timago.com. Thank you for choosing Timago!

Timago International Group

Spółka z o.o. i Spółka – Spółka komandytowa

ul. Karpacka 24/12

43-316 Bielsko-Biała, Polska

T.: +48 33 499 50 00

F.: +48 33 499 50 11

E.: info@timago.com

Rev. II, date 20.05.2021
