TIC AS P25 Manual de usuario

TIC Outdoor Patio Speakers Feature

Weatherproof Design

Pair of Architectural Patio Speakers

180° swivel bracket mounts included

Full range 50 - 150W 2-way or 3-way

speaker drivers (model dependent)

4”, 5.25”or 6.5”acoustic drivers

1” aluminum, silk dome, titanium

tweeters (model dependent)

Surge protected Revchem® switch

Silicone sealed cabinetry

6-8 Ohm Impedance

ASP60 & ASP120 w/70v switch

option for Commercial Installations

Multi mount system(s)

ABS Impact Resistant Formulated

Enclosure

Black (B) or White (W) finish

©TIC Corporation U.S.A.

s…

…

Manufacturers

Name:

TIC Corporation

Manufacture

Contact:

www.ticcorp.com

(800) SPX-OMNI

TIC Model

Number:

_____________

Serial Number:

________________

Dealers Name:

_____________

Dealers Contact:

________________

Purchase

Date:

_____________

Invoice/ Receipt

Number:

________________

We recommend you keep your sales receipt and warranty card together

with this owners guide for safe keeping and future reference.

This TIC Exterior Audio Product Conforms to all applicable:

EMC/ EEC

Directives

One World, TIC Recycles

x…

…

Introduction ………………….……………

Component List …………………….…….

Pre-Installation …………………… ……..

Connection Cable ……… ……………....

Exterior Installation ………………………

5/6

Maintenance ………………………………

Customer Service ………………..………

Warranty …………………………..………

Trouble Shooting ……...…………….…...

Technical Specifications …………….…..

Thank You for purchasing another high quality audio

product from TIC Corporation. Please read the enclosed

installation guidelines carefully and thoroughly to ensure

years of trouble free service from your new TIC exterior

audio products.

Carefully unpack your new TIC exterior product and

save all packaging materials for possible future use. Check

that your new TIC product contains all system parts

detailed in the Components list. Do not attempt to operate,

install or use your new TIC product if any components

appear missing or damaged. If so, please notify TIC

Corporation or your TIC Dealer as soon as possible.

!WARNING! to avoid possible suffocation or injury please

keep all plastic bags away from children and pets.

t…

…

Outdoor Patio Speakers

Mounting swivel brackets, M6

screw mounts/connectors and

surface feet per pair

ASP60 & ASP120

models

Included 70v option switching

assemblies

New product flysheet

(enclosed with literature)

Instruction Manual

Warranty Card

-I

n…

…

Need Professional Help?

Please read this owners guide carefully before installation. Failure to follow

these instructions fully or incorrect installation may damage your new TIC

products and any third party equipment used in your new system installation.

This may also Void any Warranty for your new TIC products. If you are unsure

of your ability to fully understand and fully complete the installation of this TIC

product, please consult a professional installer.

Note: TIC Corporation always recommends that you test your product and its

components prior to exterior installation. Test your components near a mains

power and, if required, receiver amplifiers source somewhere convenient,

perhaps inside after unpacking. Ensure all components are working smoothly

and correctly before exterior placement and operation.

n…

…

Before you begin the installation of your new TIC outdoor product, please

carefully select the locations of your new TIC products noting any impediments

or obstacles in the wiring path(s).

In general;

1. Select a reasonably clean, reasonably structurally sound surface for

the mounting and installation of your new TIC outdoor patio speakers.

This will prevent movement or excessive vibration during use. This will

also ensure more uniform sound dispersion.

2. Ensure your new TIC outdoor speaker cables or power source if

required, can easily reach your new speakers. Ensuring that there are

no obstructions or difficulties such as concrete paths or architectural

feature(s) impediments. If the cable is surface mounted you must make

sure the cable is placed where it cannot be tripped over, pulled,

abraded, pierced or crushed.

3. Wherever possible avoid long term exposure of your new TIC outdoor

speakers to chlorinated solvents, acids such as those often contained

in fertilizers and other solvents which have the potential to eventually

wear the speaker components prematurely.

4. When installing either burial cable or TIC’s in-ground outdoor speakers

please be very aware of any existing in-wall cable, submerged

plumbing, piping such as sprinklers or irrigation pipes and any sub-

surface wiring already in place.

Carefully unpack and check all components

Run speaker test prior to exterior use or installation

A note on Speaker Cable;

TIC recommends the use of our SPC30, 50 or 100’ double insulated high

quality speaker cable, however just about any reasonable speaker cable may

be used including existing runs that may be in place. For standard 8Ω

installations of 10 –50ft., just about any 14/16 gauges 2 core cables can

usually be used although we would prefer a double insulated or burial spec

cable be used. For longer runs of 50 –100ft. 12 gauge cable can be used

however resistance down the line will become a contributing factor.

Please visit TIC Corporations website at www.ticcorp.com and review the

Audio Installation Basics articles under Technical Resources for more in depth

exterior audio and cable guidelines.

An Important note on Polarity!

Pleasure proper polarity when connecting your new TIC outdoor speakers.

This is very important and will result in poor sound reproduction and possibly

equipment damage if not connected correctly. This is normally avoided by

ensuring + to + and –to –or as sometimes color coded Red to Red and Black

to Black from your amplified source to your speakers respectively.

5. Once you have checked the components and tested the system ready

for exterior install, recheck your cable runs carefully marking the correct

channel for each speaker.

6. Mount your speakers carefully using the supplied mounting brackets for

each patio speaker.

7. Connect you new TIC Patio Speakers at the speaker end first ensuring

enough “play” in the cable to allow angle adjustment as necessary.

8. Reconnect the speakers to your receiver amplifier being careful to

ensure correct “Polarity” (+ to + and –to –)matching.

9. TIC speakers are factory pre-set to standard 8Ω.

10. *for 70v commercial systems please note diagram below;

TIC ASP60 & ASP120 models only

Once connected properly, test the system at low volume first and then, sit back

and enjoy another successful installation of a TIC outdoor product!

Disclaimer;

TIC Corporation will in no way be held responsible for the improper or

unsecured installation of this product. Any and all damage arising from the

installation or use of this product is the purchaser and final installer’s sole

responsibility.

e…

…

Occasional maintenance of your TIC products cannot hurt and may help

greatly. Inspect the installation area regularly removing and twigs, dirt or

particulate matter from impeding or building up around the output grill area. The

units may be cleaned using very mild detergents like dishwashing liquid if

desired. A hose with clean water may also be used but please avoid using high

pressure or forcing water into the grill or acoustic ports.

In very cold climates with moderate to heavy snowfall an old trick from the

major theme parks we supply world wide is to place a plastic bag over the unit

for the winter or periods it may be not in use or under such snowfall.

e…

…

For any additional help please contact TIC Corporation at (800) SPX-OMNI, on

line at www.ticcorp.com , or by email at [email protected]om where we would be

happy to assist you at any time. Also please visit our website for FAQ

(frequently asked questions) and full contact information.

d…

…

TIC Corporation offers a full, UCC approved, one year full parts and labor

warranty on all its products as standard however there are other 3 and 5 year

warranties in use with various TIC authorized Dealers world wide. Please check

your enclosed Warranty card or your Dealer receipt to find out which one

applies to you. Also please note TIC Corporation General Terms & Conditions

posted on our website at www.ticcorp.com for further information.

s…

…

Please note series vs. parallel installation wiring choices below;

g…

…

Problem

Please Check

No Sound

Check the speakers are connected to the cable

correctly.

Check the speaker cable is connected to the receiver

amplifier correctly.

Check the receiver amplifier is powered “on” at the

mains, is not on “mute”, has no headphones attached

and that the Channels used for the exterior speakers

(usually A or B) is in operation.

Refer to the owners guide that came with your

receiver amplifier.

Most initial problems are simple connectivity, please

try a different connection cable to your outdoor

speakers or equipment.

No Sound from one

speaker

Check the “balance” control on your receiver

amplifier.

Check all connections and cable to the inoperable

speaker.

1. Disconnect the “working” speaker from the receiver

amplifier connection/ channel. Switch the cord from

the non-operating speaker from its current connection

to the “working” speaker connection. If the speaker

now works the problem is your receiver amplifier.

2. Reconnect as original. Remove the speaker cable

at the “working” speaker directly and connect it

directly to the non-working speaker. If the speaker

now works the problem is somewhere in the original

speaker cable.

3. If the speaker still does not work the problem is the

speaker.

One speaker

sounds distorted,

lower volume or

“different”

Follow same procedure as above for “No Sound”.

Treble or Bass

Check the “tone” setting on your receiver amplifier.

Adjust the Treble and Bass settings on your receiver

amplifier.

Check the connections carefully from the amplifier to

your speakers and ensure correct Phase (+ to + and

–to –accordingly). Poor sound replication is

expected from a speakers or speakers out of polarity

or phase.

ASP25, ASP60, ASP100 - ASP120 Models

Woofer(s)

Injection molded PP cones with

Butyl rubber surround

Cabinetry

Formulated Impact resistant ABS

Grill

Aluminum or Anodized - “sound assist grill”

*Inches/ lbs

ASP25

ASP60

ASP120

ASP100

Speaker

Drivers

4.25” woofer

2” mid-range

1” aluminum

tweeter

5.25” woofer

1” silk dome

tweeter

6.5” woofer

1” Titanium

tweeter

5.25” woofer

1” silk dome

tweeter

Frequency

response

75Hz –20kHz

60Hz –20kHz

45Hz –20kHz

60Hz - 20kHz

Sensitivity

@1W/ 1M

83db

86db

88db

85db

Continuous/

Peak

25 / 50W

35 / 75W

75 / 150W

50 / 100W

Unit Size

5.5x5x8.5

7.5x7x10

8.5x8x12

6.6x5.6x8.9

Unit Wt.

2.5 Lbs.

5 Lbs.

7 Lbs.

3.3 Lbs.

Pack Size

12x5.25x10

15.5x11x9

18x13x10

16x9.6x8.7

Pack Wt.

5.5 Lbs.

6 Lbs.

16 Lbs.

7.5 Lbs.

TIC Corporation engages in continual product research and development, new

materials, production methods and design improvements. TIC Corporation therefore,

reserves all rights to change or improve TIC products specifications without notice.

TIC Corporation

15224 East Stafford Street

City of Industry, CA. 91744-4418 U.S.A.

Tel: (626) 968-0211 (5 lines) Fax: (626) 968-1363

Email: in[email protected]m WWW: www.ticcorp.com

Otros manuales para AS P25

Este manual sirve para los siguientes modelos

Tabla de contenidos

Manuales populares de Oradores de otras marcas

argon audio

argon audio IE20 Manual de usuario

Denon

Denon SC-N7 Manual de usuario

Gemline

Gemline Ace 3952 Manual de usuario

Focal

Focal ON WALL 300 Manual de instrucciones

HEADRUSH

HEADRUSH Maximus HRSP 5024 Manual de usuario

SoundLogic

SoundLogic BCCS-6/6395 Manual de usuario

Peavey

Peavey DTH 218 Manual de usuario

Avantree

Avantree Pluto Air Manual de usuario

Morel

Morel Integra Series INTEGRA OVATION 4 Manual de usuario

Oppo

Oppo SONICA Manual de usuario

Bose

Bose SoundLink Wireless Music System Manual de usuario

Rocksteady

Rocksteady Stadium Manual de usuario

Bowers & Wilkins

Bowers & Wilkins 4 Manual de usuario

Sonance

Sonance SONOS OUTDOOR Series Manual de usuario

Electro-Voice

Electro-Voice EVID FM4.2 Manual de usuario

Pioneer

Pioneer XW-HTD630 Manual de usuario

Onn

Onn BWA16AA002 Manual de usuario

HP GL313AA - USB Speakers PC Multimedia Manual de usuario
