ThermoPro TP-19 Manual de usuario

MLAB

www.instrument.co.th

English........... 2 Français........... 12

LED DIGITAL INSTANT READ

THERMOCOUPLE THERMOMETER

INSTRUCTION MANUAL

Model No.: TP-19

20190814 EN FR

MLAB

www.instrument.co.th

-2-

Thermocouple Probe LED Display

Built-in Magnet

Battery Compartment

CAL

1 Product

LOCK

1. LED Display: Displays the current

temperature.

2. C/°F: Hold for 3 seconds to switch

between °C and °F.

3 LOCK: Press once to lock the current

temperature for 5 seconds, press

again to unlock.

4 Temperature Probe: Insert the probe

into food to get the internal meat

temperature.

5 Battery Compartment: Use 1 x AAA

battery to power the unit.

6 Super-Fast Thermocouple Probe:

High precision sensor, you can get a

temp readout within 3 seconds.

7 Calibration Function.

8 Waterproof: IP65.

9 Motion-sensing sleep and wake

modes

10 Built-in magnets.

2 Specifications

1. Temperature range: 58°F ~ 572°F

(-50°C ~ 300°C). If the temperature

is below -58°F (-50 °C) or above

572 °F (300 °C), LLL or HHH will

show on the screen

2 Three Buttons: LOCK/ C/°F/CAL. °

3 90 seconds Auto-off feature .

4 Resolution: 0.1 °C/°F.

5 Temperature Accuracy: ±0.9°F (±0.5

°C) in range between 14 to 212°F

(-10 to 100°C)

6 Battery: 1 x AAA 1.5V included.

7 180° auto-rotating display.

3 BEFORE FIRST USE

1 Insert 1* AAA battery with correct

polarity (+) and (-) as indicated.

2 Wash probe tip with warm soapy

sponge or cloth, then rinse and dry.

3 Wash under running water without

fear!

4 PLEASE READ AND FOLLOW ALL

INSTRUCTIONS.

5 The thermometer is now ready to use..

4 TO MEASURE FOOD

TEMPERATURE

1 Pull the probe away from the body of

the thermometer to turn on the

thermometer, and fold in the probe

to turn off the thermometer.

°C/°F

-3-

EN EN

MLAB

www.instrument.co.th

2 Press and hold °C/°F button for 3

seconds to switch between °C and °F.

Please note that the temperature unit

selected will remain when you turn on

the thermometer next time.

3 Insert the tip of the probe into food

being cooked as shown in the picture

below. The thermometer will start to

measure the internal food

temperature.

5. Temperature reading can be

displayed with a 180° global viewing

angle

6. Press the LOCK button to hold the

temperature for 5 seconds.

7. Wash the thermometer under running

water after use.

8. Thermometer will automatically turn

off if the probe is not folded in and

no button has been pressed in 90

seconds.

the probe not folded in and then

picked up or moved, the thermometer

will automatically power on.

The thermometer comes with a

Calibration feature. In most cases, the

thermometer was calibrated precisely

at our manufacturing facility, and

generally you do NOT need to calibrate

the thermometer. However, after a long

period of use and you believe that the

temperature reading displayed by the

thermometer is not accurate, you may

follow the process below to re-calibrate

the thermometer:

1. Use distilled or purified water to

make ice cubes in your refrigerator;

2. Get a thermal insulated bottle. If you

don’t have one, use a beaker or a

regular cup;

3. Fill the bottle with ice cubes (no less

than 70% of the volume), then top off

with cold distilled or purified water

(no greater than 30% of the volume);

4 Wait until temperature reading

stabilizes on the display.

5 Calibration

4. Stir the mixture and let it sit for 10

minutes to allow the ice and water to

reach its temperature equilibration;

5 Turn on the thermometer, unscrew

and take off the battery cover.

9. If the thermometer is sleeping with

-4- -5-

EN EN

MLAB

www.instrument.co.th

6 Immerse the probe in the ice/water

mixture and make sure not to touch

the sides of the container. Wait till

the temperature reading drops to its

lowest value, which should be around

32°F or 0°C. If the temperature of the

ice/water mixture is not within 28°F

to 36°F (or -2°C to +2°C), the

calibration can’t be continued: you

will need to follow the above steps to

re-make the ice/water mixture;

8. Press the CAL button once to confirm

the calibration mode and exit the

calibration mode.

Note:

The Calibration mode will only last for

15 seconds. If you’re unable to finish

7. Press and hold the CAL button for 5

seconds to enter the Calibration

mode. CAL will display for 3 seconds

and current temperature will display

on the screen.

the calibration within 15 seconds, the

thermometer will automatically exit

Calibration mode.

6 Undo-Calibration

If you want to undo the calibration and

go back to the default calibration

setting, please follow the below steps:

1. Turn on the thermometer and press

the “CAL” button 5 seconds to enter

Calibration mode;

2. Press the lock button to undo the

calibration and it will reset to the

default setting.

7 HELPFUL HINTS

When measuring different foods or

meat, it may be desirable to cool the

probe first by rinsing the tip with

cold water.

It is recommended that you wipe the

probe tip clean between readings.

This is especially important when

taking temperature readings from

different foods or meat.

The thermometer is designed for

temporary, hand held use. Do NOT

use in an oven. Do NOT leave it in

extremely hot foods or liquid

(anything over 572°F) for more than

1 minute.

Always take your reading in the

-6- -7-

EN EN

MLAB

www.instrument.co.th

8 CARE OF YOUR

THERMOMETER

Do not touch the stainless portion

of the thermometer during or right

after measuring temperatures since

it will be very hot.

Do not place the unit in dishwasher

or immerse in any liquid. To clean,

wipe the probe tip with a damp

soapy cloth or sponge and then dry.

Do not leave exposed to extreme

high or low temperatures since this

will damage electronic parts and

plastics.

Not intended for use by persons

under age 12.

thickest available portion of meat.

Thin portions of meat are difficult to

measure because they tend to cook

through fast. Avoid touching bone.

If the tip touches the bone or heavy

fat area of the meat, or if the tip is

not deep enough, take a second

reading to ensure accuracy.

9 Declaration of Conformity

Hereby,

this product complies with the basic

requirements and applicable complies

with the basic requirements and

applicable regulations of the EMC

Directive 2014/30/EU. The complete

declaration of conformity can be found

at: https://itronicsmall.com/

eu-declaration-of-conformity/

the manufacturer declares that

Do not keep the thermometer

inserted in food during cooking.

Remove batteries if store for more

than four months.

10 Disposal

Meaning of the “Dustbin”

Symbol

Protect our environment:

do not dispose

electrical equipment in

the domestic waste.

Please return any

electrical equipment

you will no longer use to

the collection points

provided for their disposal.

that

This helps avoid the

potential effects of

incorrect disposal on the

environment and human

health.

This will contribute to the

recycling and

of reutilisation of

electrical and electronic

equipment.

other forms

-8- -9-

EN EN

MLAB

www.instrument.co.th

CAUTION:

rechargeable batteries must

not be disposed of with

household waste!

Batteries/

Take spent batteries to the

appropriate collection point or to a

dealer.

The batteries must be removed from

the appliance.

Your town or local authority can

provide information about public

collection points.

Information concerning where the

equipment can be disposed of can

be obtained from your local

authority.

Telephone: 1-877-515-7797(USA &

Canada only)

Email: service@buythermopro.com

Hours: Weekdays 8:00 AM- 8:00 PM

EST(USA & Canada only)

Weekdays

44-203-769-1321(UK)

1:00 PM - 12:00 PM

CET(UK)

This symbol can be found on batteries/

rechargeable batteries which contain

hazardous.

Cd = contains cadmium

Hg = contains mercury

11 LIMITED ONE-YEAR

WARRANTY

ThermoPro warrants this product to be

free of defects in parts, materials and

workmanship for a period of one year,

from date of purchase.

and RECEIVE EXTENDED 3 YEARS

Warranty on our website: https://

itronicsmall.com/pages/warranty-

registration

Should any repair or service under this

warranty be required, please contact

Customer Service by phone or email for

instructions on how to pack and ship

the product back to ThermoPro.

This warranty gives you specific legal

rights and you may also have other

rights which vary from state to state.

12 CUSTOMER SERVICE

Pb = contains lead

Li = contains lithium

-10- -11-

EN EN
