Texas Instruments DLP3030-Q1 Manual de usuario

DLP3030-Q1 Combiner HUD EVM

DLP3030CHUDQ1EVM

User's Guide

Literature Number: DLPU065

November 2017

2DLPU065–November 2017

Submit Documentation Feedback

Contents

1 Introduction......................................................................................................................... 4

1.1 EVM Overview ............................................................................................................... 4

1.2 Warnings...................................................................................................................... 4

1.3 Specifications................................................................................................................. 5

1.4 Kit Contents................................................................................................................... 6

1.5 Electronic Boards Overview................................................................................................ 7

2 Getting Started .................................................................................................................... 9

2.1 Section Overview ............................................................................................................ 9

2.2 Kit Assembly.................................................................................................................. 9

2.2.1 Instructions to Assemble EVM .................................................................................... 9

2.3 First Power Up.............................................................................................................. 14

2.4 EVM Software Tool Configuration........................................................................................ 15

2.4.1 Automotive Control Program (ACP) Lite and Total Phase Cheetah Software Installation............... 15

2.4.2 How to Connect and Use the ACP Lite Tool .................................................................. 16

2.5 Connector Pinouts.......................................................................................................... 18

www.ti.com

DLPU065–November 2017

List of Figures

1-1. DLP3030CHUDQ1EVM Kit Contents ..................................................................................... 6

1-2. Formatter Controller Board Front.......................................................................................... 7

1-3. Formatter Controller Board Back .......................................................................................... 7

1-4. DMD Interface Board Front................................................................................................. 8

1-5. DMD Interface Board Back................................................................................................. 8

2-1. DMD Flex Cable Installation Alignment................................................................................... 9

2-2. Installation of PGU Cables into Formatter Board ...................................................................... 10

2-3. Installation of LED and Photodiode Cables into PGU................................................................. 11

2-4. HDMI Cable Install ......................................................................................................... 11

2-5. Power Cable Install ........................................................................................................ 12

2-6. Combiner Glass Install..................................................................................................... 12

2-7. Securing Combiner......................................................................................................... 13

2-8. PC Video Output Mode Configuration................................................................................... 14

2-9. Example of C-HUD Displaying Video Content ......................................................................... 14

List of Tables

1-1. Performance Specifications ................................................................................................ 5

1-2. Power Specifications ........................................................................................................ 5

1-3. Temperature Specifications ................................................................................................ 5

1-4. DLP3030CHUDQ1EVM Kit Contents ..................................................................................... 6

2-1. Required Tools and Items .................................................................................................. 9

2-2. External Input Resolutions ................................................................................................ 15

2-3. Power Input Connector.................................................................................................... 18

2-4. SPI Communication Connector........................................................................................... 18

2-5. Photodiode Connector..................................................................................................... 18

2-6. LED Power Connector..................................................................................................... 18

2-7. MCU JTAG Connector..................................................................................................... 19

2-8. LED Thermistor Connector................................................................................................ 19

4DLPU065–November 2017

Submit Documentation Feedback

Introduction

Chapter 1

DLPU065–November 2017

Introduction

1.1 EVM Overview

The DLP3030CHUDQ1EVM evaluation module (EVM) is a wide field of view (WFOV) combiner head-up

display (C-HUD) table top demonstrator. This C-HUD demonstrator enables Tier 1 and OEM customers to

demonstrate a state of the art, high-performance WFOV HUD powered by TI DLP®technology. The C-

HUD is based on the DLP3030-Q1 chipset and DLP3030-Q1 PGU.

The EVM runs off of a nominal 12-V supply (not provided; see Section 2.3 for details) and accepts an

HDMI input video interface.

Additionally, TI provides a software tool that can communicate via a Microsoft®Windows®PC's USB port

for brightness and display mode configuration.

1.2 Warnings

CAUTION

Caution Hot surface.

Contact may cause burns.

Do not touch.

www.ti.com

Specifications

DLPU065–November 2017

Introduction

1.3 Specifications

(1) System was calibrated at 25°C and Vbatt at 12 V.

Table 1-1. Performance Specifications

Resolution WVGA (864 × 480) Dimming Range >5,000:1(1)

Field of View 12° × 3.6° Contrast Ratio >1,000:1 (FoFo)

Virtual Image Distance 2.5 m Color Gamut 125% NTSC(1)

Virtual Image Size 487 mm × 155 mm Overall Dimensions Roughly 300 mm × 275 mm × 250 mm

Eyebox Size 130 mm × 60 mm Power Input 6-18 VDC

Max Brightness (Eyebox) >34,000 cd/m2(1) Video Input HDMI

PGU Lumens >70 Lumens(1) Control Interface SPI (via Cheetah USB to SPI adapter)

(1) This value defines minimum white-balanced brightness setting. With LEDs off, power consumption drops to 1.44 W.

(2) Produces 15,000 cd/m2on DLP3030CHUDQ1EVM or 32 lumens on DLP3030PGUQ1EVM.

(3) Produces 34,000 cd/m2on DLP3030CHUDQ1EVM or 70 lumens on DLP3030PGUQ1EVM.

Table 1-2. Power Specifications

PARAMETER TEST CONDITIONS MIN NOM MAX UNIT

Vbatt Input Voltage 6 12 18 V

Power Consumption Q8WP RGB LEDs operating at 70/30 DMD duty cycle 2(1) 5.6(2) 13.9(3) W

Table 1-3. Temperature Specifications

PARAMETER MIN NOM MAX UNIT

Operational Ambient Temperature Range –40 105 °C

Storage Ambient Temperature Range –40 105 °C

12 3 4

78 9

Kit Contents

www.ti.com

6DLPU065–November 2017

Submit Documentation Feedback

Introduction

1.4 Kit Contents

Table 1-4. DLP3030CHUDQ1EVM Kit Contents

ITEM NO. ITEM

1 DMD Interface Board

2 Formatter Controller Board

3 Total Phase Cheetah USB to SPI Adapter

4 3-in DMD Ribbon Cable (2×)

5 Photodiode Cable

6 RGB LED Power and Thermistor Cable

7 Cheetah SPI Interface Cable

8 Power Input Cable

9 6-ft HDMI cable

10 WFOV HUD PGU

11 5-mm M3 Screws (4×)

12 1-ft HDMI cable extender

13 HDMI Panel Mount Connector

14 Combiner HUD Optics

15 12-mm M3 Screws (2×)

16 10-mm M4 Screws (4×)

17 Combiner Glass Mount

18 Combiner Glass

Figure 1-1. DLP3030CHUDQ1EVM Kit Contents

LED Power

Connector

Photo Diode

Connector

DMD FFC

Connector

Power Good

Indicator LED SPI Communicator

Connector

Power Input

Connector

Type A HDMI

Connector

www.ti.com

Electronic Boards Overview

DLPU065–November 2017

Introduction

1.5 Electronic Boards Overview

Figure 1-2. Formatter Controller Board Front

Figure 1-3. Formatter Controller Board Back

Electronic Boards Overview

www.ti.com

8DLPU065–November 2017

Submit Documentation Feedback

Introduction

Figure 1-4. DMD Interface Board Front

Figure 1-5. DMD Interface Board Back

DLPU065–November 2017

Getting Started

Chapter 2

DLPU065–November 2017

Getting Started

2.1 Section Overview

This section will provide step-by-step instructions to display an image using the EVM. Section 2.2 contains

EVM physical assembly instructions, Section 2.3 contains electrical power-up instructions, Section 2.4

contains EVM GUI installation and use, and Section 2.5 contains connector pinout tables.

2.2 Kit Assembly

Table 2-1. Required Tools and Items

ITEM NO. ITEM

1 M3 Allen Wrench

2 M4 Allen Wrench

3 Phillips Screw Driver

4 12 V @ 3-A Power Supply

2.2.1 Instructions to Assemble EVM

• Install the DMD Ribbon Cable between the DMD Board and the Formatter Board, ensuring that it is

inserted evenly across the entire connector, as shown on the right in Figure 2-1.

Note: This connector has a latch that must be lifted when installing the cable and then clamped down

to secure its position.

Figure 2-1. DMD Flex Cable Installation Alignment

Kit Assembly

www.ti.com

10 DLPU065–November 2017

Submit Documentation Feedback

Getting Started

• Install the LED Power Cable into the Formatter Board using the cable connector with the red, green

and blue wires.

• Install the LED Thermistor Cable, part of the LED Power Cable, into the Formatter Board using the

cable connector with the three brown wires.

• Install the Photodiode Cable to the Formatter Board.

CAUTION

Please ensure that the LED Power and LED Thermistor cables are installed

into the proper connector, as shown in Figure 2-2. Improper installation may

cause damage to the LEDs.

Figure 2-2. Installation of PGU Cables into Formatter Board
