User's Guide

SNAA068B–July 2009–Revised May 2013

AN-1966 LMH2190 Evaluation Board

1 General Description

The evaluation board (Figure 1) is designed to help the evaluation of the LMH2190 Quad Channel 26 MHz

Clock Tree Driver with I2C™ interface. The LMH2190 provides a digital system clock to peripheral devices

in mobile handsets. It provides a solution to clocking issues such as limited drive capability for fanout or

longer traces, protection of the master clock from varying loads and frequency pulling effects, isolation

buffering from noisy modules, and crosstalk isolation. It has very low phase noise which enables it to drive

sensitive modules such as Wireless LAN and Bluetooth.

Figure 1. LMH2190 Evaluation Board

I2C is a trademark of Philips Semiconductor Corp.

All other trademarks are the property of their respective owners.

SNAA068B–July 2009–Revised May 2013 AN-1966 LMH2190 Evaluation Board

Basic Operation

www.ti.com

2 Basic Operation

The LMH2190 evaluation board is designed such that it gives maximum flexibility in evaluating the

LMH2190 in various configurations. The schematic, Bill of material and board layout can be found at the

end of this document. In the following sections a description will be given on how to setup the

measurement bench. For the factory default jumper setting, refer to Section 3.

2.1 Supply

The common ground of the evaluation board is connected via Connector CON3. The LMH2190 is

powered via VBAT (CON2). The typical supply voltage for VBAT is 3.5V, but it may range from 2.5V to 5.5V.

In the factory default configuration the ENABLE voltage is supplied externally via connector CON7 and

should be 1.8V. Three on-board buffers are separately powered through Connector CON18 (+5V) and

CON 19 (-5V). If they are not used for evaluation they can be left un-powered when jumper locations J7,

J16 and J17 are open.

2.2 Applying Clock

In factory default configuration the clock to the LMH2190 is supplied by the on-board TCXO. Alternatively

the clock can be applied externally either in DC mode via CON12 or in AC mode via CON10. The clock

source can be selected by J13. Note that for DC mode, the I2C registers also need to be changed.

The LMH2190 distributes the clock to a maximum of 4 outputs, CLK1 to CLK4, that are accessible via

CON1, CON5, CON6 and CON8. An additional capacitive load can be connected between CLK to GND to

simulate the load in the actual application via J1, J2, J14 and J15.

There is also a possibility to measure the clocks as well as the TCXO clock via a buffer. This buffer can

drive 50 ohm making them excellent for connecting to measurement equipment, like a Signal Source

Analyzer. This analyzer can for instance measure the Phase noise and Jitter. The three buffers can be

connected to the clock's by J7, J16 and J17. When the buffers are not used it is recommended to

disconnect them, since they increase the capacitive load on the clocks slightly.

2.3 Clock Request

The CLK's can be enabled by their appropriate CLK_REQ's. The CLK_REQ pin can be connected to a

logic Low or High level via J6, J8, J10 and J12. The level of the Logic High can be selected by J5, either

VOUT, VBAT or VENABLE. Instead of via the jumpers, the CLK_REQ's can also be controlled via CON9,

CON11, CON13 and CON14. Make sure that the jumpers are removed in this case. In factory default

configuration only CLK1 is enabled. The other clocks can simply be enabled by placing the jumper on J8,

J10 and J12 in the other position.

2.4 I2C Interface

The LMH2190 can be controlled by an I2C host device that can be connected via J4. It can configure the

registers inside the LMH2190 to change the default configuration. According to the I2C specification one

set of pull-up resistors needs to be present on the I2C bus. If they are not present elsewhere in the system

they can be connected on the evaluation board via J19. The evaluation board can be used without I2C

host device connected. It will then work in its default configuration.

3 Configuration

The LMH2190 evaluation board can be configured via jumper settings. An overview of the various jumper

positions on the board is given in Figure 2. The settings of these jumpers and their functions are listed in

Table 1.

2AN-1966 LMH2190 Evaluation Board SNAA068B–July 2009–Revised May 2013

Submit Documentation Feedback

www.ti.com

Configuration

Figure 2. Jumper Positions

Table 1. Jumper and Header Overview (1)

Jumper Function Jumper Desription

Position

J1 CLK1 Capacitive load 1-2 Connects 10 pF from CLK1 to GND

3-4 Connects 22 pF from CLK1 to GND

5-6 Connects 33 pF from CLK1 to GND

7-8 Connects 47 pF from CLK1 to GND

J2 CLK2 Capacitive load 1-2 Connects 10 pF from CLK2 to GND

3-4 Connects 22 pF from CLK2 to GND

5-6 Connects 33 pF from CLK2 to GND

7-8 Connects 47 pF from CLK2 to GND

J3 ENABLE 1-2 ENABLE = VOUT

3-4 ENABLE is supplied by CON7

5-6 ENABLE is supplied by I2C conector J4 pin 4

7-8 ENABLE = GND

J4 I2C Header Header to connect I2C signals

J5 CLK_REQx Logic High 1-2 CLK_REQxHIGH = VOUT

Level 3-4 CLK_REQxHIGH = VBAT

5-6 CLK_REQxHIGH = VENABLE

(1) Bold face jumper settings refer to the factory default configuration.

SNAA068B–July 2009–Revised May 2013 AN-1966 LMH2190 Evaluation Board

Configuration

www.ti.com

Table 1. Jumper and Header Overview (1) (continued)

Jumper Function Jumper Desription

Position

J6 CLK_REQ1 Open CLK_REQ1 can be controlled externally via CON9

1-2 CLK_REQ1 = GND

2-3 CLK_REQ1 = High. Level is determined by J5

J7 Connects Buffer to Open No buffer connected to measure TCXO Clock

TCXO OUT 1-2 Buffer LMH6559MA (U2) is connected to measure TCXO Clock. Buffer can

drive 50 Ohm.

J8 CLK_REQ2 Open CLK_REQ2 can be controlled externally via CON11

1-2 CLK_REQ2 = GND

2-3 CLK_REQ2 = High. Level is determined by J5

J9 TCXO Supply 1-2 TCXO is supplied by VOUT

J10 CLK_REQ3 Open CLK_REQ3 can be controlled externally via CON13

1-2 CLK_REQ3 = GND

2-3 CLK_REQ3 = High. Level is determined by J5

J11 SCLK_REQ Pull Up / Open No Pull-up or Pull-down connected to SCLK_REQ

Pull Down 1-2 100 kΩPull-down resistor connected from SCLK_REQ to GND

2-3 100 kΩPull-up resistor connected from SCLK_REQ to VBAT

J12 CLK_REQ4 Open CLK_REQ4 can be controlled externally via CON14

1-2 CLK_REQ4 = GND

2-3 CLK_REQ4 = High. Level is determined by J5

J13 SCLK_IN Source 1-2 SCLK_IN is connected to External Source, either through CON10 (AC-

Coupled) or CON12 (DC-Coupled)

3-4 SCLK_IN is connected to on-board TCXO

J14 CLK3 Capacitive load 1-2 Connects 10 pF from CLK3 to GND

3-4 Connects 22 pF from CLK3 to GND

5-6 Connects 33 pF from CLK3 to GND

7-8 Connects 47 pF from CLK3 to GND

J15 CLK4 Capacitive load 1-2 Connects 10 pF from CLK4 to GND

3-4 Connects 22 pF from CLK4 to GND

5-6 Connects 33 pF from CLK4 to GND

7-8 Connects 47 pF from CLK4 to GND

J16 Connects Buffer to Open No buffer connected to CLK1/2

CLK1/2 1-2 Buffer LMH6559MA (U3) is connected to measure CLK2. Buffer can drive

50 Ohm.

2-3 Buffer LMH6559MA (U3) is connected to measure CLK1. Buffer can

drive 50 Ohm.

J17 Connects Buffer to Open No buffer connected to measure TCXO Clock

CLK3/4 1-2 Buffer LMH6559MA (U4) is connected to measure CLK4. Buffer can drive

50 Ohm.

2-3 Buffer LMH6559MA (U4) is connected to measure CLK3. Buffer can drive

50 Ohm.

J18 TCXO Supply Header Header can be used to provide an (external) TCXO supply instead of the

on-board VOUT supply. Header J9 should be open in this case.

J19 I2C Pull-up Resistors Open No Pull-up resistor connected to SDA and SCL line. Elsewhere should be

pull-up resistors present on SDA and SCL

1-2 Pull-up resistors connected on SDA and SCL

J20 SCLK_REQ Header Header to monitor SCLK_REQ.

J21 Future purpose Not Assembled

4AN-1966 LMH2190 Evaluation Board SNAA068B–July 2009–Revised May 2013

Submit Documentation Feedback

SCLK_IN

CLK1

CLK2

CLK3

CLK4

TIME (5 ns/DIV)

0.5 V/DIV

SCLK_IN

CLK1

LMH2190TM

Eval Board

VBAT

GND

+3.5V

Power

Supply

Oscilloscope

Volt Meter

+1.8V ENABLE

VOUT

CLK1

CLK2

CLK3

CLK4

GND

Power

Supply

(Optional)

+5V

-5V V+

V-

GND

CON3

CON2

CON7 CON4

CON18

CON19

TP1

TP5

TP9

TP11

SCLK_IN

J13-4

www.ti.com

Measurement Setup

4 Measurement Setup

The performance of the LMH2190 can be measured with the setup shown in Figure 3.

Figure 3. Measurement Setup

The +5V and -5V to connector CON18 and CON19 don't need to be applied unless buffers U2, U3 and/or

U4 are used for the measurements. In factory default configuration, only CLK1 is enabled. With an

oscilloscope and Hi-impedance probes the TCXO (J13–4) and CLK1 (TP1) can be measured. This should

result in a measurement as depicted in Figure 4. Other CLK's can be enabled by connecting the

appropriate CLK_REQ to VBAT (J8, J10, J12). A schematic representation of the TCXO and all the CLKs is

depicted in Figure 5. It can be seen that the CLK's are skewed from each other.

Figure 4. CLK1 Response, CL= 22 pF Figure 5. Clock Outputs Skewed

SNAA068B–July 2009–Revised May 2013 AN-1966 LMH2190 Evaluation Board

Schematic

www.ti.com

5 Schematic

Figure 6. Evaluation Board Schematic

6 Bill of Material

The Bill of Material (BOM) of the evaluation board is in Table 2.

Table 2. Bill of Material

Designator Description Comment

C1, C4, C11, C13 0603 Capacitor 10 pF

C2, C5, C19, C22 0603 Capacitor 22 pF

C3, C8, C20, C23 0603 Capacitor 33 pF

C6 Case A Capacitor NC

C7, C28, C31 Case A Capacitor 10 µF

C9, C10, C25, C29, C30 0603 Capacitor 100 nF

C12, C16 0603 Capacitor 10 nF

C14, C15 0603 Capacitor 470 pF

C17, C18, C21, C24 0603 Capacitor 47 pF

C26, R9, R10, R13, R15 0603 Capacitor / Resistor NC

C27 Case A Capacitor 2.2 µF

CON1 Connector SMA

6AN-1966 LMH2190 Evaluation Board SNAA068B–July 2009–Revised May 2013

Submit Documentation Feedback

www.ti.com

Board Layout

Table 2. Bill of Material (continued)

Designator Description Comment

CON2 Connector Banana

CON3 Connector Banana

CON4 Connector Banana

CON5 Connector SMA

CON6 Connector SMA

CON7 Connector Banana

CON8 Connector SMA

CON9 Connector SMA

CON10 Connector SMA

CON11 Connector SMA

CON12 Connector SMA

CON13 Connector SMA

CON14 Connector SMA

CON15 Connector SMA

CON16, CON17 Connector SMA

CON18 Connector Banana

CON19 Connector Banana

J1, J2, J14, J15 Header 2x4

J3 Header 2x4

J4 Header 2x5

J21 Header 2x7

J5 Header 2x3

J6, J8, J10, J11, J12 Header 1x3

J7, J9, J19, J20 Header 1x2

J13 Header 2x2

J16, J17 Header 1x3

J18 Header 1x2

R1, R2, R3, R4, R5, R6, R12, R17, R18, R19 0603 Resistor 0Ω

R7, R11, R14 0603 Resistor 100 kΩ

R8 0603 Resistor 4.7 kΩ

R16 0805 Resistor 4.7 kΩ

R20, R21, R22 0603 Resistor 51Ω

U1 DSBGA LMH2190

U2, U3, U4 SOIC LMH6559

X1 small TCXO 26.0MHz

7 Board Layout

As with any other device, careful attention must be paid to the board layout. If the board is not properly

designed, the performance of the device can be less than might be expected. Especially the input clock

trace (SCLK_IN) and output traces (CLK1/2/3/4) should be as short as possible to reduce the capacitive

load observed by the clock outputs. Also proper decoupling close to the device is necessary. Beside a

capacitor in the µF range, a capacitor of 100 nF on VBAT and VOUT is recommended close to device. The

equivalent series resistance (ESR) of the capacitors should be sufficiently low. A standard capacitor is

usually adequate. The copper layers of the evaluation board are depicted in Figure 9,Figure 10, and

Figure 11.

SNAA068B–July 2009–Revised May 2013 AN-1966 LMH2190 Evaluation Board

Board Layout

www.ti.com

Figure 7. Component Locations Top Side

8AN-1966 LMH2190 Evaluation Board SNAA068B–July 2009–Revised May 2013

Submit Documentation Feedback

www.ti.com

Board Layout

Figure 8. Component Locations Bottom Side (Bottom View)

SNAA068B–July 2009–Revised May 2013 AN-1966 LMH2190 Evaluation Board

Board Layout

www.ti.com

Figure 9. Top Layer of Evaluation Board

Figure 10. Inner Layer of Evaluation Board

Figure 11. Bottom Layer of Evaluation Board

10 AN-1966 LMH2190 Evaluation Board SNAA068B–July 2009–Revised May 2013

Submit Documentation Feedback

Tabla de contenidos

Otros manuales de Placa madre de Texas Instruments

Texas Instruments

Texas Instruments CC2538-CC2592 Manual de usuario

Texas Instruments

Texas Instruments TDC7201-ZAX-EVM Manual de usuario

Texas Instruments

Texas Instruments MSP-EXP432P401R Manual de usuario

Texas Instruments

Texas Instruments SN65LVCP22 Manual de usuario

Texas Instruments

Texas Instruments Chipset TRF2436EVM Manual de usuario

Texas Instruments

Texas Instruments DRV8432EVM Manual de usuario

Texas Instruments

Texas Instruments TLC6C5724-Q1 Manual de usuario

Texas Instruments

Texas Instruments Stellaris LM3S2965 Manual de usuario

Texas Instruments

Texas Instruments TPS563300EVM-226 Manual de usuario

Texas Instruments

Texas Instruments ADS62P EVM Series Manual de usuario

Texas Instruments

Texas Instruments OPA818DRGEVM Manual de usuario

Texas Instruments

Texas Instruments TUSB3210 Manual de usuario

Texas Instruments

Texas Instruments UCD9080EVM Manual de usuario

Texas Instruments

Texas Instruments BQ79600-Q1 Manual de usuario

Texas Instruments

Texas Instruments DP83TD510E-EVM Manual de usuario

Texas Instruments

Texas Instruments ADS8168EVM-PDK Manual de usuario

Texas Instruments

Texas Instruments DS80PCI810EVM Manual de usuario

Texas Instruments

Texas Instruments TAS5514BQ1DKDEVM Manual de usuario

Texas Instruments

Texas Instruments AN-2150 LM3450A Manual de usuario

Texas Instruments

Texas Instruments DS250DF230EVM Manual de usuario

Texas Instruments

Texas Instruments ADC161S626 Manual de usuario

Texas Instruments

Texas Instruments TIDA-050026-23881 Guía

Texas Instruments

Texas Instruments XIO2200 Manual de usuario

Texas Instruments

Texas Instruments LMR36506MSCEVM Manual de usuario

Manuales populares de Placa madre de otras marcas

DFI

DFI SD170 Manual de usuario

ASROCK

ASROCK ROMED8-2T Manual de usuario

Asus

Asus P2L97A Manual de usuario

Winmate

Winmate IC70 Manual de usuario

Asus

Asus MES-B Manual de usuario

Grantech

Grantech SYS8F377VGGA-3OMN Manual de usuario

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manual de usuario

Gigabyte

Gigabyte GA-9IVDT Manual de usuario

Commell

Commell MS-C73 Manual de usuario

IBT Technologies

IBT Technologies MB860 Manual de usuario

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manual de usuario

Biostar

Biostar M7VIT Bravo Instrucciones de funcionamiento e instalación

Intel

Intel D33217CK Manual de usuario

Asus

Asus F1A55-M LX PLUS R2.0 Manual de usuario

EPC

EPC EPC9147C Manual de usuario

Asus

Asus EX-B760M-V5 D4 Manual de usuario

EPOX

EPOX MU-8KHA0010 Manual de usuario

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manual de usuario
