Texas Instruments AM1810 Manual de usuario

For more information on the AM1810 processor

or to download the latest software, please visit:

www.ti.com/am1810.

For support questions, please contact:

support.ti.com or www.ti.com/e2e.

Important Notice: The products and services of Texas Instruments Incorporated and its

subsidiaries described herein are sold subject to TI’s standard terms and conditions of sale.

Customers are advised to obtain the most current and complete information about TI prod-

ucts and services before placing orders. TI assumes no liability for applications assistance,

customer’s applications or product designs, software performance, or infringement of pat-

ents. The publication of information regarding any other company’s products or services

does not constitute TI’s approval, warranty or endorsement thereof.

Trademarks in this issue: The platform bar and Sitara are trademarks of Texas

Instruments. All other trademarks are the property of their respective owners.

SPRT591

513310-0001 Rev A

Troubleshooting

• If you are having trouble accessing the demos on

the included SD card, try the following:

•

•Verify that the AM1810 SOM is securely

connected to the baseboard.

•

•Verify that all the DIP switches are set to the

OFF position.

AM1810 Evaluation Module (EVM)

Quick Start Guide

For more information:

www.ti.com/am1810

Printed in U.S.A. by (Printer, City, State)

Next steps

To prepare your workstation

for software development,

power off the kit, remove

the SD card and insert into

the included USB SD card

reader.

The following items will be used in this Quick Start Guide.

Baseboard, AM1810 SOM-M1,

4.3” LCD, PROFIBUS Daughter Card

(pre-assembled)

Ethernet

cable

USB SD

card reader

Important baseboard locations

(Numbers correspond to the steps on the right.)

Serial

cable

SD card

(Linux™

SDK)

Power supply & cord

(use power cord

speciﬁc to

your region)

* See back of board

Sitara™

514232-0001A

SPRW210

AM1810 EVM

Linux SDK

Quick start setup (OS demo)

2Connect the supplied

serial cable to the

UART-1/2 DB-9

connector. Connect the

other end of the cable to

a PC or workstation

3Connect Ethernet cable to

the RJ-45 jack on the

board. Connect the other

end to a router or Ethernet

switch

1Verify all DIP switches are

set to OFF

6Switch power on

7You are now ready to

explore the application

launcher which contains

various example applica-

tions and demos. Matrix

GUI shown

4Insert the Linux SDK SD

card in the AM1810 EVM

SD slot on back of board 5Connect power to

baseboard

Congratulations on your purchase of the AM1810 EVM and welcome to the Quick Start Guide. This guide

is designed to help you through the initial setup of your EVM. The EVM provides a product-ready hardware

and software platform for evaluating the functionality of the Texas Instruments (TI) AM1810 processor.

Connect the USB SD card

reader into your Linux™-based

PC, locate the START HERE

folder on the SD card and

view setup.htm. The setup.

htm ﬁle includes the software

development guide which will

provide information to guide

you through the software

installation.

(Continued on following page)
