Texas Instruments ADS8364EVM Manual de usuario

ADS8364EVM

April 2002 Data Acquisition Products

User’s Guide

SLAU084

IMPORTANT NOTICE

Texas Instruments Incorporated and its subsidiaries (TI) reserve the right to make corrections, modifications,

enhancements, improvements, and other changes to its products and services at any time and to discontinue

any product or service without notice. Customers should obtain the latest relevant information before placing

orders and should verify that such information is current and complete. All products are sold subject to TI’s terms

and conditions of sale supplied at the time of order acknowledgment.

TI warrants performance of its hardware products to the specifications applicable at the time of sale in

accordance with TI’s standard warranty. Testing and other quality control techniques are used to the extent TI

deems necessary to support this warranty. Except where mandated by government requirements, testing of all

parameters of each product is not necessarily performed.

TI assumes no liability for applications assistance or customer product design. Customers are responsible for

their products and applications using TI components. To minimize the risks associated with customer products

and applications, customers should provide adequate design and operating safeguards.

TI does not warrant or represent that any license, either express or implied, is granted under any TI patent right,

in which TI products or services are used. Information published by TI regarding third-party products or services

does not constitute a license from TI to use such products or services or a warranty or endorsement thereof.

Use of such information may require a license from a third party under the patents or other intellectual property

of the third party, or a license from TI under the patents or other intellectual property of TI.

Reproduction of information in TI data books or data sheets is permissible only if reproduction is without

alteration and is accompanied by all associated warranties, conditions, limitations, and notices. Reproduction

of this information with alteration is an unfair and deceptive business practice. TI is not responsible or liable for

such altered documentation.

Resale of TI products or services with statements different from or beyond the parameters stated by TI for that

product or service voids all express and any implied warranties for the associated TI product or service and

is an unfair and deceptive business practice. TI is not responsible or liable for any such statements.

Mailing Address:

Texas Instruments

Post Office Box 655303

Dallas, Texas 75265

EVM IMPORTANT NOTICE

Texas Instruments (TI) provides the enclosed product(s) under the following conditions:

This evaluation kit being sold by TI is intended for use for ENGINEERING DEVELOPMENT OR EVALUATION

PURPOSES ONLY and is not considered by TI to be fit for commercial use. As such, the goods being provided

may not be complete in terms of required design-, marketing-, and/or manufacturing-related protective

considerations, including product safety measures typically found in the end product incorporating the goods.

As a prototype, this product does not fall within the scope of the European Union directive on electromagnetic

compatibility and therefore may not meet the technical requirements of the directive.

Should this evaluation kit not meet the specifications indicated in the EVM User’s Guide, the kit may be returned

within 30 days from the date of delivery for a full refund. THE FOREGOING WARRANTY IS THE EXCLUSIVE

WARRANTY MADE BY SELLER TO BUYER AND IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED,

IMPLIED, OR STATUTORY, INCLUDING ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR ANY

PARTICULAR PURPOSE.

The user assumes all responsibility and liability for proper and safe handling of the goods. Further, the user

indemnifies TI from all claims arising from the handling or use of the goods. Please be aware that the products

received may not be regulatory compliant or agency certified (FCC, UL, CE, etc.). Due to the open construction

of the product, it is the user’s responsibility to take any and all appropriate precautions with regard to electrostatic

discharge.

EXCEPT TO THE EXTENT OF THE INDEMNITY SET FORTH ABOVE, NEITHER PARTY SHALL BE LIABLE

TO THE OTHER FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES.

TI currently deals with a variety of customers for products, and therefore our arrangement with the user is not

exclusive.

TI assumes no liability for applications assistance, customer product design, software performance, or

infringement of patents or services described herein.

Please read the EVM User’s Guide and, specifically, the EVM Warnings and Restrictions notice in the EVM

User’s Guide prior to handling the product. This notice contains important safety information about temperatures

and voltages. For further safety concerns, please contact the TI application engineer.

Persons handling the product must have electronics training and observe good laboratory practice standards.

No license is granted under any patent right or other intellectual property right of TI covering or relating to any

machine, process, or combination in which such TI products or services might be or are used.

Mailing Address:

Texas Instruments

Post Office Box 655303

Dallas, Texas 75265

EVM WARNINGS AND RESTRICTIONS

It is important to operate this EVM within the input voltage range of ±12 VDC and output

voltage range of 3.3 VDC and 5 VDC.

Exceeding the specified input range may cause unexpected operation and/or irreversible

damage to the EVM. If there are questions concerning the input range, please contact a TI

field representative prior to connecting the input power.

Applying loads outside of the specified output range may result in unintended operation and/or

possible permanent damage to the EVM. Please consult the EVM User’s Guide prior to

connecting any load to the EVM output. If there is uncertainty as to the load specification,

please contact a TI field representative.

During normal operation, some circuit components may have case temperatures greater than

30°C. The EVM is designed to operate properly with certain components above 40°C as long

as the input and output ranges are maintained. These components include but are not limited

to linear regulators, switching transistors, pass transistors, and current sense resistors. These

types of devices can be identified using the EVM schematic located in the EVM User’s Guide.

When placing measurement probes near these devices during operation, please be aware

that these devices may be very warm to the touch.

Mailing Address:

Texas Instruments

Post Office Box 655303

Dallas, Texas 75265

Information About Cautions and Warnings

iii

Preface

Read This First

About This Manual

This users guide describes the characteristics, operation, and use of the

ADS8364EVM 16-bit parallel analog-to-digital converter evaluation board. A

complete circuit description as well as schematic diagram is included.

How to Use This Manual

This document contains the following chapters:

Chapter 1—EVM Overview

Chapter 2—Analog Interface

Chapter 3—Digital Interface

Chapter 4—Power Supply

Chapter 5—Initial Setup of the Board

Chapter 6—EVM Schematic

Information About Cautions and Warnings

This book may contain cautions and warnings.

This is an example of a caution statement.

A caution statement describes a situation that could potentially

damage your software or equipment.

This is an example of a warning statement.

A warning statement describes a situation that could potentially

cause harm to you.

Related Documentation From Texas Instruments

The information in a caution or a warning is provided for your protection.

Please read each caution and warning carefully.

Related Documentation From Texas Instruments

To obtain a copy of any of the following TI documents, call the Texas

Instruments Literature Response Center at (800) 477-8924 or the Product

Information Center (PIC) at (972) 644-5580. When ordering, please identify

this booklet by its title and literature number. Updated documents can also be

obtained through our website at www.ti.com.

Data Sheets Literature Number

ADS8364 SBAS219

OPA2132 SBOS054

OPA2350 SBOS099

TPS2104 SLVS235

SN74CBT3257 SCDS017

FCC Warning

This equipment is intended for use in a laboratory test environment only. It

generates, uses, and can radiate radio frequency energy and has not been

tested for compliance with the limits of computing devices pursuant to subpart

J of part 15 of FCC rules, which are designed to provide reasonable protection

against radio frequency interference. Operation of this equipment in other

environments may cause interference with radio communications, in which

case the user at his own expense will be required to take whatever measures

may be required to correct this interference.

Contents

1 EVM Overview 1-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2 Analog Interface 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.1 Dual Supply—Input Buffer 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.2 Bipolar Inputs 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.3 Analog and Digital 5-V Supplies 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.4 Output Buffer 3.3-V Supply 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.5 Reference Voltage 2-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3 Digital Interface 3-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.1 Control Signals 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.2 Bus Width 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.3 External Clock 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4 Power Supply 4-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.1 Analog Front-End Supply 4-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.2 ADC Power Supply 4-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.3 Digital Interface Supply 4-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5 Initial Setup of the Board 5-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6 EVM Schematic 6-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Contents

Figures

2-1 ADS8364EVM Schematic—Analog Input Section 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2-2 Digital Buffer Voltage Selection 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2-3 ADS8364EVM Reference Circuit 2-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4-1 Analog Front-End Supply 4-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4-2 ADC Power-Supply Input 4-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4-3 Digital Buffer Alternate Supply Input 4-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Tables

2-1 Typical Analog Input Buffer Circuit Values (A0 Shown) 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3-1 Address Map 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5-1 Factory Defaults—Analog Input Buffers (A0 Shown) 5-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1-1

EVM Overview

The ADS8364 is a high-speed, low power, dual 16-bit A/D converter that

operates from independent 5-V AVDD and DVDD supplies. The digital output

is delivered through a built-in buffer circuit that can be powered from DVDD or

separate 2.7-V to 5.25-V (BVDD) sources. This allows for flexibility when

designing within mixed voltage environments.

The six fully differential sample and hold circuits are divided into three pairs (A,

B, and C). Each pair of channels has a hold signal (HOLDA, HOLDB, and

HOLDC) which, when strobed together, allows simultaneous sampling on all

six analog inputs. The part accepts an analog input voltage in the range of

–VREF to +VREF, centered on the internal 2.5-V reference. The part also accepts

bipolar input ranges when a level shift circuit is used in the analog front-end

circuitry (see Figure 2-1).

Conversion time for the ADS8364 is 3.2 µs when a 5-MHz external clock is

used. The corresponding acquisition time is 0.8 µs. To achieve the maximum

output rate (250 KSPS), the read function can be performed during the start

of the next conversion.

The ADS8364 EVM includes the following features:

Full-featured evaluation board for the ADS8364 250-kHz, 16-bit,

6-channel simultaneous sampling analog-to-digital converter

Analog inputs can be configured as single-ended or differential

Direct connection to C5000 and C6000 DSK platforms through the 80-pin

interface connectors

Built-in reference

High-speed parallel interface

Chapter 1

1-2

Tabla de contenidos

Otros manuales de Placa madre de Texas Instruments

Texas Instruments

Texas Instruments DAC7568EVM Manual de usuario

Texas Instruments

Texas Instruments LMK5B33414EVM Manual de usuario

Texas Instruments

Texas Instruments LP592201EVM Manual de usuario

Texas Instruments

Texas Instruments ADS9120EVM-PDK Manual de usuario

Texas Instruments

Texas Instruments HSS-MOTHERBOARDEVM Manual de usuario

Texas Instruments

Texas Instruments DEM-PCM2912 EVM Manual de usuario

Texas Instruments

Texas Instruments INA185EVM Manual de usuario

Texas Instruments

Texas Instruments AM64 GP EVM Series Manual de usuario

Texas Instruments

Texas Instruments TUSB6020EVM Manual de usuario

Texas Instruments

Texas Instruments ADS4449 EVM Manual de usuario

Texas Instruments

Texas Instruments TPD E05U06-Q1 Series Manual de usuario

Texas Instruments

Texas Instruments SRC4194EVM Manual de usuario

Texas Instruments

Texas Instruments TPS25980EVM Manual de usuario

Texas Instruments

Texas Instruments BQ25170EVM Manual de usuario

Texas Instruments

Texas Instruments bq20z70EVM-001 Manual de usuario

Texas Instruments

Texas Instruments TUSB522PEVM Manual de usuario

Texas Instruments

Texas Instruments FDC2114 Manual de usuario

Texas Instruments

Texas Instruments BQ25616J Manual de usuario

Texas Instruments

Texas Instruments TPS65265EVM-705 Manual de usuario

Texas Instruments

Texas Instruments AFE882H1 Manual de usuario

Texas Instruments

Texas Instruments TLV62080 Manual de usuario

Texas Instruments

Texas Instruments Modular MSOP8 EVM Manual de usuario

Texas Instruments

Texas Instruments MCF8315EVM Manual de usuario

Texas Instruments

Texas Instruments TPS54110EVM-044 Manual de usuario

Manuales populares de Placa madre de otras marcas

DFI

DFI SD170 Manual de usuario

ASROCK

ASROCK ROMED8-2T Manual de usuario

Asus

Asus P2L97A Manual de usuario

Winmate

Winmate IC70 Manual de usuario

Asus

Asus MES-B Manual de usuario

Grantech

Grantech SYS8F377VGGA-3OMN Manual de usuario

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manual de usuario

Gigabyte

Gigabyte GA-9IVDT Manual de usuario

Commell

Commell MS-C73 Manual de usuario

IBT Technologies

IBT Technologies MB860 Manual de usuario

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manual de usuario

Biostar

Biostar M7VIT Bravo Instrucciones de funcionamiento e instalación

Intel

Intel D33217CK Manual de usuario

Asus

Asus F1A55-M LX PLUS R2.0 Manual de usuario

EPC

EPC EPC9147C Manual de usuario

Asus

Asus EX-B760M-V5 D4 Manual de usuario

EPOX

EPOX MU-8KHA0010 Manual de usuario

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manual de usuario
