Preface

Read This First

About This Manual

This user’s guide describes the characteristics, operation, and use of the

DAC7731 evaluation module. It covers all pertinent areas involved in properly

using this EVM board along with the devices that it supports. The physical PCB

layout, schematic diagram, and circuit descriptions are included.

How to Use This Manual

This document contains the following chapters:

Chapter 1—EVM Overview

Chapter 2—PCB Design and Performance

Chapter 3—EVM Operation

Information About Cautions and Warnings

This book may contain cautions and warnings.

This is an example of a caution statement.

A caution statement describes a situation that could potentially

damage your software or equipment.

This is an example of a warning statement.

A warning statement describes a situation that could potentially

cause harm to you.

The information in a caution or a warning is provided for your protection.

Please read each caution and warning carefully.

Trademarks

Related Documentation From Texas Instruments

To obtain a copy of any of the following TI documents, call the Texas

Instruments Literature Response Center at (800) 477-8924 or the Product

Information Center (PIC) at (972) 644-5580. When ordering, identify this

manual by its title and literature number. Updated documents can also be

obtained through our website at www.ti.com.

Data Sheets: Literature Number:

DAC7731 SBAS249

REF102 SBCS022

OPA627 SBOS165

Questions about this or other Data Converter EVM’s?

If you have questions about this or other Texas Instruments Data Converter

evaluation modules, please feel free to e-mail the Data Converter Application

Team at dataconvap[email protected].Include in the subject heading the

product you have questions or concerns with.

FCC Warning

This equipment is intended for use in a laboratory test environment only. It

generates, uses, and can radiate radio frequency energy and has not been

tested for compliance with the limits of computing devices pursuant to subpart

J of part 15 of FCC rules, which are designed to provide reasonable protection

against radio frequency interference. Operation of this equipment in other

environments may cause interference with radio communications, in which

case the user at his own expense will be required to take whatever measures

may be required to correct this interference.

Trademarks

The TI Logo is a trademark of Texas Instruments.

SPI and QSPI are trademarks of Motorola, Inc.

Contents

1 EVM Overview 1-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.1 Features 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.2 Power Requirements 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.2.1 Supply Voltage 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.2.2 Reference Voltage 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.3 EVM Basic Functions 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2 PCB Design and Performance 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.1 PCB Layout 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.2 EVM Performance 2-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.3 Bill of Materials 2-8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3 EVM Operation 3-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.1 Factory Default Settings 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.2 Host Processor Operation 3-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.2.1 Unity Gain Output 3-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.2.2 Output Gain of Two 3-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.2.3 Capacitive Load Drive 3-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.3 Jumper Setting 3-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.4 Schematic 3-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Contents

Figures

1-1 EVM Block Diagram 1-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2-1 Top Silkscreen 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2-2 Layer 1 (Top Signal Plane) 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2-3 Layer 2 (Ground Plane) 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2-4 Layer 3 (Power Plane) 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2-5 Layer 4 (Bottom Signal Plane) 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2-6 Bottom Silkscreen 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2-7 Drill Drawing 2-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2-8 DAC7731EVM Test Parameters 2-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2-9 INL and DNL Characterization Graphs 2-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Tables

2-1 Parts Lists 2-8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3-1 Factory Default Jumper Setting 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3-2 Unity Gain Output Jumper Settings 3-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3-3 Gain of Two Output Jumper Settings 3-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3-4 Capacitive Load Drive Output Jumper Settings 3-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3-5 Jumper Setting Functions 3-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1-1

EVM Overview

This chapter gives a general overview of the DAC7731 evaluation module

(EVM) and describes some of the factors that must be considered when using

the module.

Topic Page

1.1 Features 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.2 Power Requirements 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.3 EVM Basic Functions 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Chapter 1

Features

1-2

1.1 Features

This EVM features the DAC7731 digital-to-analog converter. The

DAC7731EVM is a simple evaluation module designed for a quick and easy

way to evaluate the functionality and performance of the high resolution,

single-channel, and serial input DAC. This EVM features a serial interface to

communicate with any host microprocessor or TI DSP (with SPI capability)

base system.

1.2 Power Requirements

The following sections describe the power requirements of the EVM.

1.2.1 Supply Voltage

The dc power-supply requirement for the digital section of the EVM is typically

5 V connected to the J3-1 or via J6-10 terminal (when plugged in with another

EVM board or interface card) and is referenced to ground through the J3-2

and J6-5 terminal. The dc power-supply requirement for the analog section

(VCC and VSS) of this EVM range is from 15.75 V to -15.75 V maximum. The

analog section connects through J1-3 and J1-1 respectively, or through J6-1

and J6-2 terminals and are referenced to analog ground through J1-2 and

J6-6 terminals.

The VCC supply source is also used to provide the positive rail of the external

output op amp while the negative rail can be selected between VSS and AGND

via the W5 jumper. The external op amp is installed as an option to provide

output signal conditioning or boost capacitive load drive and for other output

mode requirements.

To avoid potential damage to the EVM board, make sure that the

correct cables are connected to their respective terminals as

labeled on the EVM board.

Stresses above the maximum listed voltage ratings may cause

permanent damage to the device.

1.2.2 Reference Voltage

Although the DAC7731 has a built-in 10-V reference, an external reference

circuit is provided in the EVM board. The external reference circuit can be

isolated if the internal reference voltage is selected.

The 10-V precision voltage reference is provided to supply the external voltage

reference for the DAC through REF102, U3, via jumper W4 by shorting

pins 1 and 2. An adjustable 100-kΩpotentiometer, R11, is installed in series

with 20 kΩ, R10, to allow the user to adjust the reference voltage to its desired

settings. TP1 and TP2 are also provided, as well as J4-20, to allow the user

to connect other external reference source if the onboard reference circuit is

not desired. The external voltage reference must not exceed 10 V dc.

Tabla de contenidos

Otros manuales de Unidad de control de Texas Instruments

Texas Instruments

Texas Instruments ADS1254 Manual de usuario

Texas Instruments

Texas Instruments TPS62866 Manual de usuario

Texas Instruments

Texas Instruments SimpleLink BoosterPack BOOSTXL-CC3120MOD Manual de usuario

Texas Instruments

Texas Instruments LMG352 EVM-04 Series Manual de usuario

Texas Instruments

Texas Instruments TUSB320-LA-EVM Manual de usuario

Texas Instruments

Texas Instruments bq2427 Series Manual de usuario

Texas Instruments

Texas Instruments TAS2574 Manual de usuario

Texas Instruments

Texas Instruments SimpleLink CC3235MODS Manual de usuario

Texas Instruments

Texas Instruments LMK04832EVM-CVAL Manual de usuario

Texas Instruments

Texas Instruments TLV320DAC26EVM Manual de usuario

Texas Instruments

Texas Instruments DRV8803 Manual de usuario

Texas Instruments

Texas Instruments AM437x Manual de usuario

Texas Instruments

Texas Instruments TI-Navigator Manual de usuario

Texas Instruments

Texas Instruments Piccolo F280049C Manual de usuario

Texas Instruments

Texas Instruments BoosterPack Educational Plug-in Module Mark II... Manual de usuario

Texas Instruments

Texas Instruments DAC5674 EVM Manual de usuario

Texas Instruments

Texas Instruments LM3643EVM Manual de usuario

Texas Instruments

Texas Instruments WiLink WL 1MOD Series Manual de usuario

Texas Instruments

Texas Instruments TPS79301EVM Manual de usuario

Texas Instruments

Texas Instruments SimpleLink CC3200MOD Manual de usuario

Texas Instruments

Texas Instruments THS7001 Manual de usuario

Texas Instruments

Texas Instruments MCT8316AEVM Manual de usuario

Texas Instruments

Texas Instruments TWL6032 Manual de usuario

Texas Instruments

Texas Instruments CDCM9102EVM Manual de usuario

Manuales populares de Unidad de control de otras marcas

Festo

Festo Compact Performance CP-FB6-E Manual de lista de piezas

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manual de usuario

JS Automation

JS Automation MPC3034A Manual de usuario

JAUDT

JAUDT SW GII 6406 Series Guía rápida

Spektrum

Spektrum Air Module System Manual de usuario

BOC Edwards

BOC Edwards Q Series Manual de usuario

KHADAS

KHADAS BT Magic Manual de usuario

Etherma

Etherma eNEXHO-IL Manual de usuario

PMFoundations

PMFoundations Attenuverter Manual de usuario

GEA

GEA VARIVENT Manual de usuario

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manual de usuario

Altronix

Altronix LINQ8PD Instrucciones de montaje

Eaton

Eaton Powerware Series Manual de usuario

WAGO

WAGO 750-407/040-000 Manual de usuario

Sony

Sony CCU-590 Manual de usuario

Graco

Graco 25D614 Manual de usuario

Task Force Tips

Task Force Tips YE-RF-900 Manual de programación

Shini

Shini SPV-U Series Manual de usuario
