CC2640

SWRS176 –FEBRUARY 2015

CC2640 SimpleLink™ Bluetooth

Smart Wireless MCU

1 Device Overview

1.1 Features

1– Very Few External Components

• Microcontroller – Seamless Integration With the SimpleLink

– Powerful ARM®Cortex®-M3 CC2590 and CC2592 Range Extenders

– EEMBC CoreMark®score: 142 – Pin Compatible With the SimpleLink CC13xx in

– Up to 48-MHz Clock Speed 4-mm × 4-mm and 5-mm × 5-mm QFN

– 128KB of In-System Programmable Flash Packages

– 8-KB SRAM for Cache • Low Power

– 20-KB Ultra-Low Leakage SRAM – Wide Supply Voltage Range

– 2-Pin cJTAG and JTAG Debugging • Normal Operation: 1.8 to 3.8 V

– Supports Over-The-Air Upgrade (OTA) • External Regulator Mode: 1.7 to 1.95 V

• Ultra-Low Power Sensor Controller – Active-mode RX: 5.9 mA

– Can run autonomous from the rest of the – Active-mode TX at 0 dBm: 6.1 mA

system – Active-mode TX at +5 dBm: 9.1 mA

– 16-Bit Architecture – Active-mode MCU: 61 µA/MHz

– 2-KB Ultra-Low Leakage SRAM for Code and – Active-mode MCU: 48.5 CoreMark/mA

Data – Active-mode Sensor Controller: 8.2 µA/MHz

• Efficient Code Size Architecture, Placing Drivers, – Standby: 1 µA (RTC Running and RAM/CPU

Bluetooth®Low Energy Controller, and Bootloader Retention)

in ROM – Shutdown: 100 nA (Wake-up on External

• RoHS-Compliant Packages Events)

– 4-mm × 4-mm RSM QFN32 (10 GPIOs) • RF Section

– 5-mm × 5-mm RHB QFN32 (15 GPIOs) – 2.4 GHz RF Transceiver Compatible With

– 7-mm x 7-mm RGZ QFN48 (31 GPIOs) Bluetooth Low Energy (BLE) 4.1 specification

• Peripherals – Excellent Receiver Sensitivity (–97 dBm for

– All Digital Peripheral Pins can be Routed to any BLE), Selectivity, and Blocking Performance

GPIO – Programmable Output Power up to +5 dBm

– 4 General-Purpose Timer Modules (8 × 16-Bit or – Single-ended or Differential RF Interface

4 × 32-Bit Timer, PWM Each) – Suitable for Systems Targeting Compliance With

– 12-Bit ADC, 200-ksamples/s, 8-Channel Analog Worldwide Radio Frequency Regulations

MUX • ETSI EN 300 328 (Europe)

– Continuous Time Comparator • EN 300 440 Class 2 (Europe)

– Ultra-Low Power Analog Comparator • FCC CFR47 Part 15 (US)

– Programmable Current Source • ARIB STD-T66 (Japan)

– UART • Tools and Development Environment

– 2x SSI (SPI, µW, TI) – Full-Feature and Low-Cost Development Kits

– I2C– Multiple Reference Designs for Different RF

– I2S Configurations

– Real-Time Clock (RTC) – Packet Sniffer PC Software

– AES-128 Security Module – Sensor Controller Studio

– True Random Number Generator (TRNG) – SmartRF™ Studio

– 10, 15, or 31 GPIOs, Depending on Package – SmartRF Flash Programmer 2

Option – IAR Embedded Workbench®for ARM

– Support for 8 Capacitive Sensing Buttons – Code Composer Studio™

– Integrated Temperature Sensor

• External System

– On-Chip internal DC-DC Converter

An IMPORTANT NOTICE at the end of this data sheet addresses availability, warranty, changes, use in safety-critical applications,

intellectual property matters and other important disclaimers. PRODUCTION DATA.

CC2640

SWRS176 –FEBRUARY 2015

www.ti.com

1.2 Applications

• Home and Building Automation • Health and Medical

– Connected Appliances – Thermometers

– Lighting – SpO2

– Locks – Blood Glucose and Pressure Meters

– Gateways – Weight-scales

– Security Systems – Vitals Monitoring

– Hearing Aids

• Industrial

– Logistics • Sports and Fitness

– Production and Manufacturing – Activity Monitors and Fitness Trackers

– Automation – Heart Rate Monitors

– Asset Tracking and Management – Running Sensors

– Remote Display – Biking Sensors

– Cable Replacement – Sports Watches

– HMI – Gym Equipment

– Access Control – Team Sports Equipment

• Retail • HID

– Beacons – Remote Controls

– Advertising – Keyboards and Mice

– ESL / Price Tags – Gaming

– Point of Sales / Payment Systems • Accessories

– Toys

– Trackers

– Luggage-tags

– Wearables

1.3 Description

The CC2640 is a wireless MCU targeting Bluetooth Smart applications.

The device is a member of the CC26xx family of cost-effective, ultra-low power, 2.4-GHz RF devices. Very

low active RF and MCU current, and low-power mode current consumption provides excellent battery

lifetime and allows operation on small coin cell batteries and in energy-harvesting applications.

The CC2640 contains a 32-bit ARM Cortex-M3 running at 48-MHz as the main processor and a rich

peripheral feature set, including a unique ultra-low power sensor controller, ideal for interfacing external

sensors and/or collecting analog and digital data autonomously while the rest of the system is in sleep

mode.

This makes the CC2640 ideal for a wide range of applications where long battery lifetime, small form

factor, and ease of use is important.

The Bluetooth Low Energy controller is embedded into ROM and run partly on an ARM Cortex®-M0

processor. This architecture improves overall system performance and power consumption and frees up

flash memory for the application.

The Bluetooth Smart stack is available free of charge from www.ti.com.

Device Information(1)

PART NUMBER PACKAGE BODY SIZE

CC2640F128RGZ RGZ (QFN48) 7.00 mm × 7.00 mm

CC2640F128RHB RHB (QFN32) 5.00 mm × 5.00 mm

(1) For more information, see Section 9,Mechanical Packaging and Orderable Information.

Submit Documentation Feedback

Product Folder Links: CC2640

CC2640

www.ti.com

SWRS176 –FEBRUARY 2015

Device Information(1) (continued)

PART NUMBER PACKAGE BODY SIZE

CC2640F128RSM RSM (QFN32) 4.00 mm × 4.00 mm

Submit Documentation Feedback

Product Folder Links: CC2640

CC2640

SWRS176 –FEBRUARY 2015

www.ti.com

1.4 Functional Block Diagram

Section 1.4 shows a block diagram for the CC2640.

Figure 1-1. Block Diagram

Submit Documentation Feedback

Product Folder Links: CC2640

CC2640

www.ti.com

SWRS176 –FEBRUARY 2015

Table of Contents

1 Device Overview ......................................... 15.16 Battery Monitor...................................... 19

1.1 Features .............................................. 15.17 Continuous Time Comparator....................... 20

1.2 Applications........................................... 25.18 Low-Power Clocked Comparator ................... 20

1.3 Description............................................ 25.19 Programmable Current Source ..................... 20

1.4 Functional Block Diagram ............................ 45.20 DC Characteristics .................................. 21

2 Revision History ......................................... 65.21 Control Input AC Characteristics.................... 21

3 Device Comparison ..................................... 75.22 Synchronous Serial Interface (SSI) Characteristics.21

4 Terminal Configuration and Functions.............. 85.23 Typical Characteristics .............................. 22

4.1 Pin Diagram – RSM Package ........................ 86 Detailed Description ................................... 25

4.2 Signal Descriptions – RSM Package................. 86.1 Overview ............................................ 25

4.3 Pin Diagram – RHB Package ........................ 96.2 Main CPU ........................................... 25

4.4 Signal Descriptions – RHB Package................ 10 6.3 RF Core ............................................. 25

4.5 Pin Diagram – RGZ Package....................... 11 6.4 Sensor Controller ................................... 26

4.6 Signal Descriptions – RGZ Package................ 11 6.5 Memory.............................................. 27

5 Specifications........................................... 13 6.6 Debug ............................................... 27

5.1 Absolute Maximum Ratings......................... 13 6.7 Power Management................................. 28

5.2 ESD Ratings ........................................ 13 6.8 Clock Systems ...................................... 29

5.3 Recommended Operating Conditions............... 13 6.9 General Peripherals and Modules .................. 29

5.4 Thermal Characteristics............................. 14 6.10 System Architecture................................. 30

5.5 Electrical Characteristics............................ 15 7 Application Circuit ..................................... 31

5.6 General Characteristics ............................. 16 8 Device and Documentation Support ............... 33

5.7 1-Mbps GFSK (Bluetooth Low Energy) – RX....... 16 8.1 Device Support...................................... 33

5.8 1-Mbps GFSK (Bluetooth Low Energy) – TX ....... 17 8.2 Documentation Support ............................. 35

5.9 1-Mbps GFSK (Bluetooth Low Energy) – Common 8.3 Additional Information ............................... 35

RX/TX ............................................... 17 8.4 Trademarks.......................................... 36

5.10 24-MHz Crystal Oscillator (XOSC_HF) ............. 18 8.5 Electrostatic Discharge Caution..................... 36

5.11 32.768-kHz Crystal Oscillator (XOSC_LF).......... 18 8.6 Export Control Notice ............................... 36

5.12 48-MHz RC Oscillator (RCOSC_HF) ............... 18 8.7 Glossary............................................. 36

5.13 32-kHz RC Oscillator (RCOSC_LF)................. 18 9 Mechanical Packaging and Orderable

5.14 ADC Characteristics................................. 19 Information .............................................. 37

5.15 Temperature Sensor ................................ 19 9.1 Packaging Information .............................. 37

Submit Documentation Feedback

Product Folder Links: CC2640

CC2640

SWRS176 –FEBRUARY 2015

www.ti.com

2 Revision History

NOTE: Page numbers for previous revisions may differ from page numbers in the current version.

DATE REVISION NOTES

February 2015 * Initial Release

Submit Documentation Feedback

Product Folder Links: CC2640

CC2640

www.ti.com

SWRS176 –FEBRUARY 2015

3 Device Comparison

Table 3-1. Device Family Overview

Device PHY Support Flash (KB) RAM (KB) GPIO Package(1)

CC2650F128xxx Multi-Protocol(2) 128 20 31, 15, 10 RGZ, RHB, RSM

CC2640F128xxx Bluetooth low energy 128 20 31, 15, 10 RGZ, RHB, RSM

CC2630F128xxx IEEE 802.15.4 ( ZigBee®/6LoWPAN) 128 20 31, 15, 10 RGZ, RHB, RSM

CC2620F128xxx IEEE 802.15.4 (RF4CE) 128 20 31, 15, 10 RGZ, RHB, RSM

(1) Package designator replaces the xxx in device name to form a complete device name, RGZ is 7-mm x 7-mm QFN48, RHB is 5-mm x 5-

mm QFN32, and RSM is 4-mm x 4-mm QFN32.

(2) The CC2650 supports all PHYs and can be reflashed to run all the supported standards.

Submit Documentation Feedback

Product Folder Links: CC2640

CC26xx

30 QFN32 4x4

RSM

26 15

25 16

31 10

32 9

232 241

178

DIO_6

VSS

DIO_5

RESET_N

VSS

VDDS_DCDC

DCDC_SW

DIO_7

VDDR_RF

X24M_N

X24M_P

VSS

VDDR

DIO_9

VDDS

DIO_8

DIO_1

JTAG_TMSC

DIO_2

DCOUPL

VDDS2

JTAG_TCKC

DIO_3

DIO_4

RF_P

RF_N

VSS

X32K_Q2

VSS

DIO_0

RX_TX

X32K_Q1

CC2640

SWRS176 –FEBRUARY 2015

www.ti.com

4 Terminal Configuration and Functions

NOTE

I/O pins marked in bold have high drive capabilities. I/O pins marked in italics have analog

capabilities.

4.1 Pin Diagram – RSM Package

Figure 4-1. RSM (4 mm × 4 mm) Pinout, 0.4-mm Pitch

4.2 Signal Descriptions – RSM Package

Table 4-1. Signal Descriptions – RSM Package

Pin Name Pin Pin Type Description

RF_P 1 RF I/O Positive RF input signal to LNA during RX

Positive RF output signal to PA during TX

RF_N 2 RF I/O Negative RF input signal to LNA during RX

Negative RF output signal to PA during TX

RX_TX 4 RF I/O Optional bias pin for the RF LNA

VDDS 27 Power 1.8 V to 3.8 V main chip supply(1)

VDDS2 11 Power 1.8 V to 3.8 V GPIO supply(1)

VDDS_DCDC 19 Power 1.8 V to 3.8 V DC/DC supply. Tie to ground for external

regulator mode (1.7 V to 1.95 V operation)

VDDR 28 Power 1.7 V to 1.95 V supply, typically connect to output of internal

DC/DC(2)(3)

VDDR_RF 32 Power 1.7 V to 1.95 V supply, typically connect to output of internal

DC/DC(4)(3)

DCOUPL 12 Power 1.27 V regulated digital-supply decoupling capacitor(3)

VSS 3, 7, 17, 20, 29 Power Ground

(1) See Section 8.2, technical reference manual for more details.

(2) If internal DC/DC is not used, this pin is supplied internally from the main LDO.

(3) Do not supply external circuitry from this pin.

(4) If internal DC/DC is not used, this pin must be connected to VDDR for supply from the main LDO.

Submit Documentation Feedback

Product Folder Links: CC2640

CC26xx

30 QFN32 5x5

RHB

26 15

25 16

31 10

32 9

232 241

178

DIO_10

DIO_7

DIO_9

DIO_8

DCDC_SW

RESET_N

VDDS_DCDC

DIO_11

VDDR_RF

X24M_N

X24M_P

VDDR

VDDS

DIO_13

DIO_14

DIO_12

DIO_3

JTAG_TMSC

DIO_4

DCOUPL

VDDS2

JTAG_TCKC

DIO_5

DIO_6

RF_P

RF_N

RX_TX

DIO_0

DIO_1

DIO_2

X32K_Q1

X32K_Q2

CC2640

www.ti.com

SWRS176 –FEBRUARY 2015

Table 4-1. Signal Descriptions – RSM Package (continued)

Pin Name Pin Pin Type Description

DCDC_SW 18 Power Output from internal DC/DC(1). Tie to ground for external

regulator mode (1.7 V to 1.95 V operation)

EGP Power Ground – Exposed Ground Pad

RESET_N 21 Digital input Reset, active-low. No internal pullup

DIO_0 8 Digital I/O GPIO, Sensor Controller, High drive capability

DIO_1 9 Digital I/O GPIO, Sensor Controller, High drive capability

DIO_2 10 Digital I/O GPIO, Sensor Controller, High drive capability

DIO_3 15 Digital I/O GPIO, High drive capability, JTAG_TDO

DIO_4 16 Digital I/O GPIO, High drive capability, JTAG_TDI

DIO_5 22 Digital/Analog I/O GPIO, Sensor Controller, Analog

DIO_6 23 Digital/Analog I/O GPIO, Sensor Controller, Analog

DIO_7 24 Digital/Analog I/O GPIO, Sensor Controller, Analog

DIO_8 25 Digital/Analog I/O GPIO, Sensor Controller, Analog

DIO_9 26 Digital/Analog I/O GPIO, Sensor Controller, Analog

JTAG_TMSC 13 Digital I/O JTAG TMSC

JTAG_TCKC 14 Digital I/O JTAG TCKC

X32K_Q1 5 Analog I/O 32 kHz crystal oscillator pin 1

X32K_Q2 6 Analog I/O 32 kHz crystal oscillator pin 2

X24M_N 30 Analog I/O 24 MHz crystal oscillator pin 1

X24M_P 31 Analog I/O 24 MHz crystal oscillator pin 2

4.3 Pin Diagram – RHB Package

Figure 4-2. RHB (5 mm × 5 mm) Pinout, 0.5-mm Pitch

Submit Documentation Feedback

Product Folder Links: CC2640

CC2640

SWRS176 –FEBRUARY 2015

www.ti.com

4.4 Signal Descriptions – RHB Package

Table 4-2. Signal Descriptions – RHB Package

Pin Name Pin Pin Type Description

RF_P 1 RF I/O Positive RF input signal to LNA during RX

Positive RF output signal to PA during TX

RF_N 2 RF I/O Negative RF input signal to LNA during RX

Negative RF output signal to PA during TX

RX_TX 3 RF I/O Optional bias pin for the RF LNA

VDDS 28 Power 1.8 V to 3.8 V main chip supply(1)

VDDS2 11 Power 1.8 V to 3.8 V GPIO supply(1)

VDDS_DCDC 18 Power 1.8 V to 3.8 V DC/DC supply

VDDR 29 Power 1.7 V to 1.95 V supply, typically connect to output of internal

DC/DC(2)(3)

VDDR_RF 32 Power 1.7 V to 1.95 V supply, typically connect to output of internal

DC/DC(4)(3)

DCOUPL 12 Power 1.27 V regulated digital-supply decoupling(3)

DCDC_SW 17 Power Output from internal DC/DC(1)

EGP Power Ground – Exposed Ground Pad

RESET_N 19 Digital input Reset, active-low. No internal pullup

DIO_0 6 Digital I/O GPIO, Sensor Controller

DIO_1 7 Digital I/O GPIO, Sensor Controller

DIO_2 8 Digital I/O GPIO, Sensor Controller, High drive capability

DIO_3 9 Digital I/O GPIO, Sensor Controller, High drive capability

DIO_4 10 Digital I/O GPIO, Sensor Controller, High drive capability

DIO_5 15 Digital I/O GPIO, High drive capability, JTAG_TDO

DIO_6 16 Digital I/O GPIO, High drive capability, JTAG_TDI

DIO_7 20 Digital/Analog I/O GPIO, Sensor Controller, Analog

DIO_8 21 Digital/Analog I/O GPIO, Sensor Controller, Analog

DIO_9 22 Digital/Analog I/O GPIO, Sensor Controller, Analog

DIO_10 23 Digital/Analog I/O GPIO, Sensor Controller, Analog

DIO_11 24 Digital/Analog I/O GPIO, Sensor Controller, Analog

DIO_12 25 Digital/Analog I/O GPIO, Sensor Controller, Analog

DIO_13 26 Digital/Analog I/O GPIO, Sensor Controller, Analog

DIO_14 27 Digital/Analog I/O GPIO, Sensor Controller, Analog

JTAG_TMSC 13 Digital I/O JTAG TMSC, High drive capability

JTAG_TCKC 14 Digital I/O JTAG TCKC

X32K_Q1 4 Analog I/O 32 kHz crystal oscillator pin 1

X32K_Q2 5 Analog I/O 32 kHz crystal oscillator pin 2

X24M_N 30 Analog I/O 24 MHz crystal oscillator pin 1

X24M_P 31 Analog I/O 24 MHz crystal oscillator pin 2

(1) See Section 8.2, technical reference manual for more details.

(2) If internal DC/DC is not used, this pin is supplied internally from the main LDO.

(3) Do not supply external circuitry from this pin.

(4) If internal DC/DC is not used, this pin must be connected to VDDR for supply from the main LDO.

Submit Documentation Feedback

Product Folder Links: CC2640

Otros manuales para SimpleLink CC2640

Tabla de contenidos

Otros manuales de Hardware de computadora de Texas Instruments

Texas Instruments

Texas Instruments CC2540 Manual de usuario

Texas Instruments

Texas Instruments TMS320 Series Manual de usuario

Texas Instruments

Texas Instruments CC2533 Manual de instalación

Texas Instruments

Texas Instruments TPS3801 Manual de usuario

Texas Instruments

Texas Instruments System-Side Impedance Track bq27500 Manual de usuario

Texas Instruments

Texas Instruments AM64 Series Manual de usuario

Texas Instruments

Texas Instruments TMS320DM646x Manual de usuario

Texas Instruments

Texas Instruments SimpleLink CC3200 Wi-Fi Manual de usuario

Texas Instruments

Texas Instruments DS10 Instrucciones de funcionamiento

Texas Instruments

Texas Instruments TMS320C642x DSP Manual de usuario

Texas Instruments

Texas Instruments LDC3114-Q1 Manual de usuario

Texas Instruments

Texas Instruments MSP430x11x1 Manual de usuario

Texas Instruments

Texas Instruments KCU105 Manual de usuario

Texas Instruments

Texas Instruments CC3100 SimpleLink Manual de usuario

Texas Instruments

Texas Instruments TMS320C2 Series Manual de usuario

Texas Instruments

Texas Instruments TVP5154EVM Manual de usuario

Texas Instruments

Texas Instruments TPS25762Q1EVM-146 Manual de usuario

Texas Instruments

Texas Instruments DRA821 Manual de usuario

Texas Instruments

Texas Instruments SimpleLink CC3301 Manual de usuario

Texas Instruments

Texas Instruments BoosterPack BOOSTXL-ADS7142-Q1 Manual de usuario

Texas Instruments

Texas Instruments TPS62065 Manual de usuario

Texas Instruments

Texas Instruments TPS65381EVM Manual de usuario

Texas Instruments

Texas Instruments ADS8365MEVM Manual de usuario

Texas Instruments

Texas Instruments SimpleLink Wi-Fi CC3 20 Series Manual de usuario

Manuales populares de Hardware de computadora de otras marcas

EMC2

EMC2 VNX Series Manual del propietario

Panasonic

Panasonic DV0PM20105 Manual de usuario

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manual de usuario

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manual de usuario

Raidon

Raidon iT2300 Manual de usuario

National Instruments

National Instruments PXI-8186 Manual de usuario

Hauppauge

Hauppauge WinTV-HVR-2250 Manual de usuario

Kontron

Kontron CP6002 Manual de usuario

Manhattan

Manhattan 702843 Manual de usuario

Aphex

Aphex 230 Manual de usuario

AMD

AMD Phenom II Manual operacional

Intel

Intel NUC 12 Pro Manual de usuario

dbx

dbx Zone Pro 1260 Manual de usuario

Galaxy

Galaxy GHDX2-2430S-24F4D Manual de usuario

Intel

Intel AXXRMFBU4 Manual de usuario

Kontron

Kontron DIMM-PC/MD Manual de usuario

ST X-NUCLEO-SAFEA1B Instrucciones de funcionamiento

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manual de usuario
