testo 616

Materialfeuchte-Messgerät Bedienungsanleitung

Material moisture measuring instrument Instruction manual

Appareil de mesure de l'humidité

des matériaux. Mode d’emploi

Content 17

Content

General notes ....................................................18

1. Safety instructions..............................................19

2. Intended purpose ..............................................20

3. Product description ............................................21

3.1 Display and control elements ........................................21

3.2 Voltage supply ..............................................................22

3.3 Humidity measurement procedure ................................22

4. Commissioning ..................................................23

5. Operation ..........................................................23

5.1 Switching the instrument on/off ....................................23

5.2 Switching the display light on/off ..................................24

5.3 Performing settings ......................................................24

6. Measuring ..........................................................25

7. Care and maintenance ......................................27

8. Questions and answers......................................28

9. Technical data ....................................................28

10. Tips and assistance............................................29

11. Accessories/spare parts ....................................29

deenfresitptsvnl????

General notes18

General notes

This chapter provides important advice on using this

documentation.

This documentation contains information that must be

applied if the product is to be used safely and efficiently.

Please read this documentation through carefully and

familiarize yourself with the operation of the product before

putting it to use. Keep this document to hand so that you

can refer to it when necessary.

Identification

Representation Meaning Comments

Warning advice: Warning! Read warning advice carefully and take

the precautionary measures indicated!

Serious physical injury could occur if

you do not take the precautionary

measures indicated.

Warning advice: Caution! Read warning advice carefully and take

the precautionary measures indicated!

Slight physical injury or damage to

equipment could occur if you do not

take the precautionary measures

indicated.

Note Offers helpful tips and information.

±, 1, 2 Objective Denotes the objective that is to be

achieved via the steps described. Where

steps are numbered, you must always

follow the order given!

Condition A condition that must be met if an action

is to be carried out as described.

i, 1, 2, ... Step Carry out steps. Where steps are

numbered, you must always follow the

order given!

Text Display text Text appears on the instrument display.

Control key Press the key.

- Result Denotes the result of a previous step.

ºCross-reference Refers to more extensive or detailed

information.

Taste

1. Safety instructions 19

1. Safety instructions

This chapter gives general rules which must be followed

and observed if the product is to be handled safely.

Avoiding personal injury/damage to equipment

iDo not use the measuring instrument and sensors to

measure on or near live parts.

iNever store the measuring instrument/probe together

with solvents and do not use any desiccants.

Product safety/preserving warranty claims

iOperate the measuring instrument only within the

parameters specified in the Technical data.

iAlways use the measuring instrument properly and for its

intended purpose. Do not use force.

iDo not expose handles and feed lines to temperatures in

excess of 70 °C unless they are expressly permitted for

higher temperatures. Temperatures given on

probes/sensors relate only to the measuring range of the

sensors.

iOpen the instrument only when this is expressly

described in the documentation for maintenance and

repair purposes.

Carry out only the maintenance and repair work that is

described in the documentation. Follow the prescribed

steps when doing so. For safety reasons, use only

original spare parts from testo.

Ensure correct disposal

iTake faulty rechargeable batteries/spent batteries to the

collection points provided for them.

iSend the product back to testo at the end of its useful

life. We will ensure that it is disposed of in an

environmentally friendly manner.

deenfresitptsvnl????

2. Intended purpose20

2. Intended purpose

This chapter gives the areas of application for which the

product is intended.

Use the product only for those applications for which it was

designed. Ask testo if you are in any doubt.

The product was designed for the following

tasks/applications:

· Fast and non-destructive evaluation of material moisture

courses in woods and building materials.

Does not replace reference methods such as CM

method or Darr-Wäge (dry-and-weigh) method.

The instrument is not calibratable.

The product must not be used in the following areas:

· Areas at risk of explosion.

Materials subject to electrical voltage.

Electric shock!

If in doubt, check whether the materials are

energized before the measurement (e.g. in the

event of water damage in walls)

3. Product description 21

3. Product description

This chapter provides an overview of the components of

the product and their functions.

3.1 Display and control

elements

Overview Contact plates

Display

Control keys

Battery compartment (rear)

Key functions

Key Functions

Switch instrument on;

switch instrument off (press and hold)

Switch display light on/off

Keep reading, display

maximum/minimum value

Open/leave configuration mode (press

and hold);

In configuration mode:

Confirm input

In configuration mode:

Increase value, select option

In configuration mode:

Decrease value, select option

Important displays

Display Meaning

Battery capacity (bottom right in display):

· 4 segments in the battery symbol are lit: Instrument battery is fully

charged

· No segments in the battery symbol are lit: Battery is almost spent

deenfresitptsvnl????

3. Product description22

3.2 Voltage supply

Voltage is supplied by means of a 9 V monobloc battery

(included in delivery) or rechargeable battery. It is not

possible to run the instrument from the mains supply or

charge a rechargeable battery in the instrument.

3.3 Humidity measurement

procedure

The non-destructive stray field measurement uses the

ability of water molecules to dampen and thus change

electromagnetic fields. The electric field penetrates the

material via the contact plates and creates a measuring

field with a depth of approx. 5 cm (2”).

The following factors can influence the measurement result:

Factors Ideal condition

Measurement depth Material thickness > 5 cm (> 2”). Caution: The upper

layers of the material influence the measurement result

more than the deeper layers.

Material surface As level as possible as contact plates should lay flat

against it.

Material properties As homogeneous as possible with no air pockets.

Moisture distribution As even as possible.

Metals and electric fields None, if possible.

4. Commissioning 23

4. Commissioning

This chapter describes the steps required to commission

the product.

²Removing the protective film on the display:

iPull the protective film off carefully.

²Inserting a battery/rechargeable battery:

1To open the battery compartment on the rear of the

instrument, push the lid of the battery compartment in

the direction of the arrow and remove it.

2Insert a battery/rechargeable battery (9 V monobloc).

Observe the polarity!

3To close the battery compartment, replace the lid of

the battery compartment in position and push it

against the direction of the arrow.

5. Operation

This chapter describes the steps that have to be executed

frequently when using the product.

5.1 Switching the instrument

on/off

²Switching the instrument on:

iPress .

- The current reading is shown

²Switching the instrument off:

iPress and hold (for approx. 2 s) until the display

goes out.

deenfresitptsvnl????

5. Operation24

5.2 Switching the display

light on/off

²Switching the display light on/off:

The instrument is switched on.

iPress .

5.3 Performing settings

1To open configuration mode:

The instrument is switched on and is in measurement

view. Hold,Max or Min are not activated.

iPress and hold (for approx. 2 s) until the display

changes.

- The instrument is now in configuration mode.

You can change to the next function with .

You can leave configuration mode at any time. To do

so, press and hold (for approx. 2 s) until the

instrument has changed to measurement view. Any

changes that have already been made in configuration

mode will be saved.

2To set Auto Off:

Configuration mode is opened, AutoOff is flashing.

iSelect the desired option with / and confirm

with :

·on: The measuring instrument switches off

automatically if no key is pressed for 10 min.

Exception: A recorded reading is shown on the

display (Hold or Auto Hold is lit).

· oFF: The measuring instrument does not switch

itself off automatically.

6. Measuring 25

3To reset:

Configuration mode is opened, RESET is lit.

iSelect the desired option with / and confirm

with :

·no: Instrument is not reset.

· Yes: Instrument is reset. The instrument is reset to

the factory settings.

- The instrument returns to measurement view.

6. Measuring

This chapter describes the steps that are required to

perform measurements with the product.

²Setting the material characteristic curve:

1Switch between the display of wood moisture (F) and

building moisture (M): or press .

2Select the desired option with or and confirm

with :

Display Category Example

F 1 Softwood lumber Spruce, larch, cherry, pine, poplar, meranti

F 2 Hardwood lumber Beech, oak, maple, ash, Douglas-fir,

walnut, birch

F 3 Chipboard

M 1 Cement screed

M 2 Anhydrite screed

M 3 Concrete

M 4 Solid brick

M 5 High-insulating brick

M 6 Limestone

M7 Gas concrete

CAL Testing characteristic Not for on-site measurements!

deenfresitptsvnl????
