TerraTrike GTS Manual
www.TerraTrike.com | 800.945.9910
Revised 06/2022
Build Notes
www.TerraTrike.com | 800.945.9910
Alignment
Inate tires before performing alignment. The GTS alignment measurement is
approximately 29¼” (center tread to center tread), though slight variance is possible.
Most importantly, make sure the alignment remains neutral with a rider seated in the
trike.
29 ¼
29 ¼
www.TerraTrike.com | 800.945.9910
Hybrid Steering Stack Assembly*
1
2
3
4
5
8
9
10
Assemble the steering stack as shown. Grease the
steerer tube before inserting into head tube. Remove
any excess grease from steerer tube before installing
handlebar. Grease axle before installing wheel. Torque
axle to 23-25Nm.
*Right Hand assembly depicted. Some components
can be purchased individually as well as in pairs, see
parts list below.
1M6x30 Bolt TT000576
2 Hybrid Top Cap TT000506
3Trigger Handlebar - RH TT000649
Trigger Handlebar - LH TT000650
Trigger Handlebar - Pair TT000514
M5x20 Bolt - 2qty (not pictured)
TT000301
4Hybrid Headset Spacer TT000520
5Hyrbid Headset Cap TT000505
6Bushing (pre-installed)
TT000809
7 Hybrid Headset Cup (pre-installed) TT000602
8Hybrid Headset Bearing TT000600
9 Rapid Axle Hubmount - RH TT000713
Rapid Axle Hubmount - LH TT000714
Rapid Axle Hubmount - Pair TT000516
10 Rapid Axle - RH TT000717
Rapid Axle - LH TT000718
Rapid Axle - Pair TT000563
11 Axle Spacer TT000568
Parts List
6
7
www.TerraTrike.com | 800.945.9910
Hybrid Steering Stack Assembly Continued*
11
Install Axle Spacer (11) between brake rotor and hub.
www.TerraTrike.com | 800.945.9910
Chain Tube Setup
Mount the chain tube and idler assembly as shown below. Ensure the
chain tubes do not rotate in the clamps after tightening the pinch
bolts.
www.TerraTrike.com | 800.945.9910
Upper Assy. Chain Tube, 38cm LDPE TT000549 1
Chain Tube Clamp, Rov/Rab/Mav TT000152 1
M5x12mm SHCS SS TT000303
1
M5x18mm Pan Head SS N/A
1
M5 Nyloc Nut SS TT000252
1
Shared Chain Tube Bracekt Arm, M5, M8 TT000151
1
1
Lower Assy. Chain Tube, 22cm LDPE WC000010
1
Chain Tube CLamp,Traveler TT000422 1
M8x30mm BHCS SS TT000280 1
M5x18mm Pan Head SS N/A 1
M8 Flat Washer SS TT000290
2
Idler Assy. Idler, 16T w/ Cage WC000041
1
M3x6 Button HEad N/A
2
M8x35mm BHSCS SS TT000279
1
www.TerraTrike.com | 800.945.9910
Cable Routing RH
Brake Cable
Shift Cable
Chain Routing
www.TerraTrike.com | 800.945.9910
Cable Routing LH
800.945.9910 |www.TerraTrike.com
4460 40th St. SE | Grand Rapids, MI 49512 USA
