Tennant T17 Series Manual de capacitación

IB 9012969 (07- 2016) 1

INSTRUCTION BULLETIN

No. 9012969

Machine: T17

Published: 07- 2016

Rev. 01

NOTE: DO NOT DISCARD the Parts List from the Instruction Bulletin. Place the

Parts List in the appropriate place in the machine manual for future

reference. Retaining the Parts List will make it easier to reorder

individual parts and will save the cost of ordering an entire kit.

NOTE: Numbers in parenthesis ( ) are reference numbers for parts listed in Bill of Materials.

Installation instructions for kit number 9020057 / 9020206 (T17 machines NA serial numbers

000000- 010999 / EU serial numbers 0000- 0330) / 9014962 / 9014963 (T17 machines NA serial

numbers 011000- / EU serial numbers 0400- )

SYNOPSIS:

This kit contains the parts needed to install a sweeping side brush or dual sweeping side brush kit

onto T17 scrubbers.

Please follow step-by-step instructions.

Machine must be factory equipped with side brush harness kit (PREP KIT, SIDE BRUSH

HARNESS [T17] - 9020047) to install the sweeping side brush(es).

SPECIAL TOOLS / CONSIDERATIONS: NONE

(Estimated time to complete: 2.5 hours - single sweeping side brush / 3.5 hours - dual sweeping side

brushes)

PROTECT THE ENVIRONMENT

Please dispose of packaging materials, used machine components

such as batteries and fluids in an environmentally safe way according

to local waste disposal regulations.

Always remember to recycle.

PREPARATION:

1. Completely empty both the solution tank and

the recovery tank.

FOR SAFETY: Before leaving or servicing

machine, stop on level surface, turn off

machine, set parking brake, and remove key.

2. Disconnect the battery cable from the

machine.

WARNING: Always disconnect battery

cables from machine before working on

electrical components.

3. Place chocks behind both rear tires.

4. Jack up the front end of the machine. Place

jack stands under the front end of the

machine, and lower the machine onto the jack

stands.

FOR SAFETY: When servicing machine: block

machine tires before jacking machine up, jack

machine up at designated locations only.

(support machine with jack stands), use hoist

or jack that will support the weight of the

machine.

NOTE:Refer to MACHINE JACKING in the

MAINTENANCE section of Operators Manual for

additional information pertaining to safely jacking

up the machine.

IB 9012969 (07- 2016)2

INSTALLATION:

Right side sweeping side

brush mounting location

Left side sweeping side

brush mounting location

FRONT

Right side sweeping

side brush mounting

location

Left side sweeping

side brushmounting

location

T17 machines NA serial numbers

(000000- 010999) / EU serialnumbers

(0000- 0330)

T17 machines NA serial numbers

(011000- ) / EU serial numbers

(0400- ) / M17 All machines

FIG. 1 - Sweeping Side Brush Mounting Locations

IB 9012969 (07- 2016) 3

1. Remove any parts and components from the

machine necessary to install the sweeping

side brush assembly onto the machine.

2. Cut the cable ties securing the side sweep

harness connector ends for the right and / or

left sweeping side brush so the connectors

can be connected to the sweeping side brush

actuator(s) and side brush drive motor(s).

3. Use three M8 SEMS hex screws to install the

right sweeping side brush assembly onto the

frameofthemachine.(Fig.1/Fig.2)

4. Connect the side sweep harness to the right

sweeping side brush drive motor and actuator.

(Fig.2/Fig.11)

5. Use three M8 SEMS hex screws to install the

left sweeping side brush assembly onto the

frameofthemachine.(Fig.1/Fig.4)

6. Connect the side sweep harness to the left

sweeping side brush brush drive motor and

actuator. (Fig. 4 / Fig. 11)

7. Reassemble all parts removed to install the

sweeping side brush(es) back onto the

machine.

8. Use four M8 SEMS hex screws to install a

side brush cover(s) onto the right sweeping

side brush assembly and / or left sweeping

side brush assembly. (Fig. 3 / Fig. 5)

9. Install a brush onto the right sweeping side

brush assembly and / or left sweeping side

brush assembly. Use a cotter pin to secure

the brush(es) onto the sweeping side brush

assembly(ies). (Fig. 3 / Fig. 5)

10. Raise the machine slightly off the jack stands,

remove the jack stands from under the

machine, and lower the machine to the floor.

IB 9012969 (07- 2016)4

30 31

15 7

FRONT

M8 SEMS

hex screws

FIG. 2 - Sweeping Side Brush Lift Group, Right Side

IB 9012969 (07- 2016) 5

Ref.

Tennant

Part No. Description Qty.

11207330 Housing Wldt, SBA, RH (Kits 9020057 / 9020206 Only) 1

1 1225432 Housing Wldt, SBA, RH (Kits 9014962 / 9014963 Only) 1

2 1071085 Clip, Tie, 0.25d, Plstc 3

3 369781 Pulley, Cable, 1.5d Nyl 1

4 222460 Sleeve, P/M, 0.32b 0.50d 0.5l [430ss] 1

554400 Bracket, Angle, Keeper, Cable 1

6 1205013 Cable, SS, .09d 10.35l .38eye/M6- 1.0 1

7 01685 Washer, Flat, 0.38b 0.88d .08, SS 10

8 09023 Screw, Hex, M8 X 1.25 X 35, Fl, SS 1

9 08713 Nut, Hex, Lock, M8 X 1.25, Nl, SS 5

10 1201500 Actuator, 36vdc, 2.75strk, 450lb 1

11 57598 Pin, Clevis, 0.37d X 3.25l 2

12 44906 Pin, Cotter, Hair, 0.38d .093 Wir 2

13 08179 Pin, Cotter, .094 X 1.00 3

14 1204919 Bracket Wldt, Pivot, SBA (Kits 9020057 / 9020206 Only) 1

14 1225425 Bracket Wldt, Pivot, SBA (Kits 9014962 / 9014963 Only) 1

15 09010 Screw, Hex, M8 X 1.25 X 25, SS 2

16 1204774 Cable, Ss, .09d 7.87l .50eye/.50eye 1

17 222516 Sleeve, P/M, 0.32b 0.50d 0.3l [430ss] 2

18 49924 Pin, Clevis, 0.37d X 6.12l 1

19 1209244 Spring, Compr, .98od 2.5l 1

20 386299 Screw, Hex, M8 X 1.25 X 100, SS 1

21 379829 Washer, Flat, 0.34b 1.50d .12, Stl, Pl 1

22 1037346 Screw, Hex, M8 X 1.25 X 25, 9.8, SEMS 3

23 1205016 Lever Wldt, Adj, SBA 1

24 33930 Screw, Hex, M6 X 1.00 X 40, SS 1

25 01684 Washer, Flat, 0.27b 0.69d .05, SS 1

26 01847 Wheel, 01.6d 0.72w 0.21b 1

27 08712 Nut, Hex, Lock, M6 X 1.00, Nl, SS 1

28 1208858 Cover, Handle 1

29 81672 Spring, Cmpr, 0.37id X Flat Wir, 1.0l 1

30 49694 Screw, Hex, M8 X 1.25 X 50, SS 1

31 1017218 Washer, Flat, 0.32b 1.00d .12, SS 1

32 1204396 Bracket, Arm, SBA 1

33 59672 Pin, Clevis, 0.37d X 4.50l 2

34 15047 Spring, Extn, 0.62od 0.08wir 03.0l 1

35 07785 Nut, Hex, Std, M6 X 1.00, SS 2

IB 9012969 (07- 2016)6

FRONT

FIG. 3 - Sweeping Side Brush Drive Motor Group, Right Side

Ref.

Tennant

Part No. Description Qty.

11212824 Motor, Ele, 36vdc 0.08hp 0068rpm Gear RH 1

2 1207139 Bracket Wldt, Mtg, Motor, SBA 1

3 11398 Pin, Roll, .250d X 2.00l, .250/.256 1

4 1040467 Screw, Hex, M6 X 1.00 X 20, 9.8, SEMS 4

5 1207412 Cover, Sidebrush, Sweeping 1

61020341 Screw, Hex, M8 X 1.25 X 20, SS, SEMS 4

7 1017441 Plate, Adapter, Brush 1

8 87419 Brush, Disk, Swp, 19.0d, Pyp 1

9 1017802 Washer, Flat, 0.66b 2.50d .19, SS 1

10 02942 Pin, Hair, Cotter, 0.62d .120 Wir 1

11 1071085 Clip, Tie, 0.25d, Plstc 1

IB 9012969 (07- 2016) 7

21 9

FRONT

(Qty. 3)

M8 SEMS

hex screws

FIG. 4 - Sweeping Side Brush Lift Group, Left Side

IB 9012969 (07- 2016)8

Ref.

Tennant

Part No. Description Qty.

11207554 Housing Wldt, SBA, LH (Kits 9020057 / 9020206 Only) 1

1 1225423 Housing Wldt, SBA, LH (Kits 9014962 / 9014963 Only) 1

2 1071085 Clip, Tie, 0.25d, Plstc 3

3 369781 Pulley, Cable, 1.5d Nyl 1

4 222460 Sleeve, P/M, 0.32b 0.50d 0.5l [430ss] 1

554400 Bracket, Angle, Keeper, Cable 1

6 1205013 Cable, SS, .09d 10.35l .38eye/M6- 1.0 1

7 01685 Washer, Flat, 0.38b 0.88d .08, SS 10

8 09023 Screw, Hex, M8 X 1.25 X 35, Fl, SS 1

9 08713 Nut, Hex, Lock, M8 X 1.25, Nl, SS 5

10 1201500 Actuator, 36vdc, 2.75strk, 450lb 1

11 57598 Pin, Clevis, 0.37d X 3.25l 2

12 44906 Pin, Cotter, Hair, 0.38d .093 Wir 2

13 08179 Pin, Cotter, .094 X 1.00 3

14 1204919 Bracket Wldt, Pivot, SBA (Kits 9020057 / 9020206 Only) 1

14 1225425 Bracket Wldt, Pivot, SBA (Kits 9014962 / 9014963 Only) 1

15 09010 Screw, Hex, M8 X 1.25 X 25, SS 2

16 1204774 Cable, Ss, .09d 7.87l .50eye/.50eye 1

17 222516 Sleeve, P/M, 0.32b 0.50d 0.3l [430ss] 2

18 49924 Pin, Clevis, 0.37d X 6.12l 1

19 1209244 Spring, Compr, .98od 2.5l 1

20 386299 Screw, Hex, M8 X 1.25 X 100, SS 1

21 379829 Washer, Flat, 0.34b 1.50d .12, Stl, Pl 1

22 1037346 Screw, Hex, M8 X 1.25 X 25, 9.8, SEMS 3

23 1205016 Lever Wldt, Adj, SBA 1

24 33930 Screw, Hex, M6 X 1.00 X 40, SS 1

25 01684 Washer, Flat, 0.27b 0.69d .05, SS 1

26 01847 Wheel, 01.6d 0.72w 0.21b 1

27 08712 Nut, Hex, Lock, M6 X 1.00, Nl, SS 1

28 1208858 Cover, Handle 1

29 81672 Spring, Cmpr, 0.37id X Flat Wir, 1.0l 1

30 49694 Screw, Hex, M8 X 1.25 X 50, SS 1

31 1017218 Washer, Flat, 0.32b 1.00d .12, SS 1

32 1204396 Bracket, Arm, SBA 1

33 59672 Pin, Clevis, 0.37d X 4.50l 2

34 15047 Spring, Extn, 0.62od 0.08wir 03.0l 1

35 07785 Nut, Hex, Std, M6 X 1.00, SS 2

IB 9012969 (07- 2016) 9

FRONT

FIG. 5 - Sweeping Side Brush Drive Motor Group, Left Side

Ref. Part No. Description Qty.

11212823 Motor, Ele, 36vdc 0.08hp 0068rpm Gear LH 1

2 1207559 Mount Wldt, Motor, SBA 1

3 11398 Pin, Roll, .250d X 2.00l, .250/.256 1

4 1040467 Screw, Hex, M6 X 1.00 X 20, 9.8, SEMS 4

5 1207412 Cover, Sidebrush, Sweeping 1

61020341 Screw, Hex, M8 X 1.25 X 20, SS, SEMS 4

7 1017441 Plate, Adapter, Brush 1

8 87419 Brush, Disk, Swp, 19.0d, Pyp 1

9 1017802 Washer, Flat, 0.66b 2.50d .19, SS 1

10 02942 Pin, Hair, Cotter, 0.62d .120 Wir 1

11 1071085 Clip, Tie, 0.25d, Plstc 1

IB 9012969 (07- 2016)10

FRONT

Right

console

panel

Front

shroud

Do Not break wire or cable connections when

removing right console panel from front shroud or

electricalenclosurecoverfromelectricalenclosure

FRONT

2(Qty.2)

3(Qty.2)

Electrical

enclosure cover

Electrical

enclosure

Install into

circuit breaker

location 3

M6 SEMS

hex screws

Pan screws

(Qty. 5)

(Qty. 4)

FIG. 6 - Sweeping Side Brush Electrical Group

Ref. Part No. Description Qty.

19020229 Circuit Board Kit, H20, Afmkt [T17] 1

2 06926 Screw, Pan, Phl, M4 X 0.70 X 10, 4.8 2

3 1202860 Washer, Flat, 0.17b 0.31d .03, Nyl 2

4 1210399 Stand- Off, Circuit Board [0.25”] 4

5 383723 Circuit Breaker, 20.0a, Resettable 1

6397889 Switch, Rocker, Dpst, On / None / On 1

Otros manuales para T17 Series

Tabla de contenidos

Otros manuales de Depurador de Tennant

Tennant

Tennant 8010 Manual de usuario

Tennant

Tennant 7400 Manual de usuario

Tennant

Tennant Nobles WB-20B Manual del producto

Tennant

Tennant 5500 Pac Manual del producto

Tennant

Tennant SweepSmart S20 ELECTRIC Manual de capacitación

Tennant

Tennant T16 Manual de capacitación

Tennant

Tennant T5 Manual de usuario

Tennant

Tennant T290 Manual de usuario

Tennant

Tennant M30 Manual de usuario

Tennant

Tennant 5700 Manual de capacitación

Tennant

Tennant T16 Manual de capacitación

Tennant

Tennant 5500 Complete Manual del producto

Tennant

Tennant T291 Manual de usuario

Tennant

Tennant T17 Series Manual de capacitación

Tennant

Tennant T681 Manual de usuario

Tennant

Tennant T17 Series Manual de usuario

Tennant

Tennant T3 Manual de usuario

Tennant

Tennant M30 Instrucciones de funcionamiento e instalación

Tennant

Tennant T17 Series Manual de capacitación

Tennant

Tennant 7200 Manual de usuario

Tennant

Tennant 9021147 Manual de usuario

Tennant

Tennant SweepSmart S20 ELECTRIC Manual de capacitación

Tennant

Tennant 7100 Manual de capacitación

Tennant

Tennant 265XP Manual de usuario

Manuales populares de Depurador de otras marcas

Olympus

Olympus M200H Manual de usuario

Clarke

Clarke BEXT 100H Manual de instalación y funcionamiento

JOHNY VAC

JOHNY VAC JVC70BCT Manual de usuario

RCm

RCm Elan Series Manual

Kärcher

Kärcher B 120 W Manual de usuario

Truvox

Truvox Orbis MotorScrubber 20 Manual de usuario

Numatic

Numatic TTB 4045/100 Manual de usuario

U.S. Products

U.S. Products PEX 500-C-TICK Instrucciones de funcionamiento

Mclennan

Mclennan C510 Manual de usuario

Columbus

Columbus ARA 66 BM 100 Manual de usuario

Numatic

Numatic TTV 678G / 300T Manual de usuario

American-Lincoln

American-Lincoln 505-945 Manual de usuario

FIORENTINI

FIORENTINI ET 65-75 Manual de usuario

Floorpul

Floorpul ruby 48 blt Guía del usuario

Onyx

Onyx RX-34 Manual de usuario

Dustbane

Dustbane Hurricane 400 Manual de usuario

Sana

Sana EUJ-702 Manual de usuario

REMS

REMS Twist Manual de usuario
