1: Your Swirl Wheelbase / Interface Workshop Manual
The purpose of this manual is to help you get the best from your wheelbase & interface. It
does this by telling you how to complete those maintenance and repair tasks that can be
carried out by a competent person. The manual also tells you when you should contact the
manufacturer who is:
Tendercare Ltd.
PO BOX 3091, Littlehampton, BN16 2WF
Tel: (01903) 726161 Fax: (01903) 734083
Web: www.tendercareltd.com
IMPORTANT:
This manual must be read and used in conjunction with the user manual.
The Wheelbase is made of a strong and lightweight aluminium alloy, minimising weight
and providing a very rugged frame. The wheelbase provides tilt in space and rotation
facilities and has 2 fixed rear wheels and 2 castor wheels at the front for easy steering.
The Interface provides a very lightweight, easy to operate, quick release system that can
be fitted to a wide range of special seating systems. Please note the interface requires
additional framework to fit to a seat, and has been designed to take 19mm (3/4”)
aluminium or mild steel tube.
The interface can be quickly fitted and released from the wheelbase, which can be folded
for transport. The Swirl has been successfully impact tested as a wheelbase and interface,
with the Snappi, Snug and Modular seating systems. When fitting 3rd party seating
systems to the Swirl, the manufacturer of the system must carry out a risk assessment
before use.
These instructions apply to all sizes.
Interfacing Options:
IMPORTANT:
❖Maximum width; maximum space available for seating systems being fitted into
frame.
❖*Maximum carry weight is defined as the user weight, weight of the seating
system, plus any accessories / equipment which may be fitted or carried on the
chassis. Warning: Never exceed the maximum stated carry weight.
Frame Weight: 13.4kg
