Tenda TEI480T Manual de usuario

Enterprise Broadband Router

BRIEF INTRODUCTION PRODUCT FEATURES

Wired

Model No.:TEI480T

All For Better NetworkAll For Better Network

All For Better Network

Complies with IEEE 802.3、IEEE 802.3u standards;

Supports TCP/IP, PPPoE, DHCP, ICMP, NAT, SNTP, DNS, TFTP, ARP;

Provides one 10/100M WAN ports and four 10/100M LAN ports;

Specifies priority channels according to source or destination

IP addresses;

Supports MAC address binding with IP address to prevent the

network access of unauthorized clients;

The TEI480T+ integrates multiple functions. It not only supports Load

Balancing and backups connections automatically for each other, but

supports IP address filtering, Domain Name filtering and MAC address

filtering as well. Besides, port bandwidth control, port mirror, port-base

VLAN for LAN ports, VPN Pass－through, Dynamic DNS, Virtual Server,

DMZ host, UPnP functions will help you to manage the network easily.

Enterprise Broadband Router

Special for large networking Powerful management Multiple function

WHAT THIS PRODUCT DOES

BENEFITS

TECHNICAL SPECIFICATIONS

All For Better NetworkAll For Better Network

All For Better Network

Shenzhen Tenda Technology Co., Ltd.

Contact us

Address:Tenda Industrial Park, No. 34-1, Shilong Rd.,Shiyan Town,

Bao’an District, Shenzhen, P.R. China 518108

Tel: 0086.755.2765.7180 Fax: 0086.755.2765.7178

E-mail: [email protected] Http: www.tenda.cn

Copyright statement

Obligation-free statement

PACKAGE CONTENTS

MINIMUM REQUIREMENTS

Internet Explorer 5.5 or Firefox 1.0

Network Adapter

Wired

Tenda is the registered trademark of Shenzhen Tenda

Technology Co. LTD in CHINA and certain other countries.

Copyright © 2007 Shenzhen Tenda Technology Co. LTD

All rights reserved. Other brands and product name

are trademarks or registered trademarks of their

respective holders.

The maximum performance for wireless is derived from IEEE Standard 802.11 specifications. Actual

performance can vary, including lower wireless network capacity, data throughput rate, range and

coverage. Per formance depends on many factors, conditions and variables, including distance from

the access point, volume of network traffic, building materials and construction, operating system

used, mix of wireless products used, interference and other adverse conditions.

Check the product package and contents for specific features supported. Specifications are subject to

change without notice.

Model No.:TEI480T

Provides dual WAN to connect two ISPs and guarantee

a no dropped connection network.

TEI480T+ Enterprise Broadband Router

Power Cord

User Manual

Supports Load Balancing and backups connections

automatically for each other;

Supports Auto MDI/MDIX;

Supports flow statistics;

Supports the flow control based on IP address and

TCP amount;

Supports port bandwidth control, port mirror and

port-base VLAN for LAN ports;

Power Supply

Operating Temperature

Operating Humidity

Storage Temperature

Storage Humidity

Dimension (WXDXH)

Gross Weight

Certificate

Transmission Media

Interface

Housing Material

32 to 104 F (0 to 40 ) º ºC

10 to 90% Noncondensing

-40 to 158 (-40 to 70ºC) ºF

5 to 90% Noncondensing

1.99Kg

CE, RoHS

Internal Switch Power, AC 110-240V 50/60Hz input

10Base-T:Cat. 3 or above UTP/STP, 100Base-TX:Cat. 5 UTP/STP

2WAN Port, 3 LAN Port

Metal

Protocols and Standards

295 158 44mm (11.6"X6.2"X1.7")X X

IEEE 802.3, IEEE 802.3u, TCP/IP, PPPoE, DHCP, ICMP, NAT, SNTP, DNS, TFTP
