Tenda TEG1024G Manual de usuario

16-Port Unmanaged Gigabit Ethernet Switch

BRIEF INTRODUCTION PRODUCT FEATURES

Wired

Model No.:TEG1024G

All For Better NetworkAll For Better Network

All For Better Network

16-Port Unmanaged Gigabit Ethernet Switch

Expand your networking Easy to use

Store-and-forward

The TEG1016G is 16-port 1U rack-mountable Gigabit switches. It supports

auto MDI/MDIX and store-and-forward switching. The TEG1016G has a

32Gbps backplane bandwidth. the switches is ready for deployment in

server rooms or offices with a need to keep serious network traffic flowing.

This switch let your network up to 16 Ethernet-enabled devices at speeds

up to 1000Mbps and is compact enough placed to anywhere in your home

and office. This desktop switch supports Quality of Service feture that

helps reduce jitter and lag with VOIP and games ! “Plug and play” function

assists you to set up easily.

Complies with IEEE 802.3x full-duplex and flow contro;l

16 10/100/1000Mbps ports connect to the workstation;

Supports Auto MDI/MDIX;

Supports NWA auto-negotiation function, auto-detect

transfer data rate, UPnP, full-duplex, and automatically

chooses the best network connectivity mode;

Supports IEEE802.3x full-duplex flow control, and half-

duplex backpressure flow control;

WHAT THIS PRODUCT DOES

BENEFITS

TECHNICAL SPECIFICATIONS

32 to 104 F (0 to 40 ) º ºC

10 to 90% Noncondensing

-40 to 158 (-40 to 70ºC) ºF

5 to 90% Noncondensing

437mmX177mmX43mm (17.2"X7.0"X1.7")

2.53Kg

All For Better NetworkAll For Better Network

All For Better Network

Shenzhen Tenda Technology Co., Ltd.

Address:Tenda Industrial Park, No. 34-1, Shilong Rd.,Shiyan Town,

Bao’an District, Shenzhen, P.R. China 518108

Tel: 0086.755.2765.7180 Fax: 0086.755.2765.7178

E-mail: [email protected] Http: www.tenda.cn

Obligation-free statement

PACKAGE CONTENTS

MINIMUM REQUIREMENTS

Internet Explorer 5.5 or Firefox 1.0

Network Adapter

Protocols and Standards

Power Supply

Operating Temperature

Operating Humidity

Storage Temperature

Storage Humidity

Dimension (WXDXH)

Gross Weight

Certificate CE, RoHS

Wired

Tenda is the registered trademark of Shenzhen Tenda

Technology Co. LTD in CHINA and certain other countries.

are trademarks or registered trademarks of their

respective holders.

The maximum performance for wireless is derived from IEEE Standard 802.11 specifications. Actual

performance can vary, including lower wireless network capacity, data throughput rate, range and

coverage. Performance depends on many factors, conditions and variables, including distance from

the access point, volume of network traffic, building materials and construction, operating system

used, mix of wireless products used, interference and other adverse conditions.

Check the product package and contents for specific features supported. Specifications are subject to

change without notice.

Model No.:TEG1024G

To expand your networking with 15 more Pcs

TEG1016G 16-Port Unmanaged Gigabit Ethernet Switch

User Manual

Quick Installaiton Guide

One power cord, two mounting ears, eight screws and four

Simple solution for expanding your networking;

Idea for VOIP and games

Space saving design and installation options

Easy to install and use

High speed and excellent performance

IEEE802.3, IEEE802.3u and IEEE802.3ab

AC 110-240V 50/60Hz input

MAC Address Table Size 8K

Transmission Method Store-and-Forward

10Base-T: Cat.3 or 3e UTP; 100Base-TX: Cat.5 UTP; 1000Base-T: Cat.5e UTP;

Packet Buffer 2Mb

Transmission Media

Interface

16 10/100/1000Mbps RJ45 Ports,

Backplane Bandwidth 32Gbps

Housing Material Steel
