FMT100 First Start

Main Page > Fast & Easy Trackers > FMT100 > FMT100 First Start

Special and small waterproof GNSS tracker with built-in accelerometer.

Contents

1 Know your device

2 Pinout

3 Set up your device

3.1 How to insert Micro-SIM card and connect the battery

3.2 PC Connection (Windows)

3.3 How to install USB drivers (Windows)

3.4 Configuration (Windows)

3.5 Quick SMS configuration

4 Quick installation guide

5 Mounting recommendations

6 Safety information

Know your device

Pinout

NUMBER PIN NAME DESCRIPTION

1VCC (10-30)V

DC (+)

(Red) Power supply

(+10-30 V DC)

2GND (-) (Black) Ground

Set up your device

How to insert Micro-SIM card and connect the battery

Unscrew 6 screws counterclockwise.1.

Remove the cover.2.

Insert Micro-SIM card as shown with PIN request disabled or read Security info how to3.

enter it later with Teltonika Configurator. Make sure that Micro-SIM card cut-off corner is

pointing forward to slot.

Connect the battery as shown to device. Position the battery in place where it does not4.

obstruct other components.

After configuration, see PC Connection (Windows), attach device cover back and screw in all5.

screws.

Device is ready to be mounted.6.

Micro-SIM card insertion/removal must be performed when device is powered off –

external voltage and battery are disconnected. Otherwise Micro-SIM card might be

damaged or device will not detect it.

PC Connection (Windows)

Power-up FMT100 with DC voltage 10-30 V power supply using power cable. LED’s should1.

start blinking, see “FMT100 LED status”.

Connect device to computer using Micro-USB cable or Bluetooth connection:2.

Using Micro-USB cable

You will need to install USB drivers, see "How to install USB drivers

(Windows)"

Using Bluetooth

FMT100 Bluetooth is enabled by default. Turn on Bluetooth on your PC, then

select Add Bluetooth or other device > Bluetooth. Choose your device named –

“FMT100_last_7_imei_digits”, without LE in the end. Enter default password

5555, press Connect and then select Done.

You are now ready to use the device on your computer.3.

How to install USB drivers (Windows)

Please download COM port drivers from here.1.

Extract and run TeltonikaCOMDriver.exe.2.

Click Next in driver installation window.3.

In the following window click Install button.4.

Setup will continue installing the driver and eventually the confirmation window will appear.5.

Click Finish to complete the setup.

Configuration (Windows)

At first FMT100 device will have default factory settings set. These settings should be changed

according to the user's needs.

Main configuration can be performed via Teltonika Configurator software. Get the latest FMT100

Configurator version from here. Configurator operates on Microsoft Windows OS and uses

prerequisite MS .NET Framework. Make sure you have the correct version installed.

MS .NET requirements

Operatin

g system

MS .NET

Framework version Version Link

•

Windows

Vista

•

Windows

•

Windows

8.1

•

Windows

MS .NET

Framework 5.0

32 and

64 bit

.NET

Fram

ewor

Downloaded Configurator will be in compressed archive. Extract it and launch Configurator.exe.

After launch software language can be changed by clicking in the right bottom corner:

Configuration process begins by pressing on connected device:

After connection to Configurator Status window will be displayed:

Various Status window tabs display information about GNSS, GSM, I/O, Maintenance and etc.

FMT100 has one user editable profile, which can be loaded and saved to the device. After any

modification of configuration the changes need to be saved to device using Save to device button.

Main buttons offer following functionality:

Load from device – loads configuration from device.1.

Save to device – saves configuration to device.2.

Load from file – loads configuration from file.3.

Save to file – saves configuration to file.4.

Update firmware – updates firmware on device.5.

Read records – read records from device.6.

Reboot device – restarts device.7.

Reset configuration – sets device configuration to default.8.

Most important configurator section is GPRS – where all your server and GPRS settings can be

configured and Data Acquisition – where data acquiring parameters can be configured. More

details about FMT100 configuration using Configurator can be found here.

Quick SMS configuration

Default configuration has optimal parameters present to ensure best performance of track quality

and data usage.

Quickly set up your device by sending this SMS command to it:

" setparam

2001:APN;2002:APN_username;2003:APN_password;2004:Domain;2005:Port;2006:0"

GPRS settings:

2001 – APN

2002 – APN username (if there are no APN username, empty field should be left)

2003 – APN password (if there are no APN password, empty field should be left)

Server settings:

2004 – Domain

2005 – Port

2006 – Data sending protocol (0 – TCP, 1 – UDP)

Note: Before SMS text, two space symbols should be inserted.

Default configuration settings

Movement and ignition detection:

Vehicle movement will be detected

by accelerometer

Ignition will be detected by

vehicle power voltage

between 13,2 – 30 V

Device makes a record On Moving if one of these events happen:

300 seconds passes Vehicle turns 10° degrees

Vehicle drives 100 meters

Speed difference between

last coordinate and current

position is greater than 10

km/h

Device makes a record On Stop if:

1 hour passes while vehicle is

stationary and ignition is off

Records sending to server:

If device has made a record it is

sent to the server every 120

seconds

After successful SMS configuration, FMT100 device will synchronize time and update records to

configured server. Time intervals and default I/O elements can be changed by using Teltonika

Configurator or SMS parameters.

Quick installation guide

Mounting recommendations

Double sided tape on the back

Example of device mounting

Device fastening

Locate the battery in your vehicle. If present remove the battery cover to access the battery.

Wipe clean the installation surface of the battery if any dust or dirt is visable.

There is a double sided tape on the back of the device, use it to attach the device on the

battery, so that the GNSS antenna and LEDs indicators are facing up.

Connecting power wire

Device power wire is designed to be directly connected to the positive terminal fastener of the

vehicle battery.

Connecting ground wire

Device ground wire is designed to be directly connected to the negative terminal fastener of

the vehicle battery.

Safety information

This message contains information on how to operate FMT100 safely. By following these

requirements and recommendations, you will avoid any dangerous situations. You must read these

instructions carefully and follow them strictly before operating the device!

The device uses a 10 V...30 V DC power supply. The nominal voltage is 12 V DC. The allowed

range of voltage is 10 V...30 V DC.

To avoid mechanical damage, it is advised to transport the device in an impact-proof package.

Before dismounting the device from the vehicle, ignition MUST be OFF.

Do not disassemble the device. If the device is damaged, the power supply cables are

not isolated or the isolation is damaged, DO NOT touch the device before unplugging

the power supply.

All wireless data transferring devices produce interference that may affect other

devices which are placed nearby.

The device must be connected only by qualified personnel.

The device must be firmly fastened in a predefined location.

The programming must be performed using a PC with autonomic power supply.

The device is susceptible to water and humidity if the device housing is not properly

closed.

Installation and/or handling during a lightning storm is prohibited.

Teltonika is not responsible for any harm caused by wrong cables used for connection

between PC and FMT100

Risk of explosion if battery is replaced by an incorrect type.

Battery should not be disposed of with general household waste. Bring damaged or

worn-out batteries to your local recycling center or dispose them to battery recycle bin

found in stores.
