Teltonika FMB001 Guía de instalación

Quick Manual

v1.0

Easy OBDII tracker

FMB001

FMB001 | Wiki

Table of Contents

Know your device .......................................................................... 3

Pinout................................................................................................. 4

Set up your device......................................................................... 5

How to insert Micro-SIM card and connect battery ...................... 5

PC Connection (Windows)................................................................ 6

How to install USB drivers (Windows)............................................. 6

Configuration (Windows) ................................................................. 6

LED indications .............................................................................. 8

Characteristics............................................................................... 8

Basic characteristics ......................................................................... 8

Safety information ...................................................................... 10

Certification and Approvals ....................................................... 11

FMB001 | Wiki

Know your device

Figure 1 FMB001 device view

FMB001 | Wiki

Pinout

Table 1 OBDII pinout

Pinnumber Pinname Description

1 DIN1 Ignition input

2 PWM_BUS+/VPW

4 GND (-) Ground

5 GND (-) Ground

6 CAN_H CAN high

7 K-Line

10 PWM_BUS-

14 CAN_L CAN low

15 L-Line

16 VCC (10 - 30)V DC(+) Power supply (+10-30 V DC)

Figure 2 FMB001 OBDII socket pinout

FMB001 | Wiki

Set up your device

How to insert Micro-SIM card and

connect the battery

1. Gently remove FMB001 cover using plastic pry tool from both

sides.

2. Insert Micro-SIM card as shown with PIN request disabled or

read our Wiki how to enter it later in Configurator. Make sure

that Micro-SIM card cut-off corner is pointing forward to slot.

3. Connect battery as shown to device. Position the battery in

place where it does not obstruct other components.

4. Attach device cover back.

Device is ready to be connected.

Figure 3 Cover removal Figure 4 Micro-SIM card insert

Figure 5 Battery connection Figure 6 Attaching cover back

FMB001 | Wiki

PC Connection (Windows)

1. Power-up FMB001 with DC voltage (10 – 30 V) power supply

using supplied power cable. LED’s should start blinking, see

“LED indications”.

2. Connect device to computer using Micro-USB cable or Blue-

tooth connection:

•Using Micro-USB cable

▬You will need to install USB drivers, see “How to install

USB drivers (Windows)”

•Using Blue-tooth

▬FMB001 Blue-tooth is enabled by default. Turn on Blue-

tooth on your PC, then select Add Blue-tooth or other

device > Blue-tooth. Choose your device named –

“FMBxxx_last_7_imei_digits”, without LE in the end.

Enter default password 5555, press Connect and then

select Done.

3. You are now ready to use the device on your computer.

How to install USB drivers

(Windows)

1. Please download COM port drivers from here.

2. Extract and run TeltonikaCOMDriver.exe.

3. Click Next in driver installation window.

4. In the following window click Install button.

Setup will continue installing the driver and eventually the

confirmation window will appear. Click Finish to complete the

setup.

Configuration (Windows)

At first FMB001 device will have default factory settings set. These

settings should be changed according to the user's needs. Main

configuration can be performed via Teltonika Configurator

software. Contact sales manager to get the latest Configurator

version or download it from here.Configurator operates on

Microsoft Windows OS and uses prerequisite MS .NET

Framework. Make sure you have the correct version installed.

Table 2 MS .NET requirements

MS.NETrequirements

Operating

system

MS .NET Framework

version Version Links

Windows Vista

Windows 7

Windows 8.1

Windows 10

MS .NET Framework

4.6.2 32 and 64 bit www.microsoft.com

Downloaded Configurator will be in compressed archive. Extract it

and launch Configurator.exe. After launch software language can

be changed by clicking in the right bottom corner (Figure 7

Language selection).

FMB001 | Wiki

Configuration process begins by pressing on connected device

(Figure 8 Device connected via USB).

After connection to Configurator Status window will be displayed

(Figure 9 Configurator Status window).

Various Status window tabs display information about GNSS,

GSM,I/O, Maintenance and etc. FMB001 has one user editable

profile, which can be loaded and saved to the device. After any

modification of configuration the changes need to be saved to

device using Save to device button. Main buttons offer following

functionality:

1. Load from device – loads configuration from device.

2. Save to device – saves configuration to device.

3. Load from file – loads configuration from file.

4. Save to file – saves configuration to file.

5. Update firmware – updates firmware on device.

6. Read records – reads records from the device.

7. Reboot device – restarts device.

8. Reset configuration – sets device configuration to

default.

Most important configurator section is GPRS – where all your

server and GPRS settings can be configured and Data Acquisition

–where data acquiring parameters can be configured.

More details about FMB001 configuration using Configurator can

be found in our Wiki.

Figure 8 Device connected via USB

Figure 7 Language selection

Figure 9 Configurator Status window

FMB001 | Wiki

LED indications

Table 3 Navigation LED indications

Behaviour Meaning

Permanently switched on GNSS signal is not received

Blinking every second Normal mode, GNSS is working

Off

GNSS is turned off because:

Device is not working or Device is in

sleep mode

Blinking fast constantly Device firmware is being flashed

Table 4 Status LED indications

Behaviour Meaning

Blinking every second Normal mode

Blinking every two seconds Sleep mode

Blinking fast for a short time Modem activity

Off Device is not working or Device is in

boot mode

Characteristics

Basic characteristics

Table 5 Basic characteristics

Module

Name TM2500

Technology GSM, GPRS, GNSS, BLUE-TOOTH

GNSS

GNSS GPS, GLONASS, GALILEO, BEIDOU,

SBAS, QZSS, DGPS, AGPS

Receiver 33 channel

Tracking sensitivity -165 dBM

Accuracy < 3 m

Hot start < 1 s

Warm start < 25 s

Cold start < 35 s

Cellular

Technology GSM

2G bands Quad-band 850 / 900 / 1800 / 1900

MHz

Data transfer GPRS Multi-Slot Class 12 (up to 240

kbps), GPRS Mobile Station Class B

Data support SMS (text/data)

FMB001 | Wiki

Power

Input voltage range 10 - 30 V DC with overvoltage

protection

Power consumption

At 12V < 5 mA (Ultra Deep Sleep)

At 12V < 7 mA (Deep Sleep)

At 12V < 7 mA (Online Deep Sleep)

At 12V < 8 mA (GPS Sleep)

At 12V < 28 mA (nominal)

Blue-tooth

Specification 4.0 + LE

Supported peripherals Temperature and Humidity sensor,

Headset, OBDII dongle

OBDInterface

Data K-Line, CAN Bus data

Data reading Up to 32 vehicle onboard parameters,

10 supported OBD protocols

Interface

Digital Inputs 1

Connection OBDII socket

GNSS antenna Internal High Gain

GSM antenna Internal High Gain

USB 2.0 Micro-USB

LED indication 2 status LED lights

SIM Micro-SIM

Memory 128MB internal flash memory

Physicalspecification

Dimensions 50,7 x 49,6 x 25 mm (L x W x H)

Weight 63 g

Operatingenvironment

Operating temperature -25 °C to +55 °C

Storage temperature -40 °C to +70 °C

Operating humidity 5% to 95% non-condensing

Ingress Protection Rating IP41

Features

Sensors Accelerometer

Scenarios

Green Driving, Over Speeding

detection, Jamming detection, GNSS

Fuel Counter, Excessive Idling

detection, Unplug detection, Towing

detection, Crash detection, Auto

Geofence, Manual Geofence, Trip

Sleep modes GPS Sleep, Online Deep Sleep, Deep

Sleep, Ultra Deep Sleep

Configuration and firmware update

FOTA Web, FOTA, FMB Configurator

(USB, Blue-tooth), FMBT mobile

application (Configuration)

SMS Configuration, Events, Debug

GPRS commands Configuration, Debug

Time Synchronization GPS, NITZ, NTP

FMB001 | Wiki

Safety information

This message contains information on how to operate FMB001

safely. By following these requirements and recommendations,

you will avoid dangerous situations. You must read these

instructions carefully and follow them strictly before operating the

device!

•The device uses SELV limited power source. The nominal

voltage is +12 V DC. The allowed voltage range is +10…+30 V DC.

•To avoid mechanical damage, it is advised to transport the

device in an impact-proof package. Before usage, the device

should be placed so that its LED indicators are visible. They

show the status of device operation.

•Before unmounting the device from vehicle, ignition MUST be

OFF.

Do not disassemble the device. If the device is

damaged, the power supply cables are not

isolated or the isolation is damaged, DO NOT

touch the device before unplugging the power

supply.

All wireless data transferring devices produce

interference that may affect other devices which

are placed nearby.

Please consult representatives of your vehicle

model regarding OBDII location on your vehicle. In

case you are not sure about proper connection,

please consult qualified personnel.

The programming must be performed using a PC

with autonomic power supply.

Installation and/or handling during a lightning

storm is prohibited.

The device is susceptible to water and humidity.

Teltonika is not responsible for any harm caused

by wrong cables used for connection between PC

and FMB001

WARNING! Do not use FMB00 device if it distracts

driver or causes inconvenience due to OBDII

placement. Device must not interfere with driver.

Otros manuales para FMB001

Tabla de contenidos

Otros manuales de GPS de Teltonika

Teltonika

Teltonika FMB003 Manual de usuario

Teltonika

Teltonika GH1200 Manual de usuario

Teltonika

Teltonika FMB650 Manual de usuario

Teltonika

Teltonika Telematics FMM650 Manual de usuario

Teltonika

Teltonika Telematics FMM150 Guía de instalación

Teltonika

Teltonika FMB125 Guía de instalación

Teltonika

Teltonika FMB125 Guía de instalación

Teltonika

Teltonika FMB240 Guía de instalación

Teltonika

Teltonika FMA202 Manual de usuario

Teltonika

Teltonika FMC001 Manual de usuario

Teltonika

Teltonika GH4000 Manual de usuario

Teltonika

Teltonika GH4000 Manual de usuario

Teltonika

Teltonika GH4200 Instrucciones de montaje

Teltonika

Teltonika LV-CAN100 Manual de usuario

Teltonika

Teltonika FMB020 Guía de instalación

Teltonika

Teltonika FM1100 Manual de usuario

Teltonika

Teltonika GH5200 Manual de usuario

Teltonika

Teltonika FMT100 Manual de usuario

Teltonika

Teltonika Telematics FMB150 Guía de instalación

Teltonika

Teltonika Telematics FMC003 Guía de instalación

Teltonika

Teltonika FM4200 Manual de usuario

Teltonika

Teltonika MSP500 Manual de usuario

Teltonika

Teltonika FMB910 Manual de usuario

Teltonika

Teltonika FMB920 Guía de instalación

Manuales populares de GPS de otras marcas

Raven

Raven Cruizer II Manual

Hama

Hama 53118 Manual de usuario

Garmin

Garmin SOUNDER 125 Manual de usuario

Garmin

Garmin DEZL 580 Manual de usuario

Jigabot

Jigabot EX Manual de usuario

Pointer

Pointer Cellocator CelloTrack XT LTE Guía de instalación

Queclink

Queclink GV55LITE Manual de usuario

Voxson

Voxson Voxtrack GPS500 Manual de instrucciones

Garmin

Garmin ECHOMAP PLUS Manual de usuario

Starcom Systems

Starcom Systems Kylos Compact Manual de usuario

Garmin

Garmin 15 H Series Manual de usuario

Cobra

Cobra Marine MC 600Ci Manual de usuario

Cellocator

Cellocator CelloTrack T Manual de usuario

Enfora

Enfora Mini-MT GSM2228UG001 Manual de usuario

Magellan

Magellan eXplorist 100 Manual de usuario

LTE

LTE G50B Manual de usuario

Garmin

Garmin DEZL OTR500 Manual de usuario

SkyGolf

SkyGolf SkyCaddie SG1 Manual de usuario
