Telematrix 3000LBY Manual de usuario

3000LBY

SINGLE LINE

LOBBY

PHONE

INSTALLATION

AND USER GUIDE

COMPLIANCE AND SAFETY

As specified by FCC regulation, we are required to inform you of specific governmental and compliance

regulatory requirements, safety notices, safety instructions and other informative information. TeleMa-

trix, Inc. provides this information in a separate manual. We pack the separate Compliance and Safety

Manual within each outer box or product box when shipped.

Prior to reading this operation manual and prior to setting up your telephone, please refer to the Compli-

ance and Safety Manual.

If the Compliance and Safety Manual is not immediately available. Please obtain a free copy by calling

our Priority Care Department (phone number 1-800-462-9446) or by downloading a copy on our Internet

(web site address www.telematrixusa.com).

Features ...........................................………..……………………………………................................... 1

Controls ...........................................................................……………………………………………….. 2

Installation .....................................................................……………………………………………........ 4

Operation ........................................................................……………………………………………..... 6

Care and Maintenance ..................................................……………………………………………....... 7

Service …………………………………………………..……………………………………….………… 8

Warranty .......................................................................……………………………………………....... 9

CONTENTS

FEATURES

•One Line

•Convenient Data Port

•Handset Volume Control

•HI/LOW Ringer Volume Control Switch

•Desk or Wall Mountable

•Fully Modular, Easy To Install

CONTROLS

1. Handset Hanger ………….…………………..… Temporarily holds the handset when the unit is wall mounted.

2. Handset ..........…………..………….........…... Hearing aid compatible, low profile styling.

3. Ringer Controls ………………….……………. Adjusts the volume of the ringers to HI/LOW setting.

4. Handset Jack ……………………………….… Modular receptacle where handset cord plugs into the base unit.

5. Handset Volume Control ……………….…….. Increase the loudness of the receiver volume when pressed.

6. Data Port ……………………………………….. Used to connect a computer modem, fax machine, or answering device.

DEFINITION OF CONTROLS

FRONT VIEW

(2)

(1)

(4)

(6) (5)

(3)

INSTALLATION

Parts Check List

The following parts are included in this package:

1. 15’ modular telephone line cord.

2. Modular coiled handset cord.

3. Base unit

4. Handset

Caution

•Never install telephone wiring during a lightning storm.

•Never install telephone jacks in wet locations unless the jack is specifically designed for wet locations.

•Never touch uninstalled telephone wires or terminals unless the telephone line has been disconnected at the network interface.

•Use caution when installing or modifying telephone lines.

(1)

(3)

(2)

(4)

The wall mount wedge is not included . Call customer service for ordering information.

Connecting The Handset Cord

A 10’ modular coil handset cord is provided.

To install, simply plug one end of the handset

cord into the modular jack on the handset.

The remaining end of the handset cord plugs

into the jack labeled “Handset” located on

the left side of the base unit.

(figure 3)

INSTALLATION

Connecting The Line Cord

A 15’ modular line cord is provided.

To install, simply plug one end of the line

cord into the modular jack located on the

back of the base unit. The remaining end of

the line cord plugs into the wall jack.

(figure 4)

Figure 4

Figure 3

OPERATION

PLACING A CALL USING THE HANDSET

•Lift the handset.

•Dial out by using the numeric dial pad or by

pressing a speed dial location.

RECEIVING A CALL USING THE HANDSET

•lift the handset when ringing.

HANDSET VOLUME CONTROL

The handset volume control increases the

volume of the handset.

When the handset is off hook, press the

volume control key to increase the headset

volume. The volume control is a HI/LOW

operation. It is hearing aid compatible.

CARE AND MAINTENANCE

Wipe the telephone with a damp cloth occasionally to keep it look-

ing new. Do not use harsh chemicals, cleaning solvents, or strong

detergents to clean the system.

Keep the telephone dry. If it gets wet, wipe it dry immediately.

Liquids might contain minerals that can corrode the electronic cir-

cuits.

Use and store the telephone only in normal temperature environ-

ments. Temperature extremes can shorten the life of electronic

devices, damage batteries, and distort or melt plastic parts.

Keep the telephone away from excessive dust and dirt that can

cause premature wear of parts.
