Telematrix Spectrum Plus DC550 Manual de usuario

This page is intentionally left blank

Congratulations on your purchase of the TeleMatrix Spectrum PLUSTM Series DC640

Digital Centrex The DC550 includes advanced features that are suitable i n today’s

business e nvironment. The DC550 i s e quipped wi th preprinted fe ature/line ke ys

which can be used to customize your telephone features and line appearance.

TeleMatrix designed the DC550 to be simple to install and easy to use. The DC550

is f or us e be hind a No rtel Me ridian Dig ital Ce ntrex environment pr ovided by y our

local telephone company. It has a two line LCD display which displays local business

telephone features and switch features that are provided by your telephone service

provider. Switch features must be ordered from your local telephone provider. Local

features provide you the convenience of customizing your DC550 telephone for your

personal use.

The DC550 Digital Centrex Telephone is a precision electronic device that requires

minimum maintenance. Please be sure to read the contents set forth in the user’s

guide to become familiar with connecting and the functionality of this product.

Contact your T elephone Admi nistrator or y our l ocal te lephone Cus tomer S ervice

Representative for proper set up of your telephone network.

As specified by FCC regulation, we are required to inform you of specific governmental and

compliance regulatory requirements, safety notices, safety instructions and other informative

information. TeleMatrix, Inc. provides this information in a separate manual. We pack the

separate Compliance and Safety Manual within each outer box or product box when shipped.

Prior to reading this operation manual and prior to setting up your telephone, please refer to

the Compliance and Safety Manual.

Features .........................................………...................................... 5

Controls …….................................................................................. 6

Part List ……………………………………………………………………………………………...….. 10

Installation ....……......................................................................... 11

Wall Mounting .....…..............................……................................... 14

Programming ..……..............................…....................................... 16

LCD Display/Caller Identification …………..…..………………………………..……... 29

Headset Installation and Operation……........…................................... 32

Operation ………………………………………………………………………...……………………. 34

Care and Maintenance ……………………………………………………………………….…. 40

Service ………………………………………………………………………………………………….. 41

Warranty ………………………………………………………………………………………………. 42

FCC Compliance and Safe ty I nstructions, Warra nty and Se rvice Information may

be f ound in a s eparate m anual w ithin th is pa ckage. I f th ese/this ma nual is n ot

found in this products packaging, then immediately contact your local supplier

•Digital Centrex Operation with multi-line functionality

•SteelTrapTM Memory Technology (No Batteries Required)

•FreeSpeechTM Talk Feature: Allows Free Toggle between Handset, Headset and

Speakerphone

•Eleven (11) Access Feature Keys with LED Indicators (Key #M01-M11)

•TouchLiteTM One Touch Message Retrieval Key (Key #M12)

•Visual Message Waiting Indication and Visual Ringing Indicator

•Large, 2-line x 24-Character LCD Display

- Contrast Adjustable, 16-step

- Backlit LCD Display

- Display for Additional Call Information

- Programmable Date & Time

- Programmable Date and Time Format; 12 or 24 Hour Clock

- Ten (10) Programmable Dialing Memory Locations; 20 digit capacity

- Elapsed Call Timer

- Multiple Language Support; English, Spanish, and French

•LCD Display Management Keys; Up and Down Scrolling

•LCD Display Programming Keys; Exit, Select, Save

•Hands Free 2-Way Speakerphone (Half Duplex) with LED Indication

•Headset Port with ON/OFF Key (built-in Amplifier) with LED Indicator

•Speaker, Handset, Headset, and Ringer Volume Control (Soft Key Toggle Switch)

•ADA Compliant Handset with 16-step Volume Control

•Microphone Mute Key with LED Indication

•Electronic Hold Key (must be provisioned for hold)

•Programming Keys; Program, Memory, Pause, Store, Up, and Down

•Memory Review Key

•Pause Key for Programming a 1.0 Second Timing Delay

•Release Key to Disconnect Call

•On Hook Pre-dialing Feature; On Hook Dialing (User Set Up)

•User Programmable Answering Default Location; Headset or Speaker

•Programmable Primary Directory Number (PDN)

•LED Indicators show ON/OFF, Flash and Wink Key Status

•Telephone Reset Feature (removes all data)

•

Wall Mount or Desktop Placement

1. Access Feature Keys ….…………..…………... Eleven (11) illuminated pr ogrammable on e-

touch ke ys used fo r l ine or Ce ntrex fe ature

acce ss.

2. To uchliteTM Key...……………………….……….... Message Wai ting L amp (L ED i ndicator) t hat

blinks to in dicate a n ew mes sage in th e

user’s vo ice m ail b ox (use r m ust b e

subscribed to a messaging system).

3. Release Key …………...…………………...……… Used to dis connect the line, place a new call

or exit the programming mode.

4. Store Key ………...…………………………….….… Used t o p rogram a si ngle, re adily avai lable

number for later retrieval.

5. Pause Key ...............................………… Used to program a 1.0 second timing delay

in speed dial memory or on hook dialing.

6. Memory Key ................………………………. Used to initiate ten (10) programmed

memo ry locations.

7. Programming Key .............................… Used to initiate programming mode.

8. Hold Key ……………………………………………..… Key used for placing callers on hold.

9. Mute Key …………………………….………………... Lighted key used for disabling the handset,

headset and speakerphone microphone.

10. Headset ON/OFF Key ……………………………. Used to turn the headset ON or OFF. LED

Ind ication.

11. Numeric Dial Pad ………………...………………. Used for outbound dialing.

12. Speaker Key .………………...................…… Used to turn the speakerphone ON or OFF.

LED Indication.

13. Volume Bar …………………..……………………….. Adjusts t he l oudness i ndependently fo r t he

handset receiver, the headset, speaker and/

or ringer.

14. Up and Down Scroll Key ..….........……..… Used to scroll the LCD through the program

menu and Memory Dial records. Also used to

adjust LCD contrast.

15. Exit Key ..………................…….....….…..… Used t o e xit programming mo de or memory

dialin g mode.

16. Select Key ……………………………..…………..... Used for programming settings.

17. Save Key ……………………………………………... Used to save programmed settings.

18. Handset ……………………………….…………...... Hearing-aid compatible handset.

19. LCD Display ...............…….............……… Large adjustable backlit LCD display.

1. Line Jack …...…………………………………… Modular receptacle for connecting the line

cord.

2. Headset Jacks ............................. Convenient RJ port or 2.5mm coaxial port

used to connect an optional headset.

3. Handset Jack .............................. Connection for handset coil cord.

4. Power Adapter Receptacle ……..……. For optional coaxial power adapter.

5. Elevation Stand Lock ……………………… Used to “lock” the elevation stand.

Parts Check List

The following parts are included with the Spectrum PLUSTM DC550:

1. Bas e Unit

2. H andset

3. 15 foot Modular telephone line cords (2).

4. 10 foot Modular coiled handset cord.

5. 6 inch Modular wall mount line cord.

6. Power Adapter with Pass-Through AC Outlet.

7. Eleven (11) Preprinted Feature Keycaps

8. Fifteen (15) Clear Keycaps

9. Preprinted Feature Key Index Sheet and Blank Labels

NOTE: Spectrum PLUSTM Line Cords are 6-Pin 6-Conductor Line

cords (6P6C line cord). Replacement Line Cords must be same.
