EXPLORER

INTEGRATION GUIDE

P/N 95B-6146-00 (July 2023)

https://www.teledynemarine.com

Page ii

EAR99 Technology Subject to Restrictions Contained on the Cover Page.

Page iii

EAR99 Technology Subject to Restrictions Contained on the Cover Page.

TABLE OF CONTENTS

GETTING STARTED .............................................................................................................................................1

CONNECTING TO THE EXPLORERDVL.......................................................................................................................3

MECHANICAL INTEGRATION..................................................................................................................................9

ELECTRICAL INTEGRATION ....................................................................................................................................11

ACOUSTIC INTEGRATION ......................................................................................................................................12

OPERATIONAL &SETUP INTEGRATION.....................................................................................................................13

WANT TO KNOW MORE? .....................................................................................................................................15

HOW TO CONTACT TELEDYNE RD INSTRUMENTS

If you have technical issues or questions involving a specific application or deployment with your instru-

ment, contact our Field Service group:

Teledyne RD Instruments Teledyne RD Instruments Europe

14020 Stowe Drive

Poway, California 92064

2A Les Nertieres

5 Avenue Hector Pintus

06610 La Gaude, France

Phone +1 (858) 842-2600 Phone +33(0) 492-110-930

Sales – rdisales@teledyne.com Sales – rdie@teledyne.com

Field Service – rdifs@teledyne.com Field Service – rdiefs@teledyne.com

Client Services Administration – rdicsadm[email protected]

Web: https://www.teledynemarine.com

For all your customer service needs including our emergency 24/7 technical support, call +1 (858) 842-2700

Self-Service Customer Portal

Use our online customer portal at https://www.teledynemarine.com/support/RDI/technical-manuals to download manuals or other

Teledyne RDI documentation.

Teledyne Marine Software Portal

Teledyne RD Instruments Firmware, software, and Field Service Bulletins can be accessed only via our Teledyne Marine software portal.

To register, please go to https://tm-portal.force.com/TMsoftwareportal to set up your customer support account. After your account is

approved, you will receive an e-mail with a link to set up your log in credentials to access the portal (this can take up to 24 hours).

Once you have secured an account, use the Teledyne Marine software portal to access this data with your unique username and password.

If you have an urgent need, please call our Technical Support hotline at +1-858-842-2700.

Page iv

EAR99 Technology Subject to Restrictions Contained on the Cover Page.

NOTES

ExplorerDVL Integration Guide P/N 95B-6146-00 (July 2023)

EAR99 Technology Subject to Restrictions Contained on the Cover Page. Page 1

Getting Started

Identifying what’s in the Box

ExplorerDVL Inventory

Kit Part Number Name Description

Standard

Explorer Systems

70B-1002-03

70B-1003-03

Explorer PA DVL The ExplorerDVL system includes the transducer, electronics chassis

and cables. When unpacking, use care to prevent physical damage

to the transducer face and connectors. Use a soft pad to protect the

transducer.

70B-1001-03 Explorer Piston DVL

71B-2010-03 Electronics chassis

73B-2002-xxx Receiver cable

73B-2004-xxx Transmit cable

95B-6148-00 ExplorerDVL Getting Started A printed quick start sheet showing test setup is included.

Self-Contained

Explorer Systems

70B-9001-00 Self-Contained EXP600 PA The Explorer Self-Contained DVL system includes the transducer

and cables.

70B-9008-00 In-Line Self-Contained EXP600 PA

737-3055-005 Self-contained Pigtail cable The DVL PWR/COMM cable connects the ExplorerDVL to the

computer and external power supply.

737-3114-005 Self-Contained test cable The DVL/Power/Comm test cable is used for serial communications

and power.

73B-6037-005 Self-contained Sensor Comm Pigtail

cable

Sensor Communication Cable connects the ExplorerDVL to the

sensors.

95B-6147-00 ExplorerDVL SC Getting Started A printed quick start sheet showing test setup is included.

75BK6092

-00

Documentation

Kit

95Z-6007-00 Download instructions This sheet has instructions for downloading the software and

manuals.

75BK6016-00

75BK6030-00

Accessories Kit

Tools and Spare Parts kit

Shipping Case

See Chapter 4, Maintenance in the ExplorerDVL Guide for a list of

parts included in this kit.

See the packing slip for additional options. If you are missing parts, contact TRDI support

rdifs@teledyne.com or call +1 (858) 842-2700.

P/N 95B-6146-00 (July 2023) ExplorerDVL Integration Guide

Page 2 EAR99 Technology Subject to Restrictions Contained on the Cover Page.

Installing Documentation and Software

The ExplorerDVL documentation and software are downloaded.

1. Follow the instruction sheet on downloading TRDI software and manuals.

2. Software is available on https://tm-portal.force.com/TMsoftwareportal. Install TRDI

Toolz.

3. Use our online customer portal at https://www.teledynemarine.com/support/RDI/technical-manuals

to download manuals or other Teledyne RDI documentation. Download the ExplorerDVL Guide.

PDF versions of all ExplorerDVL documentation are available for download.

ExplorerDVL Guide

PDDecoder Library in C language

The Teledyne Marine PDDecoder library is an open-source library written in C language to decode the

PD0 data formats that are commonly output by Teledyne Marine/Teledyne RD Instruments ADCPs. The

definition and details of the PD0 format can be found in any of the manuals under the section, Output

Data Format.

Available for download from the Teledyne software portal:

https://tm-portal.force.com/TMsoftwareportal

ExplorerDVL Integration Guide P/N 95B-6146-00 (July 2023)

EAR99 Technology Subject to Restrictions Contained on the Cover Page. Page 3

Connecting to the ExplorerDVL

Power Overview

The ExplorerDVL requires a DC supply between 12 and 28 VDC with a minimum inrush capability of 3A.

Either an external DC power supply or battery can provide this power. Sonar performance depends on

supply voltage, but not very strongly. The processing electronics use a DC/DC converter, so their function

is independent of the supply voltage over the 12 to 28 volt range. However, the raw supply voltage is pro-

vided directly to the transmitter so that the transmitted acoustic power is proportional to Vin2. Many cus-

tomers have successfully operated the ExplorerDVL using 24 volts. It may be worth the cost of providing a

higher supply voltage to achieve the maximum bottom-tracking range.

The self-contained Explorer can accept custom power input with the inclusion of a custom power conver-

sion board. Please contact a TRDI sales representative for further details on this capability.

Power on Cycle

The power supply must be able to handle the inrush current as well. Inrush current is the current required

to fully charge up the capacitors when power is applied to the ExplorerDVL. The capacitors provide a

store of energy for use during transmit. The inrush current is as high as three Amps rms. The Ex-

plorerDVL will draw this amperage until its capacitors are fully charged.

If the power supply limits the current or the power drop on the cable is significant, then the power on

cycle will take longer. It can take up to one minute. If the power shuts down during the inrush current

draw, this may not allow the ExplorerDVL electronics to start.

Bench Testing the ExplorerDVL System

Connecting the ExplorerDVL:

Figure 1. ExplorerDVL Connections

P/N 95B-6146-00 (July 2023) ExplorerDVL Integration Guide

Page 4 EAR99 Technology Subject to Restrictions Contained on the Cover Page.

To set up the ExplorerDVL:

1. Connect the Transmit and Receive cables to the electronics housing and transducer.

Match the red dots to connect the Transmit and Receive cables.

2. Wire the I/O cable to the computer’s communication port (see Input Power and Communications

Cable Wiring).

3. Connect +12 to 28 VDC power.

The Input Power and Communications Interface Connector (J3) uses a DB37M (Amp 747375-2) con-

nector. Use the following table to make the minimum RS-232 connections required to test the Ex-

plorerDVL.

See the ExplorerDVL Operation Manual, (Table 1) for the full wiring diagram.

DB37 Male Connector / I/O Bus

DB9 Female Connector / SPI Bus (Sensor)

Pin 1

RX1

Pin 3

Transmit Data

Pin 3

TX1

Pin 2

Receive Data

Pin 5

COMM 1_2

Pin 5

Communication Return

Pin 34/35

Power +

N/A

Pin 36/37

Power -

N/A

I/O Bus COM port 1 (pins 1, 3, and 5) is reserved for communicating to and controlling the

ExplorerDVL. This port will not support sensors. I/O Bus COM ports 2, 3, 4 and the SPI bus

port are for sensors.

This setup is for systems with RS-232 on I/O Bus COM port 1 (the master port) only. For

systems with RS-422 on I/O Bus COM port 1, refer to the manual for setup and wiring.

Connecting the Self-Contained ExplorerDVL:

To disconnect the cable/Dummy Plug:

1. Release the retaining strap/Cable Clip with O-Ring by pulling it over the connector.

2. Grasp the cable close to the connector. Pull the cable straight out away from the housing with a

gentle rocking motion. Do not apply any upward force on the connector as it is being discon-

nected.

The dummy plug should be installed any time the Communications /Power cable is removed.

Use the dummy plug when the ExplorerDVL is in storage or is being handled.

To connect the cable:

1. Check all pins for signs of corrosion (greenish oxidation, black deposits, or pitting).

2. Use light amounts of silicone lubricant (such as 3MTM Silicone Lubricant (Dry Type) ID No: 62-

4678-4930-3) on both the male pins and female socket to help seat the cable connectors. Wipe off

excessive silicone spray from the metal portions of the pins. Regular lubrication is required: Apply

dry type silicone lubricant prior to each connection.

ExplorerDVL Integration Guide P/N 95B-6146-00 (July 2023)

EAR99 Technology Subject to Restrictions Contained on the Cover Page. Page 5

When the cable is connected without any lubricant, excessive force is needed to fully seat or

remove the connector. This can cause several serious problems:

•The neoprene rubber portion of the contact pin may tear from the metal pin.

•Wiggling the cable side-to-side to overcome the friction as it is connected or

disconnected may cause the neoprene rubber to tear or create pin-holes on the side

of the connector.

Any damage to the neoprene rubber may cause corrosion on current carrying pins or leakage

into the DVL.

3. Gently push the cable straight in toward the connector. Do not apply any upward force on the con-

nector as it is being connected.

4. Roll the retaining strap/Cable Clip with O-Ring over the connector.

5. Connect +12 to 28 VDC power.

Figure 2. Self-Contained ExplorerDVL Connections with Optional Test Cable shown.

Use this figure to wire the ExplorerDVL pigtail cable. Refer to the ExplorerDVL Operation Manual for

more details on system interconnections.

Figure 3. Self-Contained ExplorerDVL Comm/Power Cable P/N 737-3055

P/N 95B-6146-00 (July 2023) ExplorerDVL Integration Guide

Page 6 EAR99 Technology Subject to Restrictions Contained on the Cover Page.

Communicate with the ExplorerDVL:

To establish communications with the ExplorerDVL:

1. Connect the system and apply power.

2. Start the TRDI Toolz software.

3. Select New Serial Connection.

4. Enter the Pathfinder’s communication settings.

Serial Communications:

Select the COM Port the serial cable is

connected to and set the Baud Rate from

the drop down list to 115200

5. Click the Connect button. Once connected, the button will change to Disconnect.

6. Click the Break ( ) button. From the Break button drop down

menu, select Soft Break (= = =). The wakeup banner will dis-

play in the terminal window.

ExplorerDVL

Firmware Version: 57.01

Changing the Baud Rate to the highest baudrate:

BAUD RATE CB-command

1200

CB111

2400 CB211

4800

CB311

9600 CB411 (Default)

19200

CB511

38400 CB611

57600

CB711

115200 CB811

Connect and power the system as shown in Figure 1.

Use TRDI Toolz to send the CB command that selects the baud

rate. The table on the left shows the CB command settings for

different baud rates with no parity and 1 stop bit.

For example, to change the baud rate to 115200, at the ">"

prompt in the communication window, type cb811 then press

the Enter key.

The CB? command will identify the communication

setting.

>cb?

CB = 411 ----------------- Serial Port Con-

trol (Baud [4=9600]; Par; Stop)

>cb811

>CK

[Parameters saved as USER defaults]

>cb?

CB = 811 ----------------- Serial Port Con-

trol (Baud [8=115200]; Par; Stop)

TRDI Toolz will send the command CK to save the new baud rate

setting.

The ExplorerDVL is now set for the new baud rate. The baud rate

will stay at this setting until changed again with the CB

command.

Este manual sirve para los siguientes modelos

Otros manuales de Instrumento de medición de Teledyne

Teledyne

Teledyne CP Series Manual de usuario

Teledyne

Teledyne 2010A Manual de usuario

Teledyne

Teledyne 3300TB Manual de usuario

Teledyne

Teledyne HVG-2020A Manual de usuario

Teledyne

Teledyne TIENet 301 Instrucciones de funcionamiento

Teledyne

Teledyne 2010B Manual de usuario

Teledyne

Teledyne SierraNet M408 Manual de usuario

Teledyne

Teledyne 980 DP1.4 Manual de usuario

Teledyne

Teledyne HASTINGS 200 Series Manual de usuario

Teledyne

Teledyne WORKHORSE Guía de referencia rápida

Teledyne

Teledyne 400E Manual de usuario

Teledyne

Teledyne ULTRAFLOW 150 Manual de usuario

Teledyne

Teledyne T360 Manual de usuario

Teledyne

Teledyne 275 Manual de usuario

Teledyne

Teledyne Everywhereyoulook T3PM1100 Manual de usuario

Teledyne

Teledyne HASTINGS 200 Series Manual de usuario

Teledyne

Teledyne Kibra DDR Manual de usuario

Teledyne

Teledyne 200E Manual de usuario

Teledyne

Teledyne 1220 Manual de usuario

Teledyne

Teledyne HASTINGS 2002 Manual de usuario

Teledyne

Teledyne 2150EX Instrucciones de funcionamiento

Teledyne

Teledyne T3LCR1002 Manual de usuario

Teledyne

Teledyne T200 Manual de usuario

Teledyne

Teledyne 9070 Manual de usuario

Manuales populares de Instrumento de medición de otras marcas

Suaoki

Suaoki D40 Manual de usuario

Elster

Elster BK-G1.6 Manual de usuario

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manual

Duratool

Duratool D03128 Manual de usuario

Vega

Vega VEGAPULS 65 Manual de usuario

Tonghui

Tonghui TH2618B Manual de usuario

Tenmars

Tenmars TM-801 Manual de usuario

MSR

MSR 145 Manual de usuario

TPS

TPS WP-82 Manual de usuario

ELMETRON

ELMETRON CP-511 Manual de usuario

PCB Piezotronics

PCB Piezotronics 003C30 Manual de usuario

Tenma

Tenma 72-10465 Manual de usuario

Endress+Hauser

Endress+Hauser Proline Promag 50 Especificaciones técnicas

Siemens

Siemens SITRANS F Coriolis FCT030 Manual de lista de piezas

KLINGER

KLINGER CMF V Series Manual de usuario

EXFO

EXFO FTB-2 Manual de operación y mantenimiento

Keysight

Keysight M8290A Manual de usuario

ADTEK

ADTEK MW-5 Manual de usuario
