TeeJet Technologies CENTERLINE Manual de usuario

OPERATORS MANUAL &

FITTING INSTRUCTIONS

FOR

CENTERLINE

No. 020-021-UK Version 1.11

Mølhavevej 2

9440 Aabybro

Denmark

Tlf. +45 9696 2500

Fax. +45 9696 2501

www.teejet.com

We have endeavoured to deliver a fault free product. To ensure optimal use of the

equipment we ask that great attention be paid when reading the manual. Please

contact your local dealer if further support is needed. Regarding responsibility for

use of the product, we refer to our sales and delivery terms especially paragraph

7, which follows:

7. Product usage.

7.1 Any use of the product is at the sole risk of the buyer. The buyer is

therefore not entitled to any form for compensation caused by, for example,

any of the following:

Disturbance to/from any electronic services or products that do not

confirm to the standards for CE marking,

Missing or poor signal coverage or a succession hereof from external

transmitters/receivers, used by the buyer,

Functional faults, which apply to or from a PC-program or PC-equipment,

not delivered by the seller,

Faults that may arise from the buyers negligence to react to warnings

and fault messages from the product, or which can be traced to

negligence and/or absent constant control of the work carried out in

comparison to the planned job.

7.2 When implementing any new equipment the buyer must take great care and pay

attention. Any doubts as to correct operation/use should result in

contacting the sellers service department.

This manual may not be altered, copied or manipulated in any way. Unoriginal

manuals can lead to operational faults damaging machines or crops as a

consequence thereof. TeeJet Technologies can therefore not be held responsible

for damages incurred, which can be traced to the use of unoriginal or manipulated

manuals. Original manuals can be requisitioned at any time from your dealer.

With regards

Mølhavevej 2

9440 Aabybro

Denmark

Tlf. +45 9696 2500

Fax. +45 9696 2501

www.teejet.com

ENTER

INE

PERATOR

FITTING INSTRUCTIONS

ONTENTS

Contents

INTRODUCTION .................................................................................................................5

GENERAL OPERATION......................................................................................................6

THE WIRELESS REMOTE .........................................................................................6

ARROW UP & DOWN KEYS (POS. 1 & 3).............................................................7

RETURN TO POINT KEY (POS. 2) ........................................................................7

BRIGHTNESS + & - KEYS (POS. 4).......................................................................7

MENU/ESCAPE KEY (POS. 5) ...............................................................................7

ENTER KEY (POS. 6).............................................................................................7

THE CENTERLINE LIGHTBAR...................................................................................8

LIGHTBAR LIGHTS (POS. 1) .................................................................................8

MENU SCREEN (POS. 2).......................................................................................8

AN INTRODUCTION TO PARALLEL SWATHING......................................................8

STRAIGHT GUIDANCE ..........................................................................................9

CURVED GUIDANCE .............................................................................................9

HEADLAND GUIDANCE.........................................................................................9

A WORKING EXAMPLE .......................................................................................10

OPERATION......................................................................................................................13

OPERATING MENU OVERVIEW .............................................................................13

GENERAL .................................................................................................................13

NEW?....................................................................................................................13

RESUME?.............................................................................................................13

APPLY ON/OFF ....................................................................................................13

HEADLAND/STRAIGHT/CURVE AB ....................................................................13

NEW A – B............................................................................................................14

AREA ....................................................................................................................15

E-DIF.........................................................................................................................15

USING THE RETURN TO POINT FUNCTION..........................................................16

ENCODE ...........................................................................................................................17

SETUP MENU OVERVIEW.......................................................................................17

GENERAL .................................................................................................................18

GUIDANCE ...............................................................................................................18

WIDTH ..................................................................................................................18

AHEAD..................................................................................................................18

ANTENNA.............................................................................................................18

STATUS................................................................................................................19

ALARM..................................................................................................................19

GPS TYPE ............................................................................................................19

1HZ MESSAGE.....................................................................................................19

ONTENTS

ENTER

INE

PERATOR

FITTING INSTRUCTIONS

LIGHTBAR ................................................................................................................19

SPACING..............................................................................................................19

MODE ...................................................................................................................20

TEXT 1 & TEXT 2 .................................................................................................20

STEER BAR?........................................................................................................20

SYSTEM....................................................................................................................20

UNITS ...................................................................................................................20

LANGUAGE ..........................................................................................................20

TOOLS...............................................................................................................................21

TOOLS MENU OVERVIEW ......................................................................................21

RECEIVER STATUS.............................................................................................21

LIGHTBAR ............................................................................................................22

DEMO ...................................................................................................................22

E-DIF.....................................................................................................................22

FITTING THE CENTERLINE .............................................................................................23

SYSTEM OVERVIEW ...............................................................................................23

FITTING ....................................................................................................................24

GENERAL.............................................................................................................24

FITTING THE LIGHTBAR (POS. 1) ......................................................................24

CENTERLINE POWER CABLE CONNECTION (POS. 2) ....................................24

BATTERY CABLE CONNECTION (POS. 3).........................................................24

CONNECTING THE DGPS RECEIVER....................................................................24

ENTER

INE

PERATOR

FITTING INSTRUCTIONS

NTRODUCTION

INTRODUCTION

Congratulations on selecting the CenterLine

We – your supplier – feel certain that you will quickly learn to use it and within a

short time get the full benefit of this modern technology.

Please read this operator manual:

Sit in the tractor seat with the engine switched off!

Read the “Introduction to guidance” and look at the drawings on pages 10 & 11.

Get to know the 6 remote control buttons and their functions.

Learn to navigate through the menus.

Read the explanations for each menu item that you don’t understand carefully.

Only now, if you feel at home with the CenterLine, should you start the

tractor for the first test run.

Enjoy!

ENERAL

PERATION

ENTER

INE

PERATOR

FITTING INSTRUCTIONS

GENERAL OPERATION

The CenterLine system consists of three main components; a DGPS receiver, the

lightbar and a wireless remote control. All of the menus for operation and encoding

the CenterLine are shown on the lightbar and are selected by using the wireless

remote control. Settings for the DGPS receiver depend on the type of receiver

used; please refer to the documentation supplied with the DGPS receiver.

A description of the wireless remote control and the lightbar follows:

THE WIRELESS REMOTE

As mentioned before CenterLine is operated via the wireless remote and a

description of the buttons can be seen in the following:

DOWN

ESC

Pos.

Description Pos.

Description

1 Arrow up key 4 Brightness up and down keys

2 Return to point key 5 Menu/Escape key

3 Arrow down key 6 Enter key

ENTER

INE

PERATOR

FITTING INSTRUCTIONS

ENERAL

PERATION

ARROW UP & DOWN KEYS (POS. 1 & 3)

Key Description

DOWN

These keys are used to page through the menus, sub-menus

and the various settings that are available in the menus.

RETURN TO POINT KEY (POS. 2)

Key Description

This key is used to mark a position in the field and then to later

return to the marked position.

The return to point function is typically used if work in the field is

stopped and the point at which work stopped is to be found

when work commences again.

A description of this function can be seen on page 15.

BRIGHTNESS + & - KEYS (POS. 4)

Keys Description

Repeatedly pressing the brightness + key will increase the

brightness of the lightbar. Likewise repeatedly pressing the

brightness – key will decrease the brightness of the lightbar.

Different light conditions, i.e. bright sunlight or night work can be

compensated for with this function.

MENU/ESCAPE KEY (POS. 5)

Key Description

ESC

This key is used to leave a menu item.

Each press of this key pages one step back in the menu

structure.

If the key is pressed when encoding, the specific setting will not

be saved.

ENTER KEY (POS. 6)

Key Description

The enter key is used to open a menu plus to select and accept

an encodement.

ENERAL

PERATION

ENTER

INE

PERATOR

FITTING INSTRUCTIONS

THE CENTERLINE LIGHTBAR

LH AGRO

Pos.

Description Pos.

Description

1 Lightbar lights 2 Menu screen

LIGHTBAR LIGHTS (POS. 1)

An indication of the present position in comparison to the required position.

When driving “on track” the middle light will be lit.

MENU SCREEN (POS. 2)

Operating information and the various menus are displayed here.

AN INTRODUCTION TO PARALLEL SWATHING

Parallel swathing can be carried out in three different ways; driving around the

headland and parallel to a straight line or a curved line. Typically, work will start by

driving around the headland 2 or 3 times and thereafter “side to side” (as with

tramlines).

Whilst driving around the headland it is possible to create a reference line from

which the remainder of the field can be driven parallel to. This reference line is

created by marking 2 points, point A and point B. The shortest possible distance

between 2 points is a straight line and this straight line is the reference line that is

driven parallel to for straight guidance(not the headland).

The reference line can be created, as mentioned before, whilst working the

headland, but also at any other time whilst driving. Once the reference line is

marked, it is possible to drive parallel to this line anywhere in the field.

ENTER

INE

PERATOR

FITTING INSTRUCTIONS

ENERAL

PERATION

STRAIGHT GUIDANCE

Straight guidance is simply driving in a straight line parallel to the reference line

created with points A & B. Once the reference line has been created it is possible

to drive parallel to the left and/or the right of the line and before and/or after the

initial reference points (A & B), the following diagram illustrates this:

The solid line represents the reference line

created with points A & B.

The dashed line shows that parallel lines are

automatically created on the left- and right-

hand side plus in front of and behind the

reference line.

This means that parallel guidance is possible

outside the points A and B

CURVED GUIDANCE

Curved guidance is driving parallel to a curved line in a similar fashion to straight

guidance. Parallel guidance is possible to the left and/or right of the reference line

but not before or after the initial reference points. The following diagram illustrates

this:

The solid line represents the initial

reference line created with points A & B.

The dashed lines show that parallel lines

are automatically created in front of the

initial reference line.

The dashed lines also show that parallel

lines are not created in to the side of the

initial reference points

This means that curved guidance is not

possible outside of the points A and B

HEADLAND GUIDANCE

Headland guidance is driving parallel around the headland of the field. Once the

headland has been completed it is possible to drive to the left and/or to the right of

the initial bout. A reference line (A & B) for straight or curved guidance can be

created whilst in headland mode.

A detailed example of headland guidance can be seen on page 11.

No guidance

A B

ENERAL

PERATION

ENTER

INE

PERATOR

FITTING INSTRUCTIONS

A WORKING EXAMPLE

The following example shows that the headland is driven twice. Two reference

marks are made to create the straight reference line that the rest of the field is to

be driven parallel to:

Step Key Display Description

DOWN

Select "Start” to begin real-

time guidance.

Start a new field

Only displayed if "STATUS” =

OFF under setup.

DOWN

Select for headland work.

Start working the headland. 2

lines are shown in the

display.

DOWN

Prepare for a new reference

line.

Start the reference line.

Drive the straight line.

Stop marking the reference

line.

DOWN

Change to straight work.

Straight?

Mark B

Mark A

New A - B

Headland?

Spray On

New?

Start

Tabla de contenidos

Otros manuales de Sistema de navegación para automóviles de TeeJet Technologies

TeeJet Technologies

TeeJet Technologies Centerline 230BP Manual de usuario

TeeJet Technologies

TeeJet Technologies MATRIX 430 Manual de usuario

TeeJet Technologies

TeeJet Technologies CL220 Manual de usuario

TeeJet Technologies

TeeJet Technologies MATRIX PRO940gs Manual de usuario

Manuales populares de Sistema de navegación para automóviles de otras marcas

Clarion

Clarion Navigation In-Car Entertainment Manual de usuario

Rosen

Rosen DP-1001 Manual de usuario

Alpine

Alpine INE-W970HD Manual de usuario

Skoda

Skoda AMUNDSEN+ Manual de usuario

Blaupunkt

Blaupunkt TravelPilot DX-N Manual de usuario

Pioneer

Pioneer MZ360500EX Manual de usuario

Sanyo

Sanyo NVM-4030 - Easy Street - Automotive GPS... Manual de usuario

Kenwood

Kenwood DNN991HD Manual de usuario

AvMap

AvMap Geosat 2C Manual de usuario

Eonon

Eonon GE01B Manual de usuario

Pioneer

Pioneer AVIC-Z920DAB Manual de usuario

Nextar

Nextar M3-MX - Automotive GPS Receiver Manual de usuario

Furrion

Furrion NV2200 Manual de usuario

Mio

Mio MOOV 200-Series Manual de usuario

Prestigio

Prestigio GeoVision 5150 Manual de usuario

Hummer

Hummer 2006 H3 Manual de usuario

Magellan

Magellan Maestro 4210 - Automotive GPS Receiver Guía de configuración

Garmin

Garmin StreetPilot c510 Manual de usuario
