Techno CNC Systems Venture Series Manual de usuario

1For Support Visit· www.technocnc.com and click Support or Call: (631) 648-7481

(HTT0673)

Venture Series

This manual will provide unpacking, maintenance, and user guide for running the Techno Venture Series

and Venture Plus Series CNC Routers.

It is suggested that the operator keep this manual by the machine. This will provide the most important

information pertaining to the operation of this machine.

WARNING: DO NOT OPERATE THIS MACHINE WITHOUT PROPER

TRAINING! Improper or unsafe operation of the machine will

result in personal injury and/or damage to the equipment.

Series CNC Router

User Manual

2For Support Visit· www.technocnc.com and click Support or Call: (631) 648-7481

(HTT0673)

Venture Series

TABLE OF CONTENTS

I......General Installation Instructions.

1.1 Forklift guide and unpacking instructions. ............................. Page 3

1.2 Safety Instructions. ............................. Page 4

1.3 Correct Colleting. ............................. Page 5

1.3.5 Toolstand 1.3.6 Spindle Warmup ............................. Page 6

1.4 Electrical and Pneumatic connections. ............................. Page 7 - 8

1.5 Vacuum Pump connections. ............................. Page 9

II.....Machine Start-Up and Screen Functionality.

2.1- Start up Procedure. ............................. Page 10 - 12

2.2- Screen Callouts. ............................. Page 13 - 25

2.3- File System-Network. ............................. Page 26

III... Operating Tutorials

3.1- Jogging the Machine. ............................. Page 27 - 28

3.2- Learning Tool lengths. ............................. Page 29 - 30

3.3- Saving an Origin | Setting XYZ Zero Position ............................. Page 31 - 32

3.4- Preparing a G-Code File. ............................. Page 33 - 34

3.5- Running a G-Code File. ............................. Page 35 - 36

 3.6-MachineOrigin,WorkingOrigin,&Osets .............................Page37

IV.....Advanced Tutorials

4.1- Using Block to Block Function. ............................. Page 38

 4.2-MemSearch. 4.3-ReturntoProle. .............................Page39

4.4- Setup Parameters. ............................. Page 40 - 43

4.5- Backing up Parameters. ............................. Page 44 - 46

V......Machine Lubrication ............................. Page 47

VI....Appendix

6.0- HSD Aggregate Tool Setup. ............................. Page 48 - 49

6.1- Service and Maintenance Guide ............................. Page 50 - 54

6.2- Fault Finding/Error Messages. ............................. Page 55 - 59

Becker Vacuum Pump Manual ............................... Page 60 - 64

Becker Vacuum Pump Filter Inspection ............................... Page 65 - 67

Becker Vacuum Pump Greasing Process ............................... Page 68 - 72

Warranty .......................... Page 73

3For Support Visit· www.technocnc.com and click Support or Call: (631) 648-7481

(HTT0673)

Venture Series

Techno CNC Systems Venture Series Forklift Guide

SAFETY WARNING:

DO NOT LIFT MACHINE OR MOVE MACHINE BY THE GANTRY

For safety and to prevent damage to the machine, Lift Machine Using The Frame ONLY

** Some Venture Series CNC Routers do NOT have forklift tubes. **

If so, make sure forklift blades enter through the frame of the machine only. Use blocks when lifting

machine to prevent damage to the vacuum table plumbing **

1. Unpack all items that shipped with your machine. Check the items on your slip to be sure nothing was left out. Notify Techno if you have any missing

pieces of your shipment.

2. A toolbox and other accessories, such as vacuum hosing and leveling feet, may be packed under the machine during shipping.

3. Forklift your machine up from the oor and remove the wooden pallet (if it was shipped on a wooden pallet).

4For Support Visit· www.technocnc.com and click Support or Call: (631) 648-7481

(HTT0673)

Venture Series

1.2 SAFETY INFORMATION!

1. Keepngers,hands,andallotherobjectsawayfrom

machinewhilepowerison.

2. Disconnectpowertoallsystemcomponentswhen

notinuse,whenchangingaccessories,andbefore

servicing.

3. Donotloosen,remove,oradjustmachinepartsor

cableswhilepowerison.

4. Exercisecarewithmachinecontrolsandaround

keyboardtoavoidunintentionalstarting.

5. Makesurevoltagesuppliedisappropriateto

specicationsofcomponents.

6. Machinesmustbepluggedintofour-pronged

groundedoutlets.Donotremovethegrounding

plugorconnectintoanungroundedextension

cord.

7. Keepcablesandcordsawayfromheat,oil,and

sharpedges.Donotoverstretchorrunthem

underotherobjectsoroverworksurfaces.

8. Useproperxturesandclampstosecurework.

Neverusehandstosecurework.

9. Donotattempttoexceedlimitsofmachine.

10. Donotattempttousemachineforpurposesother

thanwhatisintended.

11. Usemachineonlyinclean,well-litareasfreefrom

ammableliquidsandexcessivemoisture.

12. Stayalertatalltimeswhenoperatingthemachine.

13. Alwayswearsafetygoggles.

14. Donotwearjewelryorloose-ttingclothingwhen

operatingmachine.Longhairshouldbeprotected.

15. Alwaysmaintainproperbalanceandfootingwhen

workingaroundthemachine.

16. Maintainequipmentwithcare.Keepcutting

toolscleanandsharp.Lubricateandchange

accessorieswhennecessary.Cablesandcords

shouldbeinspectedregularly.Keepcontrols

cleananddry.

17. Beforeusing,checkfordamagedparts.An

authorizedservicecentershouldperformall

repairs.Onlyidenticalorauthorizedreplacement

partsshouldbeused.

18. Removeanyadjustingkeysandwrenchesbefore

turningmachineon.

19. Donotoperatethemachineunattended.

20. Followallsafetyinstructionsandprocessing

instructionsintheMSDSforthematerialbeing

processed.

21. Useproperprecautionswithdustcollection

systemstopreventsparksandrehazards.

Read these instructions thoroughly before operating

machine. DO NOT operate machine if you are unfamiliar with

these safe operating instructions. DO NOT operate machine

without knowing where the emergency stop switch is located.

PREVENTFIREHAZARDSbyusingtheproperfeeds,speeds,andtoolingwhileoperatingyourTechnomachine.

Forexample,settingfeedsandspeedstoolowand/orusingdulltoolbitscreatesfrictionatthematerial.The

frictiongeneratesheatwhichcanresultinarethatcanbedrawnthroughthevacuumtableordustcollector

withoutwarning.Firehazardfromfrictionheatingcausedbydulltoolsispossiblewhencuttingcertainmaterials,

especiallycompositematerialsuchaswoodcomposites,MDFandParticleboard.  ©2015

5For Support Visit· www.technocnc.com and click Support or Call: (631) 648-7481

(HTT0673)

Venture Series

WARNING!

THE SPINDLE WILL BE DAMAGED

IF UNBALANCED EQUIPMENT IS USED.

AIR SUPPLY MUST BE FILTERED AND DRY.

1.3 Correct Colleting:

Read these instructions thoroughly

BEFORE operating machine.

6For Support Visit· www.technocnc.com and click Support or Call: (631) 648-7481

(HTT0673)

Venture Series

1.3.5 Tool Stand Diagram - Proper Placement

ReadtheseinstructionsthoroughlyBEFOREoperatingmachine.

1.3.6 —HSD

Spindle Warmup

Read these instructions thoroughly BEFORE operating machine.

USE AND ADJUSTMENT

PREHEATING

HSD S.p.A. uses high-precision angular contact bearing pairs, pre-loaded and lubricated for life

with special grease for high speeds.

When the machine is switched on for the first time every day, allow the electrospindle to perform a

brief preheating cycle in order to allow the bearings to gradually attain a uniform operating

temperature, and hence to obtain a uniform expansion of the bearing races and the correct preload

and rigidity.

The following cycle is recommended, without machining operations:

50 %of the maximum rated speed for 2minutes.

75 %of the maximum rated speed for 2minutes.

100 %of the maximum rated speed for 1minute.

The preheating cycle should also be performed every time that the machine is inoperative long

enough for the electrospindle to cool down to room temperature.

Only for HSK versions:

it is forbidden to run the electrospindle without the tool-holder inserted.

While the machine is operating, the spindle can reach high temperatures. Be very careful

not to touch it without due precautions.

Spindle Warm-up:

7For Support Visit· www.technocnc.com and click Support or Call: (631) 648-7481

(HTT0673)

Venture Series

1.4.2

AlltheelectronicsfortheVenturemachineare

locatedinthehousingcabinet.Donotopen

thesedoorswhenpowerisappliedtothe

machine.

1.4.3

Therearetworoundedconnectorsonthesideofthe

controller,theseconnectorsprovide220voltsforthe

vacuumpumpstartercontactors.

Leadthecablefor3phase220voltsthatwillbeusedto

powermachinethroughtheholeonthebottomofthe

cabinet.

Fig1.4.2

220Vinfor

powering

machine

220VOut

forVacuumPump

Network

Connection

Motor/

Encoder

Fig1.4.3.

1.4 Electrical and Pneumatic connections.

TheTechnoVentureseriesmachineispoweredbythreephase220

volts.Theamperagerequirementsforthismachineare40amps.

1.4.1

Whenthemachinehasbeenunpacked,itwill

benecessarytoattachthekeyboardshelftothe

frontofthemachine.

Whentheshelfisinplace,leadthemouseand

keyboardcablesthroughthesmallholeinthe

fontofthemachine.Plugthecablesintoan

availableUSBconnectiononthePC.

Screwstoattach

shelf

Fig1.4.1

Holeformouseand

keyboardcable

WARNING: Ensure that all electrical connections are

carried out by a qualied electrician.

Improper electrical connections can result in

damage to the equipment, re and death.

8For Support Visit· www.technocnc.com and click Support or Call: (631) 648-7481

(HTT0673)

Venture Series

1.4.4

Attachthethreephasesandthegroundtothe

connectionsshowning1.4.4aor1.4.4b

Yourmachinemaycomewithaterminalblock

(shownin1.4.4a)oryoumachinemaycomewith

noterminalblockandmustbewiredtothepower

switchshowningure1.4.4b

1.4.5

Variouscomponentsonthemachinerequireair

pressure.of90psiandneedstobesuppliedtothe

machineatalltimesforittofunctioncorrectly.

Attachanairhosetotheairinputonthebackofthe

machine.Seeg1.4.5.

Ifyourshophosedoesnotttheadaptorsupplied,the

adaptercanberemovedandasuitableoneattached.

3 phase

220V in

WARNING: Ensure that all electrical connections are

carried out by a qualied electrician.

Improper electrical connections can result in damage

to the equipment, re and death.

Fig1.4.5

Should read

90 psi

1.4.6

Removethefourbracketsusedtostabilizethegantry

duringshippingusingmetricallenwrenchs.Theremay

bebracketsattachedtotheXandZaxis,aswell.

Fig1.4.6

Fig1.4.4a.

Fig1.4.4.b

3 phase

220V in

9For Support Visit· www.technocnc.com and click Support or Call: (631) 648-7481

(HTT0673)

Venture Series

1.5 Vacuum Pump connections

YouwillneedtohaveanelectricianconnectACpower

(220or440VAC)asspeciedontheunittothemotor

starter.

TakethesilverconnectorfromtheStarterBoxand

connectittothefemaleconnectoronthemain

electronicunit.

Attachthesilverconnector

fromthestarterboxhere.

Attachthehosesfromthemachinetothe

T-connectorsandattachthemtothepump.

WARNING: Direction of Rotation is critical.

Briey start motion and check rotation (arrow on casing).

Exchange phases if rotation is incorrect.

IF YOU RUN THE PUMP/BLOWER CONTINUOUSLY IN THE WRONG

DIRECTION, THE VANES WILL BE DAMAGED

Turnonindividualsectionsofthe

vacuumtablebyturningthemanifold

handlesinthefrontofthemachine.

Vacuum on and off functions are

controlled by the Osai controller

and can only be turned on from

the computer screen.

To test the motor, press the

reset button on the starter box

once all connections are made.

10 For Support Visit· www.technocnc.com and click Support or Call: (631) 648-7481

(HTT0673)

Venture Series

Otros manuales de Sistema de control de Techno CNC Systems

Techno CNC Systems

Techno CNC Systems WinCNC Manual de usuario

Techno CNC Systems

Techno CNC Systems Titan Series Manual de usuario

Techno CNC Systems

Techno CNC Systems HD series Manual de usuario

Techno CNC Systems

Techno CNC Systems BT1212 Manual de usuario

Manuales populares de Sistema de control de otras marcas

Pentair Pool Products

Pentair Pool Products Compool Manual de usuario

ComfortNET

ComfortNET CTK04 Manual de usuario

Fireye

Fireye InSight II 95DSS3 Manual de usuario

CAME

CAME G3000 Manual de usuario

Idemia

Idemia MorphoAccess VP MD Manual de usuario

Axis

Axis P1445-LE-3 Manual de usuario

HEIDENHAIN

HEIDENHAIN TNC 150 B Manual de usuario

CNC-Step

CNC-Step High-Z T-Series Manual de usuario

Doosan

Doosan DVF Series Manual de usuario

Honeywell

Honeywell KAP 140 Manual de usuario

Honeywell

Honeywell vk41 series Manual de usuario

AirBench

AirBench FPW Guía de instalación

Cypress

Cypress HHR-3160 Manual de usuario

CAME

CAME GLT40AOS Manual de usuario

Zonex

Zonex GEN II -VVT Guía del usuario

Altronics

Altronics K 9650 Manual de usuario

micro-trak

micro-trak RoadMaster Manual de usuario

micro-trak

micro-trak Calc-An-Acre II Manual de usuario
