TechniSat DIGIT MF4-K Manual de usuario

With integrated CONAX decoding system and

PCMCIA interface for insertion of a CI module.

For reception of unencrypted and encrypted

(e.g. CONAX, VIACCESS, IRDETO, SECA etc.)

cable programmes.

DIGIT MF4-K

1 Contents

1 Contents . . . . . . . . . . . . . . . . . . . .2

2 Illustrations . . . . . . . . . . . . . . . . . .5

3 Please read this first . . . . . . . . . . .8

Important notes on operation . . . . . . . . . . .8

Disposal advice . . . . . . . . . . . . . . . . . . . . .9

Safety advice . . . . . . . . . . . . . . . . . . . . . . .9

Breaks in operation . . . . . . . . . . . . . . . . . .9

4 Connections . . . . . . . . . . . . . . . . .11

4.1 Connection to the cable network . . . . . . . .11

4.2 Connection to a television set . . . . . . . . . .11

4.3 Video cassette recorder (VCR) . . . . . . . . .11

4.4 Hi-fi amplifier . . . . . . . . . . . . . . . . . . . . . .11

4.4.1 Analogue . . . . . . . . . . . . . . . . . . . . . . . . .11

4.4.2 Digital . . . . . . . . . . . . . . . . . . . . . . . . . . .12

4.5 Serial interface (RS 232) . . . . . . . . . . . . .12

4.6 Mains power connection . . . . . . . . . . . . . .12

5 Initial installation . . . . . . . . . . . . .12

6 Settings . . . . . . . . . . . . . . . . . . . .15

6.1 Operating language . . . . . . . . . . . . . . . . .15

6.2 Basic settings . . . . . . . . . . . . . . . . . . . . . .15

6.2.1 Time difference GMT (hours) . . . . . . . . . .16

6.2.2 Country . . . . . . . . . . . . . . . . . . . . . . . . . .16

6.2.3 Remote control code . . . . . . . . . . . . . . . .16

6.2.4 Stand-by clock . . . . . . . . . . . . . . . . . . . . .16

6.3 Audio/Video settings . . . . . . . . . . . . . . . .16

6.3.1 Picture format . . . . . . . . . . . . . . . . . . . . .17

6.3.2 Language (Audio signal) . . . . . . . . . . . . .17

6.3.3 Language (Sub-titles) . . . . . . . . . . . . . . . .17

6.3.4 TV SCART mode . . . . . . . . . . . . . . . . . . .17

6.3.5 VCR SCART mode . . . . . . . . . . . . . . . . .17

6.3.6 Dolby Digital (AC3) . . . . . . . . . . . . . . . . .18

7 Operation . . . . . . . . . . . . . . . . . . .18

7.1 Switching on and off . . . . . . . . . . . . . . . . .18

7.2 Programme selection . . . . . . . . . . . . . . . .18

7.2.1 Using the programme up/down keys . . . . .18

7.2.2 Using the numeric keys . . . . . . . . . . . . . .19

7.2.3 Using the Navigator (Programme list) . . . .19

7.2.3.1 Selecting a list . . . . . . . . . . . . . . . . . . . . .19

7.2.4 Calling up blocked programmes . . . . . . . .20

7.2.5 Information box . . . . . . . . . . . . . . . . . . . .20

7.3 Receiving encrypted programmes . . . . . .20

7.3.1 Special functions . . . . . . . . . . . . . . . . . . .21

7.3.1.1 Multifeed options . . . . . . . . . . . . . . . . . . .21

7.3.1.2 Select starting time/picture . . . . . . . . . . . .21

7.3.2 CONAX PIN code . . . . . . . . . . . . . . . . . .22

7.4 Volume control . . . . . . . . . . . . . . . . . . . . .22

7.5 TV/Radio switching . . . . . . . . . . . . . . . . .23

7.6 Selecting a different language

(TV mode) resp. station (Radio mode) . . .23

7.6.1 Dolby Digital (AC3 mode) . . . . . . . . . . . . .23

7.7 Return to last programme selected . . . . . .24

7.8 Display clock and programme info . . . . . .24

7.9 Additional programme information . . . . . .24

7.10 Freeze-frame . . . . . . . . . . . . . . . . . . . . . .24

7.11 Sleep timer . . . . . . . . . . . . . . . . . . . . . . .25

7.12 Channel information . . . . . . . . . . . . . . . . .25

7.13 Video text . . . . . . . . . . . . . . . . . . . . . . . . .25

7.14 Sub-titles . . . . . . . . . . . . . . . . . . . . . . . .26

7.15 Electronic Programme Guide SFI . . . . . . .27

7.15.1 Downloadin SFI data . . . . . . . . . . . . . . . .27

7.15.2 Interrupting download procedure . . . . . . .28

7.15.3 Calling up Electronic Programme Guide . .28

7.15.4 Now . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

7.15.5 Next . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

7.15.6 More . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

7.15.7 SFI functions . . . . . . . . . . . . . . . . . . . . . .29

7.15.7.1 SFI information . . . . . . . . . . . . . . . . . . . .30

7.15.7.2 SFI timer programming . . . . . . . . . . . . . .30

7.15.7.3 SFI programme overview . . . . . . . . . . . . .31

7.15.7.4 SFI overview by programme type (Genre) 32

7.15.8 Terminating SFI . . . . . . . . . . . . . . . . . . . .32

7.16 Timer recordings . . . . . . . . . . . . . . . . . . .32

8 Changing basic settings . . . . . . .36

8.1 Configuring Favourites list . . . . . . . . . . . .36

8.1.1 Calling up programme list management . .37

8.1.2 Adding programmes to Favourites list . . . .38

8.1.3 Deleting programmes . . . . . . . . . . . . . . . .39

8.1.3.1 Removing (deleting)

from the Favourites list . . . . . . . . . . . . . . .39

8.1.3.2 Deleting from Total list . . . . . . . . . . . . . . .39

8.1.4 Sorting programmes . . . . . . . . . . . . . . . . .40

8.2 Programming the electronic

programme guide . . . . . . . . . . . . . . . . . . .41

8.2.1 Selecting channels/stations . . . . . . . . . . .41

8.2.2 Start category . . . . . . . . . . . . . . . . . . . . .42

8.2.3 Updating time . . . . . . . . . . . . . . . . . . . . . .43

8.2.4 Updating . . . . . . . . . . . . . . . . . . . . . . . . .43

8.2.5 SFI channel . . . . . . . . . . . . . . . . . . . . . . .43

8.3 Parental control . . . . . . . . . . . . . . . . . . . .43

8.3.1 Selecting channels . . . . . . . . . . . . . . . . . .44

8.3.2 Changing unit PIN . . . . . . . . . . . . . . . . . .45

8.3.3 Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . .45

8.4 Programme scan . . . . . . . . . . . . . . . . . . .45

8.4.1 Automatic scan . . . . . . . . . . . . . . . . . . . .46

8.4.3 Manual scan . . . . . . . . . . . . . . . . . . . . . .48

8.4.4 After the scan . . . . . . . . . . . . . . . . . . . . .49

8.5 Service settings . . . . . . . . . . . . . . . . . . . .50

8.5.1 Activating default settings . . . . . . . . . . . . .50

8.5.2 Delete all programmes . . . . . . . . . . . . . . .50

8.5.3 Update software . . . . . . . . . . . . . . . . . . . .51

8.5.4 Copy settings . . . . . . . . . . . . . . . . . . . . . .52

8.6 System configuration . . . . . . . . . . . . . . . .52

8.7 Encryption/decoding system . . . . . . . . . . .52

9 Technical terms . . . . . . . . . . . . . .53

10 Technical data . . . . . . . . . . . . . . .54

11 Trouble-shooting guide . . . . . . . .57

For daily use . . . . . . . . . . . . . . . .58

Your unit carries the CE logo, and complies with all relevant EU standards.

Subject to change without notice, subject to printing errors.Correct as at 11/04

TechniSat and DIGIT MF4-K are registered trademarks of

TechniSat Digital GmbH

Postfach 560

D-54541 Daun, Germany

www.technisat.de

Technical Hotline

(049) 0180/5005-910*

*0,12 EUR/Min. via the Deutsche Telekom AG network

Note !

If you should ever have to send in your unit, please use only the following

address:

TechniSat Teledigital AG

Service-Center

Löderburger Str. 94

D-39418 Stassfurt, Germany

2 Illustrations

*This function is only available if the appropriate data is being broadcast on the selected

programme slot.

Remote control option:

By switching the remote control options you can use this remote control unit to operate

two receivers, one television set as well as a video recorder, using the same coding.

>To switch the remote control option, please simultaneously press the desired key

(SAT1, SAT2, VCR or TV) and OK!!!

Please note:

To operate this receiver, the remote control option of the remote control unit selected here

and the remote control code selected in accordance with Point 6.2.3 must be identical.

Remote control

On/Stand-by

Programme list On/Off

Back

Info

Stop/Freeze-frame

Meno On/Off

Sound On/Off

EXTERNAL

Multi-function keys

TV/Radio

Volume +

Volume +/-

SFI

Programme -

Volume -

Programm +/-

Programme +

Video text*

On/Mix/Off

Arrow key right

Arrow key left

Arrow key up

Arrow key down

Sleep timer

Option*

in TV mode:

Select sound/sub-titles,

special functions

in Radio mode:

Select stations by switching

sound sub-carriers

Numeric keys

Cable

input

Cable

output

SCART socket

Audioausgang

digital (optisch)

SCART socket

VCR

Mains power

socket

Audio outputs

analogue

RS 232

interface

Audio output

digital (electrical)

Programme select

up/down On/Stand-by

LED display

Card reader for CONAX Smartcard:

> Insert the CONAX Smartcard (gold-coloured chip at the bottom,

and in the direction of insertion) carefully into the card reader as

far as it will go.

Inserting the CI module:

> Please follow the instructions of the manufacturer of the CI

module and card.

> Insert the desired Smartcard in the appropriate CI module.

> Now insert the CI module carefully in the slot provided.

Dear customer,

congratulations on your decision to purchase the TechniSat

DIGIT MF4-K digital receiver.

The operating manual you are reading is designed to help you

gain optimum use and enjoyment from the comprehensive

functions of your new digital receiver.

We have designed the operating manual to be as comprehen-

sive as necessary, and as simple as possible.

The range of functions of your receiver is constantly being

expanded, and software updates are available for this. This

may occasionally mean that operating steps are added which

are not described in this manual, or there may be changes to

functions already included. We therefore recommend that you

occasionally visit the TechniSat homepage in the Internet,

from where you can download the current version of the ope-

rating manual.

We wish you many years of listening and viewing pleasure

with your TechniSat DIGIT MF4-K!

Your

TechniSat Team

3 Please read this first

>Before you begin operating your receiver, please first

check whether the package contains all the compo-

nents that should be included. The following are supp-

lied:

1 digital receiver, 1 mains power cable,

1 remote control, 1 operating manual,

1 guarantee card, 2 batteries (1,5V micro-cell)

1 SCART cable.

>Insert the batteries provided in the battery compart-

ment of the remote control, observing the polarity indi-

cated.

>Before connecting your digital receiver, please first

read the safety notes in Chapter 3.

>Chapters 4, 5 and 6 describe how to connect the

digital receiver to the television set, VCR, etc., and

how to make the appropriate settings. These settings

need be made only once, and will only need to be

adapted if your external unit changes, or if additional

appliances are connected.

>Chapter 7 describes all the functions necessary for

daily operation of the receiver, e.g. programme selec-

tion.

> In Chapter 8 you will find information on how to set

new programmes, or how to change the order of pro-

grammes.

>Technical terms used in the operating manual are

explained in Chapter 9.

>Technical data and specifications can be found in

Chapter 10.

>Atrouble-shooting guide to help you overcome pro-

blems can be found in Chapter 11.

Important operating instructions

Operation of the digital receiver is simplified by the use of so-

called "On Screen Displays", this also serves to reduce the

number of keys required on the remote control unit. All func-

tions are displayed on the screen, and can be operated with a

few keys. Related functions are combined in a "MENU". The

function selected is highlighted in colour. The “function keys”

red, yellow, green and blue are displayed along the bottom of

the screen in the shape of coloured bars. These coloured

bars represent different functions in the individual menues,

which can be implemented by pressing the

appropriate coloured key (“multi-function key”) on the remote

control. The “function keys” are only active when a brief des-

cription is displayed in the appropriate field.

Key descriptions and terms that appear on the OSD menu

are printed bold in this operating manual.

Help:

Where available in the menues, pressing the blue function

key will cause a help text to be displayed, pressing again will

remove the text from the screen.

Disposal advice

The packaging for your unit consists entirely of recyclable

material. Please sort the items appropriately, and sort them

for disposal via your local waste disposal system.

Please note that spent batteries (from the remote control) as

well as electronic components should not be disposed of in

your household refuse, but should be disposed of in accor-

dance with your local regulations (special waste, hand back

to outlet where purchased).

Safety advice

For your own protection, please read the safety instructions

carefully before commencing operation of your new unit.

The manufacturer accepts no responsibility for damage cau-

sed by inappropriate operation, or by non-compliance with

safety precautions.

>To ensure adequate ventilation, place the unit on a

smooth horizontal surface, and do not place any

objects on the upper surface of the unit. This surface

has ventilation slots that ensure heat can escape from

the interior of the unit.

>Do not place any burning objects, such as burning

candles, on top of the unit.

>Do not subject the unit to water spray or droplets, and

do not place any objects filled with liquuid, e.g. vases,

on top of the unit.

>The unit may only be operated in a temperate climate.

>Never open the unit housing! You are in danger of

receiving an electric shock. Any necessary repairs

should be carried out only by qualified service person-

nel.

In the following cases, you should disconnect the unit

from the mains power supply, and consult a qualified

technician:

>the mains cable or the mains plug are damaged

>the unit was exposed to liquid, or liquid has run into

the unit

>in case of significant malfunction

>in case of severe external damage

When not in operation

During an electrical storm, or when the unit will not be used

for a lengthy period of time (e.g. while you are on holiday),

disconnect the unit from the mains power supply.

Connecting the DVB receiver to the cable

socket

a. Connect the Cable input of the DVB receiver to the

antenna socket of the cable network.

b. Scart connection of the DVB receiver with the television

set.

c. Scart connection of a video player with the VCR Scart

socket of the DVB receiver.

d. Connection of the Cable output with the antenna input

of the television set.

e. Connections of audio outputs with a Hi-Fi amplifier.

f. Mains power connection

VCR

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Receptor de TechniSat

TechniSat

TechniSat TechniCorder ISIO STC Manual de usuario

TechniSat

TechniSat DIGIT Series Suplemento

TechniSat

TechniSat TechniStar S2 Guía de instalación y uso

TechniSat

TechniSat TECHNISTAR S6 Manual de instrucciones

TechniSat

TechniSat DIGIT HD4 CX Manual de usuario

TechniSat

TechniSat DigiPal1 Manual de usuario

TechniSat

TechniSat DigiPlus STR 1 Manual de usuario

TechniSat

TechniSat DIGITY 1 Manual de usuario

TechniSat

TechniSat HDFS Manual de usuario

TechniSat

TechniSat TECHNISTAR S6 Guía de instalación y uso

TechniSat

TechniSat DiGYBOXX T4 VA Manual de usuario

TechniSat

TechniSat DigiCom 1A Manual de usuario

TechniSat

TechniSat DigiPlus STR 1 Manual de usuario

TechniSat

TechniSat HD-S 261 Manual de usuario

TechniSat

TechniSat DIGIT Series Suplemento

TechniSat

TechniSat VIACCESS DigiBox VIACCESS Manual de usuario

TechniSat

TechniSat TechniBox VIACAM Manual de usuario

TechniSat

TechniSat ST 6002 S Manual de usuario

TechniSat

TechniSat DIGIT MF4-S Manual de usuario

TechniSat

TechniSat HDFS Manual de usuario

TechniSat

TechniSat DIGIT MF4-K CC Manual de usuario

TechniSat

TechniSat Digit HD 8SX Manual

TechniSat

TechniSat TECHNISTAR S5 Manual de instrucciones

TechniSat

TechniSat TERRABOX T3 Manual de usuario

Manuales populares de Receptor de otras marcas

Garmin

Garmin GA 23 Manual de usuario

Aiphone

Aiphone PS-12F Manual de usuario

IMES

IMES TCS-01CA-PMI Manual de usuario

BWI Eagle

BWI Eagle AIR-EAGLE SR Manual

AMIMON

AMIMON AMN12310 WHDI Manual de usuario

Dual

Dual DMCPA79BT Instrucciones de funcionamiento

Sound Associates

Sound Associates SA652P Manual de usuario

Sherwood

Sherwood NewCastle R-772 Manual de usuario

Audio

Audio A10-RX Series Manual de usuario

AllSee

AllSee PushShare PSRV1.1 Manual de usuario

DEMAG

DEMAG DRC-DR D2 Manual de usuario

Teleco

Teleco TVRCL868A02 Manual de usuario

Bosch

Bosch RF3222E Manual de usuario

Kramer

Kramer 631R Manual de usuario

Xpress

Xpress xmc10 Manual de usuario

JVC

JVC KD-MR1BTS Manual de usuario

Omega Engineering

Omega Engineering UWTC-REC3 Manual de usuario

e-survey

e-survey E300 Pro Manual de usuario
