TC Electronic Flashback X4 Delay Manual de usuario

Flashback X4 Delay – Manual (2014-06-24) 1

Flashback X4 Delay

Manual – 2014-06 -24

Flashback X4 Delay – Manual (2014-06-24) 2

Table of contents

Important safety instructions 3

Caution 4

Service 4

Warning 4

EMC / EMI 4

Explanation of graphic symbols 5

Before you begin 6

About this manual 7

Getting support 7

About this pedal 8

Flashback X4 Delay & Looper 9

True Bypass 9

TonePrint 10

What are TonePrints? 11

Transferring TonePrints to your pedal

using the TonePrint app 11

Editing TonePrints with TonePrint Editor 12

Setup 13

Ready… 14

Set… 14

Play! 14

Inputs, outputs and controls 15

Power / Switching the effect on and off 18

Audio in and out 18

Expression pedal input 18

USB port 19

MIDI IN / MIDI THRU jacks 20

Effect controls 21

Flashback X4 Delay& Looper delay types 23

Using the Looper 25

Using the delay in Looper mode 26

Recording a loop 26

Playing a loop continuously 27

Stopping loop playback immediately 27

Playing a loop once 27

Stopping loop playback at the end of the

loop 28

Undoing a loop recording 28

Erasing a loop completely 28

Loops cannot be stored 29

Maintenance 30

Updating the firmware 31

Switching the pedal from true bypass to

buffered bypass mode 31

Kill-dry on/off 32

Frequently asked questions 33

Frequently asked questions about

TonePrint pedals 34

Links 35

TonePrint resources 36

Support resources 36

TC Electronic on… 36

Technical specifications 37

Important safety instructions

Flashback X4 Delay – Manual (2014-06-24) 3

Important safety instructions

Flashback X4 Delay – Manual (2014-06-24) 4

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with a dry cloth.

7. Do not block any ventilation openings. In-

stall in accordance with the manufacturer’s

instructions.

8. Do not install near any heat sources such

as radiators, heat registers, stoves, or other

apparatus (including amplifiers) that pro-

duce heat.

9. Do not defeat the safety purpose of the po-

larized or grounding-type plug. A polarized

plug has two blades with one wider than

the other. A grounding-type plug has two

blades and a third grounding prong. The

wide blade or the third prong is provided for

your safety. If the provided plug does not fit

into your outlet, consult an electrician for

replacement of the obsolete outlet.

10. Protect the power cord from being walked

on or pinched, particularly at plugs, con-

venience receptacles, and the point where

they exit from the apparatus.

11. Only use attachments/accessories speci-

fied by the manufacturer.

12. Use only with a cart, stand, tripod,

bracket, or table specified by the

manufacturer, or sold with the ap-

paratus. When a cart is used, use

caution when moving the cart/apparatus

combination to avoid injury from tip-over.

13. Unplug this apparatus during lightning

storms or when unused for long periods

of time.

14. Refer all servicing to qualified service per-

sonnel. Servicing is required when the ap-

paratus has been damaged in any way,

such as power-supply cord or plug is dam-

aged, liquid has been spilled or objects

have fallen into the apparatus, the appara-

tus has been exposed to rain or moisture,

does not operate normally, or has been

dropped.

Caution

You are cautioned that any change or modifi-

cations not expressly approved in this manual

could void your authority to operate this equip-

ment.

Service

All service must be performed by qualified per-

sonnel.

Warning

To reduce the risk of fire or electric shock, do not

expose this apparatus to rain or moisture and

objects filled with liquids, such as vases, should

not be placed on this apparatus.

Do not install this device in a confined space.

EMC / EMI

Electromagnetic compatibility /

Electromagnetic interference

This equipment has been tested and found to

comply with the limits for a Class B digital de-

vice, pursuant to part 15 of the FCC rules.

These limits are designed to provide reasonable

protection against harmful interference in resi-

dential installations. This equipment generates,

uses and can radiate radio frequency energy

and, if not installed and used in accordance with

the instructions, may cause harmful interference

to radio communications. However, there is no

guarantee that interference will not occur in a

particular installation.

If this equipment does cause harmful interfer-

ence to radio or television reception, which can

be determined by turning the equipment off and

on, the user is encouraged to try to correct the

interference by one or more of the following

measures:

– Reorient or relocate the receiving antenna.

– Increase the separation between the equip-

ment and receiver.

– Connect the equipment into an outlet on a cir-

cuit different from that to which the receiver is

connected.

– Consult the dealer or an experienced ra-

dio / TV technician for help.

Important safety instructions

Flashback X4 Delay – Manual (2014-06-24) 5

For customers in Canada

This Class B digital apparatus complies with Ca-

nadian ICES-003.

Cet appareil numérique de la classe B est

conforme à la norme NMB-003 du Canada.

Explanation of graphic symbols

The lightning bolt triangle is used to alert the

user to the presence of uninsulated “dangerous

voltages” within the unit’s chassis that may be of

sufficient magnitude to constitute a risk of elec-

tric shock to humans.

The exclamation point triangle is used to alert

the user to presence of important operating and

service instructions in the literature accompany-

ing the product.

Before you begin

Flashback X4 Delay – Manual (2014-06-24) 6

Before you begin

Flashback X4 Delay – Manual (2014-06-24) 7

About this manual

This manual will help you learn understanding

and operating your TC product.

To get the most from this manual, please read it

from start to finish, or you may miss important

information.

This manual is only available as a PDF download

from the TC Electronic website.

Of course, you can print this manual, but we en-

courage you to use the PDF version, which has

both internal and external hyperlinks. For ex-

ample, clicking the logo in the upper left corner

of each page will take you back to the table of

contents.

To download the most current version of this

manual, visit

tcelectronic.com/support/manuals/

Getting support

If you still have questions about the product af-

ter reading this manual, please get in touch with

TC Support:

tcelectronic.com/support/

Enjoy your TC product!

About this pedal

Flashback X4 Delay – Manual (2014-06-24) 8

About this pedal

Flashback X4 Delay – Manual (2014-06-24) 9

Thank you for spending your hard-earned mon-

ey on this TC Electronic product! We have done

our best to ensure that it will serve you for many

years to come, and we hope that you will enjoy

using it.

Flashback X4 Delay & Looper

Flashback X4 Delay & Looper builds on the suc-

cess of TC’s popular Flashback pedal. It pro-

vides 12 delay types in pristine TC Electronic

quality, tap tempo and three preset slots for an

instant classic.

Flashback X4 Delay & Looper is TonePrint-en-

abled, allowing you to load up to four signature

Flashback delay settings as created and used by

the biggest names in rock – from Steve Morse

and Doug Aldrich to Joe Perry, Steve Stevens

and many, many more.

We believe that Flashback X4 Delay & Looper

offers the best sounding delay as well as enor-

mous flexibility within a compact delay pedal –

and we are certain that you will feel the same.

True Bypass

Here at TC, we have a simple philosophy: When

you are using one of our products, you should

hear something great – and if you don’t, you

shouldn’t hear it at all. This is why this pedal

sports True Bypass. When it is bypassed, it is

really off and has zero influence on your tone, re-

sulting in optimum clarity and zero loss of high-

end.

You will also be delighted to hear (literally) that

this TC Electronic effect pedal will let your dry,

unprocessed sound pass without ever convert-

ing it to digital – keeping your original tone pure

and without any latency. This feature is called

analog dry-through.

Sometimes, it is advisable to switch an effect

pedal from True Bypass to Buffered Bypass

mode. For more information, see “Switching

the pedal from true bypass to buffered bypass

mode”.

TonePrint

Flashback X4 Delay – Manual (2014-06-24) 10

TonePrint
