SAVEVTC700

Changingthebypassdamper

Replacementinstructions

Documentinoriginallanguage209246-EN_GB

2014-11-12A002

Contents

1Warnings...................................................................................................................................1

2LeftandRightmodels................................................................................................................1

3Changingthebypassdamper.....................................................................................................2

4Changingthebypassdamperintheunitsproducedbefore10–08–2014.......................................8

4.1Disconnectingthetransformer...........................................................................................9

4.2Mountingthenewbypassdamperandconnectingtheadapter............................................13

1Warnings

Danger

•MakesurethattheMainssupplytotheunitisdisconnectedbeforeperforminganymaintenanceor

electricalwork!

•Allelectricalconnectionsandmaintenanceworkmustbecarriedoutbyanauthorizedinstallerand

inaccordancewithlocalrulesandregulations.

Warning

•Thesystemshouldoperatecontinuously,andonlybestoppedformaintenance/service.

•Theinstallationoftheunitandcompleteventilationsystemsmustbeperformedbyanauthorized

installerandinaccordancewithlocalrulesandregulations.

•Bewareofsharpedgesduringmountingandmaintenance.Useprotectivegloves.

•AlthoughtheMainssupplytotheunithasbeendisconnectedthereisstillriskforinjuryduetothe

rotatingpartsthathavenotcometoacompletestandstill.

•Makesurethatltersaremountedbeforestartingtheunit.

•Thisproductmustonlybeoperatedbyapersonwhichhassuitableknowledgeoreducationwithin

thiseldorcarriedoutwiththesupervisionofasuitablyqualiedperson.

2LeftandRightmodels

PositionDescription

RRighthandmodel(Supplyairconnectionandcontrolpanelissituatedontheright

handsideoftheunitviewedfromthefront).

LLefthandmodel(Supplyairconnectionandcontrolpanelissituatedontheleft

handsideoftheunitviewedfromthefront).

Note:

Thisdocumentdescribesinstallationofthebypassdamperontheright(R)model.Theinsideofaleft

(L)modelismirrored.

SAVEVTC700Replacementinstructions

2092461SystemairAB

3Changingthebypassdamper

Disconnecttheunitfromthemainssupply.

Usea8mmAllenkeytoreleasethelockofafront

hatch.

Tiltbackthehatch(pos1)andthenliftitoffcompletely(pos2).

SAVEVTC700Replacementinstructions

2092462SystemairAB

Remove4screwsandopentheleftdoor.

Note:

Ontheleft(L)modelthedamperislocatedontherightsideoftheunit.

Removethelid(pos2)ofthebypassdamperbyloosening4screws(pos1).

SAVEVTC700Replacementinstructions

2092463SystemairAB

Disconnectallthecables:disconnect4–pinconnector(pos1),3–pinconnector(pos2)andground

GNDconnector(pos3).

Remove2screwswiththeblackknobs(pos.1)

SAVEVTC700Replacementinstructions

2092464SystemairAB

Slightlyliftupthebypassdamper(pos1)andthenremoveitbypullingitoutside(pos2).

Mountthenewbypassdamper(pos1),lockitintotheposition(pos2).

SAVEVTC700Replacementinstructions

2092465SystemairAB

Tightenthedamperwithlockingscrewswithblackknobs(pos1).

Connectallpreviouslydisconnectedcablestothenewbypassdamper.Connect4–pinconnector(pos1),

3–pinconnector(pos2)andgroundGNDconnector.

SAVEVTC700Replacementinstructions

2092466SystemairAB

Mountthelid(pos1)ofthebypassdamperbytightening4screws(pos2).

Closetheleftdoorandtighten4screws.

Mountthefronthatchandlockitwiththe8mmAllenkey.Connecttheunittothemainssupply.

SAVEVTC700Replacementinstructions

2092467SystemairAB

4Changingthebypassdamperintheunits

producedbefore10–08–2014

IftheSAVEVTC700unitwasproducedbeforethe10thofAugust2014,anewreleasedbypassdamper

cannotbechangeddirectlyanymoreasshownintheinstallationsection3Changingthebypassdamper.

Thenewbypassdamperdonotusethetransformerwhichislocatedintheconnectionbox,thereforeit

mustbedisconnectedandcablesconnectedviaadapterbeforemountingthenewbypassdamperinto

place.Carefullyperformadditionalstepsbellowtocompletetheinstallation:

Theunitproductiondatecanbefoundonthetypelabel(see:step2,page8,pos1),whichcanbefound

ontopoftheunitclosetotheductconnectionsorinsideinthebottomoftheunit.

Disconnecttheunitfromthemainssupply(see:step1,page2),releasethelockofthefronthatch

(see:step2,page2)andremovethehatch(see:step3,page2).

Remove4screwsandopentherightdoor.

Note:

Ontheleft(L)modeltheconnectionboxislocatedontheleftsideoftheunit.

SAVEVTC700Replacementinstructions

2092468SystemairAB
