System air MA multi Manual de usuario

S-BM2

Smoke Control Damper - MA multi

2/105 | S-BM2

Table of Contents

Overview .........................................................3

Technical Parameters ..................................................5

Diagrams .........................................................9

Dimensions ........................................................14

Ordering Code ......................................................21

Installation ........................................................22

Electrical parameters ...................................................86

Operation manual ....................................................99

3/105 | S-BM2

Smoke Control Damper - MA multi

Description

Smoke control dampers are designed for mechanical or natural smoke and heat extract systems. Its function is to

extract toxic gases, smoke and fire or provide a supply of fresh air to fire compartments. Smoke control dampers are

fitted with an actuator without a spring; therefore, they have two safety positions, “open” and “closed” and require

power even in the event of fire. S-BM2 smoke control damper is designed for the installations listed in the “Installation

Methods” section of its Handbook.

Highlights

• Battery installation of up to 4 dampers

• MA – manual intervention (can be used also as an AA classified smoke control damper)

The safety position can be adjusted up to first 25 minutes during smoke extraction

• Multi - usage in compartments classified as "multi"

Can be used also in compartments classified as "single"

• Pressure level 2 (-1000 Pa ... 300 Pa)

• Casing leakage according to EN 1751, class C

• Blade leakage according to EN 1751, class 3

• Exceptional free area and low pressure drop

• Installed into walls or ducts

Fire Resistivity

S-BM2 Smoke control dampers are CE certified following the Construction Products Regulation according to EN

12101-8:2011. Tested according to EN 1366-10:2011 + A1:2017, EN 1366-2:2015 and classified according to EN

13501-4:2016. The smoke control damper together with its installation form an inseparable part of the fire resistivity

rating.

• Damper with horizontally oriented blades: EI120(vew - ved - hod - how - i↔o)S1000CmodHOT400/30MAmulti

• Damper with vertically oriented blades: EI90(vew i↔o)S1000CmodMAmulti

Product types

Depending on the S-BM2 installation assembly this damper has two main product types:

• Standalone installation - grille types 00, 01, 02, 11, 22

• Battery installation - grille types M0, M1

4/105 | S-BM2

Accessories

Detailed information about accessories is available in design.systemair.com

• K1-S-BM2: Cover boards for in-duct installation.

• H1-S-BM2: Hanger for horizontal damper mounting.

Design

S-BM2 has a casing and blades made from calcium silicate board. The closed damper is sealed by silicate wool sealing

to avoid the spread of heat and smoke. Front board surfaces are fitted with threaded inserts for sheet metal duct

flanges. If the damper is ordered with grille, both sides are fitted with threaded inserts for grille placement. S-BM2 has

mechanism and actuator enclosed by the dampers casing and two covers on each side for easy access and connection.

Material Composition

The product contains galvanized sheet metal, calcium silicate board, fireproof carbon fiberglass, polyurethane foam

and alkaline earth silicate wool. These are processed in accordance with local regulations. The product contains no

hazardous substances.

Tightness of the Blade and the Casing

S-BM2 smoke control damper standardly have class C casing tightness and class 3 blade tightness according to EN

1751.

5/105 | S-BM2

Technical Parameters

Durability Test

10000 cycles, actuator controlled (0 … 90 degrees rotation) – with no change of the required properties

10000 cycles, actuator controlled for "MOD" classification (45 ... 60 degrees rotation) - with no change of the required

properties

Testing Pressure

Underpressure up to 300 Pa, overpressure up to 1000 Pa

Safe Position

Open or Closed

Possible Installations

Vertically supported construction, rigid/flexible wall, wet/dry/soft-cross (see classification table on the page 6)

Airflow Direction

Both directions

Allowed Air Velocity

Max. 12 m/s

Side with Fire Protection

Depending on installation classification: From both sides (i <-> o)

Repeated Opening

Suitable for daily check procedure in suitable environment

Closing/Opening Time

< 60 s

Indicator Closed/Open

Indication with microswitches that are part of mechanism actuator

Environment Suitability

Only indoor environment, T > 0 °C and Rha < 95% (3K5 according to EN 60721-3-3)

Inspection Possibility

Through grille. Inspection door for connection and actuator access.

Duct inspection opening/lid where needed is not part of damper or delivery.

Maintenance

Not required/dry cleaning if demanded by law in the country in which the dampers are installed

Revisions

Determined by law in the country in which the dampers are installed, or minimally every 6 months

6/105 | S-BM2

Allowed Pressure

1000 Pa

Blade Tightness (EN 1751)

Class 3 as standard

Tightness of the Housing (EN 1751)

Class C as standard

Conformity with EC Directives

2006/42/ES Machinery Directive

2014/35/EU Low Voltage Directive

2014/30/EU Electromagnetic Compatibility Directive

Driving Actuator Types

Belimo BEN24, BEN230, BEN24-ST, BEN24-SR; BEE24, BEE230, BEE24-ST, BEE24-SR; BE24, BE230, BE24-ST; BLE24,

BLE230, BLE24-ST

Transport and Storage

Dry indoor conditions with a temperature range of -20 °C to +50 °C. The damper blade is transported in closed

position.

7/105 | S-BM2

Product Parts

The S-BM2 packaging for selected sizes also includes wooden manipulation jig.

Legend:

P1 - Damper casing

P2 - Damper blade

P3 - Actuator

P4 - Supply and communication unit (BST)

P5 - Sheet metal Grille

P6 - Threaded inserts for duct connection

P7 - Threaded inserts for the grille

P8 - Mechanism cover

P9 - Product label

8/105 | S-BM2

Assessed Performance

19 CE 1396

Systemair Production a.s.

90043 Kalinkovo 371, Slovakia

1396-CPR-0157

EN 12101-8:2011

Smoke control damper

Multi compartment

S-BM2

Nominal activation conditions/sensitivity

• Manual intervention - passed

Closure/opening during test at correct time and in allowable time

Response delay/closure time - Manual intervention - passed

Operational reliability

10 000 operations: 0° to 90° - passed and 45° to 60° - passed

HOT 400/30 - passed

Fire resistance:

• Integrity E

• EI120(vew-ved-hod-how-i↔o)S1000CmodHOT400/30MAmulti

• Damper with vertically oriented blades: EI90(vewi↔o)S1000CmodMAmulti

• Insulation I

• Smoke leakage S

• Mechanical stability (under E)

• Maintenance of cross section (under E)

Durability:

• of response delay - Pass

• of operational reliability - Pass

9/105 | S-BM2

Diagrams of S-BM2 for extract air

Accessories K1-S-BM2 and H1-S-BM2 do not affect the pressure drop and A-weighted total discharged sound power

level.

The pressure drop and A-weighted total discharged sound power level depend on the nominal width and height of the

S-BM2 and air flow volume at different duct pressures.

S-BM2 Grille Types 00, 01, 11, 22

S-BM2-...-00-

Pressure drop & A-weighted sound power level in dB(A)

500 1000 5000 m³/h

100 500 1000 l/s

100

W: 125, H: 325

W: 200, H: 325

W: 300, H: 425

55 60

S-BM2-...-00-

Pressure drop & A-weighted sound power level in dB(A)

5000 10000 50000

m³/h

1000 5000 10000 l/s

W: 500, H: 625

W: 800, H: 825

W: 1000, H: 1225

S-BM2-...-01-

Pressure drop & A-weighted sound power level in dB(A)

500 1000 5000 m³/h

100 500 1000 l/s

100

W: 125, H: 325

W: 200, H: 325

W: 300, H: 425

505560

6570

4550

100

35 40

55 60

S-BM2-...-01-

Pressure drop & A-weighted sound power level in dB(A)

5000 10000 50000

m³/h

1000 5000 10000 l/s

100

W: 500, H: 625

W: 800, H: 825

W: 1000, H: 1225

60 65

80 85

60 65

10/105 | S-BM2

S-BM2-...-11-

Pressure drop & A-weighted sound power level in dB(A)

500 1000 5000 m³/h

100 500 1000 l/s

100

W: 125, H: 325

W: 200, H: 325W: 300, H: 425

4550

65707580

8590

100

707580859095

100

40 45

50 55 60

S-BM2-...-11-

Pressure drop & A-weighted sound power level in dB(A)

5000 10000 50000

m³/h

1000 5000 10000 l/s

100

W: 500, H: 625

W: 800, H: 825

W: 1000, H: 1225

45 50

75 80

90 95

55 60

65 70

Legend:

ps (Pa) - Pressure drop

qv (m3^/h), (l/s) - Air flow volume

±Δ (%) - Deviation from measured value

Lwa (dB(A)) - A-weighted total sound power level

v (m/s) - Air face velocity
